Glentronics PHCC-1000 Pro Series Operating manual

The PHCC Pro Series Maintenance Free Battery is
compatible with most PHCC Pro Series systems
including, the PHCC-1000, PHCC-1730 (with
Remote Terminals), PHCC-1850, PHCC-2400,
PS-C11, PS-C22 (with Remote Terminals), and
PS-C33. This battery is maintenance free in
that it does not require fluid or distilled water.
Depending on the PHCC Pro Series system and the
inflow of water, this battery will keep your backup
system pumping intermittently for days.
WARRANTY
One Year Free Replacement
(Receipt Required)
09/19
Maintenance Free Battery Instructions
Please recycle old batteries.
Do NOT place in trash. Take
old batteries to a service or
recycling center.
Please review the instruction manual of your PHCC Pro Series
sump pump system for additional safety instructions.
Connection Instructions
1. Place the battery in a protective battery box.
2. Unscrew each bolt and washer from the battery terminals.
3. Insert one bolt through the washer and then the NEGATIVE ( - ) ring
terminal from the controller and screw it into the NEGATIVE ( - )
terminal of the battery.
4. Insert the other bolt through the washer and then the POSITIVE ( + )
ring terminal from the controller and screw it into the POSITIVE ( + )
terminal of the battery.
5. Attach the fluid sensor from the controller to the POSITIVE ( + )
battery terminal by placing the fluid sensor between the washer and
the POSITIVE ( + ) ring terminal. This will silence the fluid alarm.
If the sensor is not attached the low fluid alarm will sound
continuously.
6. Check to ensure all connections are snug.
Maintenance
To help prolong the life of the battery please clean any corrosion off the
ring lugs and battery posts.
• Use a stiff brush or sandpaper to clean battery terminals and ring lugs.
• DO NOT apply corrosion resisting sprays, gels or pads to the ring lugs or
battery posts after you have cleaned them, this could prevent the
battery from charging properly.
!WARNING
Distributed by Glentronics, Inc.
645 Heathrow Drive
Lincolnshire, IL 60069
800.991.0466
www.stopflooding.com
Made in Vietnam
• Never smoke or allow a spark or flame in the vicinity of the battery
• Be sure the area around the battery is well ventilated
• DO NOT drop a metal tool onto the battery. It might short circuit
the battery and cause an explosion
• Remove personal metal items such as rings, bracelets, watches, etc.
when working with the battery. A short circuit through one of
these items can melt causing a severe burn
• ALWAYS remove the charger from the electrical outlet before
connecting or disconnecting the battery cables
• Heavy Battery. Always use two hands when carrying the battery
• Battery posts and terminals contain lead, lead compounds or other
chemicals known to the State of California to cause cancer, birth
defects or other reproductive harm. Wash hands after handling.
See https://www.p65warnings.ca.gov/
NEGATIVE POST
POSITIVE POST
Bolt
NEGATIVE Ring Lug
from Controller
Battery Terminal Flat
Washer
Fluid
Sensor
POSITIVE Ring Lug
from Controller
Bolt
Battery
Terminal
Flat
Washer

LIMITED WARRANTY
By opening this package and using this GLENTRONICS, INC. product, you are agreeing to be bound by the terms of the GLENTRONICS, INC. limited
warranty (“warranty”) as set out below. Do not use your product until you have read the terms of the warranty. If you do not agree to the terms of
the warranty, do not use the product and return it within the return period stated on your purchase receipt from the retail store or authorized
distributor where you purchased it for a refund.
To the extent permitted by law, this warranty and the remedies set forth are exclusive and in lieu of all other warranties, remedies and conditions,
whether oral, written, statutory, express or implied. GLENTRONICS, INC. disclaims all statutory and implied warranties, including without limitation,
warranties of merchantability and fitness for a particular purpose and warranties against hidden or latent defects, to the extent permitted by law.
GLENTRONICS, INC. will not be liable for any incidental, special or consequential damages for breach of any express or implied warranties on this
product. In so far as such warranties cannot be disclaimed, GLENTRONICS, INC. limits the duration and remedies of such warranties to the duration of
this express warranty and, AT GLENTRONICS, INC.'s option, the repair or replacement services described below. Some states (countries and provinces)
do not allow limitations on how long an implied warranty (or condition) may last, so the limitation described above may not apply to you.
Any and all causes of action arising from, filed as a result of or in reference to, this warranty or the products described under this warranty shall be
governed by and construed under the laws of the State of Illinois. Any cause of action arising from, filed as a result of or in reference to, this
warranty or the products described under this warranty shall be filed only in the Circuit Court of the 18th Judicial District, Lake County, Waukegan,
Illinois, or in the Northern District of Illinois if filed in Federal Court. The maximum liability for any product described in this warranty shall be the
cost of product replacement only.
If any term is held to be illegal or unenforceable, the legality or enforceability of the remaining terms shall not be affected or impaired.
What is Covered by this Warranty?
GLENTRONICS, INC. warrants to the end purchaser that its pumps, switch and control unit products are free from defective materials and
workmanship for the periods indicated below:
All parts and labor (excluding installation) for a period of:
• 1 year from the date of installation, when used with a PHCC Pro Series battery backup sump pump system
What is NOT Covered by this Warranty?
This warranty does not cover the cost or value of damaged property, including expressly any property that has been affected by water overflow,
seepage or flooding. If GLENTRONICS, INC. determines that a product is deemed defective under this warranty agreement, it will repair or replace
the PRODUCT ONLY. GLENTRONICS, INC. will not cover the cost to reinstall the product, nor will GLENTRONICS, INC. pay the cost of having a
plumber or contractor repair or replace the product.
GLENTRONICS, INC. will not repair or replace a product that was installed incorrectly. A product shall be considered “installed incorrectly” when it
deviates in any way from the instructions described in this manual.
This warranty does not cover product problems resulting from handling liquids hotter than 104 degrees Fahrenheit, handling inflammable liquids,
solvents, strong chemicals or severe abrasive solutions; user abuse; misuse, neglect, improper maintenance, commercial or industrial use; improper
connection or installation, damages caused by lightning strikes; excessive surges in AC line voltage; water damage to the controller; other acts of
nature, or failure to operate in accordance with the enclosed written instructions.
How to Obtain Warranty Service
Within thirty (30) days of the product’s defective performance, contact GLENTRONICS, INC. customer service department for specific instructions.
If contact is not made to GLENTRONICS, INC. customer service department within thirty (30) days of the product’s defective performance it will not
be considered for warranty service. The product may be required to be returned to GLENTRONICS, INC. for inspection in order to be considered for
warranty service. DO NOT return the product to GLENTRONICS, INC. unless instructed by GLENTRONICS, INC. customer service. If the product is not
returned to GLENTRONICS, INC. or the product is inspected by any person, plumber, contractor or business other than GLENTRONICS, INC., this
warranty shall no longer be valid. Products received after one (1) year from the date of purchase, fall outside of the timeframe for warranty service
and will not be eligible for warranty service. Prior to defective operation, the unit must not have been previously altered, repaired or serviced by
anyone other than GLENTRONICS, INC., or its agent; the serial number on the unit must not have been altered or removed; the unit must not have
been subject to accident, misuse, abuse or operated contrary to the instructions contained in the accompanying manual. The dealer's dated bill of
sale, or installer’s invoice must be retained as evidence of the date of purchase and to establish warranty eligibility.
Where are Products Sent for Warranty Service?
Glentronics, Inc., 645 Heathrow Drive, Lincolnshire, IL 60069
How Can I Obtain More Information?
By calling 800-991-0466.
