GLIDEAWAY EDISON User manual

motion
EDISON
OWNERS MANUAL
REV 08.06.19

2
OWNERS MANUAL: EDISON
Safety Information 3
What Is Included 6
Assembly – Base 7
Location of Controls – Remote 12
Operation – Main 12
Operation – Linking the Remote 14
Troubleshooting 15
Available Accessories 16
Online Resources 16
User Info
Please take a moment and write down the serial number in the space provided below, in case you need to
refer to it in the future. This information can be found by raising the head section of the bed.
SKU: GM-030
Serial Number _________________________________________
This number will be required for future service claims.
Contents

3
OWNERS MANUAL: EDISON
Safety Information
ATTENTION!
IMPORTANT SAFETY INSTRUCTIONS. SAVE THIS MANUAL!
PLEASE READ THESE INSTRUCTIONS THOROUGHLY BEFORE USING THIS PRODUCT. PROPER
OPERATION OF YOUR ADJUSTABLE BED IS NECESSARY TO ENSURE THE LONG LIFE AND DURABILITY
YOU EXPECT FROM A HIGH-QUALITY PRODUCT. THE MANUFACTURER HAS TESTED AND INSPECTED
THIS PRODUCT PRIOR TO SHIPMENT.
RADIO FREQUENCY IS 2.4Ghz.
This device complies with part 15 of the FCC Rules and Industy Canada’s license exempt RSSs. Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation of the device.
Any change to the antenna or the device could result in the device exceeding the RF exposure requirements and void the user’s right to operate the
device. The input voltage is AC100-240 50/60HZ; the output voltage is DC29V 1.8A. Total USB power output is 2 AMP.
ELECTRICAL SAFETY
Always unplug this adjustable bed from the electrical outlet before any cleaning or maintenance of the adjustable bed. To safely disconnect, remove
the plug from the outlet. Keep cord away from heated surfaces. Use only indoors.
Discontinue use of this adjustable bed and contact the manufacturer for repair if:
(1) It has a damaged cord or plug,
(2) It is not working properly, or
(3) It has been dropped or damaged.
FOR OPTIMAL SAFETY, YOUR ADJUSTABLE BED SHOULD BE PLUGGED INTO A SURGE PROTECTOR (not supplied with this adjustable bed).
BATTERY PRECAUTIONS
Follow these precautions when using batteries in this device:
(1) Warning – Danger of explosion if battery is incorrectly replaced. Replace only with the 6LR61 9V batteries and LR03 AAA batteries.
(2) Be sure to follow the correct polarity when installing the batteries as indicated in the battery compartment. A reversed battery may cause
damage to the device.
(3) Do not mix dierent types of batteries together (e.g. Alkaline, Rechargeable and Carbon-zinc) or old batteries with fresh ones.
(4) If the device is not to be used for a long period of time, remove the batteries to prevent damage or injury from possible battery leakage.
(5) Do not try to recharge a battery not intended to be recharged; it can overheat and rupture. (Follow battery manufacturer’s directions.)
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO MOISTURE.
OPEN BOX IN
FLAT POSITION
DANGER!
DO NOT OPEN FROM
VERTICAL POSITION. THIS
CAN DAMAGE BASE.

4
OWNERS MANUAL: EDISON
Safety Information
WARRANTY WARNING!
This bed is specically designed to require no maintenance by you, the user. Any opening or tampering
with the control box, motors or hand controls (with the exception of the battery compartment, if equipped)
will void the warranty. Do not attempt to alter component wiring or adjust or modify the structure of
the product in any way or the warranty will be void. Only those authorized may conduct repairs or part
replacement on your adjustable bed.
IN-HOME USE ONLY
This adjustable bed is designed exclusively for in-home use.
HOSPITAL/MEDICAL DISCLAIMER: This base is NOT designed for commercial hospital or medical use and is
NOT designed to meet hospital standards. Do not use this base with TENT TYPE oxygen therapy equipment
or use near explosive gases.
PRODUCT RATINGS
Lift Motor Restrictions: The lift motors in this bed are NOT designed to operate continuously for more than
one (1) minute over an eight (8) minute time period, or approximately 12% duty cycle. To ensure reliable
functionality and full life of this product, do not attempt to exceed these limits.
NOTE: Attempting to circumvent or exceed this rating will shorten the life expectancy of the product and
may void the warranty.
Weight Restrictions: The recommended weight limits on our adjustable beds are:
 1/pc King: 800 lb
 Queen: 600 lb
 Full/XL: 500 lb
 Twin/XL: 400 lb (800 lb if using two twins as a King)
—
 The structure of the bed will support the recommended weight when distributed evenly across the bed.
 The head and foot sections are not designed to individually support or lift this amount of weight.
 For optimal performance and integrity of structure, entering and exiting the adjustable bed with the bed
in the at position is recommended.
 NOTE: Exceeding the recommended weight restrictions could damage your adjustable bed and void
your warranty.

5
OWNERS MANUAL: EDISON
Safety Information
SMALL CHILDREN AND PETS WARNING
Immediately dispose of all packing materials, as they can pose a smothering risk to small children and pets.
Injury could also occur if children or pets are permitted to play on or under the bed. Do not allow children to
operate this bed without adult supervision.
LUBRICATION AND CLEANING
This product is designed to be maintenance free. The lift motors are permanently lubricated and sealed—no
additional lubrication is required. Do not apply lubricant to lift motor lead screws or any nylon nuts or the
base may inadvertently creep downward from the elevated position.
LIFT WARNING
DO NOT SIT ON THE HEAD OR FOOT SECTIONS WHILE IN THE RAISED POSITION, OR DURING LIFT OR
LOWERING CYCLES.
MOVING AFTER INSTALLATION
Do not place adjustable bed base vertically on its head or foot sections. This may cause injury to persons or
damage to base.
WARNING!
To reduce the risk of burns, re, electric shock, or injury to persons:
 Unplug from outlet before putting on or taking off accessories.
 Close supervision is necessary when this base is used by, or near children, invalids, disabled persons, or
pets.
 Use this base only for its intended use as described in these instructions. Do not use attachments not
recommended by the manufacturer.
 Never operate this base if it has a damaged cord or plug, is not working properly, has been dropped or
damaged, or dropped in water.
 Keep the cord away from heated surfaces.
 Never drop or insert any object into any opening.
 Do not use outdoors.
 Do not operate where aerosol (spray) products are being used or where oxygen is being administered.
 To disconnect, remove plug from outlet.
 DO NOT USE NEAR PEOPLE USING OR WEARING MEDICAL DEVICES. FOR HOUSEHOLD/
RESIDENTIAL USE ONLY.

6
OWNERS MANUAL: EDISON
x4
What’s Included
Before discarding any packing materials, check the adjustable base shipping carton and verify the
following items are included:
(2) Base Pieces
(4) 15” Legs
(2) Connecting Rods
(1) AC Cord
(not attached to the base)
(1) Sync Cable
(1) Remote Control
(1) Power Supply
(not attached to the base)
(1) Foot Mattress Retainer
(attached to the base)
Hex Bolts
9V Batteries AAA Batteries
OR
OR
AB
D F
G I
J K L
E
H
CA
1 2
+
–
+
–
NOTE:
Carefully lift both Base Pieces from the shipping carton, keeping the unit’s top-side down.
Remove the plastic wrapping from the bottom to access the bases.
(1) Allen Key
x2
x2 x2
x8
IMPORTANT:
USE 2 PEOPLE TO LIFT BASE TO AVOID DAMAGE.
for use with TXL,
SCK, SQ models only

7
OWNERS MANUAL: EDISON
Assembly – Base
It is HIGHLY recommended to use two people for the installation of this product.
To assemble, please perform the following steps:
Carefully lift both Base Pieces from the shipping carton, keeping the unit’s topside down. Remove the
plastic wrapping from the bottom to access the bases.
1
2
3
4
Insert the Connecting Rods into one of the Base Pieces and
then slide the other Base Piece onto the Connecting Rods
as shown.
Secure the Base Pieces to each other using the eight hex
bolts (four hex bolts for each Connecting Rod) making sure
to hand tighten each and then tighten 1/4 turn more, as over-
tightening could cause damage to the frame or Connecting
Rod.
Insert the legs into the threaded holes at each corner of
the base by inserting the leg and rotating clockwise until
tight. There must not be any gap or wobble in the leg in
order to avoid risk of injury or damage to the base which
may void warranty.
A
1
A
2
H
A
2
I
J
A
1
E
NOTE:
KING SIZE bases require use of at least two leg
segments. Failure to use a minimum of two leg segments
could result in damage to base and oor and will void
your product’s warranty.

8
OWNERS MANUAL: EDISON
Head Motor
Foot Motor
Power
Supply
To AC Outlet
B
Assembly – Base (cont’d)
Please Refer to diagram when assembling the adjustable bed.
A
FIGURE
NOTE:
Make sure wire
connected to
Power Supply is
routed UNDER
the main metal
frame and lifting
mechanism.
Routing wires on
top of the metal
frame are likely to
result in damage
to the base which
may void the
warranty.

9
OWNERS MANUAL: EDISON
Assembly – Base (cont’d)
6
8Finish removing the plastic packaging from the base to orient
into nal position. Remove the Mattress Retainer Bar from the
bottom of the base. Carefully rotate the base on its side, then
lift and place on legs.
Insert the AC cord into the power supply.
IMPORTANT:
DO NOT PLUG THE BASE INTO THE AC OUTLET YET.
IMPORTANT:
DO NOT LEAN THE BED AGAINST THE INSTALLED LEGS
TO TURN OVER.
TO OUTLET
B
F
TO OUTLET
B
FROM BASE
F
7Insert DC cord from base into the power supply.
5Connect the Foot motor connector cable to control box.
REFER TO FIGURE A ON PAGE 8.
NOTE:
The Head and Foot motors are labeled per illustration.

10
OWNERS MANUAL: EDISON
Assembly – Base (cont’d)
10 Lift the battery cover and insert the two AAA size batteries
(included) into the remote as shown in the gure.
Replace the battery cover.
Remote is already linked with the base.
TO LINK REMOTE:
If the remote is not linked, see page 14.
When setting up a Split Cal King or two Twin XL beds to
form a King, refer to the instructions on page 14 on how
to link your remote.
+
–
+
–
C
L
9Insert the Mattress Retainer Bar upright as shown.
D
A
1
11 Turn the power supply upside down to access the battery
cover, then slide the battery cover off.
B
12 Insert the two 9V batteries (included) into the compartment
and slide the cover back on.
B
K
NOTE:
The battery backup will allow for the bed to be lowered
if a power outage occurs. It is not recommended to do
anything except lower the bed, as the battery backup will
not last if the features are continually used.

11
OWNERS MANUAL: EDISON
14 Initial use of base requires additional run time. Simply press
the Head Up button on the remote until the head section
begins to lift. Then press the Foot Up button on the remote
until the foot section begins to lift.
Assembly – Base (cont’d)
C
13 Insert AC plug into an AC outlet having 100-240V AC,
50/60Hz. Avoid outlets that work only with light switch.
F
NOTE:
If attaching headboard brackets (available separately) to
the base, see the included instructions. Otherwise, place
the desired mattress onto the base and enjoy your new
adjustable base!

12
OWNERS MANUAL: EDISON
Location of Controls — Remote
Operation — Main
Press and hold the Head Up button to raise the
Head position. Release button when desired position
is reached.
Press and hold the Head Down button to lower the
Head position. Release button when desired position
is reached.
C
Head Up
Head Down
Foot Up Foot Down
Underbed Light
Zero Gravity
Position
Memory Position A
Anti Snore Position
Press and hold the Foot Up button to raise the
Foot position. Release button when desired position
is reached.

13
OWNERS MANUAL: EDISON
Operation — Main (cont’d)
NOTE:
EMERGENCY LOWERING: If you cannot nd the remote
control, locate, press and hold the pair button located on
the main control box on the bottom of the bed (shown to
the left).
PAIR POWER
Press and hold the Foot Down button to lower the
Foot position. Release button when desired position
is reached.
Adjust head and/or foot section(s) to desired
positions. Press and hold Memory A button until the
backlight on remote ashes. Release button and wait
for ash to stop. Button has now been programed.
Repeat process if new pre-set position is desired.
Press the Zero Gravity button and the head and
foot positions will go to the Zero Gravity position.
This action can be stopped at any time by pressing
another button.
Press the ANTI-SNORE button and the Head position
will go to the Anti-Snore position. This action can be
stopped at any time by pressing another button.

14
OWNERS MANUAL: EDISON
for use with TXL,
SCK, SQ models only
Operation – Linking the Remote
Connecting 1 Remote to 1 Base
Connecting 1 Remote to 2 Bases
2Simultaneously press & hold the HEAD UP and HEAD DOWN
buttons. When the LED light on the control box turns green,
release the two buttons.
1Double click the PAIR button on the control box (light will
turn blue).
3Test the bed to make sure it is working. Repeat the steps if it
is not.
PAIR POWER
C
1Connect each base to the other using the sync cable (insert
into slot labeled SYNC on each control box). Route sync
cable under frames when installing. Both beds should be in
Flat position when installing sync cables to avoid improper
cable routing
Sync Cable
G

15
OWNERS MANUAL: EDISON
Troubleshooting
In the event the base fails to operate, investigate the symptoms and possible solutions provided below:
Remote control illuminates
and appears to be operable,
but no features of the base
will activate.
No features of the base will
activate.
Remote control will not
illuminate.
 Unplug power cord, wait 30 seconds and plug in to reset electronic
components.
 Defective surge protection device or electrical outlet. Test outlet
by plugging in another working appliance.
 Electrical circuit breaker may be tripped. Check electrical service
breaker box to verify.
 Re-link the remote control (see Remote Control Re-Linking section
of this manual for programming procedures).
 Replace batteries in the remote control & relink remote control.
 Unplug power cord, wait 30 seconds and plug in to reset electronic
components.
 Defective surge protection device or electrical outlet. Test outlet by
plugging in another working appliance.
 Electrical circuit breaker may be tripped. Check electrical circuit
breaker box to verify.
 Replace batteries in the remote control.
Head section will elevate, but
will not return to the horizontal
(at) position.
Head or Foot Lift Function
has minor interference during
operation.
 Base mechanism may be obstructed. Elevate base and check for
obstruction. Remove obstruction.
 Headboard may be too close to the edge of the mattress. Verify that
distance between headboard brackets and mattress is sufcient.
Adjust if required.
 Check batteries in remote, replace if necessary.
 Make sure that you are following the duty cycle of the motor (do not
operate more than one (1) minute over an eight (8) minute period, or
approximately a 12% duty cycle).
 Press the lift buttons squarely and accurately.
 Control box may be experiencing common Radio Frequency
Interference from other radio transmitting devices (see Remote
Control Re-Linking section).

16
OWNERS MANUAL: EDISON
Available Accessories
Resources
High Prole Legs
(Overall Bed Height
18.5”)
Headboard Bracket Kit
CB12LEG18.5
CB18HBBRKT
Item Part Number
To order an accessory, please call 1-855-581-3095
CUSTOMER SERVICE
1-855-581-3095
VISIT US ONLINE
glideaway.com
x4

EDISON
Sleep Well. Live Better. Be Your Best.
8226 LACKLAND RD. ST. LOUIS, MO 63114 | GLIDEAWAY.COM | 314.426.3999
