GLIDEAWAY NAVIGATE 2.0 User manual

OWNERS MANUAL
NAVIGATE 2.0
Base
Comfort
®
OWNERS MANUAL
MANUAL DE INSTRUCCIONES

1
Safety Information ...........................................................................2
What Is Included ...............................................................................5
Assembly - Base ...............................................................................6
Assembly - King Base ......................................................................9
Assembly - Headboard Bracket .................................................10
Location of Controls - Remote ..................................................12
Operation - Main ...........................................................................13
Operation - Sleep Enhancement ...............................................15
Operation - Setting the Memory Preset ................................16
Operation - Linking the Remote ................................................17
Troubleshooting .............................................................................18
Available Accessories ....................................................................20
Specifications..................................................................................21
Technical Assistance .....................................................................21
Service Requirements ..................................................................21
Cleaning ...........................................................................................21
Warranty ..........................................................................................22
Registration .....................................................................................23
Spanish starts on page 25.
Español comienza en la página 25.
Contents
User Info
Please take a moment and write down the serial number in the space provided below, in
case you need to refer to it in the future. This information can be found by raising the head
section of the bed.
SKU: CB200NAV
Serial Number ________________________________________________________
This number will be required for future service claims.

2
RADIO FREQUENCY IS 2.4 GHZ.
FCC compliance device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Any change to the antenna or the device could result in the device exceeding the RF exposure
requirements and void the user’s right to operate the device.
The input voltage is AC100-240 50/60HZ; the output voltage is DC29V 1.8A.
SAFETY INFORMATION
ATTENTION!
IMPORTANT SAFETY INSTRUCTIONS. SAVE THIS MANUAL!
PLEASE READ THESE INSTRUCTIONS THOROUGHLY BEFORE USING
THIS PRODUCT. PROPER OPERATION OF YOUR ADJUSTABLE BED IS
NECESSARY TO ENSURE THE LONG LIFE AND DURABILITY YOU
EXPECT FROM A HIGH-QUALITY PRODUCT. THE MANUFACTURER
HAS TESTED AND INSPECTED THIS PRODUCT PRIOR TO SHIPMENT.
ELECTRICAL SAFETY
Always unplug this adjustable bed frame from the electrical outlet before any cleaning or
maintenance of the bed frame. To safely disconnect, remove the plug from the outlet.
Keep cord away from heated surfaces. Use only indoors.
Discontinue use of this adjustable bed base and contact the manufacturer for repair if:
(1) it has a damaged cord or plug, (2) it is not working properly, (3) it has been dropped or
damaged.
FOR OPTIMAL SAFETY, YOUR ADJUSTABLE BED SHOULD BE PLUGGED INTO A SURGE
PROTECTOR (not supplied with this adjustable bed).
BATTERY PRECAUTIONS
Follow these precautions when using batteries in this device:
1. Warning – Danger of explosion if battery is incorrectly replaced. Replace only with the
6LR61 9V batteries and LR03 AAA batteries.
2. Be sure to follow the correct polarity when installing the batteries as indicated in the
battery compartment. A reversed battery may cause damage to the device.
3. Do not mix different types of batteries together (e.g. Alkaline, Rechargeable and
Carbon-zinc) or old batteries with fresh ones.
4. If the device is not to be used for a long period of time, remove the batteries to prevent
damage or injury from possible battery leakage.
5. Do not try to recharge a battery not intended to be recharged; it can overheat and
rupture. (Follow battery manufacturer’s directions.)
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO MOISTURE.

3
SAFETY INFORMATION
WARRANTY WARNING!
This bed is specifically designed to require no maintenance by you, the user. Any opening or
tampering with the control box, motors or hand controls (with the exception of the battery
compartment, if equipped) will void the warranty. Do not attempt to alter component wiring
or adjust or modify the structure of the product in any way or the warranty will be void.
Only those authorized may conduct repairs or part replacement on your adjustable bed.
IN-HOME USE ONLY
This adjustable bed is designed exclusively for in-home use.
HOSPITAL/MEDICAL DISCLAIMER: This base is NOT designed for hospital or
medical use (In-Home or Commercial) and is NOT designed to meet medical or hospital
standards. Do not use this base with TENT TYPE oxygen therapy equipment or use near
explosive gases.
CONSUMERS WITH PACEMAKERS
It is possible that the vibrating feature of this bed may be interpreted falsely by some
pacemakers as movement and/or exercise. This is common with any product that
produces a vibrating motion, and may or may not affect your pacemaker. Please consult
your physician with any concerns.
PRODUCT RATINGS
Lift Motor Restrictions: The lift motors in this bed are NOT designed to operate
continuously for more than one (1) minute over an eight (8) minute time period, or
approximately 12% duty cycle. To ensure reliable functionality and full life of this product,
do not attempt to exceed these limits.
NOTE: Attempting to circumvent or exceed this rating will shorten the life expectancy
of the product and may void the warranty.
Weight Restrictions: The recommended weight limits on our adjustable beds are:
Queen: 600 lb Full/XL: 500 lb Twin/XL: 400 lb (800 lb if using two twins as a King)
1/pc King: 800 lbs
The structure of the bed will support the recommended weight when distributed evenly
across the bed.
The head and foot sections are not designed to individually support or lift this
amount of weight.
For optimal performance and integrity of structure, entering and exiting the adjustable bed
with the bed in the flat position is recommended.
NOTE: Exceeding the recommended weight restrictions could damage your
adjustable bed and void your warranty.
Vibe Motor Restrictions:
Vibe motors are not designed for continuous, extended vibe motor operation. Vibe motor
systems are rated for a maximum of two hours of use within any six hour period.
The vibe motor feature will emit a minimal tone during operation. This is normal. When the
vibe motor level is increased, motor resonance will intensify accordingly.

4
SAFETY INFORMATION
SMALL CHILDREN AND PETS WARNING
Immediately dispose of all packing materials as they can pose a smothering risk to small
children and pets. Injury could occur also if children or pets are permitted to play on or
under the bed. Do not allow children to operate this bed without adult supervision.
LUBRICATION AND CLEANING
This product is designed to be maintenance free. The lift motors are permanently
lubricated and sealed—no additional lubrication is required. Do not apply lubricant to lift
motor lead screws or any nylon nuts or the base may inadvertently creep downward from
the elevated position.
LIFT WARNING
DO NOT SIT ON THE HEAD OR FOOT SECTIONS WHILE IN THE RAISED POSITION, OR
DURING LIFT OR LOWERING CYCLES.
LOCATION ENVIRONMENT
The level of sound experienced during operation is directly related to the location
environment. For example, when a base is located on a hardwood floor with the vibe
feature in operation, a vibrating tone will be audible. To minimize this resonance, place a
piece of carpet under each leg of the base.
It is possible to experience vibration or noise from the headboard brackets, headboards or
foot boards if mounting bolts are not firmly tightened.
MOVING AFTER INSTALLATION
Do not place adjustable bed base vertically on its head or foot sections. This may cause
injury to persons or damage to base.
WARNING!
To reduce the risk of burns, fire, electric shock, or injury to persons:
• Unplug from outlet before putting on or taking off accessories.
• Close supervision is necessary when this base is used by, or near children, invalids,
disabled persons, or pets.
• Use this base only for its intended use as described in these instructions. Do not use
attachments not recommended by the manufacturer.
• Never operate this base if it has a damaged cord or plug, is not working properly, has
been dropped or damaged, or dropped in water.
• Keep the cord away from heated surfaces.
• Never drop or insert any object into any opening.
• Do not use outdoors.
• Do not operate where aerosol (spray) products are being used or where oxygen is
being administered.
• To disconnect, remove plug from outlet.
• DO NOT USE NEAR PEOPLE USING OR WEARING MEDICAL DEVICES. FOR
HOUSEHOLD/RESIDENTIAL USE ONLY.

5
WHAT IS INCLUDED
Before discarding any packing materials, check the adjustable base shipping carton and
verify the following items are included:
Base Piece
(King size beds only)
(2) Base Pieces
(2) connecting rods
(8) hex bolts with (1) allen key
(1) Foot Mattress Retainer
(attached to the base)
(4) Multi-Height Low
Profile Legs (Overall Bed
height 8”, 11.5” or 15”)
(1) Remote Control
(1) AC Cord (not attached to the base)
(1) Power Supply
(not attached to the base)
(1) DC Power Cord
(1) Sync Cable (Twin XLs only)
Also included:
(3) AAA Batteries
(2) 9V Batteries
(1) Manual

6
ASSEMBLY - BASE
It is HIGHLY recommended to use two people for the installation of this product. To
assemble, please perform the following steps:
Note: If putting together a King size bed
see page 9 for instructions.
1 Carefully lift the base frame from the shipping carton, keeping the unit top-
side-down. Remove the plastic wrapping
from the bottom to access the base.
2 Insert one end of the DC cord into the power supply. Insert the other end with
locking clips into the Control Box. Lock
the Control Box using the locking clips.
3 Insert the AC cord into the power supply.
IMPORTANT: DO NOT PLUG THE BASE INTO THE AC OUTLET YET.
4 Insert the legs into the threaded holes at each corner of the base by inserting
the leg and rotating clockwise until tight.
There must not be any gap or wobble
in the leg in order to avoid risk of injury
or damage to the base which may void
warranty.
Note: If setting two Twin XL’s bases to use with one king size mattress, connect
the Sync cable to the control box (as
pictured) to one base. After bases are
arranged, connect the second Sync Cable
to other base’s control box.
To Control Box
Locking Clips

7
ASSEMBLY - BASE
5 Remove the Mattress Retainer Bar from the bottom of the base. Finish removing
the plastic packaging from the base to
orient into final position. Carefully rotate
the base on its side, then lift and place on
legs.
IMPORTANT: DO NOT LEAN THE BED AGAINST THE INSTALLED LEGS TO
TURN OVER.
6 Insert the Mattress Retainer Bar upright as shown.
7 Replace the retainer clip securely.

8
AC Plug AC Outlet
ASSEMBLY - BASE
REMOTE
8 Lift the battery cover and insert the three AAA size batteries (included) into
the remote as shown in the figure.
Replace the battery cover.
Remote is already linked with the base.
BASE POWER SUPPLY
9 Turn the power supply upside down to access the battery cover, then slide the
battery cover off.
10 Insert the two 9V battery (included) into the compartment and slide the
cover back on.
NOTE: The battery backup will allow for the bed to be lowered if a power
outage occurs. It is not recommended
to do anything except lower the bed as
the battery backup will not last if the
features are continually used.
11 Insert AC plug into an AC outlet having 100-240V AC, 50/60Hz.
+
++
READ USER MANUAL
BEFORE REMOVING
LABEL.
RE-LINK SWITCHES
UNDER LABEL
Note: If attaching a headboard to the base, see the included instructions. Otherwise, place
the desired mattress onto the base and enjoy your new adjustable base!

9
ASSEMBLY - KING BASE
It is HIGHLY recommended to use two people for the installation of this product. To
assemble, please perform the following steps:
1 Carefully lift both Base Pieces from the shipping carton, keeping the unit’s top-
side down. Remove the plastic wrapping
from the bottom to access the bases.
2 Insert the Connecting Rods into one of the Base Pieces and then slide the other
Base Piece onto the Connecting Rods as
shown.
3 Secure the Base Pieces to each other using the eight hex bolts (four hex bolts
for each Connecting Rod) making sure to
hand tighten each and then tighten 1/4
turn more, as over-tightening could cause
damage to the frame or Connecting Rod.
4 Insert the foot motor cable into the
Control box.
Note: Continue with the installation on page 6, step 2.

10
Assembly - Headboard Bracket
Headboard brackets may not be standard with purchase of adjustable base and can be
purchased separately. See page 16 to purchase.
IMPORTANT: The headboard bracket must be assembled to the base AFTER the bed
base has been completely assembled. After assembling the bed according to the
owner’s manual, see this sheet to assemble the head board bracket.
Unpack the kit and make sure the following is included:
PART A
Qty: 2
PART C
Qty: 2
PART B
Qty: 2
PART E
M8 Bolt
Qty: 4
PART D
M8x16mm Hex Bolt
Qty: 8
PART F
M8 Nut
Qty: 4 PART H
Allen Key
Qty: 1
PART G
Washer 10 Zinc
Qty: 4
Completely raise the
headsection of the bed
to access the frame to
which the headboard
bracket will mount.
Identify the two thread-
ed holes that will be used
to mount bed attach-
ment ( Part A) in Step #2
1
Line up the holes in the
bed attachment (Part A)
with the two threaded
holes on the bed base.
Make sure the horizontal
tting of the bed attach-
ment (Part A) points
towards the inside of the
bed. Insert two screws
(Part D) provided with the
kit into the threaded holes
and tighten with the Allen
key (Part H) provided with
the kit.
2
Assembly - Headboard Bracket
IMPORTANT: The headboard bracket must be assembled to the base AFTER the bed
base has been completely assembled. After assembling the bed according to the
owner’s manual, see this sheet to assemble the headboard bracket.
What is Included?
Unpack the kit and make sure the following is included:
Fig. 1
PART A
PART D
Fig. 2
Bed Attachment Horizontal Shaft Headboard Attachment Plate

11
3Attach the headboard
attachment plate (Part C)
to the horizontal shaft
(Part B) using the two at
head self locking screws
(Part E), two washers (Part
G) and two nuts (Part F)
provided with the kit.
5Adjust the position of
the headboard
attachment plates (Part
C) to the right or the left
of the bed as desired by
moving the horizontal
shaft (Part B) left and
right in the horizontal
tting of the bed
attachment (Part A).
Once positioned
correctly tighten screws
(Part D) to hold in place.
To adjust the position of the headboard attachment plates (Part C)
vertically, loosen nuts and screws from step 3. Tighten when the
appropriate height for your headboard is met.
Install the headboard using the line of 3 oval holes on the outside
of the headboard attachment plate.
WARNING: The end of the horizontal shaft (Part B) must always
extend beyond the end of the horizontal tting of the bed
attachment! (Part A) (See Fig. 5 Arrow)
Assembly - Headboard Bracket
4Insert, from the
outside of the bed,
the horizontal shaft
(Part B) into the
horizontal tting of
the bed attachment
(Part A).
PART C
PART B
PART D
Fig. 5
PART A
PART B
Fig. 4
PART A
PART C
PART B PART E
PART F
PART G
Fig. 3

12
LOCATION OF CONTROLS - REMOTE
Head Up
Head Down
Foot Up
Set Timer for Sleep
Enhancement/Turn Off All
Zero-Gravity Position
Foot Down
Anti-Snore
Position
Lay Flat
Head and Foot
Up
Head and
Foot Down
Saved Position A
Length of Time for
Sleep Enhancement
Sleep Enhancement
Wave Up
Sleep Enhancement
Wave Down
Sleep Enhancement
Intensity Up
Sleep Enhancement
Intensity Down

13
OPERATION - MAIN
Press and hold the Head Up (
FL AT
ZG
10 M IN 20 M IN 30 M IN
ANTI
SNORE
MEMORY
A
MEMORY
B
TIMER/
ALL OFF
INTENSITY
SPEED
) button
to raise the Head position. Release button
when desired position is reached.
Press and hold the Head Down (
FL AT
ZG
10 M IN 20 M IN 30 M IN
ANTI
SNORE
MEMORY
A
MEMORY
B
TIMER/
ALL OFF
INTENSITY
SPEED
) button
to lower the Head position. Release button
when desired position is reached.
Press and hold the Foot Up (
FL AT
ZG
10 M IN 20 M IN 30 M IN
ANTI
SNORE
MEMORY
A
MEMORY
B
TIMER/
ALL OFF
INTENSITY
SPEED
) button
to raise the foot position. Release button
when desired position is reached.
Press and hold the Foot Down (
FL AT
ZG
10 M IN 20 M IN 30 M IN
ANTI
SNORE
MEMORY
A
MEMORY
B
TIMER/
ALL OFF
INTENSITY
SPEED
) button
to lower the foot position. Release button
when desired position is reached.
Press and hold the Head/Foot Up (
FL AT
ZG
10 M IN 20 M IN 30 M IN
ANTI
SNORE
MEMORY
A
MEMORY
B
TIMER/
ALL OFF
INTENSITY
SPEED
)
button to raise both the Head and Foot
positions. Release button when desired
position is reached.
Press and hold the Head/Foot Down (
FL AT
ZG
10 M IN 20 M IN 30 M IN
ANTI
SNORE
MEMORY
A
MEMORY
B
TIMER/
ALL OFF
INTENSITY
SPEED
)
button to lower both the Head and Foot
positions. Release button when desired
position is reached.
The Zero-Gravity position raises both
the head and foot to a set position that
distributes the users weight so that it may
provide a feeling of weightlessness and
possibly relieve stress to the body. Press the
Zero Gravity (
FL AT
ZG
10 M IN 20 M IN 30 M IN
ANTI
SNORE
MEMORY
A
MEMORY
B
TIMER/
ALL OFF
INTENSITY
SPEED
) button and the Head/Foot
positions will go to the Zero Gravity position.
This action can be stopped at any time by
pressing another button.
The Anti-Snore position raises the head
slightly so that it may allow relief to
snoring. Press the ANTI-SNORE (
FL AT
ZG
10 M IN 20 M IN 30 M IN
ANTI
SNORE
MEMORY
A
MEMORY
B
TIMER/
ALL OFF
INTENSITY
SPEED
) button
and the Head position will go to the Anti-
Snore position. This action can be stopped at
any time by pressing another button.
FLAT
ZG
10 M I N 20 M I N 30 M I N
ANTI
SNORE
MEMORY
A
MEMORY
B
TIMER/
ALL OFF
INTENSITY
SPEED
FLAT
ZG
10 M I N 20 M I N 30 M I N
ANTI
SNORE
MEMORY
A
MEMORY
B
TIMER/
ALL OFF
INTENSITY
SPEED
FLAT
ZG
10 M I N 20 M I N 30 M I N
ANTI
SNORE
MEMORY
A
MEMORY
B
TIMER/
ALL OFF
INTENSITY
SPEED
FLAT
ZG
10 M I N 20 M I N 30 M I N
ANTI
SNORE
MEMORY
A
MEMORY
B
TIMER/
ALL OFF
INTENSITY
SPEED
FLAT
ZG
10 M I N 20 M I N 30 M I N
ANTI
SNORE
MEMORY
A
MEMORY
B
TIMER/
ALL OFF
INTENSITY
SPEED
FLAT
ZG
10 M I N 20 M I N 30 M I N
ANTI
SNORE
MEMORY
A
MEMORY
B
TIMER/
ALL OFF
INTENSITY
SPEED
FLAT
ZG
10 M I N 20 M I N 30 M I N
ANTI
SNORE
MEMORY
A
MEMORY
B
TIMER/
ALL OFF
INTENSITY
SPEED
FLAT
ZG
10 M I N 20 M I N 30 M I N
ANTI
SNORE
MEMORY
A
MEMORY
B
TIMER/
ALL OFF
INTENSITY
SPEED

14
OPERATION - MAIN
Press the FLAT ( ) button and the bed
will level. This action can be stopped at
any time by pressing another button.
Press the MEMORY A ( ) and the
Head/Feet positions will go to the preset
position. This preset can be changed as
shown later. This action can be stopped
at any time by pressing another button.
Notes:
• When a button is pressed on remote,
all buttons will light to make it easier
to view in low light conditions.
• EMERGENCY LOWERING: If you
cannot find the remote control,
locate and press the red Emergency
Lowering button located on the main
control box on the bottom of the bed
(shown to the left).

15
OPERATION - SLEEP ENHANCEMENT
1 Before starting a the total body vibration, select the duration. To do this, repeatedly
press the TIMER/ALL OFF ( ) button to
select a duration; the respective Sleep
Enhancement LED (10MIN, 20MIN or
30MIN) will briefly light.
2 To start the total body vibration, press the INTENSITY or WAVE + ( ) button once.
Press up to three more times to increase
the massage intensity (up to four levels
of intensity). Press the INTENSITY – ( )
button to decrease the intensity.
3 There are 4 Wave modes available (Low, Medium, High, and Constant). To increase
the Wave mode, press the + WAVE ( )
button once. Press up to three more times
to change the WAVE mode. It will increase
in order of Low, Medium, High, and
Constant. Press the - WAVE ( ) button
to lower the wave mode. Experiment with
different Wave and Intensity settings to
find what is most comfortable to you. The
higher the intensity, the more beneficial it
will be to your body.
4 The total body vibration will last for the duration of time set in step 1. To turn off
the massage before the time is up, simply
press the TIMER/ALL OFF ( ) button.
Sleep Enhancement may help to ease the body to sleep and creates a white noise effect
through total body vibration.

16
OPERATION - SETTING THE MEMORY PRESET
To set the Memory A preset, perform the
following steps:
1 Press the Flat ( ) button so the bed is flat.
2 Adjust the head and feet positions as desired.
3 Press and hold the TIMER/ALL OFF ( ) button until the remote’s backlight starts
blinking (approximately three seconds),
then release the button.
4 Press the MEMORY A ( ) button to memorize. The backlight will stop
blinking to confirm that the memorizing
was successful.
5 To restore the Memory Preset to their factory positions, press and hold
the TIMER/ALL OFF ( ) button for
approximately six seconds; the remote’s
backlight will blink after three seconds,
and then turn off after another three
seconds to confirm that the remote
was reset.

17
OPERATION - LINKING THE REMOTE
Connecting one Remote to one base
How do I link my remote control to the Comfort Base?
1 Press and hold the Link button (the black round button on the control box located
on the bottom of the base) until the LED
light on the control box turns on and then
off. Release the button and the LED light
will blink.
2 Simultaneously press and hold the Head Up and Foot Up buttons until the remote’s
backlight starts blinking. Release the two
buttons and the backlight and the LED
light on the control box will blink until
linked, then they will turn off.
3 Test the bed to make sure it is working,
and repeat the steps if it is not.
How do I Re-Program the Zero-Gravity button back to factory setting?
The Zero-Gravity button has the capability to be re-programmed. In case you would like to
set it back to the original Zero-Gravity setting follow the below instructions:
1. Raise Head to 17 degrees.
2. Raise Foot to 25 degrees.
3. Press and hold the program button labeled “TIMER/ALL OFF button” until the remote
starts to flash.
4. Release program button.
5. Press Zero Gravity button once.
6. Done.

18
TROUBLESHOOTING
Continued on the Next Page
In the event the Comfort Base’s base fails to operate, investigate the symptoms and
possible solutions provided below:
Remote control
illuminates and appears
to be operable, but no
features of the base will
activate.
Remote control will not
illuminate.
Head or foot section
will elevate, but will not
return to the horizontal
(flat) position.
Excessive massage
motor noise.
Head or Foot Lift
Function has minor
interference during
operation.
• Unplug power cord, wait 30 seconds and plug in to reset
electronic components.
• Defective surge protection device or electrical outlet. Test
outlet by plugging in another working appliance.
• Electrical circuit breaker may be tripped. Check electrical
service breaker box to verify.
• Re-link the remote control (see Remote Control
Re-Linking section of this manual for programming
procedures).
• Replace batteries in the remote control.
• Base mechanism may be obstructed. Elevate base and
check for obstruction. Remove obstruction.
• Headboard may be too close to the edge of the mattress.
Verify that distance between headboard brackets and
mattress is sufficient. Adjust if required.
• If base is located on hard surface flooring, place carpet
pieces or rubber cups under each leg of the base.
• Verify that the base is not positioned against a wall,
nightstand, or other object that may cause vibration or
noise.
• If base is installed inside a wood bed frame, verify
vibe motor is not causing bed frame (or bed frame
components) to vibrate.
• Verify that headboard attachment hardware is tightened
firmly (if used).
• Check batteries in remote, replace if necessary.
• Make sure that you are following the duty cycle of the
motor (do not operate more than one (1) minute over
an eight (8) minute period, or approximately a 12% duty
cycle).
• Press the lift buttons squarely and accurately.
• Control box may be experiencing common Radio
Frequency Interference from other radio transmitting
devices (see Remote Control Re-Linking section).

19
TROUBLESHOOTING
The remote is causing
interference with
appliances, TV, garage
door opener, another
base in a different
room, etc.
• Lift the battery cover on remote and remove the yellow
sticker to expose the DIP switches. Slide the switches to
different positions.
• See page 16 for remote re-linking instructions.
• After re-linking, test the bed to make sure it is working,
and repeat steps if it is not.
