Global 246610 User manual

246608
246609
246610
1
AIR CURTAIN
WARNING
•
TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK, OR INJURY TO
PERSONS, OBSERVE THE FOLLOWING:
• This product contains chemicals which are
known to the state of California to cause
birth defects or other reproductive harm.
• This product is not for use in explosive
or combustible atmospheres.
• Read and follow all instructions before
operating the product. Do not use the
product if any part is damaged or missing.
• Do not alter the product's assembly.
• All electrical connections should be made
by a qualified electrician. Installation
work and electrical wiring must be done
by qualified person(s) following all local
electrical and safety codes in the United
States and Canada, as well as the National
electrical Code (NEC) and the Occupational
Safety and Health Act (OSHA) in the United
States, and the Canadian Electric Code
(CEC) in Canada.
• Use OSHA approved lock-out tag-out
devices on power supply to prevent shock
and/or electrocution.
• When cutting or drilling into wall or ceiling,
do not damage electrical wiring and other
hidden utilities.
do not expose to water or rain.
• To reduce the risk of fire or electrical shock,
do not use this product with any solid state
speed control device.
• To reduce the risk of fire or electrical shock,
do not use an extension cord, unit is
intended to be permanently hard wired to
properly rated electrical service outlet (120V
60Hz).
• To reduce the risk of injury to persons, install
product at least 7 feet (2.1m) above the floor
(8 feet in Canada).
• The product frame and motor must be
electrically grounded to a suitable electrical
ground, such as a grounded water pipe or
ground wire system.
• This has a single speed motor which is
equipped with a thermo – protector and
will automatically de-energize the product if
it overheats for any reason.
• To reduce the risk of fire or electrical shock, 3. Disconnect the product from its power
source when removing guards for
cleaning.
4. Do not use the product in windows.
Rain and moisture may create electrical
hazard.
5. Do not place the product near an open
flame, cooking or heating appliance, or
hot surface.
6. This product is for indoor dry applications.
7. This product should not be operated
outside.
8. Periodically clean the propeller, guard,
motor, and louver of any accumulated
dirt.
9.
10.
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
Children should be supervised to ensure
that they do not play with the appliance.
READ & SAVE THESE INSTRUCTIONS
RULES FOR SAFE OPERATION:
1. Never insert fingers or any other objects
through the grill guard when product is
in operation.
2. If the power supply cord is damaged,
contact your local service centre or a
qualified electrician to install an
appropriate replacement cord to prevent
any injury or damage.

2
AIR CURTAIN
2. WIRING DIAGRAM
1. SPECIFICATION
MODEL
SIZE
LOW HIGH
Current Power Velocity Noise Current Power Velocity Noise
Inch A W m/s dB A W m/s dB
36 2.10 255 16 56 2.85 345 20 59
48 2.65 320 16 56 3.50 425 20 59
60 3.60 440 16 56 4.80 575 20 59
3. INSTALLATION DIMENSIONS
MODEL A B C D E F G
36 2 16 10 8 8 5
8
48 8 16 10 8
60 14 16 10 8
246608 / 246609 246610
246608
246609
246610
246608
246609
246610
8
8
5
5
8
8
A
B B C C
D
E E E
F
G
8 mounting holes
(8mm wood screws)
6 mounting holes (8mm bolts)
control switchair outlet
mounting
plate air inlet
4 1
3
4
4
1
1
3
3
( Inch )

3
AIR CURTAIN
Installation Plate
Fixing Screws
2” above
indoor outdoor
WARNI NG
● Installation and electrical connection must be performed by a qualifed technician.
1) Accessories
6 sets of (M8x60L) Fastening bolts, Washer, Spring
washer, and (M8) Nut.
2) Check to ensure the voltage / frequency on rating label
is complied with the local power source before use.
3) Follow the right diagram for installation position.
4) Coverage height: 99 inches (for horizontal Air Curtain
installation).
5) Installation on a concrete wall
a. Take down INSTALLATION PLATE (unscrew the fxing screws
down the REAR). See the following diagram:
b. Install INSTALLATION PLATE on the wall:
● Fix position of installation.
● Insert bolts and fll with cement for
consolidation.
● After cement solidifes, install
INSTALLATION PLATE on bolts and
fasten it with washers, spring washers
and nuts. See the diagram on the right.
● Ensure INSTALLATION PLATE is fxed securely.
c. Install the BODY (hang up the BODY onto the INSTALLATION PLATE,
check to ensure it is proper andsecure, and then tighten the fxing screws).
See the following diagram:
1
2
3
4
fxing bolts
cement
washer
spring
washer
installation plate
nut
4. INSTALLATION METHOD

4
AIR CURTAIN
5. OPERATION INSTRUCTIONS
1) Plug-in to an AC power outlet. (OFF lamp lit with a high tone beep)
2) Select a key stroke of LO or HI to set the speed at LOW or HIGH.
(or press a relevant function key stroke for the Remote Control device.)
3) Adjust AIR DEFLECTOR to preferred direction. See the following diagram:
indoor outdoor indoor outdoor
light wind strong wind
6. CAUTIONS AND MAINTENANCE
1) Install at location frmly enough for safety, check installation quality periodically.
2) Do NOT install Air Curtain at location with water-splash, or with permanent exposure to
high temperature and places close to explosive and corrosive gases.
3) Have reliable earthling set when use.
4) In case of damage or breakdown, should consult qualifed technician.
5) Clean Air Curtain periodically. (Note: Do NOT clean unit with benzene or corrosive liquid.)
7. REMOTE CONTROL
WARNING ● Please unplug the power cord before cleaning.
6) Other installation methods. See the following diagram:
I n stallation on a Steel Framework Installation on a Wooden Framework
7) Use more than one unit of Air Curtain with appropriate length to fll up the width of
the doorway.
8) The recommended distance between 2 adjacent units of Air Curtain is to be 1-2
inches.
Bolt & Nut
Wood Screw
