Gnet Gpack GB1000 User manual

SMART BATTERY MANUAL
gb1000/2000
ESS(Easy Smart System)

Product type
Serial NO.
Customer
Name Tel
Address
Warranty period
Model GB1000 / GB2000
Warranty Card
Caution
1. Use the genuine cable which G-NET provide when you install the G-PACK
2. Avoid the direct light and do not keep in the high temperature.
3. Do not throw or give the strong impact.
4. Do not repair or remodel by yourselves.
5. Be careful not to be soaked.
6. Do not to disassemble, pressure and drill a hole
7. Be careful that children and pet do not touch the G-PACK.
8. Exchange the new products when it smells bad during use.
9. Exchange the new products when it swollen during use.
10. Do not use in electrostatic place where influence performance of G-PACK protection channel.
11. It is possible that frequent nature discharge influence performance of G-PACK
12. After check the capacity output of generator and setting within a permitted limit
13. If the charge voltage is setting over condition, it will make an error.
14. Do not guarantee when it is setting wrong voltage, power and electric wiring.
Degradation, heating, ignition and explosion are happened by carelessness of
handling, please check the below article before use.

Parts and Component
※ Components
▶
G-pack battery, Manual, Connection cable(For Dash cam / Battery), 2 types Dual fuse holder(Bundle)
Charging LED / Bluetooth paring button DC
- IN Cable Jack USB port
G-pack will prevent Car’s battery to be discharged and helping to extend battery life
G-pack doesn’t need regularly check and maintains not like Accid battery. LiFePO4 battery inside of G-pack
has only 1% self-discharge rate in a month(But, Accid battery is 5~20% in a month).
Eco friendly battery
LiFePO4
Eco Green
-20 C ~ 80 C
Temperature Auto Detection
Over charging, Over currency
Built-in Sell balancing circuit
Safety
Recharge over 2,000times
Outstanding life time
GB1000 : Appx. 33hrs
GB2000 : Appx. 66hrs
Recording time
Easy checking of battery status,
setting and
Alarm via Smartphone
ESS Function
(Easy Smart System)
Reasonable Price
Easy installation with slim
and light
Slim size
Easy connection with 5pin
Safe internal design
Safety Design
Features
Power Sleep Mode
PSM Function
Fast & Easy quick charging(over 90%)
(GB1000 : 45mins / GB2000 : 90mins)
Quick Charge
Portable USB charger
PPC Function
(Portable Power Charge)

11*9mm 9*15mm
Low Profile Mini
BASIC OPTIONAL
Micro2
* Connect car fuse to gender
Fuse included in G.PACK
How to install G.PACK
2. G.PACK & Dual fuse holder
Connect between G.Pack and dual fuse holder cable
19*19mm
ATO
11*16mm
Mini
3. Connect Fuse box
1. After finishing number 2, connect fuse box with gender.
AB
1. Wiring diagram
Direct power cable from Dash cam
A
Charge cable for G.Pack.
*Over fuse box 20A
B
Operating Power Sleep Mode to protect internal battery. In case that do not use G.PACK for certain time.
(without input and output)
1. When operating Sleep mode. internal battery and USB port power will be off.
Then, run low power standby mode.
2. If user's want to wake Sleep mode up. Press Bluetooth pairing button or Input power to G.PACK
Power Sleep Mode Function(PSM)

Caution
5. Install the cable in right of direction
After put the cable in the hole and turn to the right
1
When it is boosting charge (9A), it is possible to influence performance of the car.
Please ask to specialist
Bluetooth pairing function
Download the “G-PACK” in Google play or App store.
“ ”
How to install the Smart phone Application
Caution before connect with Smart Phone
● Real time check and use are possible to be delayed depends on the specification of Smart phone
● Do not use during the driving for safety reason
How to install G.PACK
4. Connect direct power cable from Dash cam
Using 3 wire power cable
1
Using 2 wire power cable
2
G.Pack power cable
A
Dash cam Power cable
B
ACC
GND
VCC
ACC
VCC
GND
G.Pack power cable
A
Dash cam Power cable
B
GND
VCC VCC
GND
AB
1
ACC
GND
VCC
ACC
GND
VCC
AB
GND
VCC
GND
VCC
2

Specification
Capacity
Battery type LiFePO4
Input power 12V~16V, Max10A
Charging Voltage
Output / Voltage
MSIP-RMM-TLP-GB1000
MSIP-CRI-MdK-MDBT40
Certification
Model GB1000
12.8V / 6800mA / 87,04wh
LiFePO4
12V~16V, Max10A
MSIP-RMM-TLP-GB2000
MSIP-CRI-MdK-MDBT40
GB2000
12.8V / 13600mA / 174,08wh
* The specification of product may be different without notice.
148(W)x160(H)x42(D) / 1.05kg Size / Weight 163(W)x259(H)x42(D) / 1.95kg
14.6V / Current(A) follows Bluetooth setting(6A/9A)
11V ~14.6V / Max 6A 11V ~14.6V / Max 6A
14.6V / Current(A) follows Bluetooth setting(6A/9A)
Bluetooth connection
2. Run the Application
Run the application of Smart phone.
G
PACK
4. Connect the Bluetooth
Select the battery
* When reconnection, please select the “correct” button without
additional setting.
* When first time of pairing, press the button shortly.
When reentrance of pairing, put the button over 3 seconds.
1. Press the Bluetooth button
Press the Bluetooth pairing button
which is on the top of battery.
3. Search the device
Click the search button which is lower end of left.
