Go Power DOMETIC GP-ADV-LiFePO4-300 User manual

ADVANCED LITHIUM
BATTERY
Quick Start Guide
Technology Lithium Iron Phosphate
Nominal Voltage 12.8 V
Fully Charged Voltage (FC) 14.6V
Fully Discharged Voltage (FD) 9.2V
Capacity (Ah) 300Ah
Recommended Discharge
Terminated Voltage
Max Continuous Charge Current
10V
Battery Charge Voltage 14.2V
200A
Battery Discharge Terminated
Voltage 9.2V
Heater Function
Standard Charge Method
Battery pack includes heater for heating cell module temper-
ature up when battery pack is charged in a freezing en-
vironment
Inner Resistance ≤10mΩ
CE, UKCA, UN38.3, UL 2054
Operating Temperature
Charge: -32°F (0°C) to 131°F (55°C)
Discharge: -4°F (-20°C) to 131°F (55°C)
Storage Temperature1
1 month > 113°F (45°C) to 140°F (60°C) - Max 80% RH
3 months > 77°F (25°C) to 113°F (45°C) - Max 80% RH
6 months > -68°F (20°C) to 77°F (25°C) - Max 80% RH
177°F (20˚C) ±5 is the recommended storage temperature at 60% State of Charge while
being in Power Off mode.
Humidity
20uA in Shutdown Mode
BMS Leakage Current
IP Requirement
19.6in x 14.9in x8.66in (498mm x 379mm x220mm)
IP67
Dimensions (LxWxH)
77.2lbs (35kg)
Weight
Operating: 5% to 90 % RH
Storage: 45% to 85% RH
GP-ADV-LiFePO4-300
WARNINGS
Only wire 8 batteries maximum in parallel
Do not get wet
Wire a maximum of 4 in series
Find tech tips, manuals and support at gopowersolar.com
BATTERY SPECIFICATIONS
SPECIFICATIONS
Certifications Negative Terminal
Positive Terminal
Power Button (LED)
RV-C 1
RV-C 2
No.
Descrip�on
1
2
3
4
5
NO. DESCRIPTION
0.5C CC (constant current) charge to FC, then
CV (constant voltage FC) charge till charge current
decline to ≤0.05C
4 53
2
1
UN38.3
Scan for
full
manual

LED Battery Mode Definition
Solid light Power on mode
Blinking light Sleep/Reserve mode
OFF Power off mode
LED (POWER BUTTON) INDICATORS
CAN PORT WIRING
*cables purchased separately
Function
Part Number
GP-RVC-BCR – ADV LFP TERMINATOR
GP-ADV-BC-600 -ADV LFP INTER-BATT HARNESS, 600MM
GP-RVC-BC -ADV LFP RV-C SYSTEM HARNESS
INTERFACE DESCRIPTION
VARIOUS POWER MODES
Reserve
Capacity
Reserve
Capacity
Power off
Press and hold for 3s and release
Press and hold for 8s and release
Press and hold for 8s and release
Press and hold for 8s and release
Press and hold for 3s and release
Press and hold for 3s and release
Press and hold for 3s and release
or charge battery to above 5Ah
Press button for more than 3 seconds and release. The battery will enter sleep
mode. The LED will blink. Power off mode should only be used for long term
storage or to reset the BMS. Use sleep mode to disable output power of batteries.
Scan the QR code to download the Go Power! Connect App
for use with the Sun Cycle®Advanced Lithium Battery.
MOBILE APP
Power on
Power on
Power on
Power off
Power off
Sleep Mode
Sleep
Mode
HOW TO USE
NOTE:
To prevent a surge current, perform a “pre-discharge” as outlined in the
steps below.
Batteries are in Power Off mode when unboxed. Press the Power button
for 3 seconds to turn on. If it doesn’t turn on, you will need to charge
the battery.
The batteries need to be configured before they can be used. Please see
battery manual for instructions on battery configuration.
Connect batteries following the series or parallel connection diagrams
found at gopowersolar.com/advanced-lithium-wiring. The Battery
Inter-Connect Cable must be installed for each battery pack followed by
a Battery End Cap Terminating Resistor cable on the last battery.
Step 1 - Ensure all batteries are in Power Off mode.
Step 2 -
Step 3 - Ensure battery pack terminals are correctly installed and connected to
the inverter system.
Step 4 - Press the power button on one of the battery packs for 3 seconds to
wake up all battery packs from Power Off mode. The LED indicator
will turn on.
System Connection Cable
Battery Inter-Connect Cable
RV-C system
(if applicable)
Battery End Cap
Terminating Resistor
System Connection Cable
300Ah Battery Inter-Connect Cable

