GOAL ZERO LightHouse micro User manual

1
Table of Contents
Get To Know Your Gear 2
How It Works 3
Recharge Your Lighthouse Micro 3
Technical Specifications 4
BEFORE FIRST USE:
Take Lighthouse Micro out of DEMO MODE by plugging it
into a powered USB port.
Not near a USB? Press the On/Off/Dimmer Button five
times and hold on the sixth. The Battery Indicator will flash
and Lighthouse Micro will be out of DEMO MODE.

2 3
GET TO KNOW YOUR GEAR
Push the On/Off/Dimmer Button once for both sides lit,
twice for one side lit.
Press and hold to dim each mode.
Using the flip-out USB tip, plug Lighthouse Micro into
any powered USB port to charge it up in 3.5 hours. Also
charges from 3.5 hours of full sun from the Nomad®7.
Still in DEMO MODE? See the front cover for instructions.
HOW IT WORKS
Hanger
Lantern Output: 150 Lumens
Waterproof
IPX7 Rated
USB
Rechargeable
Hour Runtime
on Lowest Setting
Nomad®7
Solar Panel
(sold separately)
3.5 Hours
Full Sun
3.5 Hours
USB Port
Recharge from USB or solar panel.
RECHARGE YOUR LIGHTHOUSE MICRO
RUNTIME LUMENS CHARGE TIME
One Side (Low) 170 hours 10 lumens USB source 3.5 hours
One Side (High) 15 hours 75 lumens Nomad 7 3.5 hours
Both Sides (Low) 80 hours 20 lumens
Both Sides (High) 7 hours 150 lumens
Battery Indicator
On/Off/Dimmer
Button
TOP VIEW
25%
50%
75%
100%
USB Charging Tip

4
TECHNICAL SPECIFICATIONS
Battery
Cell chemistry Li-ion NMC
Cell type 18650
Cell capacity 9.62Wh (3.7V, 2600mAh)
Lifecycles hundreds of cycles
Shelf-life Charge every 3-6 months
Ports
USB port (input) 5V, up to 1A (5W max)
General
Durability IPX7
Weight 2.4 oz (68g)
Dimensions 3.66 x 1.5in (93 x 37.75mm)
Operating usage temp. 32-104 F (0-40 C)
Certs
Warranty 12 months
Be sure to activate your warranty at goalzero.com/warranty
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.

GOAL ZERO HEADQUARTERS
675 West 14600 South
Bluffdale, UT 84065
1-888-794-6250
Designed in the U.S.A.
Made in China
CA081916
