Goji G6P4WL20 User manual
4,000mAh Qi Wireless
Power Bank Pro
Instruction Manual
G6P4WL20
2
Product Overview
Thank you for purchasing your new
product.
We recommend that you spend some time
reading this instruction manual in order that you
fully understand all the operational features it
oers. You will also nd some hints and tips to
help you resolve any issues.
Read all the safety instructions carefully before
use and keep this instruction manual for future
reference.
Suction Cups
Battery level
Indicators
ON/OFF
Button
Wireless
Indicator
USB Type A
output sockets Input socket
Qi Sensor
3
Charging the Powerbank
While charging, the indicators will ash. When fully
charged, the indicator will light up steadily.
Battery Status
Check the power level
by pressing the ON/OFF
button. Indicators will
show the battery level.
100%
0%
USB power adaptor
(sold separately)
The USB power adaptor output should
matches the rated input of the powerbank.
4
Wireless Charging
Digital Devices
1. Press the ON/OFF button to enable wireless
charging. The wireless indicator will light up red.
The wireless charging feature will disable
if it is not in use more than 60 seconds.
Alternatively, press the ON/OFF button once
to conserve battery.
Charging Your Digital Devices
Press the ON/OFF button to start charging if it does not
start automatically.
5
2. Place your mobile
device on the top of
the powerbank. Both Qi
sensors must overlap. The
wireless indicator will light
up green when succeeded.
Qi sensor
Status Wireless indicator
Charging Light up in green
Fully charged Light will turn off
Error Flash in red and green, then light off.
• If the suction cups are not holding the
mobile device rmly, wipe o the dust from
their surface with a wet cloth and try again.
• When carrying or lifting, hold both the
powerbank and mobile device in case the
device falls.
6
Troubleshooting
If any functional abnormality is encountered, replace
your mobile device on the unit.
• Mobile device is not placed in a correct position.
• Placing any metal or other item with electric eld
may cause short circuit, such as credit card, key,
memory card, etc.
• The powerbank does not support small current
devices (e.g. smartwatch, wireless earphones, etc.)
• The charging system is malfunction.
7
Specications
Battery Type Lithium ion
Capacity 4000 mAh
Input 5V 2A
Output USB A: 5V 2.1A
Wireless charging: 5V 1A
(max. 5W)
You may charge up to 2
devices at the same time,
sharing a maximum 10.5W
output current (2 x 5V 1A).
Frequency Band(s) 108 – 207 KHz
Max. Radio
Frequency Power
Transmitted
-37 dBuA/m @10m distance
Charge up the
Powerbank
About 2.5 hours
with input 5V 2A
Operating
Condition
0°C – 35°C
Dimension
(L x W x H)
128 x 67 x 13.5 mm
Net Weight 130 g
Features and specications are subject to change
without prior notice.
IB-G6P4WL20-200305V1
Declaration of Conformity (RED)
Hereby, DSG Retail Ltd. declares that the radio
equipment type [G6P4WL20] is in compliance
with Directive 2014/53/EU.
The full text of the EU declaration of conformity is
available at the following internet address:
https://www.teamknowhow.com/
Click on SEARCH and enter the model number.
