Table Call System
User Manual
English

Contents
Introduction................................................................................1
Device & Specification..........................................................2
Transmitter: Service Call TB-A06................................ 2
Receiver: RE-300............................................................. 4
Operation & Setting.................................................................6
Manual Programming...............................................................7
Trouble Shooting.......................................................................9
Warning .......................................................................................10

Introduction
Introduction
TABLE CALL is an easy, smart wireless service bell with
800 meter coverage in diameter. Users can manually
program the table call system without using the PC. It
helps restaurants to expedite their table turnover and
service efficiency.
The system capacity is up to 200 pcs table call TB-A06
with 4 pcs receiver RE-300 that you may install from a
small restaurant to bigger ones, which is very flexible.
The high light of this system are:
• Monitorcallfunctiontoassurehighreliability
• Widecoverage
• Chargeable,longlifespan
• Manualprogrammable
TABLE Call is strongly recommended as simple solutions
at below occasions:
• R e s t aur an t 
• CoffeeShop
• Barsandcuisine
1

Transmitter – TB-A06 (The service bell)
Device & Specication
2
LED indicator
• UnderCharging:RedLED
on
• Batterylow:RedLED
blinking
• whenpushthebutton,
under charging or in
battery low
• Chargeable,10pcsmax.
at one stack
The button:
• Servicecall→Blue
LED light on
• Cancelthecall→
Push again and Blue
light off

This is a table call with one service button. With its
eye-catching LED it obtains waiter’s attention at visual
once it is pushed, meanwhile, sending alert page to
the receiver in order to get service in shortest time.
It comes with “Monitor call” function to keep receiver
aware of its availability.
Capacity:
• Upto200pcsinsamegroup
Transmitter – TB-A06 (The service bell)
Device & Specication
3

Receiver – RE-300 (The desk receiver)
Device & Specication
4
50 keys
Blue: A service on waiting
Red: Reminder (after waiting time 1~3 minutes, programmable)
Table call dis-link: Blue/Red intercross blinking
RX LED:
Blinking in Green
when getting a call
System NO.
Power

Receiver – RE-300 (The desk receiver)
Device & Specication
This is a 50-key receiver that users can lay it on
reception desk or mounted on the wall. It notifies the
staff of which table is in need of service.
Capacity:
Up to 4 pcs in same group
Key Spec:
• 50Key,eachonerepresentstoonetable,
manual programmable
• DualLEDindicator
• LEDindicatorforremind
• Wallmountedavailable
5

Device & Specication
6
RE-300 Specifications
Frequency RX 430 ~ 470MHz
Baud Rate(bps) 1200
Channel spacing 12.5KHz / 25KHz
Paging Sensitivity(dBm) -122dBm @1200
Selectivity (25KHz) >=50dB
Spurious & Image Rejection >=50dBm
Frequency Stability <= +/- 3ppm
Receiver Type Synthesized
Frequency Deviation ±2.5KHz / ±4.5KHz
Alert Tone SPL >= 80dB@ 10cm
Operation Temperature -10º~+60º C
Storage Temperature -10º to +60ºC
Power Supply DC 9V / 2.2A
Dimensions (mm) 232 (L) x 170 (W) x 50 (H)

Device & Specication
7
TBA06 Specifications
Frequency TX 430 ~ 470MHz
TX output High power 10mW
Transmission radius 400mm
Channel spacing 12.5KHz / 25KHz
Maximum Deviation ±2.5KHz / ±4.5KHz
Baud Rate(bps) 1200
Conducted Spurious Emission less - 55dBc
Frequency Stability < ±1ppm
Operating power 3.6~4.5V Battery package
(3 pcs Ni-MH Rechageable battery 1.2V)
Standby < 0.3mA
Transmit 50 ~ 57mA
Operation Temperature -10º to +60º C
Storage Temperature -10º to +60ºC
Ni-MH Rechargeable battery 3.6V 350 mAh
Low Battery Alert level < 3.65V
Dimensions (mm) 110(Diameter)X 16.2(H)
Charger

5 function keys for simple manual setting:
Operation & Setting
8
Number
+
Power on Setting
How to do
During setting, if you heard sharp beep it
means setting is void. Please reset RE-300
again if so. Always press
“50” as conrmation button
1Frequency
Until hearing short “beep” and let go, you will
seenumber“1-10”blueLEDlight-on.Keyin
frequency and press “50” until you hear long
beeping “b-e-e-p” to save it. (Ex: 450.550 MHz,
please enter 450550. (10=0))
2Beep on /
off
Until you see number “2” turns on. Push again
to cancel the beeping. Blue light turn on= Beep
on, Blue light turn off=Beep off (Default value:
Beep on).
3Waiting
Time
Until hearing short “beep”, you will see number
“1, 2, 3” is on. Then pressing number 1, 2 or 3
again to set up waiting time. After determining
the number, please press “50” until you hear
long beeping “b-e-e-p” to save it. (Default value:
2 Mins.) (1=1 Min, 2=2 Mins, 3=3 Mins)
4
Erase or
Add a TB-
A06
Until hearing short “beep” and let go. All 50 blue
LED light on besides the lost or dis-link ones.
To erase them: Press numbers they belong to.
To add them back: Follow same way and to
press their number.
5TB-A06 in
total
Until hearing short “beep” and let go, all blue
LED light on. Plese select the number key
standing out total pieces of TB-A06 you have,
then push "50" until hearing long "b-e-e-p".

Operation & Setting
9
Number
+
Power on
Setting
How to do
During setting, if you heard sharp beep it
means setting is void. Please reset RE-300
again if so.
Command 1-4, 6: Always press
“50” as conrmation button
1+21 Program
pagers
1. Until you hear short beep and let go, you
will see that all blue lights turn on.
2. Place SAP-T programmer on the table
call, pressing its “number” then “50” until
you hear long beeping “b-e-e-p”. (During
programming: the light of number turns out
to red)
3. Follow the same way until you finish the
last number of Table Call TB-A06. 4.
Reset the RE-300 and the programming is
successful.

Manual Programming
10
1. Press “1 + 21” and turn on power to enter the
programming mode. 50 blue LED all turn on
shortly.
2. Insert the programmer kit SAP-T on first TB-A06
for programming. Press the number representing
the first table call, then press 50 until you hear
long beeping.
For example:
Press NO# “1”, followed by “50” until you hear
the long beeping. You will see the LED indicator
turn out to RED which means the number is
under programmed. Once successful, the RED
LED would turn off and please go to next
programming. If failed, please retry.
Follow up the step until the last number of TB-A06.

11
Due to wireless device, the interference might happen.
Each call are guaranteed to receive within 15 to 45
seconds
1. If the button without receiving the message,
please manually dismiss the lights on the RE-300
and clear the light on TB-A06
Trouble Shooting

12
• RISKOFEXPLOSIONIFBATTERYISREPLACED
BY AN INCORRECT TYPE.
• DISPOSEOFUSEDBATTERIESACCORDINGTO
THE INSTRUCTIONS.
Warning

Make sure to read this manual before using the machine. Please keep it in hand
for future reference.
