Goodman CPC CONVERCIAL SS-CPC90-150 User manual

SS-CPC90-150 www.goodmanmfg.com 4/12
Supersedes 2/12
Standard Features
• R-410Achlorine-freerefrigerant
• High-efciencyscrollcompressors
• Two-stagecooling
• Coppertube/aluminumncoils
• Contactorwithlugs
• High-andlow-pressureswitches
• High-capacity,steel-casedlterdrier
• Heaterkitswithsingle-pointentry
• 24-voltterminalstrip
• Convertible
• Easytoservice
• Built-inlterrackwithstandard2”lters
• Bottomutilityentry
• AHRICertied;ETLListed
Cabinet Features
• Heavy-gauge,galvanized-steelcabinetwith
UV-resistantpowder-paintnish
• FullPerimeterRail
up to 11.5 EER
Cooling CapaCity: 90,000 — 146,000 Btu/h
CpC CommERCial
7½- to 12½-ton thREE-phasE
paCkagEd aiR ConditionERs
Contents
Nomenclature........................................................................2
ProductSpecications...........................................................3
AirowData...........................................................................7
HeatKitElectricalData.......................................................11
ExpandedCoolingData.......................................................16
Dimensions..........................................................................26
WiringDiagrams.................................................................30
Accessories...........................................................................34
*Completewarrantydetailsavailablefromyourlocaldealeroratwww.goodmanmfg.com.

pRoduCt spECifiCations pRoduCt spECifiCations
2 www.goodmanmfg.com SS-CPC90-150
nomEnClatuRE
    

      
           
RevisionLevels

Brand FactoryInstalledOp7ons
  

 
Configura7on
 
  
 
Applica7on 
   
  
 
FactoryInstalledOp7ons
NominalGrossCoolingCapacity 
     
     
    
    
    
 
NominalHea7ngCapacity 
CPG CPC/CPH(FactoryInstalledElectricHeat) 
     
   

  
   

  
   

 
   


   

 FactoryInstalledOp7ons
   

  
 
Voltage SupplyFan/DriveType/Motors


   


  

 

FactoryInstalledOp7ons



 
 


 
 

 

 

Product SPecificationS Product SPecificationS
SS-CPC90-150 www.goodmanmfg.com 3
Product SPecificationS — 7½ tonS
CPC090
***3B***B*
CPC090
***4B***B*
CPC090
***7B***B*
Cooling Capacity
Total BTU/h 90,000 90,000 90,000
Sensible BTU/h 64,000 64,000 64,000
EER / IEER 11.5 / 11.5 11.5 / 11.5 11.5 / 11.5
Decibels 82.0 82.0 82.0
AHRI Reference #s 5104770 5104770 5104770
Evaporator Motor / Coil
Motor Type Belt Drive Belt Drive Belt Drive
Indoor Nominal CFM 3,000 3,000 3,000
Indoor Motor FLA (Cooling) 5.0 2.5 2.3
Horsepower / RPM 1.5 / 1745 1.5 / 1745 1.5 / 1725
Piston Size (Cooling) 0.078 0.078 0.078
Filter Size (Qty) (4) 16”x20”x2” (4) 16”x20”x2” (4) 16”x20”x2”
Drain Size (NPT) ¾” ¾” ¾”
R-410A Refrigerant Charge Cir #1 & #2 175 oz. 175 oz. 175 oz.
Evaporator Coil Face Area (²) 8.9 8.9 8.9
Rows Deep / Fins per Inch 4 / 16 4 / 16 4 / 16
Belt Drive Evap Fan Data
# of Wheels (D x W) 1 (15” x 12”) 1 (15” x 12”) 1 (15” x 12”)
Motor Sheave / Blower Sheave VL40 / AK74 VL40 / AK74 VL40 / AK74
Belt AX51 AX51 AX51
Condenser Fan / Coil
Quanty of Condenser Fan Motors 222
Horsepower - RPM ¼ - 1075 ¼ - 890 ¼ - 1,075
Fan Diameter / # Fan Blades 22 / 4 22 / 4 22 / 4
Outdoor Nominal CFM 7,200 7,200 7,200
Face Area (²) 36 36 36
Rows Deep / Fins per Inch 2 / 22 2 / 22 2 / 22
Compressor
Quanty / Type 2 / Scroll 2 / Scroll 2 / Scroll
Stage 1 1 1
Electrical Data
Voltage-Phase-Frequency 208/230-3-60 460-3-60 575-3-60
Quanty of Compressors 222
Compressor RLA / LRA 13.1 / 83.1 6.1 / 41.0 4.4 / 33.0
Max External Stac 1.0” 1.0” 1.0”
Outdoor Fan HP / RLA (2) ¼ / 1.4 (2) ¼ / 0.8 (2) ¼ / 0.6
Total Unit Amps 34.0 16.3 12.3
Min. Circuit Ampacity¹ 37.3 17.8 13.4
Max. Overcurrent Protecon (amps)² 50 20 15
Entrance Power Supply Locang
Dimple
Locang
Dimple
Locang
Dimple
Entrance Control Voltage
Operating Weight (lbs) 975 975 975
Ship Weight (lbs) 1000 1000 1000
¹ Wire size should be determined in accordance with Naonal Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Note: Always check the S&R plate for electrical data on the unit being installed.

Product SPecificationS Product SPecificationS
4 www.goodmanmfg.com SS-CPC90-150
Product SPecificationS — 8½ tonS
CPC102
***3B***A*
CPC102
***4B***A*
CPC102
***7B***A*
Cooling Capacity
Total, BTU/h 102,000 102,000 102,000
Sensible BTU/h 70,380 70,380 70,380
EER / IEER 11.3 / 11.4 11.3 / 11.4 11.3 / 11.4
Decibels 83 83 83
ARI Reference #s 5104771 5104771 5104771
Evapoartor Motor / Coil
Motor Type Belt Drive Belt Drive Belt Drive
Indoor Nominal CFM 3,200 3,200 3,200
Indoor Motor FLA (Cooling) 7.8 3.9 2.3
Horsepower - RPM 1725 1725 1725
Piston Size (Cooling) 0.08 0.08 0.08
Filter Size (Qty) (4) 16” x 20” x 2” (4) 16” x 20” x 2” (4) 16” x 20” x 2”
Drain Size (NPT) 3/4" 3/4" 3/4"
R-410A Refrigerant Charge Cir #1 & #2 180 oz. 180 oz. 180 oz.
Evaporator Coil Face Area (²) 8.9 8.9 8.9
Rows Deep / Fins per Inch 4 / 16 4 / 16 4 / 16
Belt Drive Evap Fan Data
# of Wheels (D x W) 1 (15" x 12") 1 (15" x 12") 1 (15" x 12")
Motor Sheave / Blower Sheave VL40 / AK74 VL40 / AK74 VL40 / AK74
Belt AX51 AX51 AX51
Condenser Fan / Coil
Quanty of Condenser Fan Motors 222
Horsepower - RPM 1/4" - 1,090 1/4" - 890 1/4" - 1,075
Fan Diameter / # Fan Blades 22 / 4 22 / 4 22 / 4
Outdoor Nominal CFM 7,200 7,200 7,200
Face Area (²) 27 27 27
Rows Deep / Fins per Inch 2 / 22 2 / 22 2 / 22
Compressor
Quanty / Type 2 / Scroll 2 / Scroll 2 / Scroll
Stage 1 1 1
Electrical Data / Static
Voltage / Phase / Frequency 230 / 3 / 60 460 / 3 / 60 575 / 3 / 60
Quanty of Compressors 222
Compressor RLA / LRA ea. 14.5 / 98 6.3 / 55 6.0 / 41
Standard Max Stac 1" 1 1
Outdoor Fan FLA ea. 1.4 0.8 0.6
Total Unit Amps 39.6 18.1 15.5
Min. Circuit Ampacity¹ 43.2 19.7 17
Max. Overcurrent Protecon (amps)² 50 25 20
Entrance Power Supply Locang
Dimple
Locang
Dimple
Locang
Dimple
Entrance Control Voltage
Operating Weight (lbs) 975 975 975
Ship Weight (lbs) 1000 1000 1000
¹ Wire size should be determined in accordance with Naonal Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Note: Always check the S&R plate for electrical data on the unit being installed.

Product SPecificationS Product SPecificationS
SS-CPC90-150 www.goodmanmfg.com 5
Product SPecificationS — 10 tonS
CPC120
***3B***A*
CPC120
***4B***A*
CPC120
***7B***A*
Cooling Capacity
Total BTU/h 118,000 118,000 118,000
Sensible BTU/h 87,300 87,300 87,300
EER / IEER 11.5 / 11.5 11.5 / 11.5 11.5 / 11.5
Decibels 83.0 83.0 83.0
ARI Reference #s 5104772 5104772 5104772
Evaporator Motor / Coil
Motor Type Belt Drive Belt Drive Belt Drive
Indoor Nominal CFM 3,500 3,500 3,500
Indoor motor FLA (Cooling) 7.8 3.9 2.7
Horsepower - RPM 2.0/1725 2.0/1725 2.0/1725
Piston Size (Cooling) 0.086 0.086 0.086
Filter Size (Qty) (4) 16” x 24” x 2” (4) 16” x 24” x 2” (4) 16” x 24” x 2”
Drain Size (NPT) ¾” ¾” ¾”
R-410A Refrigerant Charge Cir #1 & #2 220 oz. 220 oz. 220 oz.
Evaporator Coil Face Area (²) 10.2 10.2 10.2
Rows Deep / Fins per Inch 4 / 14 4 / 14 4 / 14
Belt Drive Evap Fan Data
# of Wheels (D x W) (1) 15” x 15” (1) 15” x 15” (1) 15” x 15”
Motor Sheave / Blower Sheave VL40 / AK74 VL40 / AK74 VL40 / AK74
Belt AX51 AX51 AX51
Condenser Fan / Coil
Quanty of Condenser Fan Motors 222
Horsepower - RPM ⅓ - 1,075 ⅓ - 1,075 ⅓ - 1,075
Fan Diameter / # Fan Blades 22 / 3 22 / 3 22 / 3
Outdoor Nominal CFM 8,200 8,200 8,200
Face Area (²) 32.4 32.4 32.4
Rows Deep - Fins per Inch 2/2 rows - 22 fpi 2/2 rows - 22 fpi 2/2 rows - 22 fpi
Compressor
Quanty / Type 2 / Scroll 2 / Scroll 2 / Scroll
Stage 1 1 1
Electrical Data
Voltage/Phase/ Frequency 208-230/3/60 460/3/60 575/3/60
Quanty of Compressors 222
Compressor RLA / LRA ea. 16/110.0 7.8/52.0 5.7/38.9
Standard Max Stac 2.0” 2.0” 2.0”
Outdoor Fan RLA ea. 2.40 1.20 0.89
Total Unit Amps 45 22 16
Min. Circuit Ampacity¹ 49 24 17
Max. Overcurrent Protecon (amps)² 60.0 30 20
Entrance Power Supply Locang
Dimple
Locang
Dimple
Locang
Dimple
Entrance Control Voltage
Operating Weight (lbs) 1135 1135 1135
Ship Weight (lbs) 1175 1175 1175
¹ Wire size should be determined in accordance with Naonal Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Note: Always check the S&R plate for electrical data on the unit being installed.

Product SPecificationS Product SPecificationS
6 www.goodmanmfg.com SS-CPC90-150
Product SPecificationS — 12½ tonS
CPC150
***3B***A*
CPC150
***4B***A*
CPC150
***7B***A*
Cooling Capacity
Total, BTU/h 146,000 146,000 146,000
Sensible BTU/h 102,200 102,200 102,200
EER / iEER 11.0 / 11.2 11.0 / 11.2 11.0 / 11.2
Decibels 83 83 83
ARI Reference #s 5104773 5104773 5104773
Evaporator Motor / Coil
Motor Type Belt Drive Belt Drive Belt Drive
Indoor Nominal CFM 4,200 4,200 4,200
Indoor Motor FLA (Cooling) 9.4 4.7 4.2
Horsepower - RPM 3.0 - 1,725 3.0 - 1,725 3.0 - 1,725
Piston Size (Cooling) 0.096 0.096 0.096
Filter Size (4) 20" x 25" x 2" (4) 20" x 25" x 2" (4) 20" x 25" x 2"
Drain Size (NPT) ¾" ¾" ¾"
R-410A Refrigerant Charge Cir #1 & #2 285 oz. 285 oz. 285 oz.
Evaporator Coil Face Area (2) 14.7 14.7 14.7
Rows Deep / Fins per Inch 4 / 15 4 / 15 4 / 15
Condenser Fan / Coil
Quanty of condenser Fan Motors 222
Horsepower - RPM ⅓ - 1,075 ⅓ - 1,075 ⅓ - 1,075
Fan Diameter / # Fan Blades 22/3 22/3 22/3
Outdoor Nominal CFM 8,400 8,400 8,400
Face Area (2) 35.3 35.3 35.3
Rows Deep - Fins per Inch 2/3 rows - 15 fpi 2/3 rows - 15 fpi 2/3 rows - 15 fpi
Belt Drive Evap Fan Data
# of Wheels (D x W) (1) 15" x 15" (1) 15" x 15" (1) 15" x 15"
Motor Sheave / Blower Sheave VL40 / AK66 VL40 / AK66 VL40 / AK66
Belt AX49 AX49 AX49
Compressor
Quanty / Type 2 / Scroll 2 / Scroll 2 / Scroll
Stage Single Single Single
Compressor RLA / LRA ea. 22.4 / 149 10.6 / 75 7.7 / 54
Electrical Data / Static
Voltage / Phase / Frequency 208-230/3/60 460/3/60 575/3/60
Outdoor Fan FLA ea. 2.4 1.2 0.9
Total Unit Amps 59 28 21.4
Min. Circuit Ampacity165 31 23
Max. Overcurrent Protecon (amps)280 40 30
Entrance Power Supply Locang
Dimple
Locang
Dimple
Locang
Dimple
Entrance Control Voltage
Operating Weight (lbs) 1275 1275 1275
Ship Weight (lbs) 1300 1300 1300
¹ Wire size should be determined in accordance with Naonal Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Note: Always check the S&R plate for electrical data on the unit being installed.

pRoduCt spECifiCations pRoduCt spECifiCations
SS-CPC90-150 www.goodmanmfg.com 7
aiRflow data — 7½ tons

ESP


0 1 2 3 4 5
  BHP   BHP   BHP   BHP   BHP   BHP
0.1 3617 704 1.07 3293 653 0.84
0.3 3541 749 1.15 3179 704 0.88 2757 656 0.66
0.5 3447 798 1.23 3049 754 0.94 2606 710 0.71
0.7 3400 848 1.33 2950 798 1.01 2474 754 0.75
0.9 3303 890 1.41 2871 848 1.11 2408 804 0.82
1.1 2838 897 1.23

ESP


0 1 2 3 4 5
  BHP   BHP   BHP   BHP   BHP   BHP
0.9
DO NOT
OPERATE
3401 909 1.51
1.1 3428 965 1.71 2943 915 1.3
1.3 3471 1015 1.9 3012 971 1.5 2423 920 1.12
1.5 3722 1063 2.25 3041 1023 1.67 2503 976 1.31
1.7 3359 1075 2.04 2540 1031 1.5
1.9 3381 1119 2.22 2890 1080 1.78
2.1 3089 1129 2.04

ESP


0 1 2 3 4 5
  BHP   BHP   BHP   BHP   BHP   BHP
0.1 3625 701 1.08 3309 660 0.86
0.3 3815 797 1.44 3468 747 1.11 3177 703 0.88 2796 663 0.68
0.5 3780 841 1.52 3405 803 1.23 3053 753 0.94 2608 709 0.68 2225 665 0.53
0.7 3687 885 1.6 3327 847 1.29 2968 805 1.02 2423 758 0.73
0.9 3236 891 1.39 2850 852 1.1 2352 807 0.8
1.1 2713 896 1.17

ESP


0 1 2 3 4 5
  BHP   BHP   BHP   BHP   BHP   BHP
0.9
DO NOT
OPERATE
3447 902 1.54
1.1 3398 956 1.65 3006 908 1.31
1.3 3486 1008 1.87 2960 962 1.44
1.5 3514 1057 2.07 2949 1019 1.62
1.7 3388 1103 2.18 3036 1069 1.84
1.9 2959 1114 2.0
2.1 2527 1124 1.86
Notes :
Assume dry coil with lter in place; CFM correcon for wet coil = 3%
Any adjustment made to the blower should not cause the motor to draw more than the motor rated RLA. Applicaons that exceed the above could require a
larger motor. Minimum rated SCFM is 350 per ton.

pRoduCt spECifiCations pRoduCt spECifiCations
8 www.goodmanmfg.com SS-CPC90-150
aiRflow data — 8½ tons

ESP


0 1 2 3 4 5
  BHP   BHP   BHP   BHP   BHP   BHP
0.1 3467 701 1.04 3143 650 0.81
0.3 3391 746 1.12 3029 701 0.85 2607 653 0.63
0.5 3297 795 1.20 2899 751 0.91 2456 707 0.68
0.7 3250 845 1.30 2800 795 0.98
0.9 3153 887 1.38 2721 845 1.08
1.1 2688 894 1.20

ESP


0 1 2 3 4 5
  BHP   BHP   BHP   BHP   BHP   BHP
0.9 3251 906 1.48
1.1 3278 962 1.68 2793 912 1.27
1.3 3321 1012 1.87 2862 968 1.47
1.5 3572 1060 2.22 2891 1020 1.64
1.7 3209 1072 2.01
1.9 3231 1116 2.19 2740 1077 1.75
2.1 3256 1156 2.31 2939 1126 2.01

ESP


0 1 2 3 4 5
  BHP   BHP   BHP   BHP   BHP   BHP
0.1 3475 698 1.05 3159 657 0.83
0.3 3665 794 1.41 3318 744 1.08 3027 700 0.85 2646 660 0.65
0.5 3630 838 1.49 3255 800 1.2 2903 750 0.91 2458 706 0.65
0.7 3537 882 1.57 3177 844 1.26 2818 802 0.99
0.9 3086 888 1.36 2700 849 1.07
1.1 2563 893 1.14

ESP


0 1 2 3 4 5
  BHP   BHP   BHP   BHP   BHP   BHP
0.9 3297 899 1.51
1.1 3248 953 1.62 2856 905 1.28
1.3 3336 1005 1.84 2810 959 1.41
1.5 3364 1054 2.04 2799 1016 1.59
1.7 3238 1100 2.15 2886 1066 1.81
1.9 3188 1146 2.23 2809 1111 1.97
Notes :
Assume dry coil with lter in place; CFM correcon for wet coil = 3%
Any adjustment made to the blower should not cause the motor to draw more than the motor rated RLA. Applicaons that exceed the above could require a
larger motor. Minimum rated SCFM is 350 per ton.

pRoduCt spECifiCations pRoduCt spECifiCations
SS-CPC90-150 www.goodmanmfg.com 9
aiRflow data — 10 tons

ESP


0 1 2 3 4 5
  BHP   BHP   BHP   BHP   BHP   BHP
0.2 4632 781 1.76 4203 742 1.41 3927 691 1.17 3510 658 0.9
0.4 4488 825 1.85 4183 783 1.54 3733 748 1.23 3512 693 1
0.6 4442 880 2.02 4066 830 1.63 3717 786 1.31
0.8 4001 885 1.77 3622 835 1.41
1 3603 890 1.55
1.2

ESP


0 1 2 3 4 5
  BHP   BHP   BHP   BHP   BHP   BHP
0.8 4435 940 2.22 4078 886 1.82
1 4462 997 2.47 4103 945 2.05 3539 892 1.52
1.2 4513 1054 2.75 4127 1003 2.26 3568 950 1.71
1.4 4126 1064 2.52 3597 1008 1.92
1.6 4438 1116 2.97 3759 1069 2.25
1.8 3956 1124 2.55
2 4050 1179 3.05 3473 1132 2.32

ESP


0 1 2 3 4 5
  BHP   BHP   BHP   BHP   BHP   BHP
0.2 4562 736 1.58 4253 691 1.29 3893 642 1
0.4 4497 780 1.7 4200 736 1.41 3735 691 1.06 3322 648 0.83
0.6 4467 824 1.81 4221 784 1.55 3689 741 1.18
0.8 4564 873 2.06 4170 830 1.68 3677 785 1.29
1 4129 875 1.81 3498 835 1.34
1.2 3558 879 1.49

ESP


0 1 2 3 4 5
  BHP   BHP   BHP   BHP   BHP   BHP
0.8
DO NOT
OPERATE
4602 884 2.13
1 4749 940 2.44 4180 885 1.89
1.2 4251 945 2.12 3642 896 1.58
1.4 4443 1001 2.5 3744 951 1.8
1.6 4587 1056 2.82 3971 1006 2.17
1.8 4760 1105 3.23 4071 1061 2.43 3342 1012 1.86
2 4364 1114 2.91 3579 1067 2.05
Notes :
Assume dry coil with lter in place; CFM correcon for wet coil = 3%
Any adjustment made to the blower should not cause the motor to draw more than the motor rated RLA. Applicaons that exceed the above could require a
larger motor. Minimum rated SCFM is 350 per ton.

pRoduCt spECifiCations pRoduCt spECifiCations
10 www.goodmanmfg.com SS-CPC90-150
aiRflow data — 12½ tons

ESP
"

0 1 2 3 4 5
 BHP  BHP  BHP  BHP  BHP  BHP
0.2 5378 2.35 4967 1.92 4710 1.59 4512 1.33
0.4 5514 2.92 5349 2.56 4750 1.97 4583 1.71 4319 1.40 4030 1.13
0.6 5204 2.69 4919 2.27 4488 1.81 4258 1.54
0.8 4830 2.42 4649 2.09 4019 1.55
1.0 4497 2.19 4264 1.86

ESP
"

0 1 2 3 4 5
 BHP  BHP  BHP  BHP  BHP  BHP
0.8 5978 3.87 5691 3.38 5324 2.81
1.0 5947 4.16 5656 3.58 5376 3.12 4933 2.52
1.2 5708 3.93 5459 3.40 4950 2.79 4441 2.18
1.4 5776 4.64 5510 4.07 5245 3.48 4844 2.88 4525 2.45
1.6 5465 4.30 5199 3.74 4894 3.17 4404 2.54
1.8 5145 3.97 4871 3.41 4495 2.83
2.0 4805 3.63 4565 3.13 4142 2.55
2.2 4429 3.27 4233 2.85

ESP
"

0 1 2 3 4 5
 BHP  BHP  BHP  BHP  BHP  BHP
0.2 5570 2.27 4935 1.70 4584 1.36
0.4 5871 3.20 5639 2.77 5307 2.31 4902 1.88 4637 1.55 4178 1.19
0.6 5610 3.00 5358 2.57 5051 2.15 4603 1.72 4341 1.41
0.8 5391 2.83 5010 2.33 4799 2.00 4393 1.61
1.0 5078 2.59 4676 2.11 4448 1.79
1.2 4521 2.20 4226 1.83

ESP
"

0 1 2 3 4 5
 BHP  BHP  BHP  BHP  BHP  BHP
0.8 5858 3.51 5538 2.97
1.0 5894 3.85 5502 3.20 5282 2.78
1.2 5780 4.04 5570 3.55 5110 2.88 4869 2.47
1.4 5900 4.49 5501 3.77 5312 3.33 4793 2.64 4598 2.28
1.6 5860 4.76 5514 4.08 5257 3.54 4945 3.01 4382 2.34
1.8 5615 4.49 5315 3.88 5020 3.32 4504 2.66
2.0 5529 4.40 4906 3.49 4601 2.96
2.2 4938 3.78 4541 3.15 4222 2.65

• Assume dry coil with lter in place; CFM correcon for wet coil = 3%
• Any adjustment made to the blower should not cause the motor to draw more than the motor rated RLA. Applicaon
• that exceed the above could require a larger motor. Minimum rated SCFM is 350 per ton.
