Goodmans 347531 User manual

Classic DAB+ Digital
Radio with Bluetooth
USER MANUAL
MODEL: 347531
MODE SCAN MENU INFO PRESET ALARM SNOOZE1 2STANDBY
- VOLUME + - TUNE +
SELECT

2
1 Welcome
2 Your Classic DAB Radio with Bluetooth
2.1 In the box 4
2.2 Front 5
2.3 Rear view 6
3 Quick Setup
3.2 Standby & Auto Standby 7
3.3 Adjusting the Volume 7
3.4 Switching Modes 7
3.5 Pairing the Classic DAB Radio using Bluetooth 7
4 Features
4.2 Using DAB for the First Time 8
4.3 Changing Stations (DAB) 9
4.4 Full Scan (DAB) 9
4.5 Manual Tuning (DAB) 9
4.6 Prune stations (DAB) 10
4.7 Storing a Station Preset (DAB) 10
4.8 Recalling a Preset (DAB) 10
4.9 DAB Display Information 11
4.10 DRC (Dynamic Range Control) 12
4.11 FM Radio 12
4.12 Tuning to a Station (FM) 12
4.13 Scan Setting (FM) 12
4.14 Audio Mode (FM) 13
4.15 Storing a Station Preset (FM) 13

3
4.16 Recalling a Preset (FM) 13
4.17 FM Display Modes 14
4.18 Connecting a Bluetooth Device 14
4.19 Connect an external audio source (Line in) 15
4.20 Setting the alarms 16
4.21 Stop the Alarm 17
4.22 Snooze 17
4.23 Turn off the Alarm 17
4.24 Sleep timer 17
4.25 Display backlight timeout 18
4.26 Display Language 18
4.27 Software Version 18
4.28 Factory Reset 19
5 Troubleshooting
6 Technical Specication
7 Customer Support

4
1 Welcome
Thank you for choosing this Goodmans product. We’ve been making
electronics for the British people 90 years. Each of our projects has been
carefully designed to be great at what it does and this one is no exception. We
hope you enjoy your new Classic DAB Radio with Bluetooth.
2 Your Classic DAB Radio with Bluetooth
2.1 In the box
Carefully remove your Classic DAB Radio with Bluetooth from the packaging.
Inside the box you will nd:
• Classic DAB+ Radio with Bluetooth
• Mains power adapter
• Quick Start Guide
• Guarantee Booklet
If any of these items are missing, contact customer support at
[email protected]

5
2.2 Front
VOLUME control
Rotate the VOLUME control to
adjust the volume.
STANDBY button
Press to power on or enter
STANDBY mode.
MODE button
Press to switch between DAB, FM,
Bluetooth and Line ln mode.
SCAN button
Press to scan DAB and FM
stations.
MENU button
Press and hold to enter MENU
options.
INFO button
Press to view station information.
PRESET button
Press and hold to save a station as
a preset, or press to recall a saved
preset station.
PRESET 1 button
Press and hold to store a favourite
station (DAB and FM) to preset 1;
Press to recall preset 1 (DAB and
FM)
PRESET 2 button
Press and hold to store a favourite
station (DAB and FM) to preset 2;
Press to recall preset 2 (DAB and
FM)
ALARM button
Press to set up the ALARM 1 and
2 functions.
SNOOZE button
Press to SNOOZE the alarm for
approximately 9 minutes when the
alarm rings.
Press to set a SLEEP time and
switch your radio to STANDBY
mode.
TUNE/SELECT control
Rotate to scroll through the
available stations or MENU options.
Press to SELECT a displayed radio
station or MENU option.
A
B
C
D
E
F
G
H
I
J
K
L
MODE SCAN MENU INFO PRESET ALARM SNOOZE1 2STANDBY
- VOLUME + - TUNE +
SELECT
A
B
C
D
E
F
G
H
I
J
K
L

6
2.3 Rear view
Telescopic aerial
DC-In socket
Used to connect the Classic DAB Radio to the mains power supply.
Line ln socket
Used to connect an external audio source to the Classic DAB Radio.
3 Quick Setup
3.1 Power On and Autoscan
1. Connect the mains power lead into the DC 7.5V IN socket on the back of
the radio.
2. Connect the power plug to the mains power socket and switch the power
on.
3. Press the STANDBY button on the Classic DAB Radio.
The Classic DAB Radio will automatically begin to scan for DAB stations. In the
screen shown g. 2 (page 8) a bar graph indicates the progress of the search.
When the scan is complete, the Classic DAB Radio will select the rst available
station – stations are listed in alphanumeric order.
M
N
O
M
N
O

7
The station list is retained in the product memory so the next time you switch
the Classic DAB Radio on, the station search does not take place.
If there are no stations found, check that the telescopic antenna is fully
extended and that adequate DAB coverage exists in your area.
It is possible to perform a manual scan for stations. See page 9.
3.2 Standby & Auto Standby
1. Press the STANDBY button to power on the product/wake from standby
mode.
2. Press the STANDBY button again to enter Standby mode.
3.3 Adjusting the Volume
1. Rotate the VOLUME control clockwise or anti-clockwise to increase or
decrease the volume output.
3.4 Switching Modes
1. Press the MODE button on the product to switch to the available modes:
DAB, FM, BLUETOOTH & LINE IN. Check the display, which will conrm the
mode.
3.5 Pairing the Classic DAB Radio using Bluetooth
1. Repeatedly press the MODE button until you are in BLUETOOTH mode.
Your radio will begin searching for Bluetooth devices and ‘Searching…’ is
displayed.
2. Enable Bluetooth on your audio device and search for available Bluetooth
connections. Select GOODMANS DAB from the list. If you are asked for a
passcode, enter 0000.
3. ‘Connected’ will be displayed on your Classic DAB Radio once it has been
paired successfully. You can now begin playback from the audio device and
the output will playback through the Classic DAB Radio speakers.
Once you have paired the radio with a device, the radio will remember this
device and will pair with it automatically when activated and in range.
You do not need to re-connect any previously connected devices.
The radio will attempt to automatically connect to the last device it was paired
with, each time you go to BLUETOOTH mode.

8
To pair the Classic DAB Radio with a new device, turn OFF the Bluetooth
function on your last connected audio device. Use your new audio device to
search for Bluetooth devices as described above.
4 Features
4.1 DAB Radio
Please make sure that the aerial is fully extended before you attempt to tune
to a DAB station. This will ensure that the maximum signal strength is available
when the radio begins to scan. Extending the aerial also ensures the best
possible sound quality.
1. To nd the optimum position, select the display
signal strength indicator by cycling through the
display modes using the INFO button.
2. Once the indicator is displayed, move the aerial
and observe the signal level as shown by the bar
graph. When you are happy with the positioning,
press the SCAN button to perform an auto-tune
and capture all of the available stations.
4.2 Using DAB for the First Time
1. After switching to DAB mode for the rst time a full scan of DAB stations is
performed automatically.
During full scan mode, a bar graph will be displayed,
showing the progress of the scan and the number of
radio stations that have been found so far. When the
scan is complete, the Classic DAB Radio will select
the rst available station – stations are listed in
alphanumeric order.
Note: The station name will be shown on the top line of the display. Information
about the DAB radio station will be displayed on the second line of the display.
Absolute 80s
Fig 1.
Fig 2.
Scanning 14
...

9
4.3 Changing Stations (DAB)
1. Use the right hand rotary TUNE/SELECT control to scroll through the
available stations.
2. When the station that you would like to listen to is displayed, press the
TUNE/SELECT control to select it. There will be a short delay whilst your
radio tunes to your selected station.
Note: If no stations were found, or no DAB stations can be received currently
[No DAB station] will be displayed. In this case you may need to perform
another station scan.
4.4 Full Scan (DAB)
Additional radio stations and services regularly become available, so it’s a good
idea to carry out a manual scan every now and then. If you have moved your
radio to another location, it’s also a good idea to carry out a manual scan.
1. Press the SCAN button.
2. A bar graph showing the progress of the scan and the number of radio
stations found so far, as well as ‘Scanning…’ will be displayed.
4.5 Manual Tuning (DAB)
As well as an auto tune SCAN function, you can manually tune the Radio.
1. Press and hold the MENU button in DAB mode to enter the menu options.
Use the TUNE/SELECT rotary to display <Manual tune> Press the TUNE/
SELECT rotary to Select.
2. Use the TUNE/SELECT rotary to cycle through the DAB ensembles/
multiplexes, which are numbered from 5A to 13F.
3. Press the TUNE/SELECT rotary to view the ensemble/multiplex details.
Press the TUNE/SELECT rotary, then press the MENU button until you
return to the default display.
4. Any stations found during the manual tune operation will be added to your
station list.

10
4.6 Prune stations (DAB)
You can remove DAB stations in the station list that cannot be received in your
area. These are listed with a ‘?’ prex.
1. Press and hold the MENU button in DAB mode to enter the menu options.
Use the TUNE/SELECT rotary to display <Prune> Press the TUNE/SELECT
rotary to Select.
2. Use the TUNE/SELECT rotary to scroll to Yes. Press the TUNE/SELECT
rotary to prune the station list.
4.7 Storing a Station Preset (DAB)
Your radio can store up to 10 DAB stations in its preset memories for quick
access to your favourite stations. When you store DAB radio station presets,
these do not overwrite your FM station presets
Note: When you store a radio station to Preset location 1 or 2, this will also be
saved under the number ‘1’ or ‘2’ buttons on the front of your radio.
1. Tune the radio to the DAB station that you would like to preset.
2. Press and hold the PRESET button until Preset Store <1 (Empty)> is
displayed.
3. Turn the TUNE/SELECT rotary to move to the preset location that you
would like to store the radio station to (1-10).
4. Press in the TUNE/SELECT rotary to conrm.
5. ‘Preset X stored’ where ‘X’ is the number of the preset (1-10) will be
displayed.
Note: If there is already an existing DAB station under a preset, if will be
overwritten when you store the new station.
4.8 Recalling a Preset (DAB)
Note: To quickly access the radio stations stored under Preset locations 1 and
2, just press the 1 or 2 button on the front of your radio.
1. Press the PRESET button. <Preset Recall <1:> is displayed together with
the name or frequency of the station stored there, or (Empty) if no station
has been stored there.
2. Turn the TUNE/SELECT rotary to move to the Preset location and station
that you would like to listen to (1-10).

11
3. Press the TUNE/SELECT rotary to Select. The radio will tune to that station.
4.9 DAB Display Information
Every time you press the INFO button the display will
cycle through the following information options.
• DLS (Dynamic label segment): Dynamic label
segment is a scrolling message that the
broadcaster may include with their transmissions.
This message usually includes information, such
as program detail etc.
• Signal strength: This option will display a
bar indicating the signal strength. An empty
indicates the minimum signal strength for
acceptable listening. The stronger the signal, the
further to the right the row of solid rectangles will
be.
• Program type: Such as ‘Rock’, ‘Pop’, ‘Talk’ or
‘News’.
• Ensemble/Multiplex (group name): Displays the broadcasting area and
collection of radio stations on this frequency e.g.: BBC National DAB, Digital
1 Network.
• Channel frequency: Displays the current DAB multiplex in use, e.g.: 12B
225.648 MHz
• Signal error: This is displayed as a number between 0-99. It would not be
possible to satisfactorily listen to a radio station with a signal error rate of 30
or more.
• Signal information: Displays the data rate at which the signal is being
transmitted as well as the current mode.
• Time & date: The time & date is supplied automatically by the broadcaster.
Fig 3.
Signal Strength
DLS (scrolling text)
Programme Type
Ensemble Name
Channel Frequency
Signal Error
Mode
Time
Date

12
4.10 DRC (Dynamic Range Control)
This causes the radio to change the dynamic range of the audio signal.
Changing the dynamic range can change the ‘loudness’ and/or ‘quality of
sound’ of the programme that you are listening to so that it will be more suited
to your listening environment.
1. Press and hold the MENU button in DAB mode to enter the menu options.
Use the TUNE/SELECT rotary to display <DRC> Press the TUNE/SELECT
rotary to Select.
2. Use the TUNE/SELECT rotary to choose between DRC off, DRC Low and
DRC High.
3. Press the TUNE/SELECT rotary to Select and save the setting.
4.11 FM Radio
Press the MODE button until you are in FM mode, check the display, which will
conrm the mode.
4.12 Tuning to a Station (FM)
Please make sure that the aerial is fully extended before you attempt to tune
to an FM station. This will ensure that the maximum signal strength is available
when the radio begins to scan. Extending the aerial also ensures the best
possible sound quality.
1. You can use the TUNE/SELECT rotary to scroll up or down the FM
frequency band.
2. Alternatively you can press the SCAN button to scan up the frequency band
or press and hold the SCAN button to scan down the frequency band.
Once a station has been found, the scan will stop automatically.
3. Use the TUNE/SELECT rotary to ne tune each station in 0.05 MHz
increments.
4.13 Scan Setting (FM)
When performing a scan you can set the sensitivity level of the stations to be
found. E.g.: strong signals only or all stations.
1. In FM mode, press and hold the MENU button, <Scan setting> will be
displayed. Press the TUNE/SELECT rotary to select.

13
2. Use the TUNE/SELECT rotary to display <All stations> (which will detect
any station, even with a weak signal) or <Strong stations only> (which will
only detect stations with a good signal strength). Press the TUNE/SELECT
rotary to select.
4.14 Audio Mode (FM)
Your radio will automatically switch between Stereo and Mono, depending on
the quality of the signal being received, but you can override this function and
manually switch between Stereo and Mono.
1. In FM mode, press and hold the MENU button. Use the TUNE/SELECT
rotary to display <Audio Setting>. Press the TUNE/SELECT rotary to Select.
2. Use the TUNE/SELECT rotary to display <Stereo allowed> or <Forced
mono> as required. Press the TUNE/SELECT rotary to Select.
4.15 Storing a Station Preset (FM)
Your radio can store up to 10 FM stations in its preset memories for quick
access to your favourite stations. When you store FM radio station presets,
these do not overwrite your DAB station presets
Note: When you store a radio station to Preset location 1 or 2, this will also be
saved under the number ‘1’ or ‘2’ buttons on the front of your radio.
1. Tune the radio to the FM station that you would like to preset.
2. Press and hold the PRESET button until Preset Store <1 (Empty)> is
displayed.
3. Turn the TUNE/SELECT rotary to move to the preset location that you
would like to store the radio station to (1-10).
4. Press in the TUNE/SELECT rotary to conrm.
5. ‘Preset X stored’ where ‘X’ is the number of the preset (1-10) will be
displayed.
Note: If there is already an existing FM station under a preset, if will be
overwritten when you store the new station.
4.16 Recalling a Preset (FM)
Note: To quickly access the radio stations stored under Preset locations 1 and
2, just press the 1 or 2 button on the front of your radio.

14
1. Press the PRESET button. <Preset Recall <1:> is displayed together with
the name or frequency of the station stored there, or (Empty) if no station
has been stored there.
2. Turn the TUNE/SELECT rotary to move to the Preset location and station
that you would like to listen to (1-10).
3. Press the TUNE/SELECT rotary to Select. The radio will tune to that station.
4.17 FM Display Modes
Every time you press the INFO button the display will cycle through the following
information options.
• Radio text: Broadcasters can include a scrolling text that displays
information about the current program. If radio text is not available then the
display will show ‘[No RadioText].
• Program type: Such as ‘Rock’, ‘Pop’, ‘Talk’ or ‘News’.
• Program name: Displays the name or frequency of the current station.
• Audio mode: Stereo or Mono.
• Time & date: The time & date is supplied automatically by the broadcaster.
4.18 Connecting a Bluetooth Device
When using a Bluetooth connection, you can listen to audio wirelessly from a
secondary Bluetooth audio device (For example an MP3 player/iPhone/Android/
other phone/computer) within 10 metres or less (33 feet or less) of the Classic
DAB Radio.
1. Press the MODE button until you are in BLUETOOTH mode. Your radio will
begin searching for Bluetooth devices and ‘Searching…’ is displayed.
2. Enable Bluetooth on your audio device and search for available Bluetooth
connections. Select GOODMANS DAB from the list. If you are asked for a
passcode, enter 0000.
3. Connected will be displayed on your Classic DAB Radio once it has been
paired successfully. You can now begin playback from the audio device and
the output will playback through the Classic DAB Radio speakers.
Once you have paired the radio with a device, the radio will remember this
device and will pair with it automatically when activated and in range.
You do not need to re-connect any previously connected devices.

15
The radio will attempt to automatically connect to the last device it was paired
with, each time you go to BLUETOOTH mode.
To pair the Classic DAB Radio with a new device, turn OFF the Bluetooth
function on your last connected audio device. Use your new audio device to
search for Bluetooth devices as described above.
Note: The volume output is of the Classic DAB Radio will be affected by the
volume level on the connected secondary audio source e.g.: MP3 Player, Phone
or laptop, so make sure that the volume level is set to about 70-80% (not too
loud to avoid distortion).
4. Once connected you can use the controls on the secondary audiodevice to
begin playback, skip tracks etc.
4.19 Connect an external audio source (Line in)
It is possible to connect an external audio source (such as an MP3 Player) using
a 3.5mm audio cable (not supplied).
1. Connect one end of the cable to the headphone or auxiliary out socket on
the secondary device. Connect the other end to the LINE IN socket on the
rear of the Classic DAB Radio.
2. Press the MODE button until you are in the LINE IN mode.
3. Adjust the volume on your Classic DAB Radio as well as on your secondary
device.
The volume output of the Classic DAB Radio is affected by the volume level on
the secondary audio source e.g.: MP3 player, so make sure that is set to about
70-80% (not too loud to avoid distortion).

16
4.20 Setting the alarms
You can set two completely separate alarm times (ALARM 1 and ALARM 2) and
activate either or both of them to wake you with a buzzer or the radio. You can
also pre-set the station and volume settings that the alarms will wake you with.
Note: You must complete all settings before leaving the menu or your changes
will not be saved.
1. With the radio switched on (Alarm settings cannot be set in Standby mode).
Press the ALARM button.
2. Alarm 1 Setup is displayed. To set Alarm 2 press the ALARM button again.
Press the TUNE/SELECT rotary control to Select.
3. Alarm 1 Wizard On time is displayed and the hour digits for the alarm will
ash. Use the TUNE/SELECT rotary to scroll to the hour for the alarm and
press the TUNE/SELECT rotary to Select.
4. The minutes for the alarm will now ash. Use the TUNE/SELECT rotary to
scroll to the minutes for the alarm and press the TUNE/SELECT rotary to
Select.
5. The duration for the alarm will now ash. Use the TUNE/SELECT rotary to
scroll for the duration for the alarm and press the TUNE/SELECT rotary
to Select. You can choose from 15, 30, 45, 60, 90 and 120 minutes. The
source for the alarm will now ash.
6. Use the TUNE/SELECT rotary to scroll to the sound source for the alarm.
You can choose from Buzzer, DAB or FM radio. Press the TUNE/SELECT
rotary to Select.
Note: If you select DAB or FM radio for the alarm source ‘Last listened’ will
ash in the display. Press the TUNE/SELECT rotary and the last listened to radio
station in DAB or FM, as appropriate, will be used for your alarm.
7. Daily will ash in the display. Use the TUNE/SELECT rotary to scroll to the
frequency for your alarm. You can choose from Daily, Once, Weekends or
Weekends. Press the TUNE/SELECT rotary to Select.
Note: If you select ‘Once’ you will be prompted to set the date for your alarm.
8. Alarm 1 Wizard will be displayed and a row of rectangles. Please use the
TUNE/SELECT rotary to indicate the volume level for your alarm. You will
not be able to set this for less than 4 rectangles.
9. Alarm 1 Wizard Alarm Off is displayed and ‘Off’ will be ashing. Use the
TUNE/SELECT rotary to display Alarm On or Off and press the TUNE/
SELECT rotary to select. Alarm Saved is displayed.

17
10. A bell icon will appear in the top right of the display to conrm than an alarm
has been set.
4.21 Stop the Alarm
1. When the alarm sounds, press the TUNE/SELECT control to turn the alarm
off. Alternatively, you can press the SNOOZE button, see Snooze function
below.
4.22 Snooze
1. When the Alarm sounds you can press the SNOOZE button to snooze for
9 minutes. Snooze will be displayed, follow by the snooze time countdown
from 9 minutes until the alarm sounds again.
4.23 Turn off the Alarm
1. In standby mode, repeatedly press the ALARM button to turn Alarm 1 and
2 On or Off.
4.24 Sleep timer
You can set your Classic DAB Radio to automatically go to Standby mode using
the sleep timer. You can choose from Sleep off, 15, 30, 45, 60 and 90 minutes.
1. Press the SNOOZE button. Use the TUNE/SELECT rotary to scroll through
the available options.
2. Stop when the sleep time you would like is displayed and press the TUNE/
SELECT rotary to Select.
3. In the top right of the radio display the number of minutes until your radio
will automatically go to Standby mode will be displayed e.g.: S15.
Note: To cancel the Sleep timer, follow the steps above and select ‘Sleep off’ in
Step 2.

18
4.25 Display backlight timeout
You can adjust the backlight timeout. Options of permanently On, 10, 20, 30,
45, 60, 90, 120 and 180 seconds are available.
1. Press and hold the MENU button. Use the TUNE/SELECT rotary to display
<System> and press the TUNE/SELECT rotary to Select.
2. <Sleep> is displayed. Use the TUNE/SELECT rotary to scroll to
<Backlight>. Press the TUNE/SELECT rotary again.
3. <Timeout> is displayed. Press the TUNE/SELECT rotary again. Use the
TUNE/SELECT rotary to scroll through the available options. Stop when the
backlight timeout you would like is displayed and press the TUNE/SELECT
rotary to Select.
Note: You can now use the TUNE/SELECT rotary to scroll and Select, as
you did to set the Backlight timeout, to change the settings for the backlight
brightness for the <Dim level> (Standby) and <On level>. There are 3 options
available, High, Medium and Low.
4.26 Display Language
You can change the display language of your radio, there are 4 options
available: English, French, German and Italian.
1. Press and hold the MENU button. Use the TUNE/SELECT rotary to display
<System> and press the TUNE/SELECT rotary to Select.
2. <Sleep> is displayed. Use the TUNE/SELECT rotary to scroll to
<Language>. Press the TUNE/SELECT rotary again.
3. <English> is displayed. Use the TUNE/SELECT rotary to scroll through the
available options and press the TUNE/SELECT rotary to Select.
4.27 Software Version
1. Press and hold the MENU button. Use the TUNE/SELECT rotary to display
<System> and press the TUNE/SELECT rotary to Select.
2. <Sleep> is displayed. Use the TUNE/SELECT rotary to scroll to <SW
version>. Press the TUNE/SELECT rotary again.
3. The software version will be displayed.

19
4.28 Factory Reset
The factory reset function can ONLY be activated from DAB or FM mode.
Note: If you reset your radio all of your stored station presets will be deleted
and any connected Bluetooth devices will be unpaired.
1. Press and hold the MENU button. Use the TUNE/SELECT rotary to display
<System> and press the TUNE/SELECT rotary to Select.
2. <Sleep> is displayed. Use the TUNE/SELECT rotary to scroll to <Factory
Reset>. Press the TUNE/SELECT rotary again.
3. Factory Reset? Yes <No> is displayed. Use the TUNE/SELECT rotary to
Select Yes or No and press the TUNE/SELECT rotary to Select.
4. If you selected Yes in step 3 above, Restarting… is displayed. After a few
seconds the display will change to Welcome to Digital Radio and will then
go to Standby mode.

20
5 Troubleshooting
Problem What to do
No power Check the mains plug is connected
to the mains power socket and is
switched on. Press the STANDBY
button to wake the radio from
Standby mode.
No sound from a LINE IN input The volume level is too low. Increase
using the volume control on both the
secondary audio device and on your
radio.
The sound is distorted from a LINE IN
input
The secondary audio source volume
is too high, decrease the volume level.
Static interference/Burbling sound
when listening to the radio
This is caused by poor reception.
Adjust the aerial or if that fails try
moving the Classic DAB Radio to a
different location. Check that you do
not have other electrical equipment
too close to your radio cause
interference.
Bluetooth sound is interrupted or
distorted
The unit is too close to other electrical
devices. Re-locate the Classic DAB
Radio at least 1 metre away from
other electrical appliances to avoid
interference.
Check the distance between the
connected audio device and the
Classic DAB Radio, it should be 10
metres or less (33 feet or less).
If possible, turn off other nearby
Bluetooth devices or disable their
Bluetooth functionality.
