Goodmans 2719
STEREO 3CD MINI HI-FI SYSTEM WITH RADIO AND DOUBLE CASSETTE
INSTRUCTION MANUAL
Please read this instruction manual carefully and familiarize yourself with your new HIFI system before
using it for the first time. Please retain this manual for future reference.
LOCATION OF CONTROLS
1) TURNTABLE DUST COVER
2) LCD DISPLAY
3) FM STEREO INDICATOR
4) REMOTE SENSOR
5) STANDBY LED INDICATOR
6) POWER BUTTON
7) RANDOM BUTTON
8) MUTE BUTTON
9) REPEAT BUTTON
10) MEMORY BUTTON
11) DISC CHANGE BUTTON
12) CD SEARCH BACKWARD BUTTON
13) HEADPHONE JACK
14) CD SEARCH FORWARD BUTTON
15) FUNCTION SELECTOR
16) CASSETTE DECK 1
17) DECK 1 CONTROL KEY
18) DISC 1-2-3 BUTTON
RECORD KEY
PLAYBACK KEY
REWIND KEY
FAST FORWARD KEY
STOP/EJECT KEY
PAUSE KEY
19) TUNING KNOB
20) CD STOP BUTTON
21) CD PLAY / PAUSE BUTTON
22) VOLUME UP-DOWN BUTTON
23) CD SKIP FORWARD BUTTON
24) CD SKIP BACKWARD BUTTON
25) EXTRA BASS BUTTON
26) BAND/FM MODE SWITCH
27) CASSETTE DECK 2
28) DECK 2 CONTROL KEYS
29) CD DOOR OPEN/CLOSE BUTTON
30) CENTER SPINDALE ADAPTOR
31) 33/45 RPM SPEED SELECTOR
32) ARM PICK-UP HOLDER
33) SPEAKER TERMINALS
34) FM WIRE ANTENNA
35) AUTO STOP SWITCH
36) POWER CORD
2 English

REMOTE CONTROL
BATTERY INSTALLATION (Battery not Supplied )
INSERT BATTERIES INTO THE REMOTE CONTROL BATTERY COMPARTMENT FOLLOWING THE
POLARITY ( + - ) INDICATED. THE REMOTE CONTROL REQUIRE 2 X 1,5 “ AAA “ BATTERY FOR
OPERATION (WE RECOMMEND TO USE A GOOD BRAND ALKALINE BATTERIES )
1. POWER BUTTON
PRESS TO SWITCHING ON/STANDBY THE SYSTEM
2. DISC-CH
PRESS TO ROTATE THE DISC TRAY IN CLOCKWISE
3. MEMORY BUTTON
TO ACTIVE “MEMORY“ MODE FOR CD PROGRAMMING
4. PLAY /PAUSE BUTTON
TO START PLAYING THE DISC AND INTERRUPT THE DISC PLAY AS
DESIRED
5. SKIP SEARCH BACKWARD BUTTON
PRESS TO SKIP/SEARCH DOWN OF CD DURING PLAYBACK
6. SKIP SEARCH FORWARD BUTTON
PRESS TO SKIP/SEARCH UP OF CD DURING PLAYBACK
7. STOP BUTTON
PRESS TO STOP THE PAYBACK OF CD OR CANCEL
THE MEMORY/RANDOM FUNCTION AT CD MODE
8. VOL +/- BUTTON
TO CONTROL THE VOLUME AT CD/VCD MODE
9. MUTE
PRESS TO ACTIVE MUTE FUNCTION
CONNECTING TO POWER
BEFORE SWITCHING ON MAKE SURE THAT THE VOLTAGE OF YOUR ELECTRICITY SUPPLY IS SAME AS
THAT INDICATED ON THE RATING LABEL
FOR YOUR OWN SAFETY READ THE FOLLOWING INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO
CONNECT THIS UNIT TO THE MAINS.
MAINS (AC) OPERATION
THIS UNIT IS DESIGNED TO OPERATE ON AC240V 50Hz CURRENT ONLY. CONNECTING IT TO OTHER
POWER SOURCES MAY DAMAGE THE UNIT.
CAUTION
TO PREVENT ELECTRIC SHOCK DISCONNECT FROM THE MAINS BEFOREREMOVING COVER. NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
SAFETY PRECAUTION
DO NOT ALLOW THIS UNIT TO BE EXPOSED TO RAIN OR MOISTURE.
MAINS SUPPLY: 240V 50Hz – AC ONLY
THIS SYMBOL MEANS THAT THIS UNIT IS DOUBLE INSULATED. AN EARTH CONNECTION IS NOT
REQUIRED.
3English

POWER SUPPLY
REMOVE THE STEREO CAREFULLY FORM THE BOX, RETAIN THE PACKAGING FOR FUTURE USE.
AC POWER OPERATION
CONNECT THE PLUG TO A MAINS POWER INLET 240V AC~50Hz
IMPORTANT
SINCE MOVEMENT OF THE CD MECHANISM AND THE SENSITIVE CIRCUITY MAY CAUSE INTERFERENCE TO
THE RADIO TUNER NEARBY, SWITCH THIS UNIT OFF WHILE OPERATING OTHER RADIO DEVICES.
INSTALLATION
zUNPACK ALL PARTS AND REMOVE PROTECTIVE MATERIAL.
zDO NOT CONNECT THE UNIT TO THE MAINS BEFORE CHECKING THE MAINS VOLTAGE AND BEFORE
ALL OTHER CONNECTIONS HAVE BEEN MADE.
zDO NOT COVER ANY VENTS AND MAKE SURE THAT THERE IS A SPACE OF SEVERAL CENTIMETERS
AROUND THE UNIT FOR VENTILATION.
CONNECTION
1. CONNECT THE SPEAKER COLOUR CODED WIRES TO THE SPEAKER TERMINAL LOCATED AT THE BACK
OF THE UNIT.
2. BEFORE CONNECTING THE POWER PLUG. BE SURE THE SWITCH AT THE POWER WALL OUTLET IS IN
OFF POSITION.
3. CONNECT THE POWER CORD TO AC~240V 50Hz INTO THE WALL OUTLET.
4. SWITCH BACK ON THE POWER AT THE WALL OUTLET.
5. THE UNIT WILL GO INTO STANDBY MODE.
6. TURN ON THE POWER AND SELECT “ CD “ FUNCTION. IF THE LCD DISPLAY IS ON WITH BACKLIGHTING,
IT’S MEAN THE POWER SUPPLY IS NORMAL. NOW YOUR SYSTEM IS READY TO PLAY THE MUSIC.
LISTENING TO RADIO
OPERATION
1. SET THE FUNCTION SELECTOR TO “ RADIO” POSITION.
2. SELECT THE DESIRED RADIO FREQUENCY BAND FROM BAND SELECTOR.
3. TURN THE TUNING CONTROL, TO SET THE DESIRED RADIO STATION.
4. ADJUST VOLUME CONTROLS FOR THE DESIRED VOLUME LEVEL.
FM & FM-STEREO RECEPTION
zSET THE FM MODE SELECTOR AT “ FM ” POSITION. PROGRAMS ARE RECEIVED IN MONO MODE. IN
PARTICULAR WHEN STEREO SIGNALS ARE WEAK. IT IS PREFERABLE TO RECEIVE THE PROGRAM IN
MONO.
zSET THE FM MODE SELECTOR AT “ FM-ST ” POSITION FOR RECEIVING STEREO PROGRAMS. THE
STEREO LED INDICATOR WILL LIGHT UP TO SHOW FM STEREO PROGRAM IS RECEIVING.
HINTS FOR BEST RECEPTION
AM: THE RECEIVER HAS A BUILT-IN ANTENNA. IF THE AM RECEPTION IS WEAK, SLIGHT ROTATE OR
RE-POSITIONING THE UNIT, FOR BETTER AM RECEPTION.
FM: THE RECEIVER HAS A FM WIRE ANTENNA, HANGING AT THE REAR CABINET. THIS WIRE SHOULD BE
TOTALLY UNRAVELED AND EXTENDED FOR BEST RECEPTION.
4 English

PHONO
zREMOVE THE STYLUS PROTECTOR.
zBE SURE THAT THE TONE ARM IS BEING DETACHED FROM THE
TONE ARM REST BEFORE OPERATING, AND RE-SECURED AGAIN
AFTERWARDS.
1. PRESS THE “ PHONO ” FUNCTION SWITCH.
2. SET THE SPEED SELECTOR TO THE PROPER POSITION
DEPENDING ON THE RECORD TO BE PLAYED.
3. PLACE THE RECORD ON THE PLATTER (USE THE SPINDLE ADAPTOR IF
REQUIRED).
4. LIFT THE TONE ARM FROM THE REST AND SLOWLY MOVE IT TO THE
RECORD SIDE. THE PLATTER WILL BEGIN TO ROTATE.
5. PLACE THE TONE ARM TO THE DESIRED POSITION OF THE RECORD.
6. ADJUST THE VOLUME TO THE DESIRED LEVEL.
7. AT THE END OF RECORD, THE PLATTER WILL AUTOMATICALLY STOP
ROTATING. LIFT THE TONE ARM FROM THE RECORD AND RETURN IT TO THE REST.
8. TO STOP MANUALLY, LIFT THE TONE ARM FROM THE RECORD AND RETURN IT TO THE REST.
REMARK : AS SOME KIND OF RECORD THE AUTO-STOP AREA WAS OUT OF THE UNIT SETTING, SO IT WILL
STOP BEFORE THE LAST RACK FINISH. IN THIS CASE, SELECT THE AUTO-STOP SWITCH TO “ OFF
“ POSITION, THEN IT WILL RUN TO THE END OF THE RECORD BUT WILL NOT STOP AUTOMATICALLY (TURN
OFF THE UNIT BY POWER BUTTON OR SWITCH BACK THE AUTO-STOP SWITCH TO “ ON “ POSITION TO
STOP THE PLATTER ROTATE). THEN PUT BACK THE TONE ARM TO THE REST POSITION.
PLAYING COMPACT DISC
GETTING START
1. SELECT “CD” FUNCTION.
2. PRESS “OPEN/CLOSE” BUTTON TO OPEN THE CD DOOR.
3. PLACE A CD WITH THE PRINTED SIDE FACING UP INSIDE THE TRAY.
4. PRESS THE “ “ OR “ DISC-CH ” BUTTON TO TURNING THE CD TRAY, AND LOADING OUT THE
OTHER DISC COMPARMENT.
5. PRESS THE “OPEN/CLOSE” BUTTON TO CLOSE THE CD DOOR.
6. CD SEARCH IS PERFORMING, AND THE 1ST DEDECTED DISC WILL BE STARTED PLAYBACK
AUTOMATICALLY.
NOTE: CD SEARCHING WILL BE PERFORMED EVERY TIME WHEN SWITCHING TO CD MODE
OR CLOSING THE CD DOOR.
PLAY / PAUSE MODE
1. PRESS THE “PLAY/PAUSE” BUTTON TO START PLAYBACK, THE FIRST TRACK OF THE FIRST DISC WILL
BE PLAYED AND THE PLAY INDICATOR WILL APPEAR ON THE LCD DISPLAY.
2. OR PRESS EITHER THE “ DISC 1 ” , “ DISC 2 ” , “ DISC 3 ” BUTTON, UNIT WILL PLAY THE DISC INSIDE
THE DESIRE TRAY DIRECTLY.
3. TO INTERRUPT, PRESS THE “PLAY/PAUSE” BUTTON ONCE, AND THE DISPLAY WILL START FLASHING.
PRESS AGAIN TO RELEASE & RESUME PLAYBACK.
STOP MODE
1. IF “STOP” BUTTON IS PRESSED DURING PLAY OR PAUSE MODE, SYSTEM WILL GO TO STOP MODE.
SKIP MODE (SKIP UP /SKIP DOWN
1. DURING PLAY OR PAUSE MODE, IF “ SKIP + ” BUTTON IS PRESSED IT WILL GO TO NEXT TRACK AND
DISPLAY THE TRACK NO. AND THEN REMAIN THE PLAY OR PAUSE MODE.
2. DURING PLAY OR PAUSE MODE, IF “ SKIP - ” BUTTON IS PRESSED. IT WILL GO BACK TO THE
PREVIOUS TRACK AND REMAIN THE PLAY OR PAUSE MODE.
SEARCH MODE ( SEARCH UP SEARCH DOWN )
1. DURING PLAY MODE, IF “ SEARCH + ” BUTTON IS PRESSED & HOLD FOR FEW SECONDS, IT WILL
START SEARCHING FORWARD.
2. DURING PLAY MODE, IF “ SEARCH - ” BUTTON IS PRESSED & HOLD FOR FEW SECONDS. IT WILL STAR
SEARCHING BACKWARDS.
NOTE: UNIT WILL GO TO MUTE MODE DURING SEARCHING
5English

REPEAT PLAY
THIS FUNCTION ALLOW TO REPEAT 1 SINGLE TRACK, 1 SINGLE DISC OR ALL DISCS
PRESS THE “ REPEAT “ KEYS REPEATEDLY TO SWITCH THE FUNCTION
REP. ONE TRACK REP. 1 DISC REP. ALL DISCS REP. OFF
NOTE: SINGLE TRACK REPEAT FUNCTION IS POSSIBLE IN NORMAL OR PROGRAMMED
PLAYBACK, REPEAT ONE DISC OR ALL DISCS IS ONLY AVAILABLE IN NORMAL
PLAYBACK.
RANDOM PLAY
YOU CAN LISTEN ALL THE TACKS OF ONE SINGLE DISC IN A RANDOM ORDER BY THIS FUNCTION
1. PRESS “RANDOM” BUTTON ONCE DURING CD STOP/PLAYBACK MODE, UNIT WILL PLAY THE 1ST
AVAIALBLE DISC IN RANDOM ORDER, AND THE “ RANDOM ” SIGN APPEAR ON THE LCD DISPLAY.
2. PRESS “ STOP ” BUTTON TO CANCEL THE RANDOM MODE.
CD PROGRAMMING (BY REMOTE CONTROL)
UP TO 32 TACKS CAN BE PROGRAMMED, CAN BE PLAYED IN ANY REQUIRED ORDER FROM ONE CD OR ALL
CDs IN THE CD CHANGER.
1. SET IN CD MODE.
2. PRESS THE MEMORY BUTTON
3. PRESS THE “ ” TO SELECT THE DESIRED DISC.
4. PRESS SKIP
OR BUTTON TO SELECT THE DESIRED TRACK.
5. PRESS THE “ MEMORY “ BUTTON AGAIN TO STORE THE TRACK IN MEMORY.
6. REPEAT STEPS 3 TO 5 TO ENTER ADDITIONAL PROGRAM
7. PRESS PLAY/PAUSE BUTTON TO START PLAYBACK IN ORDER.
8. PRESS “STOP” BUTTON TO STOP PLAYBACK AND PRESS AGAIN TO CLEAR ALL PROGRAMMED
TRACKS.
TAPE DECK
GENERAL OPERATION
STOP / EJECT KEY
zPRESS TO STOP ALL DECK OPERATION. PRESS AGAIN TO OPEN THE CASSETTE DOOR.
FAST FORWARD
zPRESS TO START, FAST FORWARD WINDING THE TAPE.
FAST REWIND
zPRESS TO START, FAST REWIND WINDING THE TAPE.
PLAY
zPRESS TO START PLAYING TAPE.
PAUSE
zPRESS TO STOP TAPE OPERATION TEMPORARILY. PRESS AGAIN TO RESUME PLAY.
RECORD
zPRESS TOGETHER WITH PLAY KEY TO START TAPE RECORDING. (TAPE DECK 1 ONLY)
6 English

PLAYBACK
zSELECT “ TAPE ” FUNCTION
zPUT IN THE CASSETTE TAPE.
zPRESS PLAY KEY TO ACTIVE PLAYBACK
zADJUST THE VOLUME CONTROL TO THE DESIRED LEVEL.
zUSE PAUSE KEY WHEN YOU WANT TO STOP PLAYBACK TEMPORARILY.
zPRESS STOP / EJECT KEY WHEN FINISHED.
RECORDING
A. RECORDING FROM TAPE (DECK 2 TO DECK 1)
THIS UNIT ENABLES YOU TO DUPLICATE A PRE-RECORDED TAPE TO ANOTHER TAPE. IT IS PERFORMED
ONLY ONE WAY FROM DECK 2 (PLAYBAK) TO DECK 1 (RECORDING).
DUBBING AT NORMAL SPEED
zSELECT “ TAPE ” FUNCTION.
zINSET A PRE-RECORDED CASSETTE INTO DECK 2 AND A BLANK CASSETTE TAPE INTO DECK 1.
zPRESS THE “ PAUSE ” KEY AND THEN PRESS THE “ RECORD ” AND “ PLAY ” KEY AT DECK 1.
zPRESS THE “ PLAY ” KEY TO START PLAYBACK AT DECK 2 & THEN PRESS “ PAUSE ” KEY AT DECK 1 TO
START DUBBING.
zPRESS “ PAUSE ” KEY AT DECK 1 & “ STOP ” KEY AT DECK 2 WHEN FINISH.
DUBBING AT HIGH SPEED
THIS UNIT IS QUIPPED WITH A HIGH SPEED DUBBING SYSTEM WHICH CAN SAVE THE TIME FOR DUBBING
BY 2/3 WHEN COMPARE TO NORMAL SPEED.
zPRESS THE DUBBING BUTTON TO “ HI “ POSITION AND THEN FOLLOW THE SAME PROCEDURES AS
STIPULATED IN “DUBBING AT NORMAL SPEED”.
zWHEN DUBBING A PRE-RECORDED CASSETTE TAPE AT HIGH SPEED, A CHATTERING SOUND IS
BEING HEARD. TO AVOID THIS, SET THE VOLUME CONTROL TO A MINIMUM LEVEL.
zDO NO ACTIVE/DE-ACTIVE THE “HI-NOR. DUBBING” BUTTON DURING DUBBING, THIS WILL VARY THE
SPEED OF RECORDING AND MAY BE DAMAGE THE CASSETTE TAPE.
B. RECORDING FROM RADIO
zSELECT “RADIO” FUNCTION
zTUNE TO THE DESIRED STATION AND INSERT A BLANK CASSETTE TAPE IN DECK 1.
zPRESS “RECORD” & “PLAY“ KEY TO START RECORDING.
zPRESS “PAUSE” KEYS AND THEN “STOP/EJECT” KEY WHEN FINISH.
C. RECORDING FROM CD
zSELECT “CD” FUNCTION.
zINSERT A BLANK CASSETTE TAPE IN DECK 1 WHICH SUITABLE FOR RECORDING.
zPRESS “PAUSE” KEY FIRST AND THEN “RECORD” & “PLAY“ KEY AT CASSETTE. RECORDING
FUNCTION IS NOW STAND BY.
zACTIVATE THE CD PLAYER, AND THEN PRESS “PAUSE KEY” AT CASSETTE TO START RECORDING.
zTO STOP RECORDING, PRESS “STOP” BUTTON ON CD PLAYER FIRST, THEN PRESSES THE “PAUSE”
KEY AND THEN “STOP/EJECT” KEY ON CASSETTE TAPE DECK.
SPECIFICATIONS
POWER SUPPLY
AC: 240V ~ 50Hz
RADIO FREQUENCY COVERAGE
FM: 88-108 MHz
AM: 540-1600 kHz
Design and specifications are subject to change without notice.
7English

CARE & MAINTENANCE
STYLUS
zRegularly check and remove any build-up of fluff from the stylus to
prevent it from skidding and jumping across the disc surface.
zWhen transporting the unit always fit the stylus head protector and
secure the ARM using the ARM clamp,
If the stylus is broken please contact our spares department.
SPARES Phone [phone] or EMAIL: spares[email protected]
RECORDS
zClean your records with an anti-static lint free cloth. Gently wipe the
disc surface in the direction of the grooves.
zWhen handling records avoid touching the disc surface.
zAlways store records in their sleeves and away from heat.
8 English
