Goodmans MICRO1109IP User manual

MICRO1109IP
CD Micro System with iPod Docking Station
User Guide
IMPORTANT: Please read all instructions carefully before use and keep for future reference
MICR01109IP_UserGuide 241008.indd 1 24/10/2008 09:45:26

2
Introduction
Thank you for choosing this CD Micro System with iPod Docking
Station. Not only can you listen to all your favourite tracks on your
iPod, but you can also listen to FM and MW Radio and play music
from CDs.
It’s really simple to use: you can fully operate your iPod directly from the control
panel or from the Remote Control. You can even connect auxiliary devices to it.
Throughout this User Guide, the CD Micro System with iPod Docking Station will be
referred to as the Micro System.
Safety is important
Use of any electrical equipment should be undertaken with care. Please read the
safety section on pages 20 to 22 before using this Micro System. This appliance
is for household use only.
An audio system that allows docking
of an iPod and which fully supports the
iPod menu system.
The Micro System can playback music
from USB, SD and MMC storage media.
•Internet Radio
•DAB Radio
•Your iPod
•Your Computer
• CDs•FM Radio
•USB drive for
MP3 players
•SD/MMC Card
Slot
•Internet Radio
•DAB Radio
•Your iPod
•Your Computer
• CDs•FM Radio
•USB drive for
MP3 players
•SD/MMC Card
Slot
•Internet Radio
•DAB Radio
•Your iPod
•Your Computer
• CDs•FM Radio
•USB drive for
MP3 players
•SD/MMC Card
Slot
The Micro System features a CD player
allowing playback of all your CD, CD-R
and CD-RW discs.
MICR01109IP_UserGuide 241008.indd 2 24/10/2008 09:45:27

3
What’s in the box?
EQVOLMUTE
SLEEPCLOCKTIMER
FUNCTION
FOLDER+
PROG
INTRO
STANDBY
REPEAT
SCAN
MEM
RANDOM
USB/SD
TUNING-TUNING+
FOLDER-
BAND
123
456
789
0/1010+
ENTER
ST/MO
I-MENU
Speakers
Micro System
USB Extension Cable
Remote Control
2 x AAA Batteries
8 iPod Adaptors
MW Aerial FM Aerial 2 x Speaker Cables
01
02
03
04
Your Micro System....................4
Getting Started..........................6
Daily Use...................................8
MW and FM Radio ....................9
iPod Docking............................10
CD Playback ............................11
USB and Card..........................14
Clock and Timer.......................15
Troubleshooting.......................16
Specifications..........................19
Warnings.................................20
Electrical Information...............22
Guarantee ...............................23
05
06
07
08
09
10
11
12
13
Contents
The above images are for illustrative purposes only and may differ to the items supplied.
MICR01109IP_UserGuide 241008.indd 3 24/10/2008 09:45:28

4
01 Your Micro System
BAND Button
AUX Socket
REMOTE Sensor
EQ Button
CD/USB/SD Button
SCAN Button
REPEAT Button
IPOD Dock
POWER Cable
POWER ON/OFF Switch
FUNCTION Button
STANDBY Button
NEXT Button
MW AERIAL Socket FUSE (T2A 20mm)
SPEAKER Connections
Front view
Rear view
-
+
REPEAT RANDOM
FUNCTION CD/USB/SD BAND EQ
SCAN
STANDBY
AUXSD
VOL
RANDOM Button
PREVIOUS Button
USB Socket
OPEN/CLOSE Button
VOLUME Control
PLAY/PAUSE Button
STOP Button
HEADPHONE Socket
SD Socket
Top view
AC 250V
FUSE:T 2AL
ON
OFF
AC 230-240 V
~ 50Hz
WARNING
RISK OF ELECTRIC SHOCK
DO NOTOPEN
SOCKET WHEN NOT IN USE.
DISCONNECT THIS MAINSPLUGFROMTHE SUPPLY
PRODUCTTOBEEXPOSED TO RAIN OR MOISTURE.
SERVICING PERSONNEL.DONOTALLOW THIS
SCREW. REFERALLSERVICING TOQUALIFIED
ELECTRICAL SHOCKDONOT REMOVE ANY COVER OR
HIGH VOLTAGEINSIDE. TO PREVENT
WARNING:
POWER
ANTENNA
FM 75 MW
SPEAKER OUTPUT
R
+
-
IMPEDANCE: 6
L
+
-
FM AERIAL Socket
MICR01109IP_UserGuide 241008.indd 4 24/10/2008 09:45:30

5
01
EQ VOLMUTE
SLEEP CLOCK TIMER FUNCTION
FOLDER+
PROG
INTRO
STANDBY
REPEAT
SCAN
MEM
RANDOM
USB/SD
TUNING - TUNING +
FOLDER-
BAND
1 2 3
456
789
0/10 10+
ENTER
ST/MO
I-MENU
7
Your Micro System
STANDBY Button
SEARCH FORWARDS Button
STOP Button
IPOD MENU Button
INTRO Button
USB/SD Button
FUNCTION Button
FOLDER - / IPOD DOWN Button
TUNING- / IPOD LEFT Button
FM/MW BAND Button
SCAN Button
IPOD PLAY/PAUSE Button
MEM Button
FOLDER+ / IPOD UP Button
EQ Button
TUNING + / IPOD RIGHT Button
SEARCH BACKWARDS Button
TIMER Button
MUTE Button
VOLUME UP Button
NUMBER Buttons
NEXT Button
Remote Control
PLAY Button
OPEN/CLOSE Button
PAUSE Button
PROG Button
REPEAT Button
RANDOM Button
ST/MO / IPOD ENTER Button
VOLUME DOWN Button
SLEEP Button
CLOCK Button
PREVIOUS Button
MICR01109IP_UserGuide 241008.indd 5 24/10/2008 09:45:30

6
02
Connecting up
Connect the left and
right speakers to the
Micro System. The
black and white wires
should be connected to
the red sockets and the
black wires to the black
sockets on the rear of
the Micro System.
Connect the FM and MW aerials to the sockets on the back of the Micro
System.
Switch On the Power after ALL connections have been made.
Getting Started
Using the Remote
Control
Insert the batteries (supplied)
into the Remote Control,
observing the polarity marked.
To use the Remote Control,
simply direct it towards the
front of the Micro System and
press the desired buttons.
DON’T FORGET! When replacing the batteries make sure that you
use the same size and type.
2
1
AC 250V
FUSE:T 2AL
ON
OFF
AC 230-240 V
~50Hz
WARNING
RISK OF ELECTRIC SHOCK
DO NOTOPEN
SOCKETWHEN NOTINUSE.
DISCONNECTTHIS MAINSPLUGFROMTHESUPPLY
PRODUCTTO BE EXPOSEDTORAINORMOISTURE.
SERVICINGPERSONNEL.DONOTALLOWTHIS
SCREW. REFERALL SERVICINGTOQUALIFIED
ELECTRICALSHOCKDONOT REMOVE ANYCOVER OR
HIGH VOLTAGEINSIDE.TO PREVENT
WARNING:
POWER
ANTENNA
FM 75 MW
SPEAKER OUTPUT
R
+
-
IMPEDANCE: 6
L
+
-
MICR01109IP_UserGuide 241008.indd 6 24/10/2008 09:45:31

7
02Getting Started
Connecting to External Devices
The Micro System can be connected to a number of external devices
using the Aux Socket on the front of the Micro System.
This requires a 3.5 mm Stereo Cable (not supplied).
3
Turn the Micro System On
Insert the plug into the wall socket and turn the socket on.
Press the STANDBY button on the front of the Micro System or the
Remote Control to turn the Micro System On.
4
-
+
REPEAT RANDOM
FUNCTION CD/USB/SD BAND EQ
SCAN
STANDBY
AUXSD
VOL
-
+
REPEAT RANDOM
FUNCTION CD/USB/SD BAND EQ
SCAN
STANDBY
AUXSD
VOL
MICR01109IP_UserGuide 241008.indd 7 24/10/2008 09:45:32

8
03
Switching On
To turn the Micro System on, press
the STANDBY button.
To turn the Micro System off, press
the STANDBY button again.
Adjusting the Volume
To increase the volume, rotate the
VOLUME CONTROL on the front of
the Micro System clockwise or press
the VOL + button.
To decrease the volume, rotate the
VOLUME CONTROL anti-clockwise
or press the VOL - button.
You can also press the MUTE
button to turn the sound off. Press
the MUTE button again to turn the
sound back on again.
Preset Equaliser (EQ)
The range of sound can be adjusted to
suit the different types of music that
you are listening to, by changing the
preset equaliser settings.
To select the Equaliser type, press
the EQ button on the Remote
Control repeatedly until the desired
type appears on the display.
The available settings are:
• FLAT
• MONITOR
• ARENA
• STUDIO
• CLUB
Mode Selection
The Micro System has the following
modes of operation:
•CD
•USB/SDcard
•FM
•MW
•iPod
•Auxiliary
To select a mode, repeatedly press
the FUNCTION button on the Micro
System. The Micro System will
cycle through the available modes.
The currently selected mode will be
shown on the display.
Alternatively, press the FUNCTION
button on the Remote Control.
Daily use
MICR01109IP_UserGuide 241008.indd 8 24/10/2008 09:45:33

9
04
Selecting Radio Mode:
Press the STANDBY button.
Press the FUNCTION button to
select Tuner mode.
Press the BAND button to select
either MW or FM.
Scanning for Stations:
To automatically search for the next
available station, press the TUNING
+button. The Micro System will
automatically search for the next
available radio station.
To search for another station, press
the TUNING - or TUNING +
button again.
Presetting Stations:
The preset function allows you to store
your favourite MW and FM stations for
easy access. You can preset up to 30
FM stations and 20 MW stations.
When in FM mode, use the TUNING
- or TUNING + buttons to scan for
the radio station you want to preset.
Press and hold the MEM button to
enter store mode.
Press the FOLDER - or FOLDER
+ buttons to select the memory
location where you want to store the
station.
Press the MEM button again to
store the station.
DON’T FORGET! Repeat the
previous steps to store your other
favourite stations.
DON’T FORGET! If you select
a preset number that is already
preset with a station, the existing
station will be replaced with the
new one.
Selecting a Preset Station:
Press the number buttons to select a
preset station.
Stereo / Mono Sound:
You can select stereo or mono sound
while listening to the FM radio.
To switch between stereo or mono
sound types, press the ENTER ST/
MO button.
The display will show “STEREO”
when in Stereo mode.
MW and FM Radio
MICR01109IP_UserGuide 241008.indd 9 24/10/2008 09:45:34

10
05
Any iPod can be connected to the
Micro System allowing all your favourite
songs to be played through the Micro
System’s speakers. The iPod can be
completely controlled by the Micro
System and charges when docked.
To connect an iPod to the Micro
System, select the compatible
adaptor from one of the 8 iPod
adaptors supplied. The iPod adaptors
have markings on the bottom which
clearly identify which iPod they
should be used with.
DON’T FORGET! If your iPod is not
compatible with any of the supplied
iPod adaptors, use the adaptor
supplied with your iPod.
Place the iPod adaptor into the
recess on the top of the Micro
System and then insert your iPod
into the adaptor.
To disconnect the iPod, turn it off and
disconnect it from the dock.
DON’T FORGET! Your iPod will
charge while docked when the
Micro System is in Standby Mode.
The following instructions describe how
to operate an iPod when it is connected
to the Micro System using the Remote
Control.
Selecting iPod Mode:
Press the STANDBY button.
Press the FUNCTION button until
iPod is selected.
To start playback, press the IPOD
PLAY/PAUSE button.
Menu Navigation:
To access the iPod menu system,
press the I-MENU button.
Use the ▲or ▼ buttons to highlight
the menu options.
Press the ENTER ST/MO button to
select a menu option.
iPod Docking
MICR01109IP_UserGuide 241008.indd 10 24/10/2008 09:45:34
