Short-form Operating Instructions
MAVOWATT 230, 240, 270 &270-400
Power Quality Analyzer
3-349-833-03
2/10.22
Software
„Dran-View®“
for download

MAVOWATT 230, 240, 270 & 270-400
2
Gossen Metrawatt GmbH
CONTENT
SAFETY INSTRUCTIONS 4
APPLICATION 7
INTENDED USE/USE FOR INTENDED PURPOSE 7
USE FOR OTHER THAN INTENDED PURPOSE 7
LIABILITY AND GUARANTEE 8
OPENING THE INSTRUMENT /REPAIRS 8
INSTALLATION AND CONFIGURATION 9
CONNECTING TO AC POWER SOURCE 10
CONTROLS,INDICATORS AND CONNECTORS 12
MAKING CONNECTIONS15
CONNECTING VOLTAGE MEASUREMENT CABLES 15
MAVOWATT 270 TOUCHSCREEN FEATURES 21
ICON FUNCTION KEYS, MAVOWATT 270 23
MAVOWATT 270 HOME MONITORING PAGE 24
KEY INSTRUMENT CONTROL FUNCTIONS 25
SETUP MONITORING 26
MEASUREMENT CONNECTIONS 27
AUTOMATIC SETUP FOR POWER QUALITY 27
AUTOMATIC SETUP FOR ENERGY/DEMAND 28
WIZARD SETUP 29
INPUT CONFIGURATION 30
MONITOR SAME CIRCUIT 42
LOAD SETUP TEMPLATE 43
LOAD DATA FILE FROM MEMORY 44
CHANGE INSTRUMENT CONFIGURATION 46
VIEW/SAVE MONITORING 46
INSTRUMENT SETTINGS 47
SET UP COMMUNICATIONS OPTIONS 48
DOWNLOAD DATA REMOTELY VIA NETWORK,WIFI &BLUETOOTH®PAN 49
REAL TIME METER MODES 51
SCOPE MODE 51
DIAL METERS (GRAPHICAL) 52
TEXT DISPLAY METERS (TABULAR) 53
DASHBOARD 54
HARMONICS 55
PHASOR DISPLAY 55
STRIP CHART RECORDER 56

MAVOWATT 230, 240, 270 & 270-400
Gossen Metrawatt GmbH
3
STORED DATA FUNCTIONS AND DISPLAYS 57
EVENT DATA AND REPORTS MENU 57
TREND PLOT 58
TREND WITH EVENT MARKERS 59
EVENT LIST 60
EVENT PLOT (RMS) 61
EVENT WAVEFORM 62
EVENT DETAIL 63
REPORTS 64
VOLTAGE COMPLIANCE REPORT 64
ENERGY AND DEMAND REPORT 66
HARMONICS STATISTICS REPORT 67
MINI-REPORT VIEWER 68
TECHNICAL CHARACTERISTICS 69
FCC COMPATIBILITY 69
RETURN AND ENVIRONMENTALLY SOUND DISPOSAL 70
CONTACT, SUPPORT AND SERVICE 71

MAVOWATT 230, 240, 270 & 270-400
4
Gossen Metrawatt GmbH
SAFETY INSTRUCTIONS
GENERAL
Observe this documentation, in particular all included safety information, in order to
protect yourself and others from injury, and to prevent damage to the instrument.
•Carefully and completely read and adhere to these short-form operating
instructions for the instrument.
The respective operating instructions can be found at
http://www.gossenmetrawatt.com. Retain the document for future reference.
•Use only the specified accessories (included in the scope of delivery or listed as
options) with the instrument.
•Carefully and completely read and adhere to the product documentation for
optional accessories. Retain these documents for future reference.
•Observe and comply with all safety regulations which are applicable for your
work environment.
WARNING
Risk of injury or even death results from incorrect connection of the instrument. Read
these operating instructions before connecting the instrument. Observe all installation
and operating procedures in these operating instructions.
•All relevant country-specific laws, regulations and standards must be complied
with when working with or on the instrument (connection, measurement,
installation, maintenance, repair).
•Work on or near current-carrying lines must always be conducted in compliance
with all applicable safety regulations.
DEFINITIONS
WARNING identifies a hazard which may result in death or serious injury if not
avoided.
CAUTION identifies a hazard that could result in damage to the instrument and/or
data loss, or damage to other equipment or devices if not avoided.
NOTE identifies special instructions for handling the instrument.

MAVOWATT 230, 240, 270 & 270-400
Gossen Metrawatt GmbH
5
SYMBOLS
Connectors and switches on the top and back of the instrument are marked with the
following IEC symbols:
Caution, refer to accompanying documents (this manual).
Alternating current (AC)
Direct current (DC)
Mains switch
European conformity marking
The instrument may not be disposed of with household trash, Return and
Environmentally Sound Disposal (page 70).

MAVOWATT 230, 240, 270 & 270-400
6
Gossen Metrawatt GmbH
SAFETY PRECAUTIONS
The following safety precautions must be followed whenever any type of voltage
or current connection is being made to the instrument.
•Connect the safety (earth) ground first, before making any other
connections.
•When connecting to electric circuits or pulse initiating equipment, open
their related breakers. DO NOT install any connection of the instrument
on live power lines.
•Connections must be made to the instrument first, then connect to the
circuit to be monitored.
•Wear proper personal protective equipment, including safety glasses
and insulated gloves when making connections to power circuits.
•Hands, shoes and floor must be dry when making any connection to a
power line.
•Make sure the instrument is turned OFF before connecting probes to
the rear panel.
•Before each use, inspect all cables for breaks or cracks in the
insulation. Replace immediately if defective.
•Observe all information included in the operating instructions. Any use
of the instrument which deviates from these instructions represents a
potential safety risk. The above-mentioned safety instructions may
appear repeatedly in this manual.

MAVOWATT 230, 240, 270 & 270-400
Gossen Metrawatt GmbH
7
APPLICATION
Please read this important information!
Intended Use/Use for Intended Purpose
The MAVOWATT 2XX series by GOSSEN METRAWATT comprises models
MAVOWATT 270, MAVOWATT 270-400, MAVOWATT 240 and MAVOWATT 230.
They are portable, hand-held, eight-channel power quality meter/monitors which are
very similar in operation, although the MAVOWATT 270 also has a high speed
sampling board for capturing the details of very fast transients. The features common
to all monitors are covered in this document, and the MAVOWATT 270 name will be
used to represent all four instruments. These cutting-edge power quality instruments
are designed with a 7” WVGA wide screen LCD, using touch screen technology.
They can monitor, record and display data on four voltage channels, as well as four
current channels simultaneously.
The MAVOWATT 270 is designed to meet both the IEEE 1159 and IEC 61000-4-30
Class A standards for accuracy and measurement requirements. It can do PQ-
optimized acquisition of power quality related disturbances and events. It is designed
with a statistical package called Quality of Supply (QOS), with monitoring and setup
protocols set to determine voltage measurement compliance required for EN 50160
monitoring. European standard EN 50160 requires that measurement parameters
must be within a specified percentage for 95% of the time.
The MAVOWATT 270 also allows you to perform automatic setup or to customize
threshold settings for power quality or energy/demand. The power quality and
energy/demand dashboard interface helps you monitor and manage energy
consumption including utility costs.
The MAVOWATT 270 firmware can monitor power quality and energy/demand
phenomena for troubleshooting and/or compliance purposes. It can record inrush
conditions, carry out long-term statistical studies to establish performance baselines,
and perform field-based equipment testing and evaluation for commissioning and
maintenance. The firmware integrates an intuitive instrument setup procedure to
ensure the capture of all relevant data for additional post process analysis, report
writing, and data archiving using other compatible GOSSEN METRAWATT software
applications such as Dran-View®.
.
Use for Other than Intended Purpose
Using the instrument for any purposes other than those described in these
condensed operating instructions, or in the instrument’s operating instructions, is
contrary to use for intended purpose.

MAVOWATT 230, 240, 270 & 270-400
8
Gossen Metrawatt GmbH
Liability and Guarantee
Gossen Metrawatt GmbH assumes no liability for property damage, personal injury or
consequential damage resulting from improper or incorrect use of the product, in
particular due to failure to observe the product documentation. Furthermore, all
guarantee claims are rendered null and void in such cases.
Nor does Gossen Metrawatt GmbH assume any liability for data loss.
Opening the Instrument / Repairs
The instrument may only be opened by authorized, trained personnel in order to
ensure flawless, safe operation and to assure that the guarantee isn’t rendered null
and void. Even original replacement parts may only be installed by authorized,
trained personnel.
Unauthorized modification of the instrument is prohibited.
If it can be ascertained that the instrument has been opened by unauthorized
personnel, no guarantee claims can be honored by the manufacturer with regard to
personal safety, measuring accuracy, compliance with applicable safety measures or
any consequential damages.

MAVOWATT 230, 240, 270 & 270-400
Gossen Metrawatt GmbH
9
INSTALLATION AND CONFIGURATION
NOTICE
•Charge Battery Before Use!
Always charge the battery fully before using the instrument! The instrument
will fully charge its internal battery in three (3) hours.
The instrument will always operate on the charger and is designed to do so
regardless of the state of charge of the battery.
Refer to the User Guide for additional information.
•Set Time and Date
From the Home screen, press the Setup Instrument ( ) icon, then press Set
Time and Date.
Set the time zone applicable to your application using the Time Zone drop down
selection list.
NOTE: Time and/or date cannot be changed if monitoring is on.
The MAVOWATT 270 also lets you synchronize time, so that all of your devices
are using the same time for data recording. Time sync options include GPS, NTP
or Real Time Clock (RTC). Each Time Sync Source button toggles the respective
source enabled or disabled.
If all three are enabled, time sync is sourced by the instrument in the following
priority order: If GPS is available, then it is used. If not and NTP is available, then
NTP is used. If neither GPS nor NTP is available, then RTC is used.
NOTE: If the battery is removed and only RTC time is available, the instrument
reverts to the default time/date.
Refer to the operating instructions for further information, which can be found at
http://www.gossenmetrawatt.com. Retain the document for future reference.

MAVOWATT 230, 240, 270 & 270-400
10
Gossen Metrawatt GmbH
Connecting to AC Power Source
Power Specifications
The MAVOWATT 270 adapter can be connected to a 50/60 Hz, 90-264 V AC power
input source.
CAUTION
Before plugging in or unplugging the mains cable, switch the instrument off
(set mains switch to OFF).
In order to avoid damage to the instrument, use only approved mains power
packs (see rating plate for nominal voltage range).
AC Adapter
The MAVOWATT 270 can be operated from a 50/60 Hz, 120/240 V AC power input
source with or without the battery pack installed.
•Voltage range: 120/240 V AC
•Frequency: 50/60 Hz
•Power consumption: 20 W
STEP 1
Connect the AC adapter/battery charger plug into the left side of the instrument.
STEP 2
Plug the AC adapter into an AC power source.
STEP 3
Press the momentary On/Off mains switch to turn the instrument on.
Result: The GOSSEN METRAWATT logo will be displayed while the instrument is
booting.
STEP 4
The instrument completes the power on sequence. If the instrument was shut down
while monitoring, the instrument will resume monitoring upon power up.
Result: Upon start-up, the Home screen serves as the access point for major
instrument control functionalities.

MAVOWATT 230, 240, 270 & 270-400
Gossen Metrawatt GmbH
11
Home Screen:
The Home screen displays large shortcut buttons to include Start Monitoring, Real
Time Data, Recorded Data and Instrument Setup. Repeated pressing of the
GOSSEN METRAWATT logo alternates between the Home screen and the Home
Monitoring screen.
Home Monitoring Screen:
After the instrument has been powered up and monitoring is turned ON, the Home
Monitoring screen becomes the start-up page. This is the screen from which all other
functions launch and eventually return back to using the Exit function key.

MAVOWATT 230, 240, 270 & 270-400
12
Gossen Metrawatt GmbH
Controls, Indicators and Connectors
Top View
Voltage and Current Connections - There are four differential voltage and four
differential current channels, which can be wired to measure a variety of circuit
configurations. Use only GOSSEN METRAWATT voltage leads and current probes
for proper operation. Do not exceed the marked maximum ratings.

MAVOWATT 230, 240, 270 & 270-400
Gossen Metrawatt GmbH
13
Front View
1
Mainframe / Rubber Boot Enclosure
2
Power Indicator
3
Three Touch Icons
4
Color LCD with Touch Screen
Touchscreen – various instrument and measuring functions are controlled via the
touchscreen. Functions can be activated with your fingers or a PDA stylus. All of the
menus can be accessed and alphanumeric data can be entered via the touchscreen.
Clean with a soft cloth only!
Power Indicator - LED will light steadily when the instrument is operating normally.
Function Keys – for various functions: snapshots, mini-reports and help. These keys
cannot be activated while wearing gloves!
1
4
3
2

MAVOWATT 230, 240, 270 & 270-400
14
Gossen Metrawatt GmbH
Left Side View
1
Mains Switch
2
GPS Receiver Port
3
AC Mains Adapter / Battery Charge Input Connector (+12 V DC)
Right Side View
1
USB Cable Connector for File Transfer
2
USB Port Connector for USB Flash Drive and Bluetooth® Dongle
3
Ethernet Port
1
2
3
1
2
3

MAVOWATT 230, 240, 270 & 270-400
Gossen Metrawatt GmbH
15
Rear View
1
Device Mounting Hanger
2
Hinge Deploys a Stand
3
Wire Coil Holders to Manage Wire Connections
Always ensure that the batteries are adequately charged and perform specified
maintenance on the UPS in accordance with the manufacturer’s instructions. If the
battery pack is in need of replacement, de-energize the connections and power to the
instrument before opening the battery door. Replace the pack only with the GOSSEN
METRAWATT battery pack.
Making Connections
WARNING
Death, serious injury, or fire hazard could result from improper connection of this
instrument. Read and understand the warnings in the beginning of this manual before
connecting this instrument.
Connecting Voltage Measurement Cables
Measurement Cable Set
Description: Voltage measurement cables are provided as standard accessories,
and are stored in a cable pouch as part of the measurement cable set. Each cable
set consists of a cable and an alligator clip.
Voltage Rating: Direct connection of all voltage measurement cables are rated at
1000 VCAT III Vrms max. For measuring voltages greater than 1000 Vrms, potential
transformers (PTs) must be used.
1
2
3

MAVOWATT 230, 240, 270 & 270-400
16
Gossen Metrawatt GmbH
Interconnect Jumper
The standard cable set for the MAVOWATT series includes four (4) interconnect
jumpers bearing part number 114013-G1. These interconnect jumpers can be used
to connect the same conductor points together and are rated 600V CAT III. When
using the interconnect jumpers, also use the supplied wire markers to identify the
wiring connections applicable to your installation.
WARNING
DO NOT EXCEED 600 VRMS when using the included interconnect jumpers with
article number 114013-G1.
For circuit configurations above 600VRMS, each voltage channel input is to be
individually connected to the MAVOWATT instrument with the supplied 1000V CAT
III cables and safety clips ONLY.
Wire Markers
Each kit consisting of snap-on wire markers in various colors is supplied as described
in the following table. These wire markers are to be used to identify each wire
connection applicable to your installation
•WMV-KIT (118376-G1) measures 0.138 inch (3,5 mm) diameter; kit is included
with the standard measurement cable set and used for identifying voltage cables.
•WMI-KIT (118377-G1) measures 0.218 inch (5,5 mm) diameter; kit is included
with the standard measurement cable set and is used for identifying current
probes.
•WMFV-KIT (118376-G2) measures 0.138 inch (3,5 mm) diameter; kit is supplied
with each Fuse Voltage Adapter and is used for identifying voltage cables.
Wire Marker Color
WMV KIT
Quantity
WMI KIT
Quantity
WMFV KIT
Quantity
Blue
16
4
4
Black
4
4
4
Brown
4
4
4
Orange
4
4
4
Yellow
4
4
4
Red
4
4
4
Green
4
4
4
White
16
4
4

MAVOWATT 230, 240, 270 & 270-400
Gossen Metrawatt GmbH
17
Measurement Cable with Optional Fused Voltage Adapter
WARNING
To avoid the risk of electric shock or burns, always connect the safety (or earth)
ground before making any other connections.
WARNING
To reduce the risk of fire, electrical shock, or physical injury, it is strongly
recommended to fuse the voltage measurement inputs. Fuses must be located as
close to the load as possible to maximize protection.
WARNING
For continued protection against risk of fire or shock hazard, replace only with same
type and rating of recommended fuse.
WARNING
Do not replace fuse again if failure is repeated. Repeated failure indicates a defective
condition that will not clear with replacement of the fuse. Refer condition to a qualified
technician.
Mavowatt
Black 50 cm cable
Test clip (supplied with standard equipment)
(FVA-1K)
Standard cable 3
meters, supplied with
standard equipment

MAVOWATT 230, 240, 270 & 270-400
18
Gossen Metrawatt GmbH
The MAVOWATT 270 can monitor the following power configurations:
•Single Phase
•Split Phase
•3 Phase, Four Wire Wye
•3 Phase (Floating or Grounded) Delta
•3 Phase 2-Watt Delta
•Generic Circuit
•2 ½ Element without Vb
•2 ½ Element without Vc
3 Phase, Four Wire Wye and 3 Phase (Floating or Grounded) Delta are described in
this Quick Reference Guide. For other configurations, please refer to the complete
operating instructions.

MAVOWATT 230, 240, 270 & 270-400
Gossen Metrawatt GmbH
19
3 Phase, Four Wire Wye
Channels A, B, and C are connected to voltage and current probes. The neutral is
connected to common, and is the reference for the three channels. The figure also
shows voltage connection using channel D as a differential input for measuring
neutral to ground voltage. Neutral to ground measurements are important, but
optional.

MAVOWATT 230, 240, 270 & 270-400
20
Gossen Metrawatt GmbH
3 Phase (Floating or Grounded) Delta
In this power connection, the MAVOWATT 270 uses voltage channels A, B, and C as
differential inputs with channel A using source voltage A-B, channel B using B-C, and
channel C using C-A as the reference. Current probes are connected to channels A,
B, and C. Neutral to ground measurements are important, but
optional.
