GPM CODE 3 User manual

DISH TRAY
Assembly Instructions – Please keep for future reference
GLOBAL PROCUREMENT AND MARKETING LIMITED
CODE 3
CODE 4 CODE 2
TABALPGRY
Dimensions No. people Assembly Time OW #
Width: 40cm
Depth: 40cm
Height: 44.5cm
10 mins
(approx.) GP0431
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, please email [email protected]

• Check you have all the
components and tools listed
on pages 4 and 5.
• Remove all fittings from the
plastic bags and separate
them into their groups.
• Keep children and animals
away from the work area,
small parts could choke if
swallowed.
• Make sure you have enough
space to lay out the parts
before starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft, level
surface to avoid damaging the
unit or your floor.
• We do not recommend the
use of power
drill/drivers for
inserting screws,
as this could
damage the unit.
Only use hand screwdrivers.
• Dispose of all packaging
carefully and responsibly.
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
Glass Warnings
1. Do not place very hot or very cold items against or in close proximity to glass surfaces unless an
adequately thick insulating material is used to prevent such items from coming into contact with the
glass.
2. Do not strike the glass with hard or pointed items.
3. When cleaning glass panels or mirrors use a damp cloth or leather with washing up liquid or soft soap
if necessary: do not use washing powders or any other substance containing abrasives since these
substances can scratch glass.
4. It is essential that this unit is fixed to a wall with the ifxings provided (if applicable).
5. This product complies with BS7449: 1991
Imported by Global Procurement and Marketing Ltd
Model no. FH-CFT190043 Batch no. GP0431
Dimensions: 40*40*44.5cm.
6. If a glass component is chipped or broken, replace with glass of the type described above. Consult the
manufacturer, retailer or agent with regard to obtaining a manufacturing specification and shape for
replacement glass quoting the model number and batch number or date of manufacture.
Care and Maintenance
• Only clean using a damp cloth and mild
detergent, do not use bleach or
abrasive cleaners.
• From time to time check that there
are no loose screws on this unit.
• This product should not be
discarded with household waste.
Take to your local authority waste
disposal centre.
If you are unhappy with the product and wish to return it,
please follow the retailer’s returns procedure.

Exploded View If you have damaged or missing components,
email: [email protected]
2
6
7
1
8
9
4
5
3

If you have damaged or missing components,
email: [email protected]
Components - Panels
Part No Description Qty Size
(mm)
Thickness
(mm)
1
1PC
400X400
59
2
1PC 545X31 12
3
1PC 545X31 12
4
1PC 545X31 12
5
1PC 545X31 12
6
1PC 324x33 15
7
1PC 350x33 15
8
1PC 324x33 15
9
1PC 350x33 15

Please check that you have all the components listed below before constructing your item.
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
(A)
X16
4x40Mm
(B)
X2
3x12MM
(C)
X2
(D)
X1
(E)
X16
(F)
X16
(G)
X4
Tools Required
Ruler – Use this to measure your screws (mm)
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, please email aftersa[email protected]
Components - Fixings If you have damaged or missing components,
email: [email protected]

1
2
Assembly Instructions If you have damaged or missing components,
email: [email protected]

FF
F
F
F
F
F
3
4
G
G
G
G
