GPM BSDNOROAK User manual

GOLBAL PROCUREMENT AND MARKETING LIMITED
NORDICA NIGHTSTAND
Assembly instruction- Please keep for future reference BSDNOROAK
BSDNORWHT
BSDNORGRY
Dimensions No.People Assembly Time OW#
Width: 53.7cm BSDNOROAK
Depth: 40cm BSDNORWHT
Height: 55cm BSDNORGRY
Important-Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, please email [e-mail]
1
35 mins
(approx)
400
550
537
372165

2
If you are unhappy with the product and wish to return it,
please following the retailer’s return procedure
13
13 14
14 15
15
15
15
1
2
4
5
6
7
8
12
12
11
11
9
9
10
10
33

Components - Panels
Please check that you have all the components listed below before constructing your item.
Part No Description Qty Thickness
(mm)
1 Top panel 1 40mm
2 Down panel 1 40mm
3 Back side panel 2 15mm
4 Back cover panel 1 2.5mm
5 Left side panel 1 15mm
6 Right side panel 1 15mm
7 Drawer face 1 panel 1 15mm
8 Drawer face 2 panel 1 15mm
9 Left drawer inside panel 2 15mm
10 Right drawer inside panel 2 15mm
11 Back drawer inside panel 2 15mm
12 Bottom drawer panel 2 2.5mm
13 Front support down panel 2 15mm
14 Side support down panel 2 15mm
15 Leg panel 4 25mm
Important-Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, please email [e-mail]
3
If you have damaged or missing components,
email [email protected]

Components - Fixings
Please check that you have all the components listed below before constructing your item.
HARDWARE
Tools Required (Not Provided)
Ruler - Use this to measure your screws (mm)
Important-Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, please email [e-mail]
4
If you have damaged or missing components,
email [email protected]
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than
MINIFIX 16MM X 16 MIN ICAM 16M M X 16 ALLEN KEY X 1 WO O D DOW EL
(A) (B) (C) (D) (E)
(F) (G ) (H ) (I) (J)
(K) (L) (M ) (N) (O)
8 X 30 MM X 14
CSK M3.5 X 16 M M
X 24
PAN HEAD 3.5 X 16MM
X 6
CSK M3.5 X 12MM
X 8
CSK M3 X 12MM
X 16
CSK M 4 X 38 MM
X 14
NAIL X 6 NAIL LEG 5/8 X 4
WASHER X 8
DR A W ER SLIDE 300mm
X 2
METAL CORNER
X 4
JCBC M6 X 20MM
X 8

Assembly Instructions
Step 1
Step 2
5
If you have damaged or missing components,
email [email protected]
5 6
33
13
13
10
9
E
x16
Insert dowel (D) to parts as shown.
Dowel (D) follow hole.
56
12
A
x16
78
screw minifix (A) as shown on
diagram. Minifix (A) follow hole.

Step 3
Step 4
6
65
H
1st HOLE
H
1st HOLE
H
F
I
H
F
I
1b. Follow the hole as shown on diagram and screw drawer
slide (F) to panel number (6) with screw (I&H) as shown.
Repeat on the side panel (5) with drawer slide (F) with the
same instruction.
3
3
6
5
SHOW N
A1 TO THE HOLE AS
A2 AND M INIFIX
FIX THE KLIX CAM
LOCK
SHOW N
A1 TO THE HOLE AS
A2 AND M INIFIX
FIX THE KLIX CAM
LOCK
A
B
C
ARROW
TIGHTEN
1
2
3
Fix the panel no (3) to both side of panel no
(6,5) as shown. Fix the minifix (A) then lock it
using minicam (B). Follow the diagram shows.

Step 5
Step 6
7
1
2
6
5
SHOW N
A1 TO THE H OLE AS
A2 AND MIN IF IX
FIX THE K LIX CAM
LOCK
SHOW N
A1 TO THE H OLE AS
A2 AND MIN IF IX
FIX THE K LIX CAM
LOCK
A
B
C
ARROW
TIG HTEN
1
2
3
Attach the panel no (6,5) to panel no (1)
and fit the minifix (A) with minicam (B).
Then fit the panel (2) to bottom side and
lock it with minicam (B).
JK
4
2
5
K
x6
Follow the 3mm hole then screw (J) to the
back of the support then tap the nail (K)
use hammer as shown.

Step 7
Step 8
8
G
O
2
13
13 14
14
15
15
15
15
13
13 14
14
L
N
L
MC
7b. Screw Leg panel (15) to
metal corner and screw with
screw (M) as shown.
Attach the previous part of step 7 to bottom of the
panel (2) with screw (G).Then tap the nail leg (O)
to each leg using hammer as shown.
7a. Fit metal corner (L) to each angle
between panel (13,14) with screw (N).
Follow the detail instruction.

Step 9
Step 10
9
STEP 2
G
G
G
B
A
E
9
11
10
8
9
10
11
12
E
E
12
A
BC
ARROW
TIGHTEN
1 2 3 SHO W N
A1 T O THE HOLE AS
A2 A N D MINIFIX
FIX TH E K LIX CAM
LOCK
SHO W N
A1 T O THE HOLE AS
A2 A N D MINIFIX
FIX TH E K LIX CAM
LOCK
STEP 2
G
G
G
B
A
E
9
11
10
7
9
10
11
12
E
E
12
A
BC
AR ROW
TIGHTEN
1 2 3 S HO WN
A1 TO THE HOLE A S
A2 AND M INIF IX
FIX THE KLIX C A M
LOC K
SHO WN
A1 TO THE HOLE A S
A2 AND M INIF IX
FIX THE KLIX C A M
LOC K
9a. Fix panel (9,10) to each
side panel (11) using screw
(G).
9b. Slide in panel (12) as
shown on diagram
9c. Attach panel (7) to panel (10,9).
Tighten the minifix with minicam (B).
Follow the detail shown.
FIRST DRAWER
SECOND DRAWER
10a. Fix panel (9,10) to each
side panel (11) using screw
(G).
10b. Slide in panel (12) as
shown on diagram
10c. Attach panel (7) to panel (10,9).
Tighten the minifix with minicam (B).
Follow the detail shown.

Step 11
Step 12
10
11
10
I
12
I
H
H
F
F
10
F
H
I
I
8
7
SLIDE IN THE DRAWER
11a. Attach Drawer slide
(F) to drawer side panel
(10 & 9).
