GPS FC24-AC User manual

5. Record Name of Installer:
6. Record Date of Installation/Startup:
7. Record Devise ID Unit is Installed In/On:
8. Record Incoming Power Level:
9. Record Voltage Output at GPS-FC24-AC Emitters:
10. Confirm Installation Type:
1. Record Manufacturer: GPS
2. Record Model Number: GPS-FC24-AC
3. Record Serial Number of Ionizer:
EQUIPMENT + INSTALLER DATA
Start-up Checklist
™
GPS Air
Complete 1 Checklist Per Ionizer
MODEL VERIFICATION
Mounting on ferrous surfaces subject to low levels of vibration (if using fasteners, skip to next section)
MECHANICAL MOUNT |Magnet Installation
INSTALLATION
PTAC Mini Split AHU Blower Inlet Ceiling Cassette Other:
INSTALLATION DATA
1. Confirm the included magnets are firmly attached using the provided fasteners
2. Confirm the GPS-FC24-AC is to be installed downstream of all filters in the system
3. Confirm the GPS-FC24-AC is installed such that air passes over the emitters as indicated on the product
4. Confirm that airflow over the emitters is not obscured/restricted - see the IOM for details
5. Confirm the GPS-FC24-AC is secure

1. Confirm incoming power to the GPS-FC24-AC is one of the following:
2. Confirm the electrical connections on the GPS-FC24-AC are wired in accordance with the installation manual
3. Confirm the electrical supply is terminated in an appropriate fashion at the supply end and all local
and national electrical and building codes are complied with
4. Use a soft cloth with isopropyl alcohol to wipe debris off the GPS-FC24-AC emitters
5. Allow any residual alcohol to evaporate off the emitters prior to turning the ionizer on for the first time
Checklist | GPS-FC24-AC
24VAC 110VAC
1. Confirm the GPS-FC24-AC is installed downstream of all filters in the system
2. Confirm appropriate fasteners (e.g. self-tapping sheet metal screws) are used to secure the GPS-FC24-AC to the
appropriate surface
3. Confirm the GPS-FC24-AC is installed such that air passes over the emitters as indicated on the product
4. Confirm that airflow over the emitters is not obscured/restricted - see the IOM for details
ELECTRICAL INSTALLATION
For non-ferrous surfaces or those where significant levels of vibration may be experienced
MECHANICAL MOUNT |Fastener Installation
STARTUP
UNIT STARTUP
1. Power on the GPS-FC24-AC using the in-line switch
2. Confirm the GPS-FC24-AC is continuously powered and not configured to cycle with the HVAC duty
3. Once powered on, confirm the power LED is illuminated
4. Confirm the cleaning cycle frequency is set to 1 day in accordance with the method detailed in the IOM
5. Measure the voltage at the GPS-FC24-AC emitters (both polarities) and confirm it is above the minimum
target level of 3kV
6. Visually confirm there is no duct or dirt on the carbon fiber emitters after they were cleaned with
isopropyl alcohol during installation
7. With the GPS-FC24-AC operational, verify ion density output. Confirm it meets the combined polarity target
of 300M ions/cc using the AIC2 ion meter ions/cc for each polarity measured 1” away with air handler
fan off (no airflow)
8. Confirm the final configuration is securely attached to the appropriate surface, and operational in accordance
with the installation manual
240VAC

©2022 GPS Air GPS-056-23-R20-FC24C
For the latest applicable version of the GPS-FC24-AC
installation manual, visit
www.gpsair.com/downloads
or scan the QR code.
Register your products at
www.gpsair.com/product-registration
By registering your order, the standard limited warranty
on eligible products from your purchase is automatically
extended to 3 years, at no additional cost.
For instructions on how to measure emitter voltage, scan
the QR code.
Checklist | GPS-FC24-AC
