GPS PS-2 Instruction manual

www.globalplasmasolutions.com
Installation, Operation & Maintenance Manual
™
NOTICE: This product is to be used only as directed. Read entire manual before use. Do not use unless properly installed.

IMPORTANT SAFETY INSTRUCTIONS
When using electrical products, basic precautions should always be practiced including the following:
1. READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
2. Read and follow all instructions that are on the product or provided with the product.
3. Reference the National Electrical Code, NFPA 70, specifically for the installation of wiring and
clearances from power and lighting conductors.
4. Installation work and electrical wiring must be done by qualified person(s) in accordance with all
applicable codes and standards, including fire-rated construction.
5. WARNING: Risk of Fire. Installation involves special wiring methods to run wiring through a
building structure. Consult a qualified electrician.
SAVE THESE INSTRUCTIONS
This manual contains important safety and operating instructions for power units.

For technical product queries, please reach out to [email protected]
Thank you for purchasing a PS-2™ air ionization system from GPS Air.
What’s Included
Location
Install PS-2 within 100 feet of ionization system to avoid excessive power losses. Take care to not damage
wiring when installing away from ionizer.
NOTE: Use temperature - Maximum ambient temperature in which unit shall be used: 160°F/ 70°C.
Before you start, confirm the contents of your shipment. Each PS-2 will consist of the following:
1. PS-2 Power Supply (1)
2. Cable Gland (1)
3. Self drilling sheet metal screws (4)
Supplies Not Included
1. Conduit fitting for incoming AC power
2. Wiring for incoming AC power
3. Grommets/glands for any wiring penetrations
(1) (4)(1)

Installation
WARNING: Make sure power is disconnected to the HVAC equipment before installation.
Remove Screws
Remove two screws from the top cover as shown.
Step 1.
·
Review the installation video at our website or scan the QR
code opposite.
CAUTION! High Voltage.

Remove Top Cover
Lift top cover straight up to remove as shown.
Step 2.
·
PS-2
24V DC
OUTPUT
L
INPUT 120-277 VAC
G N
RLY1
RLY2
[ -]
[+]
RLY1
RLY2
RELAY
Wiring
NOTE: Metallic conduit shall be properly bonded in accordance with the national electric code article 250.
Connect the appropriate conduit and fitting as necessary for the application.
Route the wires as shown and make connections according to the marking located on the product.
Tighten the fittings to adequately secure the cable and conduit.
Step 3.
·
·
·
For installations in plenum spaces use only metallic clad conduit on incoming AC power.
Wire colors will vary by incoming AC power and GPS product.

Mounting
Using the supplied fasteners mount the PS-2 to an appropriate vertical or horizontal surface.
Step 4.
·

The information provided in this manual is up to date at the time of printing.
Any revisions to this document will supersede the content included. For the
latest applicable version of this manual, visit our website or utilize the QR code.
Product Registration
By registering your order, the standard limited warranty on eligible products
from your purchase is automatically extended to 3 years, at no additional cost.
Register your products at www.gpsair.com/product-registration or scan the
QR code.

3101 Yorkmont Road · Suite 400
Charlotte, NC 28208
980-279-5622
www.gpsair.com
© 2022 GPS Air
GPS Air is the owner of certain trademarks that appear in our materials. Please visit www.gpsair.com/trademarks for a list of our marks. GPS-041-31-R21-PS2 IOM
