Instructions - Parts List
Uni-Drum™
Supply System
Bulk Supply System for 300 Gallon (1200 Liter) Magnadrums. For professional use only.
Not approved for use in explosive atmospheres or hazardous (classified) locations.
The Uni-Drum Supply System evacuates 300 gallon (1200 liter) magnadrums or other tote drums of the same size
and capacity. The Uni-Drum Supply System pumps and transfers flowable and highly viscous materials such as
sealant, adhesives, and sound deadeners from bulk drums with maximum efficiency.
The Uni-Drum Supply System is designed to work with other high pressure equipment to optimize material use.
See page 4 for model information.
Important Safety Instructions
Read all warnings and instructions in this
manual and related manuals before using
the equipment. Save these instructions.
Uni-Drum Left Hand Supply Unit Uni-Drum Right Hand Supply Unit

2309028ZAT
Contents
Related Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Uncrating the System. . . . . . . . . . . . . . . . . . . . . . . . 9
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installation Overview . . . . . . . . . . . . . . . . . . . . . . 9
Operation Overview . . . . . . . . . . . . . . . . . . . . . . . 9
Component Identification . . . . . . . . . . . . . . . . . . . 10
Uni-Drum Supply System with Customer Mounted
Manifold and Drum Clamps . . . . . . . . . . . . . 10
Uni-Drum Supply System with Machine Mounted
Manifold . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Uni-Drum Supply System with Customer Mounted
Manifold . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Pneumatic Logic Panel . . . . . . . . . . . . . . . . . . . 13
Junction Box Panel . . . . . . . . . . . . . . . . . . . . . . 16
General Description . . . . . . . . . . . . . . . . . . . . . . 18
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Preparing the Site . . . . . . . . . . . . . . . . . . . . . . . 20
Selecting a Location for the Uni-Drum . . . . . . . . 20
Preparing to Install the Uni-Drum. . . . . . . . . . . . 20
Installing the Uni-Drum . . . . . . . . . . . . . . . . . . . 21
Installing Drum Clamps . . . . . . . . . . . . . . . . . . . 21
Installing Drum In Position Switch . . . . . . . . . . . 21
Connecting Power to the Junction Box . . . . . . . 22
Grounding the System . . . . . . . . . . . . . . . . . . . . 24
Checking the Resistance Between the Pumps and
the True Earth Ground. . . . . . . . . . . . . . . . . 24
Connecting the Air Supply Lines to the Uni-Drum25
Connecting Output Hose to the Pumps . . . . . . . 26
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Prepare the Operator . . . . . . . . . . . . . . . . . . . . . 27
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
General Functional Description . . . . . . . . . . . . . 27
System Startup . . . . . . . . . . . . . . . . . . . . . . . . . 27
System Operation . . . . . . . . . . . . . . . . . . . . . . . 27
Supply Unit Operation . . . . . . . . . . . . . . . . . . . . 27
System Shutdown . . . . . . . . . . . . . . . . . . . . . . . 27
Flushing the System Before Initial Use . . . . . . . 28
Adjusting the Drum Lid Holder Before Initial Use 28
Initial System Startup Procedure . . . . . . . . . . . . 29
Changing Empty Drums. . . . . . . . . . . . . . . . . . . 31
Daily System Startup . . . . . . . . . . . . . . . . . . . . . 33
System Shutdown . . . . . . . . . . . . . . . . . . . . . . . 33
Stopping the System . . . . . . . . . . . . . . . . . . . . . 33
Restarting the System . . . . . . . . . . . . . . . . . . . . 33
Pressure Relief Procedures . . . . . . . . . . . . . . . . . . 34
Fluid Pressure Relief Procedure. . . . . . . . . . . . . 34
Pneumatic Pressure Relief Procedure . . . . . . . . 35
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Preventative Maintenance Schedule . . . . . . . . . 36
Flushing the System. . . . . . . . . . . . . . . . . . . . . . 36
Cleaning the System . . . . . . . . . . . . . . . . . . . . . 36
Wiper Lubrication . . . . . . . . . . . . . . . . . . . . . . . . 37
Junction Box Panel Service. . . . . . . . . . . . . . . . . . 38
Indicator Light and Pushbutton Switch Removal 38
Indicator Light and Pushbutton Switch Replacement
38
Light Bulb Removal . . . . . . . . . . . . . . . . . . . . . . 38
Light Bulb Replacement . . . . . . . . . . . . . . . . . . . 38
Fuse Removal . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Fuse Replacement . . . . . . . . . . . . . . . . . . . . . . . 40
Surge Suppressor Removal . . . . . . . . . . . . . . . . 40
Surge Suppressor Replacement . . . . . . . . . . . . 40
PLC Interface Accessory Kit Service . . . . . . . . . . 42
Valve Assembly Bank. . . . . . . . . . . . . . . . . . . . . 42
Pressure Switch Assembly Replacement. . . . . . 42
Pneumatic Logic Panel Service. . . . . . . . . . . . . . . 44
Filter/Element Replacement . . . . . . . . . . . . . . . . 44
Ram Assembly Service . . . . . . . . . . . . . . . . . . . . . 45
Piston Rod Seal Service. . . . . . . . . . . . . . . . . . . 45
Ram Piston Service . . . . . . . . . . . . . . . . . . . . . . 46
Low/Empty Limit Switch Replacement . . . . . . . . 47
Depressurization Valve (Ball Seat Applicator)
Repair Procedure. . . . . . . . . . . . . . . . . . . . . 48
Replacing Wipers . . . . . . . . . . . . . . . . . . . . . . . . 48
Pump Removal . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Recycling and Disposal . . . . . . . . . . . . . . . . . . . . . 51
End of Product Life. . . . . . . . . . . . . . . . . . . . . . . 51
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Ram Assembly Troubleshooting. . . . . . . . . . . . . 52
Pump Troubleshooting . . . . . . . . . . . . . . . . . . . . 53
Air Motor Troubleshooting . . . . . . . . . . . . . . . . . 54
Junction Box Panel Troubleshooting . . . . . . . . . 54
Pneumatic Logic Panel Troubleshooting . . . . . . 55
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
246981, 248306, 249339, 253676, 258910 - 47:1
Left Hand Supply Unit . . . . . . . . . . . . . . . . . 56
246982, 248307, 249340, 253677, 258911 - 47:1
Right Hand Supply Unit . . . . . . . . . . . . . . . . 56

309028ZAT 3
249152, 249341, 234972, 258956 - 35:1 Left Hand
Supply Unit . . . . . . . . . . . . . . . . . . . . . . . . . 56
249153, 249342, 234973, 258957 - 35:1 Right Hand
Supply Unit . . . . . . . . . . . . . . . . . . . . . . . . . 56
24U642 - 35:1 Left Hand Supply Unit. . . . . . . . . 60
24U643 - 35:1 Right Hand Supply Unit . . . . . . . 60
232729, 47:1 Left Hand Supply Unit, with carbon
steel pump . . . . . . . . . . . . . . . . . . . . . . . . . . 64
232839, 47:1 Left Hand Supply Unit, with stainless
steel and ceramic pump. . . . . . . . . . . . . . . . 64
232730, 47:1 Right Hand Supply Unit, with carbon
steel pump (shown) . . . . . . . . . . . . . . . . . . . 64
232840, 47:1 Right Hand Supply Unit, with stainless
steel and ceramic pump. . . . . . . . . . . . . . . . 64
246921, 47:1 Right Hand Supply Unit, with stainless
steel pump . . . . . . . . . . . . . . . . . . . . . . . . . . 64
246922, 47:1 Left Hand Supply Unit, with stainless
steel pump . . . . . . . . . . . . . . . . . . . . . . . . . . 64
255666, 47:1 Left Hand Supply Unit, with carbon
steel pump . . . . . . . . . . . . . . . . . . . . . . . . . . 64
255665, 47:1 Right Hand Supply Unit, with carbon
steel pump . . . . . . . . . . . . . . . . . . . . . . . . . . 64
24N914 - 35:1 Left Hand Supply Unit. . . . . . . . . 67
24N915 - 35:1 Right Hand Supply Unit . . . . . . . 67
Depressurization Kit, 241840 . . . . . . . . . . . . . . . 71
Pneumatic Accessory Kit, 241837 . . . . . . . . . . . 72
Low/Empty Limit Kit (for Uni-Drum Use), 24183973
Proximity Switch Accessory Kit, 243488 . . . . . . 74
Follower Plate Assembly, 241891 and 243510 . 75
PLC Pneumatic Logic Panel. . . . . . . . . . . . . . . . 77
PLC Interface Accessory Kit, 241838 and 24V775
80
Junction Box Panel, 195320 and 119773. . . . . . 82
Follower Plate, 233041. . . . . . . . . . . . . . . . . . . . 84
Safety Pin Maintenance Kit, 26B772 . . . . . . . . . 86
Elevator Assembly, 241902 . . . . . . . . . . . . . . . . 88
Recommended Spare Parts . . . . . . . . . . . . . . . . . . 90
Spare Parts for Pump and Air Motor . . . . . . . . . 90
Spare Parts for 47:1 and 35:1 Uni-Drum Supply
Units. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Electrical Diagram . . . . . . . . . . . . . . . . . . . . . . . . . 91
Junction Box Panel. . . . . . . . . . . . . . . . . . . . . . . 91
Pneumatic Diagram . . . . . . . . . . . . . . . . . . . . . . . . 92
Technical Specifications . . . . . . . . . . . . . . . . . . . . 94
Models 248306, 248307, 249339, 249340, 253676,
253677. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Models 249152, 249153, 249341, 249342, 234972,
234973, 258956, 258957, 24U642, 24U643,
25N914, 25N915 . . . . . . . . . . . . . . . . . . . . . 95
Models 232729, 232730, 255665, 255666 . . . . . 96
Models 232839, 232840, 246921, 246922 . . . . . 97
California Proposition 65 . . . . . . . . . . . . . . . . . . . . 97
Graco Standard Warranty. . . . . . . . . . . . . . . . . . . . 98
Related Manuals
Dura-Flo™ and XL 10000™ are trademarks of Graco, Inc.
Manual in
English Description
308147 Carbon Steel Dura-Flo™ Pump 1800 with
XL 10000™ Air Motor
308151 Carbon Steel Dura-Flo™ Pump 2400 with
XL 10000™ Air Motor
308148 Stainless Steel Dura-Flo™ Pump 1800 with
XL 10000™ Air Motor
308152 Stainless Steel Dura-Flo™ Pump 2400 with
XL 10000™ Air Motor
334644 XL 10000™ Air Motor
3A1792 DV Series Dispense Valves
308213 XL 10000™ Air Motor

Models
4309028ZAT
Models
The Uni-Drum Supply Units listed below are covered in this manual. For specific pump information, refer to the chart
in Servicing the Pumps on page 48.
Supply Unit
Part No. Pump Ratio Voltage
Max. Outlet
Pressure
Max. Fluid Flow
@ 60 cpm
Pump
Manual
Platen
Material
246981 (Left
Hand)
XL 10000™, SST,
silicone nitride, ceramic 47:1 120V 4500 psi (31.0 MPa, 310 bar) 6.9 gpm (26 lpm) 308148
Carbon
Steel,
Painted
246982
(Right Hand)
XL 10000™, SST,
silicone nitride, ceramic 47:1 120V 4500 psi (31.0 MPa, 310 bar) 6.9 gpm (26 lpm) 308148
248306 (Left
Hand)
XL 10000™, SST,
silicone nitride 47:1 120V 4500 psi (31.0 MPa, 310 bar) 6.9 gpm (26 lpm) 308148
248307
(Right Hand)
XL 10000™, SST,
silicone nitride 47:1 120V 4500 psi (31.0 MPa, 310 bar) 6.9 gpm (26 lpm) 308148
249339 (Left
Hand)
XL 10000™, SST,
silicone nitride 47:1 24V 4500 psi (31.0 MPa, 310 bar) 6.9 gpm (26 lpm) 308148
249340
(Right Hand)
XL 10000™, SST,
silicone nitride 47:1 24V 4500 psi (31.0 MPa, 310 bar) 6.9 gpm (26 lpm) 308148
232729 (Left
Hand) XL 10000™, carbon steel 47:1 120V 4500 psi (31.0 MPa, 310 bar) 6.9 gpm (26 lpm) 308147
232730
(Right Hand) XL 10000™, carbon steel 47:1 120V 4500 psi (31.0 MPa, 310 bar) 6.9 gpm (26 lpm) 308147
232839 (Left
Hand)
XL 10000™, stainless
steel 47:1 120V 4500 psi (31.0 MPa, 310 bar) 6.9 gpm (26 lpm) 308148
232840
(Right Hand)
XL 10000™, stainless
steel 47:1 120V 4500 psi (31.0 MPa, 310 bar) 6.9 gpm (26 lpm) 308148
246921 (Left
Hand)
XL 10000™, stainless
steel 47:1 120V 4500 psi (31.0 MPa, 310 bar) 6.9 gpm (26 lpm) 308148
246922
(Right Hand)
XL 10000™, stainless
steel 47:1 120V 4500 psi (31.0 MPa, 310 bar) 6.9 gpm (26 lpm) 308148
*253676
(Left Hand)
XL 10000™, stainless
steel 47:1 120V 4500 psi (31.0 MPa, 310 bar) 6.9 gpm (26 lpm) 308148
*253677
(Right Hand)
XL 10000™, stainless
steel 47:1 120V 4500 psi (31.0 MPa, 310 bar) 6.9 gpm (26 lpm) 308148
*258910
(Left Hand)
XL 10000™, stainless
steel 47:1 24V 4500 psi (31.0 MPa, 310 bar) 6.9 gpm (26 lpm) 308148
*258911
(Right Hand)
XL 10000™, stainless
steel 47:1 24V 4500 psi (31.0 MPa, 310 bar) 6.9 gpm (26 lpm) 308148
249152 (Left
Hand)
XL 10000™, stainless
steel 35:1 120V 3400 psi (23.1 MPa, 231 bar)
9.2 gpm (34.8
lpm) 308152
249153
(Right Hand)
XL 10000™, stainless
steel 35:1 120V 3400 psi (23.1 MPa, 231 bar)
9.2 gpm (34.8
lpm) 308152
*234972
(Left Hand)
XL 10000™, stainless
steel 35:1 120V 3400 psi (23.1 MPa, 231 bar)
9.2 gpm (34.8
lpm) 308152
*234973
(Right Hand)
XL 10000™, stainless
steel 35:1 120V 3400 psi (23.1 MPa, 231 bar)
9.2 gpm (34.8
lpm) 308152

Models
309028ZAT 5
* For LASD applications, outlet ball valves, fittings and
manifolds are stainless steel. All other models, if
equipped with ball valves, fittings, and a manifold,
are carbon steel.
† Models are for conveyors by others (unit does not
have guides or end stops). The end user is
responsible for mounting drum clamps and drum in
position sensor.
*258956
(Left Hand)
XL 10000™, stainless
steel 35:1 24V 3400 psi (23.1 MPa, 231 bar)
9.2 gpm (34.8
lpm) 308152
Carbon
Steel,
Painted
*258957
(Right Hand)
XL 10000™, stainless
steel 35:1 24V 3400 psi (23.1 MPa, 231 bar)
9.2 gpm (34.8
lpm) 308152
249341 (Left
Hand)
XL 10000™, stainless
steel 35:1 24V 3400 psi (23.1 MPa, 231 bar)
9.2 gpm (34.8
lpm) 308152
249342
(Right Hand)
XL 10000™, stainless
steel 35:1 24V 3400 psi (23.1 MPa, 231 bar)
9.2 gpm (34.8
lpm) 308152
255666 (Left
Hand) XL 10000™, carbon steel 47:1 24V 4500 psi (31.0 MPa, 310 bar) 6.9 gpm 26 lpm) 308147
255665
(Right Hand) XL 10000™, carbon steel 47:1 24V 4500 psi (31.0 MPa, 310 bar) 6.9 gpm (26 lpm) 308147
24U642 (Left
Hand)
XL 10000™, stainless
steel 35:1 24V 3400 psi (23.1 MPa, 231 bar)
9.2 gpm (34.8
lpm) 308152
24U643
(Right Hand)
XL 10000™, stainless
steel 35:1 24V 3400 psi (23.1 MPa, 231 bar)
9.2 gpm (34.8
lpm) 308152
†*25N914
(Left Hand)
XL 10000™, stainless
steel 35:1 120V 3400 psi (23.1 MPa, 231 bar)
9.2 gpm (34.8
lpm) 308152
†*25N915
(Right Hand)
XL 10000™, stainless
steel 35:1 120V 3400 psi (23.1
MPa, 231 bar)
9.2 gpm (34.8
lpm) 308152
Supply Unit
Part No. Pump Ratio Voltage
Max. Outlet
Pressure
Max. Fluid Flow
@ 60 cpm
Pump
Manual
Platen
Material

Warnings
6309028ZAT
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The
exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks.
When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings.
Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this
manual where applicable.
WARNING
MOVING PARTS HAZARD
Moving parts can pinch, cut or amputate fingers and other body parts.
• Keep clear of moving parts.
• Keep your hands away from the follower plate and the lip of the drum while the ram is operating.
• Keep your hands away from the ram frame while the ram is operating.
• Do not operate equipment with protective guards or covers removed.
• Equipment can start without warning. Before checking, moving, or servicing equipment, follow the
Pressure Relief Procedure and disconnect all power sources.
SKIN INJECTION HAZARD
High-pressure fluid from gun, hose leaks, or ruptured components will pierce skin. This may look like
just a cut, but it is a serious injury that can result in amputation. Get immediate surgical treatment.
• Do not spray without tip guard and trigger guard installed.
• Engage trigger lock when not spraying.
• Do not point gun at anyone or at any part of the body.
• Do not put your hand over the spray tip.
• Do not stop or deflect leaks with your hand, body, glove, or rag.
• Follow the Pressure Relief Procedure when you stop spraying and before cleaning, checking, or
servicing equipment.
• Tighten all fluid connections before operating the equipment.
• Check hoses and couplings daily. Replace worn or damaged parts immediately.
• Use only Graco approved hoses. Do not remove any spring guard that is used to help protect the hose
from rupture caused by kinks or bends near the couplings.

Warnings
309028ZAT 7
ELECTRIC SHOCK HAZARD
This equipment must be grounded. Improper grounding, setup, or usage of the system can cause
electric shock.
• Turn off and disconnect power at main switch before disconnecting any cables and before servicing
or installing equipment.
• Connect only to grounded power source.
• All electrical wiring must be done by a qualified electrician and comply with all local codes and
regulations.
FIRE AND EXPLOSION HAZARD
Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. Paint or
solvent flowing through the equipment can cause static sparking. To help prevent fire and explosion:
• Use equipment only in well-ventilated area.
• Eliminate all ignition sources; such as pilot lights, cigarettes, portable electric lamps, and plastic drop
cloths (potential static sparking).
• Ground all equipment in the work area. See Grounding instructions.
• Never spray or flush solvent at high pressure.
• Keep work area free of debris, including solvent, rags and gasoline.
• Do not plug or unplug power cords, or turn power or light switches on or off when flammable fumes
are present.
• Use only grounded hoses.
• Hold gun firmly to side of grounded pail when triggering into pail. Do not use pail liners unless they
are anti-static or conductive.
•Stop operation immediately if static sparking occurs or you feel a shock.Do not use equipment until
you identify and correct the problem.
• Keep a working fire extinguisher in the work area.
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not operate the unit when fatigued or under the influence of drugs or alcohol.
• Do not exceed the maximum working pressure or temperature rating of the lowest rated system
component. See Technical Specifications in all equipment manuals.
• Use fluids and solvents that are compatible with equipment wetted parts. See Technical
Specifications in all equipment manuals. Read fluid and solvent manufacturer’s warnings. For
complete information about your material, request Safety Data Sheets (SDSs) from distributor or
retailer.
• Turn off all equipment and follow the Pressure Relief Procedure when equipment is not in use.
• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine
manufacturer’s replacement parts only.
• Do not alter or modify equipment. Alterations or modifications may void agency approvals and create
safety hazards.
• Make sure all equipment is rated and approved for the environment in which you are using it.
• Use equipment only for its intended purpose. Call your distributor for information.
• Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.
• Do not kink or over bend hoses or use hoses to pull equipment.
• Keep children and animals away from work area.
• Comply with all applicable safety regulations.
WARNING

Warnings
8309028ZAT
SPLATTER HAZARD
Hot or toxic fluid can cause serious injury if splashed in the eyes or on skin. During blow off of platen,
splatter may occur.
• Use minimum air pressure when removing platen from drum.
TOXIC FLUID OR FUMES HAZARD
Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled, or
swallowed.
• Read Safety Data Sheets (SDSs) to know the specific hazards of the fluids you are using.
• Store hazardous fluid in approved containers, and dispose of it according to applicable guidelines.
PERSONAL PROTECTIVE EQUIPMENT
Wear appropriate protective equipment when in the work area to help prevent serious injury, including
eye injury, hearing loss, inhalation of toxic fumes, and burns. Protective equipment includes but is not
limited to:
• Protective eyewear, and hearing protection.
• Respirators, protective clothing, and gloves as recommended by the fluid and solvent manufacturer.
WARNING

Uncrating the System
309028ZAT 9
Uncrating the System
The Uni-Drum Supply System was carefully packaged
for shipment by Graco. When the system arrives,
perform the following procedure to uncrate the system.
To uncrate the system, perform the following steps:
1. Inspect the crate carefully for shipping damage.
Contact the carrier promptly if damage is
discovered.
2. Remove the plywood sides and top of the crate.
3. Inspect the contents carefully. There should not be
any loose or damaged parts.
4. Compare the packing slip against all items included
in the crate. Report any shortages or other
inspection problems immediately.
5. Remove the band straps that hold the Uni-Drum to
the pallet.
6. The Uni-Drum is ready for installation. Before
installing the system, read the General Description
section on page 18 to become familiar with the
system components.
Overview
Installation Overview
The location of the Uni-Drum should allow for easy
loading and unloading of the 300 gallon (1200 liter)
magnadrum or other tote drums with either a forklift
truck or pallet-jack hand truck.
The Uni-Drum Supply System must be leveled and
mounted on a horizontal floor. An unleveled condition
can keep the Uni-Drum from operating properly.
Anchor the frame’s four foot pads securely to the floor.
The anchor bolts should be sized with sufficient safety
factor to withstand the downward force of the follower
plate and other objects that can push the frame off the
floor.
Operation Overview
The Uni-Drum is a supply system that evacuates fluids
from a 300 gallon (1200 liter) magnadrum or other tote
drums.
Each Uni-Drum includes two Graco air motors and
displacement pumps, a ram assembly with a follower
plate, a pneumatic layout panel that controls the air
components and a junction box panel that connects with
an electrical controller (supplied by the customer).
In short, the operator places the magnadrum inside the
frame with the follower plate placed directly on top of the
material. Locally, the system can be operated using the
pneumatic layout panel. Remotely, the system can be
operated using signals through the junction box panel.
Two displacement pumps evacuate material out of each
magnadrum. After removing the empty drum from the
system, the operator repeats the evacuation process
when another drum is ready for evacuation.
NOTICE
Moving the unit off of the pallet without following the
uncrating procedure can damage the equipment.

Component Identification
10 309028ZAT
Component Identification
NOTE: F IG . 1, F IG . 2, and F IG . 3 shows the typical Uni-Drum Supply System equipped with XL 10000™ air motors.
Uni-Drum Supply System with Customer Mounted Manifold and
Drum Clamps
Key:
A Left Hand (LH) Supply Unit
B Right Hand (RH) Supply Unit
C Dura-Flo 1800 Pumps with XL 10000 Air Motors (2
units)
D Follower Plate
E Main Air Inlet
F Pneumatic Panel Air Filter
G Pneumatic Logic Panel
H Junction Box Panel
J Drum Lid Holders
K Drum Clamps (installed by end user)
L Drum in Position Switch (installed by end user)
M Safety Pins
N Main Air Filter
P Main Air Shutoff Valve
Q Bleed Port
R Follower Vent
S Limit Switches
F IG . 1: Uni-Drum Supply System with XL 10000 Air Motors
A - Left Hand Unit B - Right Hand Unit
P
G
H
C
G
F
K
D
N
G
H
C
H
F
KD
L
E
N
PE
Q
Q
R
R
J
S
S
M
MM
M
Left Hand Models Right Hand Models
25N914 25N915

Component Identification
309028ZAT 11
Uni-Drum Supply System with Machine Mounted Manifold
Key:
A Left Hand (LH) Supply Unit
B Right Hand (RH) Supply Unit
C Dura-Flo 1800 Pumps with XL 10000 Air Motors (2
units)
D Follower Plate
E Main Air Inlet
F Pneumatic Panel Air Filter
G Pneumatic Logic Panel
H Junction Box Panel
J Drum Lid Holders
M Safety Pins
N Main Air Filter
P Main Air Shutoff Valve
Q Bleed Port
R Follower Vent
S Limit Switches
F IG . 2: Uni-Drum Supply System with XL 10000 Air Motors
A - Left Hand Unit B - Right Hand Unit
N
G
HC
H
F
D
J
N
G
H
C
H
F
D
Q
RQ
R
E
EPP
S
S
M
M
M
Left Hand Models Right Hand Models
232729 232730
232839 232840
246921 246922
255666 255665
24H017 24H016
24U642 24U643

Component Identification
12 309028ZAT
Uni-Drum Supply System with Customer Mounted Manifold
Key:
A Left Hand (LH) Supply Unit
B Right Hand (RH) Supply Unit
C Dura-Flo 1800 Pumps with XL 10000 Air Motors (2
units)
D Follower Plate
E Main Air Inlet
F Pneumatic Panel Air Filter
G Pneumatic Logic Panel
H Junction Box Panel
J Drum Lid Holders
M Safety Pins
N Main Air Filter
P Main Air Shutoff Valve
Q Bleed Port\
R Follower Vent
S Limit Switches
F IG . 3: Uni-Drum Supply System with XL 10000 Air Motors
A - Left Hand Unit B - Right Hand Unit
E
G
H
C
H
F
D
E
G
H
C
H
F
D
J
N
N
P
Q
R
Q
R
S
S
P
M
MM
Left Hand Models Right Hand Models
246981 246982
248306 248307
249339 249340
253676 253677
258910 258911
249152 249153
249341 249342
234972 234973
258956 258957

Component Identification
309028ZAT 13
Pneumatic Logic Panel
F IG . 4: Pneumatic Logic Panel
TI0202
FOLLOWER VENT
AUTO OPEN
24K172 Panel Shown
AA
AD
AC
AF
AB
AE
AG
AH

Component Identification
14 309028ZAT
F IG . 5: Pneumatic Logic Panel Interior
AJ
AK
AL

Component Identification
309028ZAT 15
Pneumatic Logic Panel Switches and Indicators
Use the table and F IG . 4 when operating the switches and reading the indicators on the Pneumatic Logic Panel (G).
Ref. Button/Switch/Guage What it Does
AA PUMP NO. 1 PRESSURE Air Gauge Indicates the air outlet pressure setting from Pump No. 1.
AB PUMP NO. 2 PRESSURE Air Gauge Indicates the air outlet pressure setting from Pump No. 2.
AC PUMP NO. 1 REGULATOR Control Knob Controls Pump speed and outlet pressure by adjusting the
air pressure to Pump No. 1.
AD FOLLOWER VENT Directional Valve Opens and closes the vent that relieves air pressure from
the Follower Plate (D).
AE PUMP NO. 2 REGULATOR Control Knob Controls Pump speed and outlet pressure by adjusting the
air pressure to Pump No. 2.
AF RAM UP Pushbutton Raises the Follower Plate (D) when the RAM POSITION
Switch (AG) is set to RAISE.
AG RAM POSITION
Switch
RAISE Allows the Follower Plate (D) to raise.
HOLD/NEUTRAL Holds the Follower Plate (D) in the current position.
LOWER Lowers the Follower Plate (D).
AH Panel Air Inlet Valve Opens air supply line to the Pneumatic Logic Panel (G).
AJ RAM UP Air Regulator Controls the air pressure used to raise the ram assembly.
AK RAM DOWN Air Regulator Controls the air pressure used to lower the ram assembly.
AL R3 Regulator
Maintains air pressure on top of the ram cylinders to
prevent the Follower Plate (D) from raising too quickly out
of the drum.

Component Identification
16 309028ZAT
Junction Box Panel
F IG . 6: Junction Box Panel
BULK SUPPLY
DEPRESSURIZATION
SYSTEM
PRESSURIZED
PUMP
ACTIVE
AIR PRESS
ON
RAM
READY
PUMP
READY
PRIME
PUMP
PUMP
RESET
PUMP
ON
LOCAL REMOTE
MODE
REMOTE
195320 and 119773 Panel Shown

Component Identification
309028ZAT 17
Junction Box Panel Switches and Indicators
Use the table and F IG . 6 when operating the switches and reading the indicator on the Junction Box Panel.
Button/Switch What it Does
PRIME PUMP Pushbutton • Primes both displacement Pumps with material, making the
Pumps ready to operate.
• Lights PUMP READY Light.
PUMP RESET Pushbutton • Restarts the Pumps after the Pumps were turned off.
• Lights PUMP ACTIVE Light
PUMP ON Pushbutton • Activates the Pumps.
• Deactivates the Pumps.
BULK SUPPLY
DEPRESSURIZATION Pushbutton
• Opens the depressurization valve to lower the fluid supply
pressure.
LOCAL REMOTE Switch • Places fluid dispensing system into Automatic or Manual mode.
Indicator Indicator
Light is Meaning
SYSTEM
PRESSURIZED Light
ON System is pressurized.
OFF System is depressurized.
PUMP ACTIVE Light ON Pumps are active; air is available to the Pumps.
OFF Pumps are inactive; air is unavailable to the Pumps.
AIR PRESS ON Light ON Air pressure is available to the Pumps for use.
OFF Air pressure is not available to the Pumps for use.
RAM READY Light ON Follower Plate (D) is ready for use.
OFF Follower Plate (D) is not ready for use.
PUMP READY Light ON Pumps are primed and ready to use.
OFF Pumps are not ready to use.

Component Identification
18 309028ZAT
General Description
A general description of the Uni-Drum Supply System
helps the installers and operators become familiar with
the system components. Contact your Graco distributor
for help in choosing accessories to suit your particular
needs.
Before you install the system, you should be familiar
with the parts described in the following paragraphs.
System Components
See F IG . 1 on page 10.
•Uni-Drum Supply Unit (A,B) is usually setup to
alternate the material supply operation between the
left hand (LH) and right hand (RH) Supply Units,
which is accomplished using a combination of
robotic software programming (provided by others)
and manual operators. Drum changeovers occur
after the Follower Plate (D) has reached its preset
low limit level in the drum. Alternating between
Supply Units eliminates the downtime that is usually
expended unloading an empty drum and reloading a
full drum.
- LH Supply Unit (A) accommodates one 300
gallon (1200 liter) drum. The LH Supply Unit
has a local Pneumatic Logic Panel (G) and
Junction Box Panel (H).
- RH Supply Unit (B) accommodates one 300
gallon (1200 liter) drum. The RH Supply Unit
has a local Pneumatic Logic Panel (G) and
Junction Box Panel (H).
• The two Dura-Flo™ 1800 Pumps (C) have XL
10000™ air motors. The Pumps evacuate material
from the drum.
•The Follower Plate (D) is connected to the ram
assembly and is designed to apply an even amount
of pressure to the material in the drum. With the
Follower Plate in its raised position, the operator
moves a drum inside the frame. The Follower Plate
is lowered directly on top of the material in the drum.
When pressure is applied to the Follower Plate, the
material is pumped out of the drum through hoses,
which are attached to the Pump outlet ports. When
the drum is empty, the operator raises the Follower
Plate, removes the empty drum. The process is
repeated when another drum is ready to be
unloaded.
•Pneumatic Panel Air Filter (F) filters air to the
Pneumatic Logic Panel (G). The 5 micron filter
removes particles, such as dust, moisture, foreign
matter and other contaminants from the
compressed air.
•TheSafety Pins (M) are used to keep the ram from
lowering while in the fully raised position during
drum changes or maintenance of the supply
system.
•Main Air Shutoff Valve (P) is used to open or
shutoff the air supply to the entire Supply Unit (A,B).
Pneumatic Logic Panel (G)
See F IG . 4 on page 13 and F IG . 5 on page 14.
The Pneumatic Logic Panel (G) includes the following
system components. For more information, refer to the
Pneumatic Diagram on page 92.
• PUMP NO. 1 REGULATOR Control Knob (AC)
controls Pump speed and outlet pressure for Pump
No. 1 by adjusting the air pressure to the Pump.
• PUMP NO. 1 PRESSURE Air Gauge (AA) displays
the amount of air pressure supplied to Pump No. 1.
• PUMP NO. 2 REGULATOR Control Knob (AE)
controls Pump speed and outlet pressure for Pump
No. 2 by adjusting the air pressure to the Pump.
• PUMP NO. 2 PRESSURE Air Gauge (AB) displays
the amount of air pressure supplied to Pump No. 2.
• FOLLOWER VENT Directional Valve (AD) is
activated to open the vent to relieve container
pressure.
• RAM UP Pushbutton (AF) turns on air pressure to
raise the Follower Plate (D) when used in
conjunction with the RAM POSITION Switch (AG).
• The RAM POSITION Switch (AG) performs the
following three functions:
- Place the switch in the RAISE position to raise
the Follower Plate (D).
- Place the switch in the HOLD/NEUTRAL
position to hold the Follower Plate (D) in the
current position.
- Place the switch in the LOWER position to
lower the Follower Plate (D).

Component Identification
309028ZAT 19
Junction Box Panel (H)
See F IG . 6 on page 16.
The Junction Box Panel (H) includes the following
system components. For additional information, refer to
the Electrical Diagram on page 91.
• SYSTEM PRESSURIZED Light is lit when air
pressure is supplied to the system; the light is
extinguished when the air supply is depressurized.
This occurs after the PUMP ON Pushbutton has
been pushed and the Pumps turned on.
• PUMP ACTIVE Light is lit when the air supply is
turned on to the Pumps; the light is extinguished
when the Pumps are inactive, thus turned off. This
is activated by the PUMP ON Pushbutton.
• AIR PRESS ON Light is lit when air pressure to the
system is turned on; the light is extinguished when
air pressure to the system is shutoff.
• RAM READY Light is lit when the drum is in
position; the light is extinguished when the drum is
not in position.
• PUMP READY Light is lit when the Pumps are
primed and ready for operation; the light is
extinguished when the Pumps are not ready for
operation.
• PRIME PUMP Pushbutton turns on the Pumps, for
priming. When the Pumps are primed, the PUMP
READY Light turns on. The switch is not used when
the PUMP READY Light is lit. The PUMP ACTIVE
Light will blink.
• PUMP RESET Pushbutton resets the Pumps to an
active state. When the Pumps are reset, the PUMP
ACTIVE Light turns off. The switch is not used when
the PUMP ACTIVE Light is lit. The PUMP READY
Light is on.
• PUMP ON Pushbutton turns the Pumps on and off.
When the Pumps are turned on, the PUMP ACTIVE
Light also turns on. When the Pumps are turned off,
the PUMP ACTIVE Light also turns off.
• BULK SUPPLY DEPRESSURIZATION Pushbutton
opens the depressurization valve to lower the fluid
pressure.
• LOCAL REMOTE Switch puts the system into or out
of automatic operation.

Installation
20 309028ZAT
Installation
The installation procedures in this section are intended
to serve as a guide for installing the Uni-Drum Supply
System. If you need more information, contact your
Graco distributor.
NOTE: When raising and lowering the Ram, be sure
that the unit is unobstructed overhead to avoid
interference with other objects.
Preparing the Site
Ensure that you have an adequate compressed air supply.
Refer to the applicable instruction manual listed in Related
Manuals on page 3 to find the air consumption of your
Pump. Approximately 450 cfm at 80 psi is required to
operate the Pumps at the maximum rate.
Keep the site clear of any obstacles or debris that could
interfere with the installer’s and operator’s movement.
Selecting a Location for the
Uni-Drum
Refer to Technical Specifications on page 94 for ram
mounting and clearance dimensions.
When selecting a location for the Uni-Drum, keep the
following in mind:
1. There should be sufficient space for installing,
servicing, and using the equipment.
• Select an accessible location for the system.
There must be sufficient space around the
system for maintenance.
• Select a convenient location for the equipment.
Check that there is sufficient overhead clearance
for the Pump and ram when the ram is in the fully
raised position. Make sure the Air Regulators
(AC, AE) for the Pumps (C) and Follower Plate
(D) are fully accessible.
• Make sure the air source for the PLC control
panel and shutoff valves are fully accessible.
• Make sure there is easy and safe access to an
appropriate pneumatic source. Graco
recommends a minimum of 3 feet (0.91 m) of
open space in front of the Pneumatic Logic Panel
(G).
2. Make sure that you will be able to level the base of
the ram using metal shims.
Preparing to Install the
Uni-Drum
Before installing the system:
• See component manuals for specific data on
component requirements. Data presented here
pertains to the system only.
• Have all system and subassembly documentation
available during installation.
• Be sure that all non-Graco supplied hoses are
adequately sized and pressure-rated to meet the
system requirements.
The Uni-Drum Supply System is supplied with every
major component attached and weighs approximately
3950 lb (1792 kg). The Uni-Drum Supply System
should never be moved or lifted by one person. To
avoid serious injury or equipment damage, engage an
adequate number of personnel and use a forklift,
hand truck, and support devices, such as a hoist
when moving and installing the Uni-Drum.
NOTICE
Exercise care when the system is being moved to its
installed location. Jarring, dropping, or tilting the frame
while it is being lifted or moved can result in damage to
the system.
