Graco Hopper 24B250 User manual

313606A
Instructions
Hopper Kit 24B250 for
FinishPro™ 290 Sprayer
- This manual contains kit installation instructions only -
Pressure Relief Procedure
1. Turn Power switch OFF. Unplug sprayer.
2. Turn Spray/Prime valve to PRIME to relieve pres-
sure. Turn pressure control knob left (counterclock-
wise) to minimize pressure.
3. Trigger gun.
4. Put trigger safety in safety ON position.
NOTE: Leave Spray/Prime valve in the PRIME position
until you are ready to spray again.
If you suspect that the spray tip or hose is completely
clogged or that pressure has not been fully relieved after
following the steps above, VERY SLOWLY loosen the tip
guard retaining nut or hose end coupling to relieve pres-
sure gradually. Then loosen it completely. Clear the tip or
hose obstruction.
Important Safety Instructions
For detailed sprayer information and warnings,
see Operation manual 313316 included with
FinishPro 290 Sprayer.
To help prevent injection injuries, follow this procedure
when you stop spraying and before you service or
clean the sprayer, remove parts, or repair leaks.
Ref. Part Description Qty.
1 188787 HOPPER, 1.5 gallon 1
2 112133 SCREEN, hopper 1
3 104938 PACKING, o-ring 1
4 257518 TUBE, inlet hopper 1
5 15B652 WASHER, suction 1
6 117559 O-RING 2
7 15E813 NUT, jam 1
8 15Y587 TUBE, drain, hopper kit 1
9 115489 CLAMP, drain tube 2
10 244035 DEFLECTOR, barbed 1
ti11868a
ti13684a
7
6
1
2
3
4
910
8
5

Hopper Kit 24B250
2313606A
Hopper Kit 24B250
Installation
1. Relieve pressure.
2. Loosen jam nut and remove suction set.
3. Remove drain tube.
4. Remove hopper lid. Insert hopper into pump.
5. Tighten jam nut until hopper does not move.
6. Replace drain tube with longer tube and place into
hopper. Push drain tube fully onto barbs with hose
clamps in place.
7. Replace hopper lid.
ti13688a
ti13687a
ti3134b ti13686a
ti13689a
ti13685a
All written and visual data contained in this document reflects the latest product information available at the time of publication.
Graco reserves the right to make changes at any time without notice.
