Graco M73109 A Series Operation manual

308–422
Rev. B
Supersedes A
03015
03016A
Series 700 and 900
Series 800
INSTRUCTIONS-PARTS LIST
INSTRUCTIONS
This manual contains important
warnings and information.
READ AND KEEP FOR REFERENCE.
Series 700, 800, and 900
T urbine Sprayers
120 V AC 50/60 Hz: Series 700 and 900
120 VAC 60 Hz: Series 800
Maximum Working Pressure:
Series 700 and 800: 5 psi (0.34 bar)
Series 900: 6 psi (0.41 bar)
Model M73109, Series A
Complete Series 700 T urbine, with hose and turbine gun
Model M73111, Series A
Basic Series 700 T
urbine, without hose or gun
Model M73154, Series A
Complete Series 800 T urbine,
with remote 2 qt cup, hose, and turbine gun
Model M73157, Series A
Basic Series 800 T
urbine, without hose or gun
Model M73331, Series A
Complete Series 900 T urbine, with hose and turbine gun
Model M73333, Series A
Basic Series 900 T
urbine, without hose or gun
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
COPYRIGHT 1994, GRACO INC.
Graco Inc. is registered to I.S. EN ISO 9001

  
Table of Contents
Warnings 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General Information 5. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications 6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions 6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setup 7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shutdown 11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance 12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting 13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Repair 14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts 18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessories 24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warranty Back Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Symbols
Warning Symbol
WARNING
This symbol alerts you to the possibility of serious
injury or death if you do not follow the instructions.
Caution Symbol
CAUTION
This symbol alerts you to the possibility of damage to
or destruction of equipment if you do not follow the
instructions.
WARNING
FIRE AND EXPLOSION HAZARD
Improper grounding, poor ventilation, open flames or sparks can cause a hazardous condition and
result in a fire or explosion and serious injury
.
D Ground the equipment and the object being sprayed. Refer to Grounding on page 8.
D If there is any static sparking or you feel an electric shock while using this equipment, stop spray-
ing immediately . Do not use the equipment until you identify and correct the problem.
D Provide fresh air ventilation to avoid the buildup of flammable fumes from solvents or the fluid
being sprayed.
D When flammable liquid is sprayed or used for flushing or cleaning the equipment, the turbine must
be placed at least 20 feet (6.1 m) away from areas where hazardous concentrations of flammable
vapors are likely to occur .
D
Use additional air hose if necessary to ensure that the turbine is operated in a clean, dry , well
ventilated area.
D Never place the turbine inside a spray booth! Use this equipment outdoors or in extremely well
ventilated areas.
D Keep the spray area free of debris, including solvent, rags, and gasoline.
D Electrically disconnect all equipment in the spray area.
D Extinguish all open flames or pilot lights in the spray area.
D Do not smoke in the spray area.
D Do not turn on or of f any light switch in the spray area while operating or if fumes are present.
D Do not operate a gasoline engine in the spray area.


WARNING
INSTRUCTIONS
EQUIPMENT MISUSE HAZARD
Equipment misuse can cause the equipment to rupture or malfunction and result in serious injury .
D This equipment is for professional use only .
D
Read all instruction manuals, tags, and labels before operating the equipment.
D Use the equipment only for its intended purpose. If you are not sure, call Graco T echnical Assis -
tance at 1–800–543–0339.
D Do not alter or modify this equipment.
D Check equipment daily . Repair or replace worn or damaged parts immediately .
D
Do not exceed the maximum working pressure of the lowest rated system component. The Series
700 and 800 turbines have a working pressure of 5 psi (0.34 bar) and the Series 900 has a working
pressure of 6 psi (0.41 bar).
D Use fluids and solvents which are compatible with the equipment wetted parts. Refer to the Speci-
fications
on page 6 for this information.
D Do not use hoses to pull equipment.
D Route hoses away from traffic areas, sharp edges, moving parts, and hot surfaces. Do not expose
Graco hoses to temperatures above 82 _ C (180 _ F) or below –40 _ C (–40 _F).
DW
ear hearing protection when operating this equipment.
D Do not lift pressurized equipment.
D Comply with all applicable local, state, and national fire, electrical, and safety regulations.
D Do not point the gun at anyone or at any part of the body .
D
Do not put your hand or fingers over the gun fluid nozzle.
D Do not stop or deflect leaks with your hand, body , glove or rag.
D Do not “blow back” fluid; this is not an air spray system.
D Follow the Pressure Relief Procedure on page 1 1 if the fluid nozzle clogs and before cleaning,
checking or servicing the equipment.
DT ighten all fluid connections before operating the equipment.
D Check the hoses, tubes, and couplings daily . Replace worn or damaged parts immediately .

  
WARNING
TOXIC FLUID HAZARD
Hazardous fluid or toxic fumes can cause serious injury or death if splashed in the eyes or on the skin,
inhaled, or swallowed.
D Know the specific hazards of the fluid you are using.
D Store hazardous fluid in an approved container . Dispose of hazardous fluid according to all local,
state and national guidelines.
D Always wear protective eyewear , gloves, clothing and respirator as recommended by the fluid and
solvent manufacturer .
D
Do not use 1,1,1-trichloroethane, methylene chloride, other halogenated hydrocarbon solvents or
fluids containing such solvents in the turbine spray system, which contains aluminum and/or galva -
nized-coated parts. Such use could result in a serious chemical reaction, with the possibility of
explosion, which could cause death, serious injury , and/or substantial property damage.
CAUTION
CSA Certification of this sprayer is valid only when used with the following Graco hoses:
M71452 M71453
M71454 M71455
M71631 M71633
M71481 M71484
M71485 M71486
Manual Change Summary
Changed all model numbers from CX–7, CX–8, and CX–9, to Series 700, Series 800, and Series 900, respectively .
Also changed part numbers according to project 157F–07.


General Information
The Series 700, 800 and 900 T urbine Spray Guns can
spray most coatings or finishes currently being used
for automotive refinish, industrial, aerospace, marine,
wood, plastic and architectural applications.
This spray gun typically utilizes 5 psi (0.34 bar) for
Series 700 and Series 800 and 6 psi (0.41 bar) for the
Series 900 inbound air pressure to produce high
quality paint finishes. The gun produces a cone of air
that carries and directs the paint from the gun to the
surface, minimizing overspray and increasing transfer
efficiency . This enables painters to comply with new
clean air laws that are designed to reduce VOC (vola
-
tile organic compounds) emissions, eases paint
application by requiring fewer paint passes to obtain
coverage, and saves on both material and clean-up
time.
Refer to the turbine gun manual, 308–336, for more
information on the operation and use of the turbine
spray gun.
Unpack the Graco T urbine Sprayer from the shipping
carton and inspect for any possible shipping damage.
If necessary , call your distributor .
The contents of the Series 700 T
urbine Sprayer ,
Model M73109, includes:
D 1 Series 700 T urbine Sprayer , M73486
D1 T urbine Gun, M73200
D 1 25 ft. hose, M71452
D 1 Sprayer Instruction Manual, 308–422
D 1 Gun Instruction Manual, 308–336
The contents of the Series 700 bare sprayer , Model
M73111, includes:
D
1 Series 700 T urbine Sprayer , M73486
D 1 Sprayer Instruction Manual, 308–422
The contents of the Series 800 T urbine Sprayer ,
Model M73154, includes:
D
1 Series 800 T urbine Sprayer , M73487
D1 T urbine Gun, M73225
D 1 25 ft. hose, M71452
D 1 2 qt. cup, M70962
D 1 25 ft. braided air hose, M71631
D 10 wire ties, M71 179
D
1 Sprayer Instruction Manual, 308–422
D 1 Gun Instruction Manual, 308–336
The contents of the Series 800 bare sprayer , Model
M73157, includes:
D
1 Series 800 T urbine Sprayer , M73487
D 1 Sprayer Instruction Manual, 308–422
The contents of the Series 900 T urbine Sprayer ,
Model M73331, includes:
D
1 Series 900 T urbine Sprayer , M73488
D1 T urbine Gun, M73200
D 1 25 ft. hose, M71452
D 1 Sprayer Instruction Manual, 308–422
D 1 Gun Instruction Manual, 308–336
The contents of the Series 900 bare sprayer , Model
M73333, includes:
D
1 Series 900 T urbine Sprayer , M73488
D 1 Sprayer Instruction Manual, 308–422

  
Specifications
Power Requirements
Series 700, Series 900 120 V ac, 50/60 Hz . . . . . . . . . . .
Series 800 120 V ac, 60 Hz . . . . . . . . . . . . . . . . . . . . . . . .
Amps @ 120 volts
Series 700 1 phase, 12A minimum . . . . . . . . . . . . . . . . .
Series 800 1 phase, 12A minimum . . . . . . . . . . . . . . . . .
Series 900 1 phase, 12A minimum . . . . . . . . . . . . . . . . .
Power Cord No. 16 A WG, 3 wire, 10 ft (3 m) {. . . . . . .
CFM unrestricted
Series 700, Series 800 101 cfm . . . . . . . . . . . . . . . . . . . .
Series 900 1 15 cfm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turbine Stages 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maximum T urbine Hose Length
Series 700, Series 800 40 ft (12 m). . . . . . . . . . . . . . . . .
Series 900 60 ft (18 m). . . . . . . . . . . . . . . . . . . . . . . . . . .
Cup
Series
700, Series 900 1 qt (1 liter). . . . . . . . . . . . . . . . .
Series 800 2 qt (2 liter). . . . . . . . . . . . . . . . . . . . . . . . . . .
{ Extension cord must be 3-wire, 12 A WG; 100 ft or shorter .
is a registered trademark of the DuPont Corporation.
Locktite r is a registered trademark of the Locktite Corpora -
tion.
Wetted Parts
Bare Spray Gun Stainless Steel, Brass, PTFE, r. .
Hard-coated Aluminum
Spray Gun Cups Aluminum, Polyethylene . . . . . . . .
2 Quart Accessory Remote
Pressure Pot Aluminum, Brass, . . . . . . . . . . . . . . . .
Polyethylene
2-1/2 Gallon Accessory Remote
Pressure Pot Steel with . . . . . . . . . . . . . . . . . . . . . . .
solvent–resistant finish, EPDM Gasket (standard)
Series 800 Air Compressor
CFM 0.4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HP 1/30 hp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PSI 30 psi (1.03 bar) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turbine Shipping W eight (w/o pkg, hose, or gun)
Series 700 40 lb (18 kg) . . . . . . . . . . . . . . . . . . . . . . . . . .
Series 800 47 lb (21.3 kg) . . . . . . . . . . . . . . . . . . . . . . . . .
Series 900 46 lb (21 kg) . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions
Turbine Diameter
Series 700, Series 800 5.7 in (144.78 mm) . . . . . . . . . . .
Series 900 7.2 in (182.88 mm) . . . . . . . . . . . . . . . . . . . . .
PTFEPTFEPTFE

Fig. 1
A
B
B
2-1/2 Gallon Remote Pressure Pot
Part No. M70604 (see Accessories)
2 Quart Remote Pressure Pot
Part No. M70962
(see Accessories)
C
C
04958
X
Y
Y
Y
EE
DF
Series 800
T urbine shown
X
X
A
G
Z
ZZ
A
GG
E
Air Control V alve
(used to shut of f air
without shutting of f
turbine)
Air Control V alve
(used to shut of f
air without shut -
ting of f turbine)

Setup
NOTE: Refer to the turbine gun manual, 308–336, for
information on the operation and setup of the gun.
Connect the Fluid and Air Supply
1. Connect the hose to the gun.
2. Connect the gun air supply hose (A) between the
turbine air outlet (D) and the gun air inlet. DO
NOT use a wrench to tighten connections; hand–
tighten only . See Fig. 1.
3. If using a spray gun cup (B), connect the cup to
the gun fluid inlet.
4. For Series 800 only: If using an accessory remote
pressure pot (C), connect the fluid supply hose (G)
between the gun fluid inlet and the remote pres -
sure pot.
Connect the air hose (E) between the pressure pot
air inlet and the compressor air outlet (F).
NOTES:
D
The circled letters in Fig. 1 indicate hose line con -
nections.
D
Only the Series 800 turbine unit includes a com -
pressor for use with a remote pressure pot.
Connect to Electric Supply
1. Plug the sprayer power cord into a grounded
outlet.
2.
If an extension cord is used, it must be 3-wire, 12
A WG and 100 ft or less in length.

  
Setup
Grounding
WARNING
FIRE AND EXPLOSION HAZARD
Before operating the turbine sprayer ,
ground the system as explained below .
Also read the section FIRE OR EXPLO -
SION HAZARD on page 2.
1. Turbine: Plug the turbine power supply cord into a
properly grounded outlet. Do not remove the
grounding prong from the power cord. Do not use
an adapter .
2.
Extension cords: Extension cords must have three
wires and be rated for a minimum of 15 amps.
3. Fluid supply container: follow your local code.
4. Object being sprayed: follow your local code.
Prepare the Fluid
1. Always strain the fluid before spraying; this
includes color , reducer and hardeners if used.
2. When using a turbine spray system, you need to
use a slower drying reducer or thinner to compen -
sate for the faster drying time caused by the warm
air of the turbine. Do not over reduce.
CAUTION
The performance of the turbine sprayer will vary
with the viscosity of the material. Unnecessary hose
length will cause the air pressure to drop.
Paint Reduction – Automotive Type Finishes
Reduce and catalyze all paint to manufacturer ’ s speci -
fications. T o compensate for the faster drying time of
turbine systems, use a reducer one-step slower than
what is used for conventional air spray .
Paint Reduction – Industrial or Domestic Coatings
Reduce and catalyze all paint to manufacturer ’ s speci -
fications. If no reductions are given, first thoroughly
mix the fluid to be sprayed. Then gradually mix in the
proper reducer , testing the fluid until you have the
correct spraying consistency .
T o test the consistency: Remove the stir stick from the
thinned paint. When the paint stream running of
f the
stir stick breaks into droplets, the first few drops should
be about one second apart.


Setup
Fill the Cup or Remote Pressure Pot
Spray Gun Cup
WARNING
The spray gun cup is pressurized by the gun’ s air
supply. T o reduce the risk of serious injury from
pressurized fluid or accidental spray from the gun,
always turn of f the air supply to the gun before
removing the spray gun cup.
Only fill the cup 3/4 full to help keep the air pressure
tube clean, then install the cover
. The under-cup cover
has a latch (H) to secure it to the cup. The over-cup
has a ring with notches (J) that secures the cup hood
into place when locked in place on the cup.
Fig. 2 
H
J

Accessory Remote Pressure Pot
WARNING
The accessory remote pressure pots remain pres -
surized until pressure is manually relieved. T o
reduce the risk of serious injury from pressurized
fluid or accidental spray from the gun, always
relieve pressure in the pressure pot before loosen -
ing or removing the cover .
1. Relieve the remote pressure pot pressure by
following these steps:
a. T urn of f the air supply to the pressure pot.
b. 2 Quart Remote Pot: T urn out the pressure
relief knob (1 13) about one turn. W ait until
pressure is completely relieved before remov -
ing the cover . Close the knob before using the
system again. See Fig. 3.
Fig. 3

113
2 quart
2. Remove the pressure pot cover and fill the pres -
sure pot. Secure the cover .
NOTE: 2 quart remote pressure pot only: lightly coat
the cover threads with petroleum jelly .
CAUTION
If the 2 quart remote pressure pot is accidentally
tipped over or held at too great of an angle, fluid may
leak into the air regulator . T ake precautions to avoid
this. If fluid does get into the regulator , clean it
immediately.
CAUTION
Do not tighten the pressure pot cover more than
hand-tight. Excessive tightening may damage the
cover gasket.

10  308-422
Setup
Prepare the Surface to be Sprayed
To achieve proper adhesion, make sure the surface to
be sprayed is completely clean.
Operating the Turbine
WARNING
Sparking can be expected in the normal operation
of the turbine motor . Sparks could ignite fumes
from flammable liquid, dust particles and other
flammable substances in the spray area, and
cause serious injury and property damage. Be sure
to follow the precautions below:
D When flammable liquid is sprayed or used for
flushing or cleaning equipment, the turbine must
be placed at least 20 feet (6.1 m) away from
areas where hazardous concentrations of
flammable vapors are likely to occur .
D
Use additional air hose if necessary to ensure
that the turbine is operated in a clean, dry , well
ventilated area.
D Never place the turbine inside a spray booth!
Use this equipment outdoors or in extremely
well ventilated areas.
DA void all ignition sources such as static electric -
ity from plastic drop cloths, open flames such as
pilot lights, hot objects such as cigarettes, arcs
from connecting or disconnecting power cords
or turning light switches on and of f. Extinguish
or remove all sources of ignition.
1. T urn the turbine on a few minutes before you start
spraying to allow for warm-up time.
NOTE: When the turbine is not in use for an extended
period of time, turn it of f. The turbine does not shut of f
automatically.
2. Be sure the turbine filter is clean before operating.
See page 12 to check and clean the filter .
NOTE: T o adjust the spray gun pattern, see the
turbine gun manual 308–336.
Series 800 Cold W eather Operation
T urbine Spray Model Series 800 has a diaphragm
compressor . When this compressors is new , the
diaphragm will become stiff in cold weather . If cold
enough, the stif f diaphragm will not allow the compres -
sor to start (the unit will hum). If this occurs, follow
these steps:
1. T urn the turbine and compressor of f.
2.
Unplug the turbine from the power source.
3. Loosen the four main filter screws and remove the
filter; replace the main filter and pre-filter if they
are dirty .
4.
Hand spin the cooling fan on the compressor for a
few revolutions.
5. Reassemble the turbine.
6. Plug in the turbine and turn compressor on. The
compressor should start.

308-42211
Shutdown
Pressure Relief Procedure
WARNING
PRESSURIZED EQUIPMENT HAZARD
The equipment stays pressurized until pressure is
manually relieved. To reduce the risk of a serious
injury from pressurized fluid, accidental spray from
the gun, or splashing fluid, follow the Pressure Re -
lief Procedure whenever you:
D are instructed to relieve the pressure,
D stop spraying,
D check or service any of the system equipment,
D or install or clean the fluid nozzles.
1. When spraying is finished, release the gun trigger
and turn of f the air supply to the gun.
2. T urn of f the turbine sprayer .
WARNING
The turbine hose outlet may be hot. Carefully
check the hose end before removing the hose.
3. If using a remote pressure pot, relieve its pressure
by following these steps:
a. T urn of f the air supply to the pressure pot.
b. 2 Quart Remote Pot: T urn out the pressure
relief knob (1 13) about one turn. W ait until
pressure is completely relieved before remov -
ing the cover . Close the knob before using the
system again.
See Fig. 4.
Fig. 4 
113
2 quart
NOTE: Elevate the spray gun and pull the trigger . This
will allow the fluid in the fluid hose to drain back into
the remote pressure pot.
4. Clean the spray gun and cup as instructed in the
turbine gun manual, 308–336.

12  308-422
Maintenance
Daily
Check the main turbine filter daily for cleanliness.
The turbine systems are lifetime lubricated. The only
maintenance required is filter cleaning and replace -
ment.
The turbine main filter and pre-filter must be clean at
all times to provide suf ficient air flow to cool the motor
and atomize the fluid. Check the filters weekly , mini -
mum. Replace the pre-filter as required.
NOTE: T o check the filter , turn on the turbine and
place a piece of paper against the air intake filter . If the
air intake holds the paper in place, the filter is okay .
T
o clean the main filter:
1. T urn of f and unplug the turbine.
2. Loosen the four main filter screws. See Fig. 5.
3. Remove the main filter and clean it by following
one of the following three methods:
DT ap the filter gently on a flat surface, dirty side
down.
D
Direct compressed air (100 psi [7 bar] maxi -
mum) through the filter panel in the opposite
direction of the arrows on the side of the filter .
D
Soak the filter for 15 minutes in water and a
mild detergent. Rinse the filter until it is clean.
Air dry the filter; do not use compressed air .
WARNING
T o avoid damage to the turbine and possible elec -
tric shock, never install a damp filter in the turbine.
CAUTION
Do not operate the turbine sprayer without the filter
installed.
Fig. 5
03072 Series 800 T urbine shown
Main
filter
screws
Weekly
Check the hose for cracks, leaks, and holes. Replace,
if necessary
.
Annually or 600 Hours (whichever comes
first)
Replace the motor brushes 600 hours after turbine
sprayer operation. If the brushes are not replaced,
motor failure will occur .
NOTE: It is recommended that an authorized service
center perform the motor brush replacement. See the
procedure on page 16.

308-42213
Troubleshooting
PROBLEM CAUSE SOLUTION
Remote Container Pressur-
ization
No fluid delivery .Check for leaks at the container gasket,
2
quart lid, and 2 1/2 gal pot wing nuts.
Check for air flow from male quick–dis-
connect at compressor outlet (approx.
1/4 CFM).
Turn pressure regulator clockwise. Look
for pressure on gauge. (If no pressure on
gauge, check air line and fittings).
Check hole in tank lid under regulator or
needle valve 2 Qt lid. Clean if necessary .
Check for obstructions.
Check if fluid pickup tube is unplugged.
Tighten.
Blow out and clear material hose.
Check container for material.
(Series 800) Compressor fails
to start
Cold weather operation. See Cold W eather Operation instruc-
tions,
page 10.
T urbine fails to start Power supply . Cycle red rocker switch.
Poor atomization Dirty filter . Clean filter .
Extension cord too long. Replace with shorter extension cord (do
not exceed 100 ft). Extension cord must
be
3-wire, 12 A WG.
Hose length too long. Replace with shorter hose. See Acces-
sories
for shorter hose and P/N.
Red Rocker Circuit Breaker
Switch Trips
Check filter . Clean filter and replace as necessary .
Excessive high ambient temperature. Move turbine to cooler area.
Excessive brush wear . Remove turbine wrapper and:
. Check for free motor rotation,
. Check brush wear ,
. Replace motor brushes if necessary .
Excessive current draw . Return to authorized service center .

14  308-422
Repair
WARNING
Turn of f turbine and unplug power for the following
procedures.
T urbine Switch Replacement (Red Rocker Circuit
Breaker)
1. T
o remove the turbine switch (3), wedge a large
flat blade screwdriver between the top of the
switch and the turbine face plate. See Fig. 6.
2. Push down firmly on the switch. Pry the switch out
far enough so the two top switch locking tabs are
visible.
3.
While maintaining outward pressure on the switch,
push down on the two locking tabs with a small flat
blade screwdriver until they release. The switch
will pop out.
4. Disconnect the two wires and remove the switch.
5. Reinstall by connecting wires to the new switch.
Snap the switch into place.
Fig. 6
Locking Tabs
3
03728
Series 800 Compressor Replacement
1. Remove the four main filter stop screws and
remove the main filter . (Clean or replace filter as
necessary).
2.
Remove the air hose from the “out” side of the
compressor.
3.
Locate and remove the three compressor hold–
down screws.
4. Remove the ground screw . Clip the lead wires and
remove the compressor .
5.
Rewire and install the new compressor . Apply
removable Loctite
R
on the compressor screws and
tighten the screws. Do not overtighten the rubber
bumpers.
6. Reinstall the hose on the “out” side of the com -
pressor.
7. Replace the main filter .
W
rapper Removal
Remove the cabinet wrapper by following these steps.
1. Remove the four filter screws. Remove the main
filter . Clean and replace the filter if necessary .
2.
Remove the four remaining top wrapper screws.
Do not remove handle screws.
3. Remove one screw from each side of the wrap -
per.
4. Remove the four remaining bottom wrapper
screws. Do not remove the rubber feet.
5. Gently pry loose and remove the wrapper from the
cabinet.
NOTE: The wrapper is sealed with caulk.
Fig. 7
Filter
Screws
Wrapper
Screws
Series 900 shown
Side
Screws
03067
Power Cord Replacement
Remove the cabinet wrapper by following the Wrapper
Removal
procedure.
The power cord may now be replaced.
Series 800 Compressor T oggle Switch Replace -
ment
Remove the cabinet wrapper by following the Wrapper
Removal
procedure.
The compressor toggle switch (Series 800) may now
be replaced.

308-42215
Repair
Turbine/Motor Replacement
The Series 700 and 800 turbine replacement kit
M73525 contains: T urbine unit (62), rubber bottom
spacer (16), foam fan seal (83), ground ring terminal
(7) red butt connector (not shown, used on series 800
only) and 2 switch connectors (8)
The Series 900 turbine replacement kit M73526 con -
tains: T urbine unit (62), rubber bottom spacer (16),
foam fan seal (83), ground ring terminal (7) and 2
switch connectors (8)
Remove the cabinet wrapper by following the steps in
the W rapper Removal procedure. Reference the parts
list exploded view for disassembly .
Note:
the wrapper is sealed with caulk.
1. The motor may now be replaced.
2. Remove the upper motor mount (42) by removing
the five screws that retain it.
3. Remove the ground wire (green) and switch wires
(black & white).
Note: Series 800 only , clip the neutral lead (white)
approximately 2 in. from the three wire crimp connec -
tor.
4.
Install (crimp) the female switch connectors or red
butt connectors on the new turbine as shown in the
appropriate wiring diagram. The round ring con -
nector always goes on the green wire.
Note: On Series 800 only , strip the white neutral wire
(attached to the three wire crimp connector) back
approximately 3/8 in. and install the red butt connector .
5.
Remove the old motor from the lower mount by
removing the three bolts (54). The nuts are at -
tached to the lower mount, a holding wrench is not
required.
6.
Reinstall the new turbine (62) and pad (16).
Note: Application of removable Loctite r is recom -
mended on the threads of the three bolts (54).
Note: Do not over tighten the three bolts (54) securing
the turbine to the lower motor mount, damage to the
turbine may occur
.
7.
Be sure to install the ground wire to the grounding
stud on the lower motor mount.
8. Replace the upper motor mount and the five
screws that retain it.
9. Install the new fan seal gasket (83) on the top of
the upper motor mount
10. Replace the wrapper and filter system.

Fig. 8
61
8
Power
Cord
Black
9
White
Black
Green
Rocker
Switch
Motor
7
Series 700 shown
Green
White
60
8
Fig. 9
Series 800 shown
61 Black
White
Black
Green
Motor
Compressor
Green
Black
Green
White
Power
Cord
Rocker
Switch
T
oggle
Switch
60
79
Black
Black
03733A
22
6
White
78
78
12
8
8

16  308-422
Repair
Fig. 10
Series 900 shown
8
Power
Cord
Black
8
White
Black
Green
Rocker
Switch
Motor
7
Green
03735A
White
9
Motor Brush Replacement
NOTE: It is recommended that this procedure be
performed by an authorized service center .
1.
Follow the steps for removing the motor in the
Motor Replacement procedure.
2. On the Series 700 and 800 turbine motor , remove
the two retaining clips and plastic fan cover .
3.
On the Series 900 turbine motor , lift the retaining
clips out of the top of the motor for brush replace -
ment.
4.
Remove the brushes. Check the commutator for
excessive wear .
5.
Reassemble the new motor brushes using reverse
order . Keep lead wires from all rotating parts and
the motor frame.
CAUTION
Do not run the motor with the air inlet or outlet
sealed of f.
6. Reinstall the motor in the reverse order .
7.
After running the motor for 30–45 minutes at
full–rated voltage, the motor will return to full
performance.

308-42217
Notes

18  308-422
Parts for Series 700
31
30
29
28
20
33
7
3
6
5
4
9
10
53
17
16
42
25
24
26
27
83
50
84
85
86
88
26
39
38
60
43
54
94
04959A
36
37
93
21,
51
93
34
35
62
8
59
45
7
8

61
8
Power
Cord
Black
White
Black
Green
Rocker
Switch
Motor
7
03732A
Green
White
60
8
9
6
308-42219
Parts for Series 700
Ref
No. Part No. Description Qty
3 M70657
SWITCH, rocker 12A 1
4 M70601
CORD, power 1
5 106013
FITTING, strain relief 1
6 107260 CONNECT
OR, female 1
7 102799
TERMINAL, ground ring 1
8 M70760
SWITCH, connector , female 2
9 107266 CONNECT
OR, male 1
10 M73044 PLA
TE, face 1
16 M73323 P
AD, turbine mount 1
17 M70773 W
ASHER, 1/4 6
20 M73043 WRAPPER 1
21 M73024
DECAL, RH 1
24 M70763 BUMPER 4
25 M70775 SCREW
, 8–32x5/8 4
26 M70774 SCREW
, black oxide, 8–32x1/2 20
27 M73048 PLA
TE, bottom 1
28 M70859 FIL
TER, stop 1
29 M70757 FIL
TER, foam stop 4
30 M71558 FIL
TER KIT , main 1
31 M70607 FIL
TER, pre 1
33 M71628
FOAM, die cut 2
34 M70872 NUT
, cabinet handle 2
35 M70874 W
ASHER, 3/16x1 2
36 M71246 O-RING 1
37 M71262
FITTING, air outlet 1
Ref
No. Part No. Description Qty
38 M70870
HANDLE, 1
39 M70873 SCREW
, cabinet handle 2
42 M73009 MOUNT
, turbine upper 1
43 M70776 NUT
, hex 2
45 M73019 SP
ACER, 2.9 3
50 113400 SCREW 3
51 M73025
DECAL, LH (not shown) 1
53 M70764 O-
RING 3
54 M73021 BOLT
, 1/4–20x4.00 3
59 M71012 MOUNT
, turbine lower 1
60 M73503
WIRE, green/yellow 1
61 M71185 SCREW
, self–tapping 1
62 M73525* MOT
OR KIT , Series 700, 120V 1
82 186620
LABEL, ground (not shown) 1
83 M73362 GASKET
, fan seal 1
84 M71452
HOSE, turbine, 25 ft 1
85 M71681** VAL
VE, turbine air 1
86 M70402 DISCONNECT
, quick 1
88 M70721
O-RING, hose 1
93 M71603
LABEL, Danger/W arning 1
94
GUN, T urbine, see Gun Instruction
Manual, 308–336 1
* Motor Kit M73525 includes: motor , ground wire connectors,
gaskets, and electrical connectors. Motor Brush Kit M73521
is also available. Purchase separately .
** V
alve Kit M71681 includes air valve and o–ring.

  
Parts for Series 800
31
30
29
28
33
7
3
5
4
8
10
53
17
59 25
24
26
27
83
45
84
26
39
38
60
61 54
1
52
32
62
2
85
04960A
20
95
92
37
89
93
50
34
35
21,
51
96
M70962
(see
page 24)
89
58
16
42
36
43
1
6
