Graco GH 130 Operating instructions

334654B
EN
Repair
GH™130/200/230/300 and
DutyMax GH/EH™230/300 Displacement Pump
For professional use only.
Not approved for use in explosive atmosphere or hazardous locations.
For portable airless spraying of architectural paints and coatings.
Models: 24B748, 24W995, 24W996, 24W997, 24W998, 24W999, 24X001
Important Safety Instructions
Read all warnings and instructions in this manual and related manuals.
Be familiar with the controls and the proper usage of the equipment.
Save these instructions.
Use only genuine Graco replacement parts.
The use of non-Graco replacement parts may void warranty.
24X00124W999
24W996
24W998
ti25242a
24B748 24W997
24W995

Table of Contents
2334654B
Table of Contents
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Trigger Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Pressure Relief Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Disassemble Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Assemble Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Pump 24B748 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Pump 24W995 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Pump 24W996 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Pump 24W997 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Pump 24W998 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Pump 24W999 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Pump 24X001 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Graco Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Warnings
334654B 3
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this
equipment. The exclamation point symbol alerts you to a general warning and the hazard
symbols refer to procedure-specific risks. When these symbols appear in the body of this
manual or on warning labels, refer back to these Warnings. Product-specific hazard symbols
and warnings not covered in this section may appear throughout the body of this manual
where applicable.
SKIN INJECTION HAZARD
High-pressuresprayisabletoinjecttoxins intothe body andcause serious bodilyinjury. Inthe
event that injection occurs, get immediate surgical treatment.
•Do not aim the gun at, or spray any person or animal.
•Keephandsand other bodyparts awayfromthe discharge.Forexample,donot trytostop
leaks with any part of the body.
•Always use the nozzle tip guard. Do not spray without nozzle tip guard in place.
•Use Graco nozzle tips.
•Usecautionwhencleaningandchangingnozzletips.Inthecasewherethenozzletipclogs
while spraying, follow the Pressure Relief Procedure for turning off the unit and relieving
the pressure before removing the nozzle tip to clean.
•Equipment maintains pressure after power is shut off. Do not leave the equipment
energized or under pressure while unattended. Follow the Pressure Relief Procedure
when the equipment is unattended or not in use, and before servicing, cleaning, or
removing parts.
•Check hoses and parts for signs of damage. Replace any damaged hoses or parts.
•Thissystemiscapableofproducing3300psi.UseGracoreplacementpartsoraccessories
that are rated a minimum of 3300 psi.
•Always engage the trigger lock when not spraying. Verify the trigger lock is functioning
properly.
•Verify that all connections are secure before operating the unit.
•Know how to stop the unit and bleed pressure quickly. Be thoroughly familiar with the
controls.
PRESSURIZED ALUMINUM PARTS HAZARD
Useof fluids thatareincompatiblewithaluminum in pressurizedequipment can causeserious
chemical reaction and equipment rupture. Failure to follow this warning can result in death,
serious injury, or property damage.
•Do not use 1,1,1-trichloroethane, methylene chloride, other halogenated hydrocarbon
solvents or fluids containing such solvents.
•Do not use chlorine bleach.
•Many other fluids may contain chemicals that can react with aluminum. Contact your
material supplier for compatibility.
PERSONAL PROTECTIVE EQUIPMENT
Wear appropriate protective equipment when in the work area to help prevent serious injury,
including eye injury, hearing loss, inhalation of toxic fumes, and burns. This protective
equipment includes but is not limited to:
•Protective eye wear, and hearing protection.
•Respirators, protective clothing, and gloves as recommended by the fluid and solvent
manufacturer.
CALIFORNIA PROPOSITION 65
ThisproductcontainsachemicalknowntotheStateofCaliforniatocausecancer,birthdefects
or other reproductive harm. Wash hands after handling.

Repair
4334654B
Repair
Trigger Lock
Always engage the trigger lock when sprayer
is stopped to prevent the gun from being
triggered accidentally by hand or if dropped
or bumped.
Pressure Relief Procedure
1. Engage trigger lock.
2. Ifapplicable,turnelectricmotorON/OFF
switch to OFF position. Wait 7 seconds
for power to dissipate.
3. Unplug power cord or shut engine off.
This equipment stays pressurized until
pressure is manually relieved. To help
prevent serious injury from pressurized
fluid, such as skin injection, splashed fluid
and moving parts, follow the Pressure
Relief Procedure whenever sprayer is
stopped and before sprayer is cleaned or
checked, and before equipment is
serviced.
ti24612a
ti24851a
OI
I
O
t
ti24853a
ti18812a
ti7529a

Repair
334654B 5
4. Disengage trigger lock.
5. Hold a metal part of the gun firmly to a
grounded metal pail. Trigger the gun to
relieve pressure.
Solvent and oil-based fluids: follow
local code. Use only conductive metal
pails, placed on a grounded surface
such as concrete.
Do not place pail on a non-conductive
surface such as paper or cardboard
which interrupts grounding continuity.
6. Engage trigger lock.
7. Open any fluid drain valves in system.
Leave drain valves open until ready to
spray again.
ti22818a
ti22700a
ti24608a
ti24585a

Repair
6334654B
Disassemble Pump
1. Remove packing nut and throat
adjustment spacer.
2. Unscrew cylinder from intake valve.
3. Disassemble intake valve. Clean and
inspect. O-ring may require a pick for
removal.
ti25168a
ti25169a
NOTICE
Ifusingapick toremovetheO-ringusecare
to avoid damage to the machined surfaces.
ti25170a

Repair
334654B 7
4. Tap piston rod out of cylinder with a
hammer or flip over and tap piston rod
out against a bench.
5. Remove piston rod from sleeve.
6. Unscrew piston valve from piston rod.
ti25171a
ti8849a
Do not clean or wipe the piston valve
threads.Cleaning thepistonvalvethreads
coulddestroythespecialsealingpatchand
cause the piston valve to come loose
during operation, causing a pump burst
and possible serious bodily injury.

Repair
8334654B
7. Cleanandinspectparts.(Thepistonhas
a special thread locking/sealing patch.
Do not remove the patch. The patch
allows for disassembly/assembly
procedures before it is necessary to
apply thread sealant to the threads. On
fifth assembly apply thread sealant to
threads.
8. Remove and discard throat packing and
glands from the cylinder.
ti25172a
ti25173a

Repair
334654B 9
Assemble Pump
1. If applicable, soak leather packings in
SAE 30W oil for one hour before
assembly.
2. Install ball in piston rod. Apply thread
sealant to piston valve threads; ensure
that none gets on the ball.
3. Torque to 55 ± 3 ft-lb (75 ± 4 N•m).
Leather
Packings
Blue
Brown
Blue
ti25174a
Leather
Packings
ti25175a
ti25176a
ti24892a

Repair
10 334654B
4. Assemble leather throat packings
soaked earlier.
5. Loosely install packing nut with o-ring
onto cylinder.
6. Install o-rings inside cylinder and on
sleeve. Slide sleeve into bottom of
cylinder. Replace o-ring if necessary.
7. Apply liberal amounts of grease or oil to
piston packings.
8. Grease top inch or two of piston rod that
will go through the cylinder throat
packings. Gently guide displacement
rod up through throat packings. Tap
bottomofpistonvalveasnecessarywith
a leather or plastic hammer.
Leather
Packing
s
ti25175a
ti25178a
ti25179a
ti25180a

Repair
334654B 11
9. Grease o-ring and place on outside
diameter ring groove.
10. Clean seat thoroughly. Reassemble
intake valve with a seat, ball, and new
o-ring. Seat may be flipped over and
used on other side.
11. For GH130 torque foot valve to 110 ± 5
ft-lb (149 ± 7 N•m). For GH200/230/300
torque foot valve to 200 ± 15 ft-lb (271 ±
20 N•m).
ti25181a
ti25182a
ti25183a

Repair
12 334654B
12. For GH130 torque packing nut to 125 ±
10 in-lbs (14 ± 1 N•m). All other GH
models torque packing nut to 140 ± 10
in-lbs (16 ± 1 N•m).
13. Storage
Throat Packing Adjustment
When pump packings begin to leak after
much use, perform Pressure Relief
Procedure, page 4, and tighten packing nut
down until leakage stops or lessens. This
allows approximately 100 gallons of
additional operation before a repacking is
required. Packing nut can be tightened
without o-ring removal.
ti25184a
ti25185a
ti25186a

Notes
334654B 13
Notes

Parts
14 334654B
Parts
Pump 24B748
1
2
20
4
5
6
7
8
9
10
24
12
14
14
16
17
18
19
26
21
27
23
22
24
3
ti25243a
12
13
28
8
2
4
1
3
Torque to 110 ± 5 ft/lbs
(149 ± 5 N•m)
Torque to 125 ± 10 in/lbs
(14 ± 1 N•m)
Torque to 55 ± 3 ft/lbs
(75 ± 4 N•m)
Soak in SAE 30W oil for 1 hour
prior to assembly
1
2
3
4

Parts
334654B 15
Parts List
Ref. Part Description Qty.
1 288727 CYLINDER, pump 1
2 248210 SLEEVE, cylinder,
chrome 1
3 195894 HOUSING, intake 1
4+ 196866 SEAT, carbide 1
5+ 108526 PACKING, o-ring, ptfe 1
6+ 102972 BALL, metallic 1
7 193027 GUIDE, ball 1
8* 107098 PACKING, o-ring 2
9* 156633 PACKING, o-ring 1
10 288479 ROD, piston 1
12* 128779 PACKING, vee 8
13* 128296 PACKING, vee 3
14* 183185 GLAND, packing,
female 2
16* 118504 WIPER, piston 1
17* 15J382 PACKING, vee 3
18* 24U983 VALVE, piston 1
19* 101947 BALL, bearing 1
20 193032 NUT, packing 1
21 C20987 PACKING, o-ring 1
22* 183171 PLUG 1
23* 15C998 WASHER, backup 1
24* 183178 GLAND, packing, male 2
26 15J141 PIN, pump 1
27 15Y463 FITTING, bushing 1
28 196178 ADAPTER, nipple 1
* Included in Repair Kit 288471
+ Included in Repair Kit 244199

Parts
16 334654B
Parts
Pump 24W995
1
2
3
4
5
6
7
9
10
11
12
13
8
14
16
13
18
19
20
21
22
23
24
8
25
15
28
12
ti25244a
26
29
30
1
2
4
4
3
Torque to 55 ± 3 ft/lbs
(75 ± 4 N•m)
Torque to 200 ± 15 ft/lbs
(271 ± 20 N•m)
Torque to 140 ± 10 in/lbs
(16 ± 1 N•m)
Soak in SAE 30W oil for 1 hour
prior to assembly
1
2
3
4

Parts
334654B 17
Parts List
Ref. Part Description Qty.
1 245413 CYLINDER, pump 1
21
248979 SLEEVE, cylinder,
chrome
249121 SLEEVE, cylinder,
MaxLife
3 15E655 HOUSING, intake 1
4+ 193395 SEAT, carbide 1
5*+ 107098 PACKING, o-ring 1
6*+ 107167 BALL, sst 1
7 198505 GUIDE, ball 1
8* 108822 PACKING, o-ring, ptfe 2
9* 160325 PACKING, o-ring 1
10 1
249000 ROD, piston
249119 ROD, piston, MaxLife
11* 189585 GLAND, packing, male 1
12* 198701 PACKING, vee 8
13* 198718 PACKING, vee 6
14* 15G657 GLAND, female 1
15* 189588 GLAND, packing,
female 1
16* 119636 WIPER, piston 1
18 287388 VALVE, piston 1
19* 107203 BALL, valve, check 1
20 15J792 NUT, packing 1
21* 157195 PACKING, o-ring 1
22* 112590 PLUG, throat seal 1
23* 15J800 WASHER, back-up 1
24* 15G658 GLAND, male 1
25 245256 SPRING, intake ball 1
26 197443 PIN, pump 1
28 196178 ADAPTER, nipple 1
29 116551 RING, retaining 1
30 119566 WASHER 1
* Included in Repair Kit 17D601
+ Included in Repair Kit 240918

Parts
18 334654B
Parts
Pump 24W996
1
2
3
4
5
6
7
9
10
11
12
13
8
14
16
17
18
19
20
21
22
23
24
8
25
15
28
12
ti25245a
30
29
3
4
2
1
Torque to 55 ± 3 ft/lbs
(75 ± 4 N•m)
Torque to 200 ± 15 ft/lbs
(271 ± 20 N•m)
Torque to 140 ± 40 in/lbs
(16 ± 1 N•m)
Soak in SAE 30W oil for 1 hour
prior to assembly
1
2
3
4

Parts
334654B 19
Parts List
Ref. Part Description Qty.
1 17D122 CYLINDER, pump 1
2 249121 SLEEVE, cylinder 1
3 15E655 HOUSING, intake 1
4+ 193395 SEAT, carbide 1
5*+ 107098 PACKING, o-ring 1
6*+ 107167 BALL, sst 1
7 198505 GUIDE, ball 1
8* 108822 PACKING, o-ring, ptfe 2
9* 160325 PACKING, o-ring 1
10 288469 ROD, piston 1
11* 189585 GLAND, packing, male 1
12* 198701 PACKING, vee 8
13* 198718 PACKING, vee 3
14* 15G657 GLAND, female 1
15* 189588 GLAND, packing,
female 1
16* 119636 WIPER, piston 1
17* 15F875 PACKING, vee 3
18 287388 VALVE, piston 1
19* 107203 BALL, valve, check 1
20 15J792 NUT, packing 1
21* 157195 PACKING, o-ring 1
22* 112590 PLUG, throat seal 1
23* 15J800 WASHER, back-up 1
24* 15G658 GLAND, male 1
25 245256 SPRING, intake ball 1
28 15J413 FITTING, pump 1
30 119566 WASHER 1
* Included in Repair Kit 287813
+ Included in Repair Kit 240918
NOTE: For Chromex Pump Kit order 24X018

Parts
20 334654B
Parts
Pump 24W997
3
1
ti25246a
1
2
3
4
6
7
9
10
12
13
5
14
16
11
18
19
20
21
22
23
24
8
25
15
12
8
13
28
26
30
29
3
4
2
4
1
Torque to 55 ± 3 ft/lbs
(75 ± 4 N•m)
Torque to 200 ± 15 ft/lbs
(271 ± 20 N•m)
Torque to 140 ± 10 in/lbs
(16 ± 1 N•m)
Soak in SAE 30W oil for 1 hour
prior to assembly
1
2
3
4
