Graco Wolverine Series Operation manual

334513A
EN
Instructions-Parts
Wolverine™
Chemical Injection
Pump
Electrical pump for injecting chemicals at well sites. For professional use only.
Not approved for use in explosive atmospheres or hazardous locations.
See page 3 for model information, including maximum working pressure.
Important Safety Instructions
Read all warnings and instructions in this manual.
Save all instructions.

2334513A
Contents
Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Component Identification . . . . . . . . . . . . . . . . . . . 18
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Flush Before Using Equipment . . . . . . . . . . . . . 19
Typical Installation . . . . . . . . . . . . . . . . . . . . . . . 20
Choosing an Installation Location . . . . . . . . . . . 21
Fluid Connections . . . . . . . . . . . . . . . . . . . . . . . 21
Electrical Connections . . . . . . . . . . . . . . . . . . . 22
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Pressure Relief Procedure . . . . . . . . . . . . . . . . 23
Flush the Equipment . . . . . . . . . . . . . . . . . . . . . 23
Prime the Pump . . . . . . . . . . . . . . . . . . . . . . . . 23
Calibrate Chemical Dosage . . . . . . . . . . . . . . . 24
Preventive Maintenance Schedule . . . . . . . . . . 27
Tighten Threaded Connections . . . . . . . . . . . . . 27
Tighten Packings . . . . . . . . . . . . . . . . . . . . . . . . 27
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Wolverine Basic Pump Repair . . . . . . . . . . . . . 29
Wolverine Advanced Pump Repair . . . . . . . . . . 34
Motor Brush Repair (DC Pumps only) . . . . . . . 38
Check Valve Repair . . . . . . . . . . . . . . . . . . . . . . 38
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Wolverine Basic Pump . . . . . . . . . . . . . . . . . . . 40
Wolverine Advanced Pump . . . . . . . . . . . . . . . . 43
Kits and Accessories . . . . . . . . . . . . . . . . . . . . . . 48
Wolverine (Both) . . . . . . . . . . . . . . . . . . . . . . . . 48
Wolverine Advanced . . . . . . . . . . . . . . . . . . . . . 48
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Wolverine Basic Pump Dimensions . . . . . . . . . 49
Wolverine Advanced Pump Dimensions . . . . . . 50
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . 52

Models
334513A 3
Models
Part No. Configuration Voltage
Pump
Type Motor
Number
of
Pumps
Plunger
Size
Maximum
Working
Pressure
psi (MPa, bar)
A26000 CI-121S-150-SA-0 12 VDC Basic Small 1 1/2 in. 800 (5.5, 55)
A26001 CI-121S-138-SA-0 12 VDC Basic Small 1 3/8 in. 1500 (10.3, 103)
A26002 CI-121S-125-SA-0 12 VDC Basic Small 1 1/4 in. 3500 (24.1, 241)
A26003 CI-121S-150-SB-0 12 VDC Basic Small 1 1/2 in. 800 (5.5, 55)
A26004 CI-121S-138-SB-0 12 VDC Basic Small 1 3/8 in. 1500 (10.3, 103)
A26005 CI-121S-125-SB-0 12 VDC Basic Small 1 1/4 in. 3500 (24.1, 241)
A26006 CI-121S-150-SC-0 12 VDC Basic Small 1 1/2 in. 800 (5.5, 55)
A26007 CI-121S-138-SC-0 12 VDC Basic Small 1 3/8 in. 1500 (10.3, 103)
A26008 CI-121S-125-SC-0 12 VDC Basic Small 1 1/4 in. 3500 (24.1, 241)
A26009 CI-121S-150-SD-0 12 VDC Basic Small 1 1/2 in. 800 (5.5, 55)
A26010 CI-121S-138-SD-0 12 VDC Basic Small 1 3/8 in. 1500 (10.3, 103)
A26011 CI-121S-125-SD-0 12 VDC Basic Small 1 1/4 in. 3500 (24.1, 241)
A26100 CI-122S-150-XA-0 12 VDC Advanced Small 1 1/2 in. 800 (5.5, 55)
A26101 CI-122S-138-XA-0 12 VDC Advanced Small 1 3/8 in. 1500 (10.3, 103)
A26102 CI-122S-125-XA-0 12 VDC Advanced Small 1 1/4 in. 3500 (24.1, 241)
A26105 CI-122S-163-XA-0 12 VDC Advanced Small 1 5/8 in. 500 (3.4, 34)
A26106 CI-122S-175-XA-0 12 VDC Advanced Small 1 3/4 in. 350 (2.4, 24)
A26107 CI-122S-150-XB-0 12 VDC Advanced Small 1 1/2 in. 800 (5.5, 55)
A26108 CI-122S-138-XB-0 12 VDC Advanced Small 1 3/8 in. 1500 (10.3, 103)
A26109 CI-122S-125-XB-0 12 VDC Advanced Small 1 1/4 in. 3500 (24.1, 241)
A26112 CI-122S-163-XB-0 12 VDC Advanced Small 1 5/8 in. 500 (3.4, 34)
A26113 CI-122S-175-XB-0 12 VDC Advanced Small 1 3/4 in. 350 (2.4, 24)
A26114 CI-122S-150-XC-0 12 VDC Advanced Small 1 1/2 in. 800 (5.5, 55)
A26115 CI-122S-138-XC-0 12 VDC Advanced Small 1 3/8 in. 1500 (10.3, 103)
A26116 CI-122S-125-XC-0 12 VDC Advanced Small 1 1/4 in. 3500 (24.1, 241)
A26119 CI-122S-163-XC-0 12 VDC Advanced Small 1 5/8 in. 500 (3.4, 34)
A26120 CI-122S-175-XC-0 12 VDC Advanced Small 1 3/4 in. 350 (2.4, 24)
A26121 CI-122S-150-XD-0 12 VDC Advanced Small 1 1/2 in. 800 (5.5, 55)
A26122 CI-122S-138-XD-0 12 VDC Advanced Small 1 3/8 in. 1500 (10.3, 103)
A26123 CI-122S-125-XD-0 12 VDC Advanced Small 1 1/4 in. 3500 (24.1, 241)
A26126 CI-122S-163-XD-0 12 VDC Advanced Small 1 5/8 in. 500 (3.4, 34)
A26127 CI-122S-175-XD-0 12 VDC Advanced Small 1 3/4 in. 350 (2.4, 24)
A26128 CI-122S-250-XA-0 12 VDC Advanced Small 2 1/2 in. 800 (5.5, 55)
A26129 CI-122S-238-XA-0 12 VDC Advanced Small 2 3/8 in. 1500 (10.3, 103)
A26130 CI-122S-225-XA-0 12 VDC Advanced Small 2 1/4 in. 3500 (24.1, 241)

Models
4334513A
A26133 CI-122S-263-XA-0 12 VDC Advanced Small 2 5/8 in. 500 (3.4, 34)
A26134 CI-122S-275-XA-0 12 VDC Advanced Small 2 3/4 in. 350 (2.4, 24)
A26135 CI-122S-250-XB-0 12 VDC Advanced Small 2 1/2 in. 800 (5.5, 55)
A26136 CI-122S-238-XB-0 12 VDC Advanced Small 2 3/8 in. 1500 (10.3, 103)
A26137 CI-122S-225-XB-0 12 VDC Advanced Small 2 1/4 in. 3500 (24.1, 241)
A26140 CI-122S-263-XB-0 12 VDC Advanced Small 2 5/8 in. 500 (3.4, 34)
A26141 CI-122S-275-XB-0 12 VDC Advanced Small 2 3/4 in. 350 (2.4, 24)
A26142 CI-122S-250-XC-0 12 VDC Advanced Small 2 1/2 in. 800 (5.5, 55)
A26143 CI-122S-238-XC-0 12 VDC Advanced Small 2 3/8 in. 1500 (10.3, 103)
A26144 CI-122S-225-XC-0 12 VDC Advanced Small 2 1/4 in. 3500 (24.1, 241)
A26147 CI-122S-263-XC-0 12 VDC Advanced Small 2 5/8 in. 500 (3.4, 34)
A26148 CI-122S-275-XC-0 12 VDC Advanced Small 2 3/4 in. 350 (2.4, 24)
A26149 CI-122S-250-XD-0 12 VDC Advanced Small 2 1/2 in. 800 (5.5, 55)
A26150 CI-122S-238-XD-0 12 VDC Advanced Small 2 3/8 in. 1500 (10.3, 103)
A26151 CI-122S-225-XD-0 12 VDC Advanced Small 2 1/4 in. 3500 (24.1, 241)
A26154 CI-122S-263-XD-0 12 VDC Advanced Small 2 5/8 in. 500 (3.4, 34)
A26155 CI-122S-275-XD-0 12 VDC Advanced Small 2 3/4 in. 350 (2.4, 24)
A26200 CI-122L-150-XA-0 12 VDC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A26201 CI-122L-138-XA-0 12 VDC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A26202 CI-122L-125-XA-0 12 VDC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A26205 CI-122L-163-XA-0 12 VDC Advanced Large 1 5/8 in. 900 (6.2, 62)
A26206 CI-122L-175-XA-0 12 VDC Advanced Large 1 3/4 in. 600 (4.1, 41)
A26207 CI-122L-150-XB-0 12 VDC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A26208 CI-122L-138-XB-0 12 VDC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A26209 CI-122L-125-XB-0 12 VDC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A26212 CI-122L-163-XB-0 12 VDC Advanced Large 1 5/8 in. 900 (6.2, 62)
A26213 CI-122L-175-XB-0 12 VDC Advanced Large 1 3/4 in. 600 (4.1, 41)
A26214 CI-122L-150-XC-0 12 VDC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A26215 CI-122L-138-XC-0 12 VDC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A26216 CI-122L-125-XC-0 12 VDC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A26219 CI-122L-163-XC-0 12 VDC Advanced Large 1 5/8 in. 900 (6.2, 62)
A26220 CI-122L-175-XC-0 12 VDC Advanced Large 1 3/4 in. 600 (4.1, 41)
A26221 CI-122L-150-XD-0 12 VDC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A26222 CI-122L-138-XD-0 12 VDC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A26223 CI-122L-125-XD-0 12 VDC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A26226 CI-122L-163-XD-0 12 VDC Advanced Large 1 5/8 in. 900 (6.2, 62)
A26227 CI-122L-175-XD-0 12 VDC Advanced Large 1 3/4 in. 600 (4.1, 41)
Part No. Configuration Voltage
Pump
Type Motor
Number
of
Pumps
Plunger
Size
Maximum
Working
Pressure
psi (MPa, bar)

Models
334513A 5
A26228 CI-122L-250-XA-0 12 VDC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A26229 CI-122L-238-XA-0 12 VDC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A26230 CI-122L-225-XA-0 12 VDC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A26233 CI-122L-263-XA-0 12 VDC Advanced Large 2 5/8 in. 900 (6.2, 62)
A26234 CI-122L-275-XA-0 12 VDC Advanced Large 2 3/4 in. 600 (4.1, 41)
A26235 CI-122L-250-XB-0 12 VDC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A26236 CI-122L-238-XB-0 12 VDC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A26237 CI-122L-225-XB-0 12 VDC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A26240 CI-122L-263-XB-0 12 VDC Advanced Large 2 5/8 in. 900 (6.2, 62)
A26241 CI-122L-275-XB-0 12 VDC Advanced Large 2 3/4 in. 600 (4.1, 41)
A26242 CI-122L-250-XC-0 12 VDC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A26243 CI-122L-238-XC-0 12 VDC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A26244 CI-122L-225-XC-0 12 VDC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A26247 CI-122L-263-XC-0 12 VDC Advanced Large 2 5/8 in. 900 (6.2, 62)
A26248 CI-122L-275-XC-0 12 VDC Advanced Large 2 3/4 in. 600 (4.1, 41)
A26249 CI-122L-250-XD-0 12 VDC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A26250 CI-122L-238-XD-0 12 VDC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A26251 CI-122L-225-XD-0 12 VDC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A26254 CI-122L-263-XD-0 12 VDC Advanced Large 2 5/8 in. 900 (6.2, 62)
A26255 CI-122L-275-XD-0 12 VDC Advanced Large 2 3/4 in. 600 (4.1, 41)
A26500 CI-1A2L-150-XA-0 115 VAC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A26501 CI-1A2L-138-XA-0 115 VAC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A26502 CI-1A2L-125-XA-0 115 VAC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A26505 CI-1A2L-163-XA-0 115 VAC Advanced Large 1 5/8 in. 900 (6.2, 62)
A26506 CI-1A2L-175-XA-0 115 VAC Advanced Large 1 3/4 in. 600 (4.1, 41)
A26507 CI-1A2L-150-XB-0 115 VAC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A26508 CI-1A2L-138-XB-0 115 VAC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A26509 CI-1A2L-125-XB-0 115 VAC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A26512 CI-1A2L-163-XB-0 115 VAC Advanced Large 1 5/8 in. 900 (6.2, 62)
A26513 CI-1A2L-175-XB-0 115 VAC Advanced Large 1 3/4 in. 600 (4.1, 41)
A26514 CI-1A2L-150-XC-0 115 VAC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A26515 CI-1A2L-138-XC-0 115 VAC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A26516 CI-1A2L-125-XC-0 115 VAC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A26519 CI-1A2L-163-XC-0 115 VAC Advanced Large 1 5/8 in. 900 (6.2, 62)
A26520 CI-1A2L-175-XC-0 115 VAC Advanced Large 1 3/4 in. 600 (4.1, 41)
A26521 CI-1A2L-150-XD-0 115 VAC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A26522 CI-1A2L-138-XD-0 115 VAC Advanced Large 1 3/8 in. 2500 (17.2, 172)
Part No. Configuration Voltage
Pump
Type Motor
Number
of
Pumps
Plunger
Size
Maximum
Working
Pressure
psi (MPa, bar)

Models
6334513A
A26523 CI-1A2L-125-XD-0 115 VAC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A26526 CI-1A2L-163-XD-0 115 VAC Advanced Large 1 5/8 in. 900 (6.2, 62)
A26527 CI-1A2L-175-XD-0 115 VAC Advanced Large 1 3/4 in. 600 (4.1, 41)
A26528 CI-1A2L-250-XA-0 115 VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A26529 CI-1A2L-238-XA-0 115 VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A26530 CI-1A2L-225-XA-0 115 VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A26533 CI-1A2L-263-XA-0 115 VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
A26534 CI-1A2L-275-XA-0 115 VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
A26535 CI-1A2L-250-XB-0 115 VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A26536 CI-1A2L-238-XB-0 115 VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A26537 CI-1A2L-225-XB-0 115 VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A26540 CI-1A2L-263-XB-0 115 VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
A26541 CI-1A2L-275-XB-0 115 VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
A26542 CI-1A2L-250-XC-0 115 VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A26543 CI-1A2L-238-XC-0 115 VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A26544 CI-1A2L-225-XC-0 115 VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A26547 CI-1A2L-263-XC-0 115 VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
A26548 CI-1A2L-275-XC-0 115 VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
A26549 CI-1A2L-250-XD-0 115 VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A26550 CI-1A2L-238-XD-0 115 VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A26551 CI-1A2L-225-XD-0 115 VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A26554 CI-1A2L-263-XD-0 115 VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
A26555 CI-1A2L-275-XD-0 115 VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
A26600 CI-2A2L-150-XA-0 230 VAC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A26601 CI-2A2L-138-XA-0 230 VAC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A26602 CI-2A2L-125-XA-0 230 VAC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A26605 CI-2A2L-163-XA-0 230 VAC Advanced Large 1 5/8 in. 900 (6.2, 62)
A26606 CI-2A2L-175-XA-0 230 VAC Advanced Large 1 3/4 in. 600 (4.1, 41)
A26607 CI-2A2L-150-XB-0 230 VAC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A26608 CI-2A2L-138-XB-0 230 VAC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A26609 CI-2A2L-125-XB-0 230 VAC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A26612 CI-2A2L-163-XB-0 230 VAC Advanced Large 1 5/8 in. 900 (6.2, 62)
A26613 CI-2A2L-175-XB-0 230 VAC Advanced Large 1 3/4 in. 600 (4.1, 41)
A26614 CI-2A2L-150-XC-0 230 VAC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A26615 CI-2A2L-138-XC-0 230 VAC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A26616 CI-2A2L-125-XC-0 230 VAC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A26619 CI-2A2L-163-XC-0 230 VAC Advanced Large 1 5/8 in. 900 (6.2, 62)
Part No. Configuration Voltage
Pump
Type Motor
Number
of
Pumps
Plunger
Size
Maximum
Working
Pressure
psi (MPa, bar)

Models
334513A 7
A26620 CI-2A2L-175-XC-0 230 VAC Advanced Large 1 3/4 in. 600 (4.1, 41)
A26621 CI-2A2L-150-XD-0 230 VAC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A26622 CI-2A2L-138-XD-0 230 VAC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A26623 CI-2A2L-125-XD-0 230 VAC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A26626 CI-2A2L-163-XD-0 230 VAC Advanced Large 1 5/8 in. 900 (6.2, 62)
A26627 CI-2A2L-175-XD-0 230 VAC Advanced Large 1 3/4 in. 600 (4.1, 41)
A26628 CI-2A2L-250-XA-0 230 VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A26629 CI-2A2L-238-XA-0 230 VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A26630 CI-2A2L-225-XA-0 230 VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A26633 CI-2A2L-263-XA-0 230 VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
A26634 CI-2A2L-275-XA-0 230 VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
A26635 CI-2A2L-250-XB-0 230 VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A26636 CI-2A2L-238-XB-0 230 VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A26637 CI-2A2L-225-XB-0 230 VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A26640 CI-2A2L-263-XB-0 230 VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
A26641 CI-2A2L-275-XB-0 230 VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
A26642 CI-2A2L-250-XC-0 230 VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A26643 CI-2A2L-238-XC-0 230 VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A26644 CI-2A2L-225-XC-0 230 VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A26647 CI-2A2L-263-XC-0 230 VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
A26648 CI-2A2L-275-XC-0 230 VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
A26649 CI-2A2L-250-XD-0 230 VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A26650 CI-2A2L-238-XD-0 230 VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A26651 CI-2A2L-225-XD-0 230 VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A26654 CI-2A2L-263-XD-0 230 VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
A26655 CI-2A2L-275-XD-0 230 VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
A26700 CI-4A2L-150-XA-0 230/480 3 Phase VAC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A26701 CI-4A2L-138-XA-0 230/480 3 Phase VAC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A26702 CI-4A2L-125-XA-0 230/480 3 Phase VAC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A26705 CI-4A2L-163-XA-0 230/480 3 Phase VAC Advanced Large 1 5/8 in. 900 (6.2, 62)
A26706 CI-4A2L-175-XA-0 230/480 3 Phase VAC Advanced Large 1 3/4 in. 600 (4.1, 41)
A26707 CI-4A2L-150-XB-0 230/480 3 Phase VAC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A26708 CI-4A2L-138-XB-0 230/480 3 Phase VAC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A26709 CI-4A2L-125-XB-0 230/480 3 Phase VAC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A26712 CI-4A2L-163-XB-0 230/480 3 Phase VAC Advanced Large 1 5/8 in. 900 (6.2, 62)
A26713 CI-4A2L-175-XB-0 230/480 3 Phase VAC Advanced Large 1 3/4 in. 600 (4.1, 41)
A26714 CI-4A2L-150-XC-0 230/480 3 Phase VAC Advanced Large 1 1/2 in. 1250 (8.6, 86)
Part No. Configuration Voltage
Pump
Type Motor
Number
of
Pumps
Plunger
Size
Maximum
Working
Pressure
psi (MPa, bar)

Models
8334513A
A26715 CI-4A2L-138-XC-0 230/480 3 Phase VAC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A26716 CI-4A2L-125-XC-0 230/480 3 Phase VAC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A26719 CI-4A2L-163-XC-0 230/480 3 Phase VAC Advanced Large 1 5/8 in. 900 (6.2, 62)
A26720 CI-4A2L-175-XC-0 230/480 3 Phase VAC Advanced Large 1 3/4 in. 600 (4.1, 41)
A26721 CI-4A2L-150-XD-0 230/480 3 Phase VAC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A26722 CI-4A2L-138-XD-0 230/480 3 Phase VAC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A26723 CI-4A2L-125-XD-0 230/480 3 Phase VAC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A26726 CI-4A2L-163-XD-0 230/480 3 Phase VAC Advanced Large 1 5/8 in. 900 (6.2, 62)
A26727 CI-4A2L-175-XD-0 230/480 3 Phase VAC Advanced Large 1 3/4 in. 600 (4.1, 41)
A26728 CI-4A2L-250-XA-0 230/480 3 Phase VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A26729 CI-4A2L-238-XA-0 230/480 3 Phase VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A26730 CI-4A2L-225-XA-0 230/480 3 Phase VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A26733 CI-4A2L-263-XA-0 230/480 3 Phase VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
A26734 CI-4A2L-275-XA-0 230/480 3 Phase VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
A26735 CI-4A2L-250-XB-0 230/480 3 Phase VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A26736 CI-4A2L-238-XB-0 230/480 3 Phase VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A26737 CI-4A2L-225-XB-0 230/480 3 Phase VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A26740 CI-4A2L-263-XB-0 230/480 3 Phase VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
A26741 CI-4A2L-275-XB-0 230/480 3 Phase VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
A26742 CI-4A2L-250-XC-0 230/480 3 Phase VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A26743 CI-4A2L-238-XC-0 230/480 3 Phase VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A26744 CI-4A2L-225-XC-0 230/480 3 Phase VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A26747 CI-4A2L-263-XC-0 230/480 3 Phase VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
A26748 CI-4A2L-275-XC-0 230/480 3 Phase VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
A26749 CI-4A2L-250-XD-0 230/480 3 Phase VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A26750 CI-4A2L-238-XD-0 230/480 3 Phase VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A26751 CI-4A2L-225-XD-0 230/480 3 Phase VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A26754 CI-4A2L-263-XD-0 230/480 3 Phase VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
A26755 CI-4A2L-275-XD-0 230/480 3 Phase VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
A29100 CI-122S-150-XA-C 12 VDC Advanced Small 1 1/2 in. 800 (5.5, 55)
A29101 CI-122S-138-XA-C 12 VDC Advanced Small 1 3/8 in. 1500 (10.3, 103)
A29102 CI-122S-125-XA-C 12 VDC Advanced Small 1 1/4 in. 3500 (24.1, 241)
A29105 CI-122S-163-XA-C 12 VDC Advanced Small 1 5/8 in. 500 (3.4, 34)
A29106 CI-122S-175-XA-C 12 VDC Advanced Small 1 3/4 in. 350 (2.4, 24)
A29107 CI-122S-150-XB-C 12 VDC Advanced Small 1 1/2 in. 800 (5.5, 55)
A29108 CI-122S-138-XB-C 12 VDC Advanced Small 1 3/8 in. 1500 (10.3, 103)
A29109 CI-122S-125-XB-C 12 VDC Advanced Small 1 1/4 in. 3500 (24.1, 241)
Part No. Configuration Voltage
Pump
Type Motor
Number
of
Pumps
Plunger
Size
Maximum
Working
Pressure
psi (MPa, bar)

Models
334513A 9
A29112 CI-122S-163-XB-C 12 VDC Advanced Small 1 5/8 in. 500 (3.4, 34)
A29113 CI-122S-175-XB-C 12 VDC Advanced Small 1 3/4 in. 350 (2.4, 24)
A29114 CI-122S-150-XC-C 12 VDC Advanced Small 1 1/2 in. 800 (5.5, 55)
A29115 CI-122S-138-XC-C 12 VDC Advanced Small 1 3/8 in. 1500 (10.3, 103)
A29116 CI-122S-125-XC-C 12 VDC Advanced Small 1 1/4 in. 3500 (24.1, 241)
A29119 CI-122S-163-XC-C 12 VDC Advanced Small 1 5/8 in. 500 (3.4, 34)
A29120 CI-122S-175-XC-C 12 VDC Advanced Small 1 3/4 in. 350 (2.4, 24)
A29121 CI-122S-150-XD-C 12 VDC Advanced Small 1 1/2 in. 800 (5.5, 55)
A29122 CI-122S-138-XD-C 12 VDC Advanced Small 1 3/8 in. 1500 (10.3, 103)
A29123 CI-122S-125-XD-C 12 VDC Advanced Small 1 1/4 in. 3500 (24.1, 241)
A29126 CI-122S-163-XD-C 12 VDC Advanced Small 1 5/8 in. 500 (3.4, 34)
A29127 CI-122S-175-XD-C 12 VDC Advanced Small 1 3/4 in. 350 (2.4, 24)
A29128 CI-122S-250-XA-C 12 VDC Advanced Small 2 1/2 in. 800 (5.5, 55)
A29129 CI-122S-238-XA-C 12 VDC Advanced Small 2 3/8 in. 1500 (10.3, 103)
A29130 CI-122S-225-XA-C 12 VDC Advanced Small 2 1/4 in. 3500 (24.1, 241)
A29133 CI-122S-263-XA-C 12 VDC Advanced Small 2 5/8 in. 500 (3.4, 34)
A29134 CI-122S-275-XA-C 12 VDC Advanced Small 2 3/4 in. 350 (2.4, 24)
A29135 CI-122S-250-XB-C 12 VDC Advanced Small 2 1/2 in. 800 (5.5, 55)
A29136 CI-122S-238-XB-C 12 VDC Advanced Small 2 3/8 in. 1500 (10.3, 103)
A29137 CI-122S-225-XB-C 12 VDC Advanced Small 2 1/4 in. 3500 (24.1, 241)
A29140 CI-122S-263-XB-C 12 VDC Advanced Small 2 5/8 in. 500 (3.4, 34)
A29141 CI-122S-275-XB-C 12 VDC Advanced Small 2 3/4 in. 350 (2.4, 24)
A29142 CI-122S-250-XC-C 12 VDC Advanced Small 2 1/2 in. 800 (5.5, 55)
A29143 CI-122S-238-XC-C 12 VDC Advanced Small 2 3/8 in. 1500 (10.3, 103)
A29144 CI-122S-225-XC-C 12 VDC Advanced Small 2 1/4 in. 3500 (24.1, 241)
A29147 CI-122S-263-XC-C 12 VDC Advanced Small 2 5/8 in. 500 (3.4, 34)
A29148 CI-122S-275-XC-C 12 VDC Advanced Small 2 3/4 in. 350 (2.4, 24)
A29149 CI-122S-250-XD-C 12 VDC Advanced Small 2 1/2 in. 800 (5.5, 55)
A29150 CI-122S-238-XD-C 12 VDC Advanced Small 2 3/8 in. 1500 (10.3, 103)
A29151 CI-122S-225-XD-C 12 VDC Advanced Small 2 1/4 in. 3500 (24.1, 241)
A29154 CI-122S-263-XD-C 12 VDC Advanced Small 2 5/8 in. 500 (3.4, 34)
A29155 CI-122S-275-XD-C 12 VDC Advanced Small 2 3/4 in. 350 (2.4, 24)
A29200 CI-122L-150-XA-C 12 VDC Advanced Small 1 1/2 in. 1250 (8.6, 86)
A29201 CI-122L-138-XA-C 12 VDC Advanced Small 1 3/8 in. 2500 (17.2, 172)
A29202 CI-122L-125-XA-C 12 VDC Advanced Small 1 1/4 in. 6000 (41.3, 413)
A29205 CI-122L-163-XA-C 12 VDC Advanced Small 1 5/8 in. 900 (6.2, 62)
A29206 CI-122L-175-XA-C 12 VDC Advanced Small 1 3/4 in. 600 (4.1, 41)
Part No. Configuration Voltage
Pump
Type Motor
Number
of
Pumps
Plunger
Size
Maximum
Working
Pressure
psi (MPa, bar)

Models
10 334513A
A29207 CI-122L-150-XB-C 12 VDC Advanced Small 1 1/2 in. 1250 (8.6, 86)
A29208 CI-122L-138-XB-C 12 VDC Advanced Small 1 3/8 in. 2500 (17.2, 172)
A29209 CI-122L-125-XB-C 12 VDC Advanced Small 1 1/4 in. 6000 (41.3, 413)
A29212 CI-122L-163-XB-C 12 VDC Advanced Small 1 5/8 in. 900 (6.2, 62)
A29213 CI-122L-175-XB-C 12 VDC Advanced Small 1 3/4 in. 600 (4.1, 41)
A29214 CI-122L-150-XC-C 12 VDC Advanced Small 1 1/2 in. 1250 (8.6, 86)
A29215 CI-122L-138-XC-C 12 VDC Advanced Small 1 3/8 in. 2500 (17.2, 172)
A29216 CI-122L-125-XC-C 12 VDC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A29219 CI-122L-163-XC-C 12 VDC Advanced Large 1 5/8 in. 900 (6.2, 62)
A29220 CI-122L-175-XC-C 12 VDC Advanced Large 1 3/4 in. 600 (4.1, 41)
A29221 CI-122L-150-XD-C 12 VDC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A29222 CI-122L-138-XD-C 12 VDC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A29223 CI-122L-125-XD-C 12 VDC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A29226 CI-122L-163-XD-C 12 VDC Advanced Large 1 5/8 in. 900 (6.2, 62)
A29227 CI-122L-175-XD-C 12 VDC Advanced Large 1 3/4 in. 600 (4.1, 41)
A29228 CI-122L-250-XA-C 12 VDC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A29229 CI-122L-238-XA-C 12 VDC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A29230 CI-122L-225-XA-C 12 VDC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A29233 CI-122L-263-XA-C 12 VDC Advanced Large 2 5/8 in. 900 (6.2, 62)
A29234 CI-122L-275-XA-C 12 VDC Advanced Large 2 3/4 in. 600 (4.1, 41)
A29235 CI-122L-250-XB-C 12 VDC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A29236 CI-122L-238-XB-C 12 VDC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A29237 CI-122L-225-XB-C 12 VDC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A29240 CI-122L-263-XB-C 12 VDC Advanced Large 2 5/8 in. 900 (6.2, 62)
A29241 CI-122L-275-XB-C 12 VDC Advanced Large 2 3/4 in. 600 (4.1, 41)
A29242 CI-122L-250-XC-C 12 VDC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A29243 CI-122L-238-XC-C 12 VDC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A29244 CI-122L-225-XC-C 12 VDC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A29247 CI-122L-263-XC-C 12 VDC Advanced Large 2 5/8 in. 900 (6.2, 62)
A29248 CI-122L-275-XC-C 12 VDC Advanced Large 2 3/4 in. 600 (4.1, 41)
A29249 CI-122L-250-XD-C 12 VDC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A29250 CI-122L-238-XD-C 12 VDC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A29251 CI-122L-225-XD-C 12 VDC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A29254 CI-122L-263-XD-C 12 VDC Advanced Large 2 5/8 in. 900 (6.2, 62)
A29255 CI-122L-275-XD-C 12 VDC Advanced Large 2 3/4 in. 600 (4.1, 41)
A29500 CI-1A2L-150-XA-C 12 VDC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A29501 CI-1A2L-138-XA-C 12 VDC Advanced Large 1 3/8 in. 2500 (17.2, 172)
Part No. Configuration Voltage
Pump
Type Motor
Number
of
Pumps
Plunger
Size
Maximum
Working
Pressure
psi (MPa, bar)

Models
334513A 11
A29502 CI-1A2L-125-XA-C 12 VDC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A29505 CI-1A2L-163-XA-C 12 VDC Advanced Large 1 5/8 in. 900 (6.2, 62)
A29506 CI-1A2L-175-XA-C 12 VDC Advanced Large 1 3/4 in. 600 (4.1, 41)
A29507 CI-1A2L-150-XB-C 12 VDC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A29508 CI-1A2L-138-XB-C 12 VDC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A29509 CI-1A2L-125-XB-C 12 VDC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A29512 CI-1A2L-163-XB-C 12 VDC Advanced Large 1 5/8 in. 900 (6.2, 62)
A29513 CI-1A2L-175-XB-C 12 VDC Advanced Large 1 3/4 in. 600 (4.1, 41)
A29514 CI-1A2L-150-XC-C 12 VDC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A29515 CI-1A2L-138-XC-C 12 VDC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A29516 CI-1A2L-125-XC-C 115 VAC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A29519 CI-1A2L-163-XC-C 115 VAC Advanced Large 1 5/8 in. 900 (6.2, 62)
A29520 CI-1A2L-175-XC-C 115 VAC Advanced Large 1 3/4 in. 600 (4.1, 41)
A29521 CI-1A2L-150-XD-C 115 VAC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A29522 CI-1A2L-138-XD-C 115 VAC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A29523 CI-1A2L-125-XD-C 115 VAC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A29526 CI-1A2L-163-XD-C 115 VAC Advanced Large 1 5/8 in. 900 (6.2, 62)
A29527 CI-1A2L-175-XD-C 115 VAC Advanced Large 1 3/4 in. 600 (4.1, 41)
A29528 CI-1A2L-250-XA-C 115 VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A29529 CI-1A2L-238-XA-C 115 VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A29530 CI-1A2L-225-XA-C 115 VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A29533 CI-1A2L-263-XA-C 115 VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
A29534 CI-1A2L-275-XA-C 115 VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
A29535 CI-1A2L-250-XB-C 115 VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A29536 CI-1A2L-238-XB-C 115 VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A29537 CI-1A2L-225-XB-C 115 VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A29540 CI-1A2L-263-XB-C 115 VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
A29541 CI-1A2L-275-XB-C 115 VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
A29542 CI-1A2L-250-XC-C 115 VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A29543 CI-1A2L-238-XC-C 115 VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A29544 CI-1A2L-225-XC-C 115 VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A29547 CI-1A2L-263-XC-C 115 VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
A29548 CI-1A2L-275-XC-C 115 VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
A29549 CI-1A2L-250-XD-C 115 VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A29550 CI-1A2L-238-XD-C 115 VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A29551 CI-1A2L-225-XD-C 115 VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A29554 CI-1A2L-263-XD-C 115 VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
Part No. Configuration Voltage
Pump
Type Motor
Number
of
Pumps
Plunger
Size
Maximum
Working
Pressure
psi (MPa, bar)

Models
12 334513A
A29555 CI-1A2L-275-XD-C 115 VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
A29600 CI-2A2L-150-XA-C 115 VAC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A29601 CI-2A2L-138-XA-C 115 VAC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A29602 CI-2A2L-125-XA-C 115 VAC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A29605 CI-2A2L-163-XA-C 115 VAC Advanced Large 1 5/8 in. 900 (6.2, 62)
A29606 CI-2A2L-175-XA-C 115 VAC Advanced Large 1 3/4 in. 600 (4.1, 41)
A29607 CI-2A2L-150-XB-C 115 VAC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A29608 CI-2A2L-138-XB-C 115 VAC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A29609 CI-2A2L-125-XB-C 115 VAC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A29612 CI-2A2L-163-XB-C 115 VAC Advanced Large 1 5/8 in. 900 (6.2, 62)
A29613 CI-2A2L-175-XB-C 115 VAC Advanced Large 1 3/4 in. 600 (4.1, 41)
A29614 CI-2A2L-150-XC-C 115 VAC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A29615 CI-2A2L-138-XC-C 115 VAC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A29616 CI-2A2L-125-XC-C 230 VAC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A29619 CI-2A2L-163-XC-C 230 VAC Advanced Large 1 5/8 in. 900 (6.2, 62)
A29620 CI-2A2L-175-XC-C 230 VAC Advanced Large 1 3/4 in. 600 (4.1, 41)
A29621 CI-2A2L-150-XD-C 230 VAC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A29622 CI-2A2L-138-XD-C 230 VAC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A29623 CI-2A2L-125-XD-C 230 VAC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A29626 CI-2A2L-163-XD-C 230 VAC Advanced Large 1 5/8 in. 900 (6.2, 62)
A29627 CI-2A2L-175-XD-C 230 VAC Advanced Large 1 3/4 in. 600 (4.1, 41)
A29628 CI-2A2L-250-XA-C 230 VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A29629 CI-2A2L-238-XA-C 230 VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A29630 CI-2A2L-225-XA-C 230 VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A29633 CI-2A2L-263-XA-C 230 VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
A29634 CI-2A2L-275-XA-C 230 VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
A29635 CI-2A2L-250-XB-C 230 VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A29636 CI-2A2L-238-XB-C 230 VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A29637 CI-2A2L-225-XB-C 230 VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A29640 CI-2A2L-263-XB-C 230 VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
A29641 CI-2A2L-275-XB-C 230 VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
A29642 CI-2A2L-250-XC-C 230 VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A29643 CI-2A2L-238-XC-C 230 VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A29644 CI-2A2L-225-XC-C 230 VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A29647 CI-2A2L-263-XC-C 230 VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
A29648 CI-2A2L-275-XC-C 230 VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
A29649 CI-2A2L-250-XD-C 230 VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
Part No. Configuration Voltage
Pump
Type Motor
Number
of
Pumps
Plunger
Size
Maximum
Working
Pressure
psi (MPa, bar)

Models
334513A 13
A29650 CI-2A2L-238-XD-C 230 VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A29651 CI-2A2L-225-XD-C 230 VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A29654 CI-2A2L-263-XD-C 230 VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
A29655 CI-2A2L-275-XD-C 230 VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
A29700 CI-4A2L-150-XA-C 230 VAC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A29701 CI-4A2L-138-XA-C 230 VAC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A29702 CI-4A2L-125-XA-C 230 VAC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A29705 CI-4A2L-163-XA-C 230 VAC Advanced Large 1 5/8 in. 900 (6.2, 62)
A29706 CI-4A2L-175-XA-C 230 VAC Advanced Large 1 3/4 in. 600 (4.1, 41)
A29707 CI-4A2L-150-XB-C 230 VAC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A29708 CI-4A2L-138-XB-C 230 VAC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A29709 CI-4A2L-125-XB-C 230 VAC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A29712 CI-4A2L-163-XB-C 230 VAC Advanced Large 1 5/8 in. 900 (6.2, 62)
A29713 CI-4A2L-175-XB-C 230 VAC Advanced Large 1 3/4 in. 600 (4.1, 41)
A29714 CI-4A2L-150-XC-C 230 VAC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A29715 CI-4A2L-138-XC-C 230 VAC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A29716 CI-4A2L-125-XC-C 230/480 3 Phase VAC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A29719 CI-4A2L-163-XC-C 230/480 3 Phase VAC Advanced Large 1 5/8 in. 900 (6.2, 62)
A29720 CI-4A2L-175-XC-C 230/480 3 Phase VAC Advanced Large 1 3/4 in. 600 (4.1, 41)
A29721 CI-4A2L-150-XD-C 230/480 3 Phase VAC Advanced Large 1 1/2 in. 1250 (8.6, 86)
A29722 CI-4A2L-138-XD-C 230/480 3 Phase VAC Advanced Large 1 3/8 in. 2500 (17.2, 172)
A29723 CI-4A2L-125-XD-C 230/480 3 Phase VAC Advanced Large 1 1/4 in. 6000 (41.3, 413)
A29726 CI-4A2L-163-XD-C 230/480 3 Phase VAC Advanced Large 1 5/8 in. 900 (6.2, 62)
A29727 CI-4A2L-175-XD-C 230/480 3 Phase VAC Advanced Large 1 3/4 in. 600 (4.1, 41)
A29728 CI-4A2L-250-XA-C 230/480 3 Phase VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A29729 CI-4A2L-238-XA-C 230/480 3 Phase VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A29730 CI-4A2L-225-XA-C 230/480 3 Phase VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A29733 CI-4A2L-263-XA-C 230/480 3 Phase VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
A29734 CI-4A2L-275-XA-C 230/480 3 Phase VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
A29735 CI-4A2L-250-XB-C 230/480 3 Phase VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A29736 CI-4A2L-238-XB-C 230/480 3 Phase VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A29737 CI-4A2L-225-XB-C 230/480 3 Phase VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A29740 CI-4A2L-263-XB-C 230/480 3 Phase VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
A29741 CI-4A2L-275-XB-C 230/480 3 Phase VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
A29742 CI-4A2L-250-XC-C 230/480 3 Phase VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A29743 CI-4A2L-238-XC-C 230/480 3 Phase VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A29744 CI-4A2L-225-XC-C 230/480 3 Phase VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
Part No. Configuration Voltage
Pump
Type Motor
Number
of
Pumps
Plunger
Size
Maximum
Working
Pressure
psi (MPa, bar)

Models
14 334513A
A29747 CI-4A2L-263-XC-C 230/480 3 Phase VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
A29748 CI-4A2L-275-XC-C 230/480 3 Phase VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
A29749 CI-4A2L-250-XD-C 230/480 3 Phase VAC Advanced Large 2 1/2 in. 1250 (8.6, 86)
A29750 CI-4A2L-238-XD-C 230/480 3 Phase VAC Advanced Large 2 3/8 in. 2500 (17.2, 172)
A29751 CI-4A2L-225-XD-C 230/480 3 Phase VAC Advanced Large 2 1/4 in. 6000 (41.3, 413)
A29754 CI-4A2L-263-XD-C 230/480 3 Phase VAC Advanced Large 2 5/8 in. 900 (6.2, 62)
A29755 CI-4A2L-275-XD-C 230/480 3 Phase VAC Advanced Large 2 3/4 in. 600 (4.1, 41)
Part No. Configuration Voltage
Pump
Type Motor
Number
of
Pumps
Plunger
Size
Maximum
Working
Pressure
psi (MPa, bar)

Models
334513A 15
Configuration Number Matrix
Check the identification plate (ID) for the 12-digit Configuration Number of your pump. Use the following matrix to
define the components of your pump.
NOTE: Not all combinations are possible.
Sample Configuration Number: CI-121S-119-SA-0
CI 12 1 S 1 19 S A 0
Chemical
Injection
Voltage Pump
Ty p e
Motor Number
of Pumps
Plunger Size Plunger
Material
Seal
Material
Qualifier
Voltage Pump Type Motor
Number of
Pumps
Plunger Size
(diameter) Plunger Material
Seal
Material Qualifier
12 12 VDC 1 Basic S Small 1 1 25 1/4” S 17-4 PH Stainless A FKM 0 None
1A 115 VAC 2 Advanced L Large 2 2 38 3/8” X Chromex-Coated
17-4 PH Stainless
B FKMET
P
C Cycle
Count
2A 230 VAC 50 1/2” CHNBR
4A 480 VAC 63 5/8” D FFKM
75 3/4”

Warnings
16 334513A
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama-
tion point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When
these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific
hazard symbols and warnings not covered in this section may appear throughout the body of this manual where
applicable.
FIRE AND EXPLOSION HAZARD
When flammable fluids are present in the work area be aware that flammable fumes can ignite or
explode. To help prevent fire and explosion:
• Use equipment only in well ventilated area.
• Eliminate all ignition sources, such as cigarettes and portable electric lamps.
• Ground all equipment in the work area.
• Keep work area free of debris, including rags and spilled or open containers of solvent.
• Do not plug or unplug power cords or turn lights on or off when flammable fumes are present.
• Use only grounded hoses.
•Stop operation immediately if static sparking occurs or you feel a shock.Do not use equipment until
you identify and correct the problem.
• Keep a working fire extinguisher in the work area.
SKIN INJECTION HAZARD
High-pressure fluid from dispensing device, hose leaks, or ruptured components will pierce skin. This
may look like just a cut, but it is a serious injury that can result in amputation. Get immediate surgical
treatment.
• Do not put your hand over the fluid outlet.
• Do not stop or deflect leaks with your hand, body, glove, or rag.
• Follow the Pressure Relief Procedure when you stop dispensing and before cleaning, checking, or
servicing equipment.
• Tighten all fluid connections before operating the equipment.
• Check hoses and couplings daily. Replace worn or damaged parts immediately.
ELECTRIC SHOCK HAZARD
This equipment must be grounded. Improper grounding, setup, or usage of the system can cause elec-
tric shock.
• Turn off and disconnect power at main switch before disconnecting any cables and before servicing
or installing equipment.
• Connect only to grounded power source.
• All electrical wiring must be done by a qualified electrician and comply with all local codes and
regulations.

Warnings
334513A 17
MOVING PARTS HAZARD
Moving parts can pinch, cut or amputate fingers and other body parts.
• Keep clear of moving parts.
• Do not operate equipment with protective guards or covers removed.
• Pressurized equipment can start without warning. Before checking, moving, or servicing equipment,
follow the Pressure Relief Procedure and disconnect all power sources.
TOXIC FLUID OR FUMES HAZARD
Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled, or
swallowed.
• Read Safety Data Sheet (SDS) to know the specific hazards of the fluids you are using.
• Store hazardous fluid in approved containers, and dispose of it according to applicable guidelines.
PERSONAL PROTECTIVE EQUIPMENT
Wear appropriate protective equipment when in the work area to help prevent serious injury, including
eye injury, hearing loss, inhalation of toxic fumes, and burns. Protective equipment includes but is not
limited to:
• Protective eyewear, and hearing protection.
• Respirators, protective clothing, and gloves as recommended by the fluid and solvent manufacturer.
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not operate the unit when fatigued or under the influence of drugs or alcohol.
• Do not exceed the maximum working pressure or temperature rating of the lowest rated system com-
ponent. See Technical Data in all equipment manuals.
• Use fluids and solvents that are compatible with equipment wetted parts. See Technical Data in all
equipment manuals. Read fluid and solvent manufacturer’s warnings. For complete information
about your material, request Safety Data Sheet (SDS) from distributor or retailer.
• Turn off all equipment and follow the Pressure Relief Procedure when equipment is not in use.
• Check equipment regularly. Repair or replace worn or damaged parts immediately with genuine man-
ufacturer’s replacement parts only.
• Do not alter or modify equipment. Alterations or modifications may void agency approvals and create
safety hazards.
• Make sure all equipment is rated and approved for the environment in which you are using it.
• Use equipment only for its intended purpose. Call your distributor for information.
• Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.
• Do not kink or over bend hoses or use hoses to pull equipment.
• Keep children and animals away from work area.
• Comply with all applicable safety regulations.

Component Identification
18 334513A
Component Identification
Numbered items in the key below correspond to the
numbers in the Parts Lists starting on page 40.
Key:
FIG. 1 Pump Components
Wolverine Basic Wolverine Advanced
26
42
15
15
14
14
1
2
2
42
20
25
24
21
78 24
25
21 78
2a 2a
2b 2b
2c
2c
1 Drive Housing
2Motor
2a Motor Junction Box
2b Motor Dust Cover
2c End ring
14 Drive Cylinder
15 Pump Dust Cover
20 Check Valve Housing (Wolverine Advanced only)
21 Prime/Bleed Valve
24 Inlet Check Valve
25 Outlet Check Valve
26 Molded Guard and Motor/Pump Support
42 Pump Cylinder
78 Stand

Installation
334513A 19
Installation
Grounding
Pump: grounded through motor Electrical Connec-
tions on page 22.
Fluid lines: use only electrically conductive lines.
Fluid supply container: follow local code.
Accessories
Install the following required accessories in the order
shown in FIG. 2, using adapters as necessary. See Kits
and Accessories starting on page 48.
•Fluid filter (Y-Strainer) (included in M): with a 60
mesh (250 micron) stainless steel element to filter
particles from the fluid before in reaches the pump.
•Fluid shutoff valves (N): shuts off fluid flow.
•Pressure relief valve (F): overload protection.
Flush Before Using Equipment
The equipment was tested with lightweight oil, which is
left in the fluid passages to protect parts. To avoid con-
taminating your fluid with oil, flush the equipment with a
compatible solvent before using the equipment. See
Flush the Equipment, page 23.
The equipment must be grounded to reduce the risk
of static sparking and electric shock. Electric or static
sparking can cause fumes to ignite or explode.
Improper grounding can cause electric shock.
Grounding provides an escape wire for the electric
current.

Installation
20 334513A
Typical Installation
FIG. 2 is an example of an installation with a Wolverine
chemical injection pump. Your installation may differ
from what is shown here. The Wolverine pump (A) is the
only component in FIG. 2 supplied by Graco. All other
components are supplied by customer.
Key:
APump
B Control Box
C Solar Panel
D Stand Unit
E Tank
F Pressure Relief Valve
G Inlet Line
H Outlet Line
J Pressure Relief Line
K Inlet Port
LOutletPort
M Manifold Assembly (includes y-strainer and fluid shutoff
valve (N))
N Fluid Shutoff Valve (inlet & outlet)
FIG. 2 Typical Installation with a Solar Panel
A
C
B
H
G
J
E
D
F
K
L
N
N
M
