Graco 222012 User manual


INSTRUCTIONS–P ARTS LIST 307–944
Rev. G
Supersedes F
and PCN G
SEVERE-DUTY
Displacement Pumps
3000 psi (210 bar) Maximum Working Pressure
Part No. 222–012, Series B
0.554 in.  (357.4 mm ) Ef fective Displacement Area
Part No. 222–015, Series A
0.443 in.  (285.8 mm ) Ef fective Displacement Area
Part No. 222–017, Series B
0.370 in.  (238.7 mm ) Ef fective Displacement Area
Part No. 222–019, Series A
0.277 in.  (178.7 mm ) Ef fective Displacement Area
Severe-Duty Displacement Pumps have an abrasion
and corrosion-resistant displacement rod and cylinder .
Refer to T echnical Data on the back cover for W etted
Parts information.
Table of Contents
Warnings 2, 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service 4, 5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessories 5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions 5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts 6, 7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Repair Kits 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Data 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warranty 8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Graco Phone Numbers 8. . . . . . . . . . . . . . . . . . . . . . . . . .
WARNING
Plural Component Materials Hazard
Graco Inc. does not manufacture or supply any of the reactive chemical materials that may be used in this
equipment and is not responsible for their ef fects. Because of the vast number of chemicals that could be
used and their varying chemical reaction, before using this equipment the buyer and the user should deter -
mine all facts relating to the materials used, including any of the potential hazards involved. Particular inquiry
and investigation should be made into the potential dangers relating to toxic fumes, fires, explosions, reaction
times, and exposure of human beings to the individual components or their resultant mixtures. Graco as -
sumes no responsibility for loss, damage, expense or claims for bodily injury or property damage, direct or
consequential, arising from the use of such chemical components.
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
COPYRIGHT 1988, GRACO INC.
This manual contains important
warnings and information.
READ AND RETAIN FOR REFERENCE

 
Warning
High Pressure Spray Can Cause Serious Injury . For Professional Use Only.
Observe All W arnings. Read and understand all instruction manuals before operating equipment.
FLUID INJECTION HAZARD
General Safety
This equipment generates very high fluid pressure. Spray from the
gun, leaks or ruptured components can inject fluid through your skin
and into your body and cause extremely serious bodily injury , includ -
ing the need for amputation. Also, fluid injected or splashed into the
eyes or on the skin can cause serious damage.
Never point the spray gun at anyone or at any part of the body . Never
put hand or fingers over the spray tip. Never try to “blow back” fluid;
this is not an air spray system.
Always have the tip guard in place on the spray gun when spraying.
Always follow the Pressure Relief Procedure , right, before cleaning
or removing the spray tip or servicing any system equipment.
Never try to stop or deflect leaks with your hand or body .
Be sure equipment safety devices are operating properly before each
use.
Medical Alert––Airless Spray W ounds
If any fluid appears to penetrate your skin, get emergency medical
care at once. Do not treat as a simple cut . T ell the doctor exactly
what fluid was injected.
NOTE T O PHYSICIAN: Injection in the skin is a traumatic injury . It is
important to treat the injury surgically as soon as possible . Do
not delay treatment to research toxicity . T oxicity is a concern with
some exotic coatings injected directly into the blood stream. Consulta -
tion
with a plastic surgeon or reconstructive hand surgeon may be
advisable.
Spray Gun Safety Devices
Be sure all spray gun safety devices are operating properly before
each use. Do not remove or modify any part of the spray gun; this can
cause a malfunction and result in serious bodily injury .
Safety Latch
Whenever you stop spraying, even for a moment, always set the
safety latch in the closed or “safe” position, making the spray gun
inoperative. Failure to set the safety latch can result in accidental trig -
gering of the spray gun.
Trigger Guard
Never operate the spray gun with the trigger guard removed. This
guard helps prevent the gun from triggering accidentally if it is dropped
or bumped.
Diffuser
The spray gun dif fuser breaks up spray and reduces the risk of fluid
injection when the tip is not installed. Check the dif fuser operation
regularly . Follow the Pressure Relief Procedure , at right, then re -
move the spray tip. Aim the spray gun into a grounded metal pail,
holding the spray gun firmly to the pail. Using the lowest possible pres -
sure,
trigger the spray gun. If the fluid emitted is not diffused into an
irregular stream, replace the dif fuser immediately .
Tip Guard
Always have the tip guard in place on the spray gun while spraying.
The tip guard alerts you to the fluid injection hazard and helps reduce,
but does not prevent , the risk of accidentally placing your fingers or
any part of your body close to the spray tip.
Spray Tip
Use extreme caution when cleaning or changing spray tips. If the
spray tip clogs while spraying, engage the safety latch immediately .
Always follow the Pressure Relief Procedure and then remove the
spray tip to clean it.
Never wipe of f build-up around the spray tip until pressure is fully re -
lieved and the safety latch is engaged.
Pressure Relief Procedure
To reduce the risk of serious bodily injury , including fluid injection,
splashing in the eyes or on the skin, or injury from moving parts, al -
ways follow this procedure whenever you shut of f the pump, when
checking or servicing any part of the spray system, when installing,
cleaning or changing spray tips, and whenever you stop spraying.
1. Engage the spray gun safety latch.
2. Shut of f the air or hydraulic fluid to the pump.
3. Close the bleed-type master air valve (required in air-powered
systems).
4.
Disengage the spray gun safety latch.
5. Hold a metal part of the spray gun firmly to the side of a grounded
metal pail, and trigger the gun to relieve pressure.
6. Engage the spray gun safety latch.
7. Open the drain valve (required in your system), having a con -
tainer ready to catch the drainage.
8. Leave the drain valve open until you are ready to spray again.
If you suspect that the spray tip or hose is completely clogged, or that
pressure has not been fully relieved after following the steps above,
very slowly loosen the retaining nut or hose end coupling and relieve
pressure gradually , then loosen completely . Now clear the tip or hose.
MOVING P ARTS HAZARD
Moving parts can pinch or amputate your fingers or other body parts.
When the pump is operating, the air motor piston (located behind the
air motor plates) moves. Therefore, never operate the pump with the
air motor plates removed. Before servicing the pump, follow the Pres -
sure
Relief Procedure above to prevent the pump from starting acci -
dentally.
PLURAL COMPONENT MA TERIALS
Be extremely cautious when handling plural component materials and
solvents used with them. Some are extremely toxic. See the WARN-
ING
on the front cover . Read and follow the coating and solvent manu -
facturer’s
safety precautions and warnings, including any regarding
protective clothing, eyewear , and respirator .

 
EQUIPMENT MISUSE HAZARD
General Safety
Any misuse of the spray equipment or accessories, such as
overpressurizing, modifying parts, using incompatible chemicals and
fluids, or using worn or damaged parts, can cause them to rupture and
result in fluid injection, splashing in the eyes or on the skin, or other
serious bodily injury , or fire, explosion or property damage.
Never alter or modify any part of this equipment; doing so could cause
it to malfunction.
Check all spray equipment regularly and repair or replace worn or
damaged parts immediately .
Always wear protective eyewear , gloves, clothing and respirator as
recommended by the fluid and solvent manufacturer .
System Pressure
The maximum working pressure of this displacement pump is 3000 psi
(210 bar). The working pressure is determined by the air or hydraulic
motor . Do not exceed the maximum working pressure stated on your
complete pump, or 3000 psi (210 bar), whichever is smaller .
Be sure that all spray equipment and accessories are rated to with -
stand
the maximum working pressure of the pump. Do not exceed the
maximum working pressure of any component or accessory used in
the system.
Fluid Compatibility
Be sure that all fluids and solvents used are chemically compatible
with the wetted parts shown in the Technical Data on the back cover .
Always read the manufacturer ’ s literature before using fluid or solvent
in this pump.
HOSE SAFETY
High pressure fluid in the hoses can be very dangerous. If the hose
develops a leak, split or rupture due to any kind of wear , damage or
misuse, the high pressure spray emitted from it can cause a fluid in -
jection injury or other serious bodily injury or property damage.
All fluid hoses must have spring guards on both ends! The spring
guards help protect the hose from kinks or bends at or close to the
coupling which can result in hose rupture.
T ighten all fluid connections securely before each use. High pressure
fluid can dislodge a loose coupling or allow high pressure spray to be
emitted from the coupling.
Never use a damaged hose. Before each use, check the entire hose
for cuts, leaks, abrasion, bulging cover , or damage or movement of the
hose couplings. If any of these conditions exist, replace the hose im -
mediately
. Do not try to recouple high pressure hose or mend it with
tape or any other device. A repaired hose cannot safely contain the
high pressure fluid.
Handle and route hoses carefully . Do not pull on hoses to move
equipment. Do not use fluids which are not compatible with the inner
tube and cover of the hose. Do not expose Graco hoses to tempera -
tures above 180  F (82  C) or below –40  F (–40  C).
Hose Grounding Continuity
Proper hose grounding continuity is essential to maintaining a
grounded spray system. Check the electrical resistance of your air
and fluid hoses at least once a week. If your hose does not have a tag
on it which specifies the maximum electrical resistance, contact the
hose supplier or manufacturer for the maximum resistance limits. Use
a resistance meter in the appropriate range for your hose to check the
resistance. If the resistance exceeds the recommended limits, replace
it immediately . An ungrounded or poorly grounded hose can make
your system hazardous. Also, read FIRE OR EXPLOSION HAZARD ,
below.
FIRE OR EXPLOSION HAZARD
Static electricity is created by the high velocity flow of fluid through the
pump and hose. If every part of the spray equipment is not properly
grounded, sparking may occur , and the system may become hazard -
ous.
Sparking may also occur when plugging in or unplugging a power
supply cord. Sparks can ignite fumes from solvents and the fluid being
sprayed, dust particles and other flammable substances, whether you
are spraying indoors or outdoors, and can cause a fire or explosion
and serious bodily injury and property damage. Do not plug in or un -
plug any power supply cords in the spray area when there is any
chance of igniting fumes still in the air .
If you experience any static sparking or even a slight shock while
using this equipment, stop spraying immediately . Check the entire
system for proper grounding. Do not use the system again until the
problem has been identified and corrected.
Grounding
T o reduce the risk of static sparking, ground the pump and all other
spray equipment used or located in the spray area. Check your local
electrical code for detailed grounding instructions for your area and
type of equipment. Be sure to ground all of this spray equipment:
1. Pump: use a ground wire and clamp as shown in your separate
pump manual.
2. Air or hydraulic hoses: use only grounded hoses.
3. Fluid hoses: use only grounded fluid hoses.
4. Air compressor or hydraulic supply: follow manufacturer ’ s recom -
mendations.
5.
Spray gun: grounding is obtained through connection to a properly
grounded fluid hose and pump.
6. Fluid supply container: according to local code.
7. Object being sprayed: according to your local code.
8. All solvent pails used when flushing, according to local code. Use
only metal pails, which are conductive, placed on a grounded
surface. Do not place the pail on a nonconductive surface, such
as paper or cardboard, which interrupts the grounding continuity .
9.
T o maintain grounding continuity when flushing or relieving pres -
sure
, always hold a metal part of the spray gun firmly to the side of
a grounded metal pail, then trigger the spray gun.
Flushing Safety
Before flushing, be sure the entire system and flushing pails are prop -
erly grounded. Refer to Grounding , at the left. Follow the Pressure
Relief Procedure on page 2, and remove the spray tip from the
spray gun. Always use the lowest possible fluid pressure, and main -
tain firm metal-to-metal contact between the spray gun and the pail
during flushing to reduce the risk of fluid injection injury , static sparking
and splashing.
IMPORTANT
United States Government safety standards have been adopted under the Occupational Safety and Health Act. These standards – particularly the
General Standards, Part 1910, and the Construction Standards, Part 1926 – should be consulted.

 
Service
Displacement Pump Repair
NOTE: Repair Kits are available. See page 6. For
the best results, use all the new parts in the kit, even if
the old ones look good. Eight shims (14*) are included
in the kit, but use only the number required. An aster -
isk behind a reference number , for example (3*), indi -
cates that this part is included in the repair kit.
1. Solvent flush the pump, if possible. Follow the
Pressure Relief Procedure on page 2, stopping
the pump at the bottom of its stroke. Then discon -
nect all hoses from the pump.
2. Unscrew the displacement rod (1) from the air mo -
tor connecting rod.
3. Screw the intake valve housing (24) out of the cyl -
inder (1
1). See Fig. 1. Disassemble and clean the
parts of the valve, inspecting for damage or wear .
If the seat in the valve housing is chipped or worn,
replace the housing (24).
4. Loosen the packing nut (2). Push down on the dis -
placement rod (1) until you can grasp the piston
stud (20). Pull the displacement rod out the bottom
of the cylinder (1 1).
5.
Inspect the outer surface of the displacement rod
(1) and the polished inner surface of the cylinder
sleeve (12) for scoring or wear by running a finger
over the surface or holding up to a light at an an -
gle. Damage to these parts may cause premature
packing wear or leaking. If either is worn or
scratched, replace it.
NOTE: If replacing the sleeve (12), be sure to install it
with the notched end up, and replace the o-ring (10*)
in the notch. If the old sleeve is hard to remove, con -
tact Graco T echnical Assistance (see back page).
6. Unscrew the piston stud (20) from the displace -
ment rod (1). Remove the ball (13), shims (14),
backup washers (15), glands (16 and 19), and v-
packings (17 and 18). Clean all parts and inspect
for damage. If the seat on the piston stud (20) is
nicked or worn, replace it.
7. Remove the packing nut/wet-cup (2). Remove the
bearing (3), glands (4 and 7), and v-packings (5
and 6) from the throat of the pump cylinder (1
1).
Clean all parts and inspect for damage.
8. Lubricate all packings before reassembling the
pump.
9.
One at a time, place a male gland (7*), one
UHMWPE v-packing (5*), two v-packings
(6*), one UHMWPE v-packing (5*), a female gland
(4*), and the bearing (3*) in the throat of the cylin -
der (11).
Be sure the lips of the v-packings face
down in the throat. See Fig. 1.
Fig 1
1
3
4
2
2
3*
5*
*4
11
12
*10
1
13*
16*
17*
18*
17*
19*
15
15
20
30
24
*22
21 23*
Torque to 50–60 ft–lb
(70–80 N.m).
Lips of v-packings
must face down.
Add shims (14*) re -
quired to make
stack height
0.950–0.975 in.
(24.13–24.77 mm).
Apply sealant.
T orque to 200 in–lb
(23 N.m).
5
Lips of v-packings
must face up.
6
1
5
2 3
4
1
5
5
6
02404
*14
6
*7
5* 4
6* 4
PTFE

307-944 5
Service
10. Loosely install the packing nut (2).
11. One at a time, place a backup washer (15), a fe -
male gland (19*), one UHMWPE v-packing (17*),
two v-packings (18*), one UHMWPE v-
packing (17*), a male gland (16*), and a backup
washer (15) on the piston stud (20). Be sure the
lips of the v-packings face up on the piston. See
Fig. 1.
12. Add shims (14*) below the top backup washer
(15*), using as many as necessary to obtain a total
packing stack height of 0.950–0.975 in.
(24.13–24.77 mm).
13. Place the ball (13*) on the piston stud (20). Apply
liquid thread sealant to the piston threads and
screw the piston assembly into the displacement
rod (1), torquing to 200 in–lb (23 N.m).
14. Lubricate the displacement rod (1), and guide it
through the bottom of the pump cylinder (1 1) and
carefully through the throat packings.
15. Install the o-ring (22*) on the intake valve housing
(24). Place the ball (23*) on the seat of the intake
valve housing. Slip the o-ring retainer (30) onto the
intake housing and align the holes in the two parts.
Install the ball stop pin (21) through the o-ring re -
tainer and intake valve housing, and screw the
housing into the pump cylinder (1 1). T orque to
50–60 ft–lb (70–80 N.m).
16. T orque the packing nut (2) to 50–60 ft–lb (70–80
N.m). Fill the packing nut cavity with Throat Seal
Liquid (TSL).
17. Screw the displacement rod (1) into the air motor
connecting rod.
NOTE: If the ground wire was disconnected before
servicing, be sure to reconnect it before operating the
pump, and check to be sure the entire system is prop
-
erly grounded.
Manual
Change Summary
Assembly
Changed
Part
Status
Ref
No.
Part No. Name
222–012, to
Series B
Old 3 181–665 Bearing
New 3 188–402 Spacer
Accessories
Must be ordered separately
ISO PUMP OIL
Use in wet-cup instead of Throat Seal Liquid (TSL)
when pumping moisture-sensitive fluids.
217–374 1 pint container
218–656 1 gallon container
HYDRA-CA T WRENCH 176–881
For tightening packing nut and intake valve.
 P ACKING CONVERSION KITS
T o convert the pump to all packings. Includes
instructions.
223–549
For pump model 222–015
223–550 For pump model 222–019
223–551 For pump model 222–012
223–552 For pump model 222–017
Dimensions
1
1/2–20 unf
1 3/4–20 un
3/8 npt(f)
3/4 npt(m)
12.50 in.
(317.5 mm)
18.62 in.
(473.0 mm)
1
With connecting rod at
bottom of stroke.
02403
PTFE
PTFE
PTFE

6 307-944
Parts

1
2
*3
*4
*6 5*
*7
*10
11
12 *13
*14
15
15
*16
*17
*18
*19
20
21 22*
24
*23
30
*17
222–236 Repair Kit
For Displacement Pump 222–012
(Must be purchased separately .)
Ref. No. Qty Ref. No. Qty
3 1 14 8
4 1 16 1
5 2 17 2
6 2 18 2
7 1 19 1
10 1 22 1
13 1 23 1
222–237 Repair Kit
For Displacement Pump 222–015
(Must be purchased separately .)
Ref. No. Qty Ref. No. Qty
3 1 14 8
4 1 16 1
5 2 17 2
6 2 18 2
7 1 19 1
10 1 22 1
13 1 23 1
222–234 Repair Kit
For Displacement Pump 222–017
(Must be purchased separately .)
Ref. No. Qty Ref. No. Qty
3 1 14 8
4 1 16 1
5 2 17 2
6 2 18 2
7 1 19 1
10 1 22 1
13 1 23 1
222–235 Repair Kit
For Displacement Pump 222–019
(Must be purchased separately .)
Ref. No. Qty Ref. No. Qty
3 1 14 8
4 1 16 1
5 2 17 2
6 2 18 2
7 1 19 1
10 1 22 1
13 1 23 1

 
Parts
Model 222–012, Series B
REF
NO. PART NO. DESCRIPTION QTY
1 181–513 ROD, displacement; sst 1
2 181–511 NUT, packing; cst 1
3* 188–402 SPACER, packing; sst 1
4* 181–725 GLAND, female; cst 1
5* 181–666 V-PACKING; UHMWPE 2
6* 183–757 V-PACKING; r2
7* 181–726 GLAND, male; cst 1
10* 109–115 O-RING; r1
11 181–649 CYLINDER, pump; cst 1
12 181–510 SLEEVE, cylinder; sst 1
13* 101–823
BALL; 5/16” dia.; sst 1
14* 178–855 SHIM; sst 8
15n176–107 WASHER, back-up; cst 2
16* 181–664 GLAND, male; cst 1
17* 181–661 V-PACKING; UHMWPE 2
18* 165–104 V-PACKING; r2
19* 181–663 GLAND, female; cst 1
20n205–383 STUD, piston; cst, w/carbide seat 1
21 165–049
PIN, stop, ball; sst 1
22* 109–176 O-RING; r1
23* 100–064
BALL; 5/8” dia.; cst 1
24 220–297 HOUSING, valve, intake;
cst, w/carbide seat 1
30n185–265 RETAINER, o-ring; sst 1
* These parts are also included in Repair Kit 222–236,
which may be purchased separately .
n Keep these spare parts on hand to reduce down time.
Model 222–015, Series A
REF
NO. PART NO. DESCRIPTION QTY
1 181–656 ROD, displacement; sst 1
2 181–511 NUT, packing; cst 1
3* 181–655 BEARING, sleeve; acetal 1
4* 181–652 GLAND, female; cst 1
5* 181–654 V-PACKING; UHMWPE 2
6* 183–758 V-PACKING; r2
7* 181–651 GLAND, male; cst 1
10* 109–115 O-RING; r1
11 181–649 CYLINDER, pump; cst 1
12 181–509 SLEEVE, cylinder; sst 1
13* 101–823
BALL; 5/16” dia.; sst 1
14* 188–204 SHIM; sst 8
15n176–108 WASHER, back-up; cst 2
16* 181–724 GLAND, male; cst 1
17* 181–653 V-PACKING; UHMWPE 2
18* 183–760 V-PACKING; r2
19* 181–723 GLAND, female; cst 1
20n205–386 STUD, piston; cst, w/carbide seat 1
21 165–049
PIN, stop, ball; sst 1
22* 109–176 O-RING; r1
23* 100–064
BALL; 5/8” dia.; cst 1
24 220–297 HOUSING, valve, intake;
cst, w/carbide seat 1
30n185–265 RETAINER, o-ring; sst 1
* These parts are also included in Repair Kit 222–237,
which may be purchased separately .
n Keep these spare parts on hand to reduce down time.
Model 222–017, Series B
REF
NO. PART NO. DESCRIPTION QTY
1 181–660 ROD, displacement; sst 1
2 181–511 NUT, packing; cst 1
3* 181–659 BEARING, sleeve; acetal 1
4* 181–719 GLAND, female; cst 1
5* 181–657 V-PACKING; UHMWPE 2
6* 183–861 V-PACKING; r2
7* 181–720 GLAND, male; cst 1
10* 109–115 O-RING; r1
11 181–649 CYLINDER, pump; cst 1
12 181–508 SLEEVE, cylinder; sst 1
13* 101–823
BALL; 5/16” dia.; sst 1
14* 178–856 SHIM; sst 8
15n164–391 WASHER, back-up; cst 2
16* 181–722 GLAND, male; cst 1
17* 181–658 V-PACKING; UHMWPE 2
18* 183–759 V-PACKING; r2
19* 181–721 GLAND, female; cst 1
20n205–388 STUD, piston; cst, w/carbide seat 1
21 165–049
PIN, stop, ball; sst 1
22* 109–176 O-RING; r1
23* 100–064
BALL; 5/8” dia.; cst 1
24 220–297 HOUSING, valve, intake;
cst, w/carbide seat 1
30n185–265 RETAINER, o-ring; sst 1
* These parts are also included in Repair Kit 222–234,
which may be purchased separately .
n Keep these spare parts on hand to reduce down time.
Model 222–019, Series A
REF
NO. PART NO. DESCRIPTION QTY
1 181–512 ROD, displacement; sst 1
2 181–511 NUT, packing; cst 1
3* 181–645 BEARING, sleeve; acetal 1
4* 181–718 GLAND, female; cst 1
5* 181–506 V-PACKING; UHMWPE 2
6* 183–761 V-PACKING; r2
7* 181–717 GLAND, male; cst 1
10* 109–115 O-RING; r1
11 181–649 CYLINDER, pump; cst 1
12 181–507 SLEEVE, cylinder; sst 1
13* 101–823
BALL; 5/16” dia.; sst 1
14* 178–857 SHIM; sst 8
15n176–109 WASHER, back-up; cst 2
16* 181–646 GLAND, male; cst 1
17* 181–662 V-PACKING; UHMWPE 2
18* 165–109 V-PACKING; r2
19* 181–647 GLAND, female; cst 1
20n207–923 STUD, piston; cst, w/carbide seat 1
21 165–049
PIN, stop, ball; sst 1
22* 109–176 O-RING; r1
23* 100–064
BALL; 5/8” dia.; cst 1
24 220–297 HOUSING, valve, intake;
cst, w/carbide seat 1
30n185–265 RETAINER, o-ring; sst 1
* These parts are also included in Repair Kit 222–235,
which may be purchased separately .
n Keep these spare parts on hand to reduce down time.
PTFE
PTFE
PTFE
PTFE
PTFE
PTFE
PTFE
PTFE
PTFE
PTFE
PTFE
PTFE
PTFE
PTFE
PTFE
PTFE

8 307-944
Technical Data
Maximum working pressure 3000 psi (210 bar) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wetted parts Stainless Steel, T ungsten Carbide, . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chrome and Zinc Plating, Carbon Steel, r,
Ultra-High Molecular W eight Polyethylene
Displ. Pump
Part No.
Cylinder ID Area
in.@ (mm @)
Displ. Rod OD Area
in.@
(mm @)
% of
Diff.
Effective Area
in.@ (mm @)
Maximum Stroke
in. (mm)
222–012 1.107 (714.20) 0.544 (350.99) 0.16 0.554 (357.44) 4.75 (120.7)
222–015 0.887 (572.29) 0.442 (285.18) –0.7 0.443 (285.81) 4.75 (120.7)
222–017 0.740 (477.42) 0.371 (239.37) 1.00 0.370 (238.71) 4.75 (120.7)
222–019 0.554 (357.44) 0.277 (178.72) 0.00 0.277 (178.72) 4.75 (120.7)
The Graco Warranty and Disclaimers
WARRANTY
Graco warrants all equipment manufactured by it and bearing its name to be free from defects in material and workmanship on
the date of sale by an authorized Graco distributor to the original purchaser for use. As purchaser ’ s sole remedy for breach of this
warranty, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment proven defec -
tive.
This warranty applies only when the equipment is installed, operated and maintained in accordance with Graco’ s written rec-
ommendations.
This warranty does not cover
, and Graco shall not be liable for , any malfunction, damage or wear caused by faulty installation,
misapplication, abrasion, corrosion, inadequate or improper maintenance, negligence, accident, tampering, or substitution of
non–Graco component parts. Nor shall Graco be liable for malfunction, damage or wear caused by the incompatibility with Graco
equipment of structures, accessories, equipment or materials not supplied by Graco, or the improper design, manufacture, instal
-
lation, operation or maintenance of structures, accessories, equipment or materials not supplied by Graco.
This warranty is conditioned upon the prepaid return of the equipment claimed to be defective to an authorized Graco distributor
for verification of the claim. If the claimed defect is verified, Graco will repair or replace free of charge any defective parts. The
equipment will be returned to the original purchaser transportation prepaid. If inspection of the equipment does not disclose any
defect in material or workmanship, repairs will be made at a reasonable charge, which charges may include the costs of parts,
labor and transportation.
DISCLAIMERS AND LIMIT ATIONS
THE TERMS OF THIS W ARRANTY CONSTITUTE PURCHASER’S SOLE AND EXCLUSIVE REMEDY AND ARE IN LIEU OF ANY OTHER
W ARRANTIES (EXPRESS OR IMPLIED), INCLUDING W ARRANTY OF MERCHANT ABILITY OR W ARRANTY OF FITNESS FOR A P ARTICU-
LAR PURPOSE, AND OF ANY NON–CONTRACTUAL LIABILITIES, INCLUDING PRODUCT LIABILITIES, BASED ON NEGLIGENCE OR
STRICT LIABILITY . EVER Y FORM OF LIABILITY FOR DIRECT , SPECIAL OR CONSEQUENTIAL DAMAGES OR LOSS IS EXPRESSL Y EX -
CLUDED AND DENIED. IN NO CASE SHALL GRACO’S LIABILITY EXCEED THE AMOUNT OF THE PURCHASE PRICE. ANY ACTION FOR
BREACH OF W ARRANTY MUST BE BROUGHT WITHIN TWO (2) YEARS OF THE DA TE OF SALE.
EQUIPMENT NOT COVERED BY GRACO W ARRANTY
GRACO MAKES NO W ARRANTY , AND DISCLAIMS ALL IMPLIED W ARRANTIES OF MERCHANT ABILITY AND FITNESS FOR A P ARTICULAR
PURPOSE,
WITH RESPECT T O ACCESSORIES, EQUIPMENT , MA TERIALS, OR COMPONENTS SOLD BUT NOT MANUF ACTURED BY
GRACO. These items sold, but not manufactured by Graco (such as electric motor , switches, hose, etc.) are subject to the war -
ranty
, if any , of their manufacturer . Graco will provide purchaser with reasonable assistance in making any claim for breach of
these warranties.
Graco Phone Numbers
TO PLACE AN ORDER , contact your Graco distrib -
utor
, or call this number to identify the distributor
closest to you: 1–800–367–4023 T oll Free
FOR TECHNICAL ASSIST ANCE, service repair
information or assistance regarding the application of
Graco equipment: 1–800–543–0339 T oll Free
Sales Offices: Atlanta, Chicago, Dallas, Detroit, Los Angeles, Mt. Arlington (N.J.)
Foreign Offices: Canada; England; Korea; Switzerland; France; Germany; Hong Kong; Japan
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
PRINTED IN U.S.A. 307–944 10/88 Revised 7/93
PTFE
PTFE
