Granberg Manulift 6380 User manual

2020-05-19
User manual Manulift 6380
Products
Height adjustable frames for worktops
MANULIFT 6380
Granberg Interior AB - Box 6112 - 600 06 Norrköping - SWEDEN
Tel: [phone] - E-mail: [email protected] - Internet: www.granberg.se

Content
1. Introduction
2. Declaration of conformity with EU directives
3. Intended use
4. Technical data
5. Safe use
6. Load distribution and side forces
7. Instructions for recycling
Granberg Interior AB - Box 6112 - 600 06 Norrköping - SWEDEN
Tel: [phone] - E-mail: [email protected] - Internet: www.granberg.se

1. Introduction
We have the pleasure to deliver a Granberg Manulift 6380, a manual operated lifting and lowering system for
kitchen. Manulift 6380 can be used separately, or together with the Granberg Wall cabinet lifts, and it becomes then
a total adaptation of the kitchen. The product is suitable for kitchens of various makes, which are made according
the standards EN 1116 and EN 1153.
Only authorized persons may use Manulift 6380!
Authorization means obligation to read and follow the instructions.
It is very important that you read and understands the instructions before you use the device.
If you have any questions - contact your supplier.
This Instruction manual shall be available for all concerned persons, be kept in a protected place and shall follow
the product, if it is moved to another installation site or another house or apartment owner.
Correct use, operation, inspections and maintenance are decisive for efficient and safe work.
2. Declaration of conformity with EU directives
This product is CE-marked and is thereby declared to conform to the basic functionality and safety requirements of
current Machinery Directives.
“EG Declaration of Conformity” is found in a separate document.
3. Intended use
Manulift 6380 is a kitchen worktop. Under the worktop, space is left for the knees and legs. The height is manually
adjustable.
The use shall be indoors, under normal housing conditions regarding temperature, humidity and lighting. Electric
hob, a sink and drawers can be incorporated.
The worktop lift unit is not intended for use in moist environments.
It is assumed that the work top benches and the cabinets are made according the standards EN 1116 and EN 1153.
Countertop on adjacent cabinets must not protrude over its cabinet frame. Protrusion of the countertop to adjacent
cabinets constitute a risk of crushing and will not be accepted!
Any use other than the above is subject to approval by Granberg and definition of the current allowable working
conditions. Contact Granberg to planned change approved!
Solid wood benches are not recommended.
Granberg Interior AB - Box 6112 - 600 06 Norrköping - SWEDEN
Tel: [phone] - E-mail: [email protected] - Internet: www.granberg.se

4. Technical data
Installation Wall-mounted
Front height 103 mm / 40 mm
Frame depth 560 - 590 mm
Depth worktop (15 mm shallower than worktops on
fixed cabinets)
565 - 630 mm
Height adjustment Manually adjustable by 300 mm in intervals of 25 mm
(700-1000 mm excl. top board)
A built-in gas spring facilitates height adjustment:
Pull out the locking pin, adjust the height with the help
of the gas spring. Lock the position with the locking pin.
Plumbing connections Connection is made with flexible hoses
Max load 100 kg
Space to wall / adjoining cabinet 5 mm
Space to wall (for tiles) 15 mm
Tiling From 700 mm above floor (alternatively all the way
down to the floor)
5. Safe use
Manulift 6380 is designed in order to prevent and avoid damages and accidents. It is however still very important
that the operator is well instructed in how to install and operate the product. In the following, Manulift 6380 means
the lifting machine and the fitted accessories, such as drawers, sink and hob.
Only use Manulift 6380 for its intended purpose.
The operation and use must be made in such way that there is no risk for damages on persons and property.
Manulift 6380 may only be operated by persons who have read and understood these instructions, and are
authorized to use it.
Be aware of that you as an operator are responsible for that nobody is damaged.
Manulift 6380 and the work area must be in proper condition. Manulift 6380 unit must not be used if any
fault has appeared which influences the functions or the operation safety. It shall also not be used if it has
been repaired, altered or adjusted without permission of a responsible person.
Notice the jamming risk between Manulift 6380 and adjacent worktops and cabinets when height
adjustment is made.
Only stable and securely loaded items may be handled. Mind the tilting risk for objects on the worktop,
which are unstable, e.g. carelessly piled.
Alterations of Manulift 6380 that influence the operational safety or the functions are not allowed.
Do not overload Manulift 6380 and make sure that the load distribution is correct.
It is absolutely forbidden for persons to stay on the worktop or stand on extended drawers.
Always distribute the load uniformly on the worktop, to avoid cantilevered loading. Consider the risk that the
load can roll, slide or fall over.
Use safe and sufficient lifting methods when handling load to and from Manulift 6380. In particular beware
when handling heavy items, and goods with hazardous content or with sharp corners and edges.
Be aware of the risks when you work on Manulift 6380. The risks are depending on the arrangements on the
worktop.
Manulift 6380 shall regularly, once a year, be inspected in order to prevent accidents.
Applicable Building and Safe use Regulations must be complied with.
Do not use Manulift 6380 in a potentially explosive environment.
Decals and markings must not be removed or made illegible.
During inspections, service and repair work there shall be no load on the worktop or in the cabinets. The
most common functions can be reached when the cover panels have been removed.
Competent persons only must carry out installation, service and repair works.
Only Granberg original spare parts shall be used when replacing any parts. Our warranty commitment can
otherwise be invalidated.
Granberg Interior AB - Box 6112 - 600 06 Norrköping - SWEDEN
Tel: [phone] - E-mail: [email protected] - Internet: www.granberg.se

6. Load distribution and side forces
Note that the max. rated load means that the load is distributed over the entire worktop.
Point loads are not allowed.
It is absolutely forbidden for persons to stay on the worktop, to stand on extended drawers.
Basic loading requirements:
100 % of the rated load distributed over the entire cabinet volume.
Horizontal forces are not allowed.
Horizontal forces can appear, for example, when pressing onto the shelves or the load.
It is difficult to estimate the size of the actual horizontal force, so utmost care must always be taken.
Further to the incorporated safety arrangements additional safety actions may be required on or at the Worktop lift
unit. Discuss suitable actions with your Granberg representative or with the health and safety inspection.
We recommend that a Risk assessment in accordance with the Machinery Directive shall be made for the actual
working conditions. If the owner fits accessories, contact Granberg to get approval for the loading conditions.
Maximum load: 100 kg
Top board and all other equipment must be included in the maximum load.
Note that the max. rated load means that the load is distributed over the entire worktop. Point loads are not
allowed.
7. Instructions for recycling
When the product lift shall be re-used it must be cleaned, inspected and go through a full operation test before it is
installed on the new site.
The machine is manufactured from re-usable materials or from materials that can be recycled.
