Granite AMERICAN CART & RACK TITAN II User manual

67101-75
TITAN II APPLIANCE CART
INSTRUCTION MANUAL
Revised: JULY 2017

2
CONTENTS
Specs......................................................................3
Parts Diagram ........................................................4
Setup......................................................................5
TOOLS NEEDED
• Box Cutters / Utility Knife
WARRANTY
3 Year Limited Warranty. Carts, excluding any
finishes, casters and wheels are warranted for three
(3) years from date of original purchase. Casters
and wheels are warranted for 90 days from date of
original purchase. We will repair, without charge,
any defect due to faulty material or workmanship.
These warranties do not cover failures due to
abuse, misuse, improper installation, accidental
damage or when repairs or modifications have been
made or attempted to be made by anyone other
than Granite Industries. Any defective products
that meet warranty specifications and Granite
Industries approval, may be returned to the factory
to be repaired or replaced free of charge. (Granite
Industries will pay to ship replacement item(s) to the
customer; however the customer is responsible for
shipment of products to the factory.) This remedy
is the sole remedy in contact, tort or otherwise,
and Granite Industries is not liable for incidental,
consequential or special damages. These warranties
give you specific legal rights, and you may have
other rights which vary from state to state. Should
you have any questions, contact Granite Industries
(Proof of purchase may be required).
Customer Service
877-447-2648
M-F, 8am - 5pm EST
To view more products from
American Cart & Rack
scan the QR code with your phone
or visit AmericanCartAndRack.com

3
SPECS
Overall Dimensions: W: 26” D: 16” H: 61”
Foot Plate: W: 26” D: 5”
Weight: 70 lbs. Capacity: 600 lbs.

4
PARTS DIAGRAM
ITEM NO QTY PART NO DESCRIPTION
1 1 MI-12-2009 CART 67101
2 4 MI-08-0543 Track for rubber belt
3 4 MI-15-0015 Bushing - 25/64" ID x 1"
4 1 MI-04-0121 Crank
5 2 PI-06-0032 10” Flat free offset wheel
6 1 PI-11-0016 Strap
7 1 PI-04-0115 Rubber cap for crank handle
8 1 PI-01-0002 1/2” Washer
9 1 PI-01-0073 Cotter Pin - 5/32" x 3/4"
10 2 PI-01-0226 Cotter Pin 1/8" x 1-1/4"
11 4 PI-01-0030 3/8" Washer
12 4 PI-01-0019 3/8" Locknut
14 2 PI-01-0140 Pop Rivet 3/16"
16 2 PI-11-0018 Rubber Belt
17 4 PI-01-0028 Hex Bolt 3/8"-16 x 1-1/2"
18 2 PI-01-0032 5/8" Washer

5
3
2
Slide the strap under the center roller.
TIE STRAP SETUP
1
Lift the center roller.
Lower the center roller and insert the strap
back through, this time going above the
roller.
4
Your strap should now lock in place when
tightened.

NOTES:
6

NOTES:
7

8
GRANITE INDUSTRIES
595 EAST LUGBILL ROAD
877-447-2648
[email protected]
