PRODUCT DATA SHEET
KEY FEATURES
Encoder
Real-time encoding and streaming of•
SD and HD video to MPEG-4 (H.264)
output
Supports distribution of video and•
audio with perfect A/V synchronization
Unicast/multicast distribution support•
Selectable distribution modes—•
choose between on-demand or
automated
Compatible with MEDIAEDGE-SVS4•
server software for live streaming
and/or capture for on-demand MPEG
playback
Easily configurable via any networked•
PC or front panel
Embedded Web server to allow•
streaming to STB decoders without
the need of a server
MEDIAEDGE System
HD and SD video distribution over•
TCP/IP networks
Live, scheduled, and on-demand•
distribution
Supports multiple simultaneous video•
streams and multiple clients
Centralized content distribution•
Server-driven menu system enables•
easy access to content
Supports IPv6•
MEDIAEDGE®is a multi-channel, multi-
location delivery system of either high- or
standard-definition (HD or SD) video
using standard TCP/IP networks and HD/
SD display devices. Comprised of server,
encoder, client software, and set-top
box (STB) components, this flexible and
modular system is ideal for point-of-sale,
corporate, and other video-retrieval and
digital-signage applications.
Three Streaming Modes
The MEDIAEDGE system lets you deliver
content in three ways: video-on-demand
(VOD), scheduled playback, and live
broadcast.
In a VOD application, users select
video clips stored on the MEDIAEDGE-
SVS4 server for viewing, either from a
dynamically updated menu, or through
direct channel number selection via a
remote control. A user can pause, stop,
and resume viewing content at any time.
Content chapter points can be created
for faster navigation, and clients can
fast forward or rewind video clips during
playback.
Scheduled playback allows an unlimited
number of users to view a pre-
programmed arrangement of multiple
video clips. The MEDIAEDGE-SVS4
server can have multiple scheduled
channels running simultaneously, with
set program times scheduled to run
hourly, daily, or monthly. MEDIAEDGE-
STB4 users can surf channels by simply
using the remote control. MEDIAEDGE-
SWT4 software users can do the same
within a Web browser.
For live broadcasting, the MEDIAEDGE
system can utilize the real-time
capabilities of its encoding devices to
transmit live external HDMI or SDI video
sources as professional-quality MPEG-4
(H.264) streams to multiple clients.
Using this feature, the system can
retransmit television and satellite feeds.
Such content, once MPEG encoded,
may also be recorded to a server on the
network for later viewing or scheduling.
MPEG-2 SD/HD video is also available
when you combine the ADVC-HD50 with
the LSB or the ADVC-HDM1 with the
LSB.
Live, Scheduled, & On-Demand
Enterprise/Digital Signage
Video Distribution.
MEDIAEDGE-LEB4
SD/HD MPEG-4 (H.264) ENCODER

To find your local reseller or dealer for Grass Valley professional audio
video products, please visit www.grassvalley.com/sales/partners/PVP.
DEALERS/RESELLERS
Twelve-month limited warranty with service provided through local
resellers. Additional support available on a contractual basis.
SERvIcE & SUppoRT
pRoDUcT DATA ShEET
1 x MEDIAEDGE-LEB4 video encoding unit•
MEDIAEDGE-LEB4 user manual•
AC power cable•
SpEcIFIcATIonS
pAcKAGE conTEnTS
Network Connection
1 x RJ-45 modular connector•
1000Base-TX full-duplex Fast Ethernet•
IEEE 802.3 frame format•
Auto negotiation supported•
Video Formats
1920x1080/59.94i, 1440x1080/59.94i,
1280x720/59.94p, 720x480/59.94i,
1920x1080/50i, 1440x1080/50i,
1280x720/50p, 720x576/50i
Video/Audio Inputs
SDI (w/embedded audio)•
HDMI (w/embedded audio)•
Data Communication Ports
2 x RS-232 (DB 9-pin)
Video Encoding Formats
ISO/IEC14496-10 (H.264/AVC) High•
Profile Level 4.0
Max. bit rate: 20 Mb/s•
Audio Encoding Formats
MPEG Layer 1, Layer 2•
16-bit stereo•
Sampling frequency: 32, 44.1,•
48 kHz
Transmission Formats
ISO/IEC 13818-1 + Amd3 MPEG-2
transport stream
Dimensions
Width: 214.5 mm (8.4 in.)•
Depth: 246 mm (9.7 in.)•
Height: 43 mm (1.7 in.)•
Weight
1.6 kg (3.5 lbs.) front panel
Service and Support
1-year limited warranty
MEDIAEDGE-LEB4 Video Encoder
Working as a separate solution or in conjunction with a
MEDIAEDGE-SVS server, it encodes HD or SD sources from
either SDI or HDMI inputs into an MPEG-4 (H.264) data stream,
and can instantly rebroadcast the stream using an internal
streaming server.
You can also use the MEDIAEDGE-LEB4 encoder to process
video from a remote location, such as a video library, and
then deliver the content to a MEDIAEDGE-SVS4 server based
within a datacenter. The content is recorded and then ready for
distribution across a MEDIAEDGE network.
As well, you can combine a MEDIAEDGE-LEB4 encoder, server,
and software clients and/or STBs. Clients can request live
streams from the encoder—or live, scheduled, or on-demand
from the server.
© Copyright 2011 Grass Valley USA, LLC. All rights reserved. MEDIAEDGE is a registered trademark and Grass Valley is a trademark of GVBB Holdings S.a.r.l.
All other tradenames referenced are service marks, trademarks, or registered trademarks of their respective companies. Specifications subject to change
without notice. PRV-4066D-3
