About this manual
This manual describes additional functions included in SP4.3. For basic
functionality please refer to the User Manual.
The steps described in this manual is operated in front panel mode.
5
October 8, 2013 T2 Additional Function Manual SP4.3

Section 2
2ch view in Workstation Mode
You can use 2ch view in additon to 1ch and 3ch view in workstation mode.
Screen elements
¾Full display – 2ch view
(2)
(4)
(3)
(1)
(1) Menu bar Please refer to the user manual.
(2) Channel display
part Displays R1, P1, and P2 channels in 3ch view.
(3) Status bar Please refer to the user manual.
(4)
Bin/transfer
screen display
part
Please refer to the user manual.
6T2 Additional Function Manual SP4.3 October 8, 2013
Section 2 ― 2ch view in Workstation Mode

¾Menu bar
[System] Please refer to the user manual.
[View]
By clicking, displays the next menu.
[2ch (R1+P1)]
Displays R1 and P1 channels in channel display part.
[2ch (R1+P2)]
Displays R1 and P2 channels in channel display part.
[2ch (P1+P2)]
Displays P1 and P2 channels in channel display part.
[3ch]
Displays R1, P1 and P2 channels in channel display part.
[Option] Please refer to the user manual.
[Help] Please refer to the user manual.
7
October 8, 2013 T2 Additional Function Manual SP4.3
MICROSOFT SOFTWARE LICENSE TERMS (WINDOWS EMBEDDED STANDARD 7)

Section 3
Preroll/Postroll
You can use preroll and postroll in P1/P2 seing.
P1/P2 settings
P1/P2 – Monitor & Remote settings
You can make seings for the monitor output from P1/P2 output section and
remote control of P1/P2 channel.
1. Tap [P1] (or [P2]), and then tap the [Monitor & Remote] tab in the
setting screen.
¾[Monitor & Remote] tab
[Monitor out]
Please refer to the user manual.
[Remote protocol:] Please refer to the user manual.
[Enable local
operations while being
remote controlled.]
Please refer to the user manual.
[Preroll :] Rewinds a short duration of time before the In
point and starts playback from the point.
[Postroll :]
Allows to set the playback duration by the
seconds in order to play back video later than
the Out point.
2. Set each item and tap [OK].
8T2 Additional Function Manual SP4.3 October 8, 2013
Section 3 ― Preroll/Postroll

Section 4
Appendix
New shortcuts are added in workstation mode.
Keyboard shortcut list in workstation mode
The following list shows the keyboard shortcuts.
Category Action Shortcut
[General] [Select R1 channel] [1]
[Select P1 channel] [2]
[Select P2 channel] [3]
[Change focus to the folder list]
[Change focus to the content list]
[Change focus to the playlist of the selected channel]
[Switch between 1ch View and 2ch/3ch View] *Update
[Change the content’s tab]
[Show the Conguration screen]
[Show the content search screen]
[Lock/Unlock the selected channel]
[Turn On/O the Loop in the selected channel (P1/P2)]
[Turn On/O the EtoE in the selected channel (P1/P2)]
[Turn On/O the Remote of the selected channel (P1/P2)]
[Turn the sync play mode On/O]
[Eject the selected channel]
[Start Recording the selected channel (R1)] [M]
[Start playback in the selected channel] [L]
[Play reverse in the selected channel] [J]
[Play or pause the selected channel] [Space]
[Stop playing/recording in the selected channel] [K]
[Fast Forward (skip) in the selected channel] [;]
[Rewind (1 step back) in the selected channel] [H]
9
October 8, 2013 T2 Additional Function Manual SP4.3
MICROSOFT SOFTWARE LICENSE TERMS (WINDOWS EMBEDDED STANDARD 7)

Category Action Shortcut
[Increase (1 step forward) the VAR speed in the selected
channel] [.]
[Slower (1 step back) the VAR speed in the selected channel] [,]
[Increase (0.1 forward) the VAR speed in the selected
channel]
[Slower (0.1 back) the VAR speed in the selected channel]
[Increase (0.01 forward) the VAR speed in the selected
channel]
[Slower (0.01 back) the VAR speed in the selected channel]
[Move to top frame(previous event) of the selected channel] [A]
[Move to last frame(next event) of the selected channel] [S]
[Move to In point of the selected channel] [Shi+I]
[Move to Out point of the selected channel] [Shi+O]
[Move to the previous frame in the selected channel] [<-]
[Move to the next frame in the selected channel] [->]
[Set the In point of the selected channel] [I]
[Set the Out point of the selected channel] [O]
[Clear the In/Out points of the selected channel] [Ctrl]+[I]
[Ctrl]+[O]
[Fast forward (0.01 forward) the current speed in the
selected channel] *New
[Fast forward (0.1 forward) the current speed in the selected
channel] *New
[Slow (0.01 back) the current speed in the selected channel]
*New
[Slow (0.1 back) the current speed in the selected channel]
*New
[Load the content(s) to the selected channel]*1
[Load the content(s) to P1]*1
[Load the content(s) to P2]*1
[Cue up to the event within the playlist in the selected
channel]*2
[Cue up to the event within the playlist in the selected
channel and pause]*2
[Cue up to the event within the playlist in the selected
channel and play]*2
[Cue up to the event within the playlist P1]*2
10 T2 Additional Function Manual SP4.3 October 8, 2013
Section 4 ― Appendix

Category Action Shortcut
[Cue up to the event within the playlist in P1 and pause]*2
[Cue up to the event within the playlist in P1 and play]*2
[Cue up to the event within the playlist P2]*2
[Cue up to the event within the playlist in P2 and pause]*2
[Cue up to the event within the playlist in P2 and play]*2
[Contents List] [Mount the selected item on the selected channel] [Return]
[Mount the selected item on the selected channel (with
shiing the focus)]
[Mount the selected item on the selected channel and
pause]
[Mount the selected item on the selected channel and pause
(with shiing the focus)]
[Mount the selected item on the selected channel and play]
[Mount the selected item on the selected channel and play
(with shiing the focus)]
[Mount the selected item on P1]
[Mount the selected item on P1 (with shiing the focus)]
[Mount and pause the selected item on P1]
[Mount and pause the selected item on P1 (with shiing the
focus)]
[Mount and play the selected item on P1]
[Mount and play the selected item on P1 (with shiing the
focus)]
[Mount the selected item on P2]
[Mount the selected item on P2 (with shiing the focus)]
[Mount and pause the selected item on P2]
[Mount and pause the selected item on P2 (with shiing the
focus)]
[Mount and play the selected item on P2]
[Mount and play the selected item on P2 (with shiing the
focus)]
[Scroll to top of selected item] [Home]
[Scroll to last selected item] [End]
[Delete selected item] [Delete]
[Copy selected item] [Ctrl]+[C]
[Cut selected item] [Ctrl]+[X]
11
October 8, 2013 T2 Additional Function Manual SP4.3
MICROSOFT SOFTWARE LICENSE TERMS (WINDOWS EMBEDDED STANDARD 7)

Category Action Shortcut
[Paste item from the clipboard] [Ctrl]+[V]
[Show the rename dialog box for the selected item]
[Change the thumbnail frame color of the selected item to
the default color]
[Change the thumbnail frame color of the selected item to
the color 1]
[Change the thumbnail frame color of the selected item to
the color 2]
[Change the thumbnail frame color of the selected item to
the color 3]
[Change the thumbnail frame color of the selected item to
the color 4]
[Change the thumbnail frame color of the selected item to
the color 5]
[Show the lm strip for the selected item]
[Show the properties for the selected item]
[Playlist] [Cue up to the selected event] [Return]
[Cue up and pause to the selected event]
[Cue up and play to the selected event]
[Delete the selected event] [Delete]
[Copy the selected event] [Ctrl]+[C]
[Paste the selected event] [Ctrl]+[V]
[Show the rename dialog box of the selected event]
[Set the fade in of the selected event to “none”]
[Set the fade in of the selected event to “from black”]
[Set the fade in of the selected event to “from white”]
[Set the fade out of the selected event to “none”]
[Set the fade out of the selected event to “from black”]
[Set the fade out of the selected event to “from white”]
[Set the end eect action to “none” in the selected event]
[Set the end eect action to “Pause (Show black frame)” in
the selected event]
[Set the end eect action to “Pause (Show white frame)” in
the selected event]
[Set the end eect action to “Pause (Show last frame)” in the
selected event]
[Set the end eect action to “Pause (Show next event frame)”
in the selected event]
12 T2 Additional Function Manual SP4.3 October 8, 2013
Section 4 ― Appendix

Category Action Shortcut
[Set the end eect action to “Pause (Show EtoE)” in the
selected event]
[Set the end eect action to “loop” in the selected event]
[Show the properties of selected event]
※3 Can mount clips and playlists that start with 00_ to 99_.
※4 Can be set to the maximum of 100 events.
13
October 8, 2013 T2 Additional Function Manual SP4.3
MICROSOFT SOFTWARE LICENSE TERMS (WINDOWS EMBEDDED STANDARD 7)
