GRASS VALLEY K2 BASECAMP EXPRESS User manual

K2
Storage
Cabling Guide
071-8780-01
February 2012

Affiliate with the N.V. KEMA in The Netherlands
CERTIFICATE
Certificate Number: 510040.001
The Quality System of:
Thomson Inc, and its worLdwide Grass Valley division affiliates DBA
GRASS VALLEY
Headquarters
400 Providence Mine Rd
Nevada City, CA 95959
United States
15655 SW Greystone Ct.
Beaverton, OR 97006
United States
10 Presidential Way
Suite 300
Woburn, MA 01801
United States
Kapittelweg 10
4827 HG Breda
The Nederlands
7140 Baymeadows Way
Ste 101
Jacksonville, FL 32256
United States
2300 So. Decker Lake Blvd.
Salt Lake City, UT 84119
United States
Rue du Clos Courtel
CS 31719
35517 Cesson-Sevigné Cedex
France
1 rue de l’Hautil
Z.I. des Boutries BP 150
78702 Conflans-Sainte
Honorine Cedex
France
Technopole Brest-Iroise
Site de la Pointe du Diable
CS 73808
29238 Brest Cedex 3
France
40 Rue de Bray
2 Rue des Landelles
35510 Cesson Sevigné
France
Spinnereistrasse 5
CH-5300 Turgi
Switzerland
Brunnenweg 9
D-64331 Weiterstadt
Germany
Carl-Benz-Strasse 6-8
67105 Schifferstadt
Germany
Including its implementation, meets the requirements of the standard:
ISO 9001:2008
Scope:
The design, manufacture and support of video and audio hardware and software products and
related systems.
This Certificate is valid until: June 14, 2012
This Certificate is valid as of: June 14, 2009
Certified for the first time: June 14, 2000
H. Pierre Sallé
President
KEMA-Registered Quality
The method of operation for quality certification is defined in the KEMA General Terms
And Conditions For Quality And Environmental Management Systems Certifications.
Integral publication of this certificate is allowed.
KEMA-Registered Quality, Inc.
4377 County Line Road
Chalfont, PA 18914
Ph: [phone]
Fax: [phone]
CRT 001 073004
Accredited By:
ANAB
CERTIFICATE
Certificate Number: 510040.001
The Quality System of:
Grass Valley USA, LLC and its Grass Valley Affiliates
Headquarters:
400 Providence Mine Road
Nevada City, CA 95945
United States
15655 SW Greystone Ct.
Beaverton, OR 97006
United States
Brunnenweg 9
D-64331 Weiterstadt
Germany
Kapittelweg 10
4827 HG Breda
The Nederlands
2300 So. Decker Lake Blvd.
Salt Lake City, UT 84119
United States
Including its implementation, meets the requirements of the standard:
ISO 9001:2008
Scope:
The design, manufacture and support of video and audio hardware and software products and related
systems.
This Certificate is valid until: June 14, 2012
This Certificate is valid as of: December 23, 2010
Certified for the first time: June 14, 2000
H. Pierre Sallé
President
KEMA-Registered Quality
The method of operation for quality certification is defined in the KEMA General Terms And Conditions For
Quality And Environmental Management Systems Certifications. Integral publication of this certificate is allowed.
KEMA-Registered Quality, Inc.
4377 County Line Road
Chalfont, PA 18914
Ph: [phone]
Fax: [phone]
CRT 001 042108
A
ccredited By:
ANAB

K2
Storage
Cabling Guide
071-8780-01
February 2012

4K2 Cabling Guide
Contacting Grass Valley
Copyright © Grass Valley USA, LLC. All rights reserved.
This product may be covered by one or more U.S. and foreign patents.
Grass Valley Web Site
The www.grassvalley.com web site offers the following:
Online User Documentation — Current versions of product catalogs, brochures,
data sheets, ordering guides, planning guides, manuals, and release notes
in .pdf format can be downloaded.
FAQ Database — Solutions to problems and troubleshooting efforts can be
found by searching our Frequently Asked Questions (FAQ) database.
Software Downloads — Download software updates, drivers, and patches.
International
Support Centers
France
24 x 7 [phone] or [phone] United States/Canada 24 x 7 [phone] or [phone]
Local Support
Centers
(available
during normal
business hours)
Asia
Hong Kong, Taiwan, Korea, Macau: [phone] Indian Subcontinent: [phone]
Southeast Asia/Malaysia: [phone] Southeast Asia/Singapore: [phone]
China: [phone] Japan: [phone]
Australia and New Zealand: [phone] Central/South America: [phone]
Middle East: [phone] Near East and Africa: [phone] or [phone]
Europe
Belarus, Russia, Tadzikistan, Ukraine, Uzbekistan: [phone] Switzerland: [phone]
S. Europe/Italy-Roma: [phone] -Milan: [phone]S. Europe/Spain: [phone]
Benelux/Belgium: [phone] Benelux/Netherlands: [phone] N. Europe: [phone]
Germany, Austria, Eastern Europe: [phone] UK, Ireland, Israel: [phone]

Contents
Chapter 1: Start with the K2 storage system diagram.............................................................7
To follow cabling instructions....................................................................................................................8
Basic K2 SAN - Online or Production.......................................................................................................9
Redundant K2 SAN - Online or Production............................................................................................10
Basic Nearline K2 SAN...........................................................................................................................11
Redundant Nearline K2 SAN..................................................................................................................12
K2 client with direct-connect storage......................................................................................................12
Chapter 2: Cable K2 devices....................................................................................................13
Cable K2 Summit system.......................................................................................................................14
K2-XDP basic......................................................................................................................................14
K2-XDP redundant..............................................................................................................................14
XDP/XDT direct-connect storage........................................................................................................15
Cable Ethernet switch.............................................................................................................................16
Ethernet cable requirements...............................................................................................................16
K2-SWE basic online/production.........................................................................................................16
K2-SWE redundant online/production.................................................................................................18
K2-SWE basic nearline.......................................................................................................................19
K2-SWE redundant nearline...............................................................................................................20
Cable K2 Media Server...........................................................................................................................21
K2-SVR basic......................................................................................................................................21
K2-SVR redundant..............................................................................................................................21
Cable NH10GE K2 Media Server...........................................................................................................23
K2-SVR-NH10GE online/production...................................................................................................23
K2-SVR-NH10GE basic nearline........................................................................................................23
K2-SVR-NH10GE redundant nearline.................................................................................................23
Cable K2 RAID.......................................................................................................................................25
K2 RAID basic online/production........................................................................................................25
K2 RAID redundant online/production.................................................................................................27
K2 RAID basic nearline.......................................................................................................................28
K2 RAID redundant nearline...............................................................................................................29
K2 RAID direct-connect.......................................................................................................................30
Chapter 3: For more information.............................................................................................31
For the installer of a standalone K2 product with internal storage..........................................................32
For the installer of a K2 product with direct connect storage..................................................................32
For the installer of K2 Summit systems with K2 SAN shared storage....................................................33
K2 Release Notes...................................................................................................................................33
Quick Start Guides..................................................................................................................................33
K2 Storage Cabling Guide......................................................................................................................33
K2 Documentation Set............................................................................................................................34
On-line Help Systems.............................................................................................................................35
K2 FCP Connect documentation............................................................................................................35
NetCentral documentation......................................................................................................................35
Grass Valley Website..............................................................................................................................36
Dell Server Documentation.....................................................................................................................36
Appendix A: Trademarks and Agreements.............................................................................37
02 February 2012 K2 Storage Cabling Guide 5

6K2 Storage Cabling Guide 02 February 2012
Contents

Chapter 1
Start with the K2 storage system diagram
This section contains the following topics:
•To follow cabling instructions
•Basic K2 SAN - Online or Production
•Redundant K2 SAN - Online or Production
•Basic Nearline K2 SAN
•Redundant Nearline K2 SAN
•K2 client with direct-connect storage
02 February 2012 K2 Storage Cabling Guide 7

To follow cabling instructions
To follow cabling instructions for your K2™Storage Area Network (SAN) or direct-connect storage
K2 Summit system, do the following:
1. Find the system cabling diagram that matches your K2 system.
2. Follow the references below the system diagram to locate cabling instructions for the individual
devices of your K2 system.
Refer to the "K2 10G SAN Installation and Service Manual" for more information on K2 SANs and
devices. Refer to the "K2 System Guide" for more information on direct-connect K2 client storage.
Related Links
Basic K2 SAN - Online or Production on page 9
Redundant K2 SAN - Online or Production on page 10
Basic Nearline K2 SAN on page 11
Redundant Nearline K2 SAN on page 12
K2 client with direct-connect storage on page 12
8K2 Storage Cabling Guide 02 February 2012
Start with the K2 storage system diagram

Basic K2 SAN - Online or Production
RAID Primary
Chassis
RAID Expansion
Chassis (optional)
K2 Media Server
Ethernet Switch
Control
Media
Control
Media
Control
FTP
Media
Control point PC
K2 clients
Control
Control
FTP/streaming
Control
Media
Fibre Channel
NH Server
(optional)
Control
FTP
Turn to these instructions:Of this model or
platform…
To cable this K2 SAN device…
K2-XDP basic on page 14K2 Summit 3G
system or first
generation K2
Summit system
K2 Summit system
K2-SWE basic online/production on page 16HP 2910Gigabit Ethernet Switch
K2-SVR basic on page 21Dell R610K2 Media Server
K2-SVR-NH10GE online/production on page 23Dell R610NH10GE K2 Media Server
(optional)
K2 RAID basic online/production on page 25K2 RAIDK2 RAID
This manual documents the default GigE switch configuration. Other configurations are available,
depending on your port count and FTP bandwidth requirements.
02 February 2012 K2 Storage Cabling Guide 9
Start with the K2 storage system diagram

Redundant K2 SAN - Online or Production
RAID Primary
Chassis
RAID Expansion
Chassis (optional)
K2 Media
Servers
NH Servers
(optional)
AB
BA
Ethernet
Switches
Fibre Channel
Control B
Media B
Control A
Media A
Control A
Media A
Control B
Media B
Control
FTP
Media
FTP
Control
Media
Control point PC
K2 clients
Control
ISLs
Control Control
FTP/streaming
Control B
Media B
Control A
Media A
Fibre Channel
Control
FTP
Control
FTP
Turn to these instructions:Of this model or
platform…
To cable this K2 SAN device…
K2-XDP redundant on page 14K2 Summit 3G
system or first
generation K2
Summit system
K2 Summit system
K2-SWE redundant online/production on page 18HP 2910Gigabit Ethernet Switch
K2-SVR redundant on page 21Dell R610K2 Media Server
K2-SVR-NH10GE online/production on page 23Dell R610NH10GE K2 Media Server
(optional)
K2 RAID redundant online/production on page 27K2 RAIDK2 RAID
This manual documents the default GigE switch configuration. Other configurations are available,
depending on your port count and FTP bandwidth requirements.
10 K2 Storage Cabling Guide 02 February 2012
Start with the K2 storage system diagram

Basic Nearline K2 SAN
Control
RAID Chassis
RAID Expansion Chassis
NH K2 Media
Server
Ethernet
Switch
Fibre Channel
connection
Control
FTP
Control point PC
Control
FTP to/from online system
Turn to these instructions:Of this model or
platform…
To cable this K2 SAN device…
K2-SWE basic nearline on page 19HP 2910Gigabit Ethernet Switch
K2-SVR-NH10GE basic nearline on page 23Dell R610NH10GE K2 Media Server
K2 RAID basic nearline on page 28K2 10G RAIDK2 RAID
02 February 2012 K2 Storage Cabling Guide 11
Start with the K2 storage system diagram

Redundant Nearline K2 SAN
ISLs
Control Control
RAID Chassis
RAID Expansion Chassis
NH K2 Media
Servers
Ethernet
Switches
Fibre Channel
connections
Control
FTP
Control
FTP
Control point PC
Control
FTP to/from online system
ISLs
A
A
B
B
Turn to these instructions:Of this model or
platform…
To cable this K2 SAN device…
K2-SWE redundant nearline on page 20HP 2910Gigabit Ethernet Switch
K2-SVR-NH10GE redundant nearline on page 23Dell R610NH10GE K2 Media Server
K2 RAID redundant nearline on page 29K2 10G RAIDK2 RAID
K2 client with direct-connect storage
RAID Primary
Chassis
RAID Expansion
Chassis (optional)
K2 Summit
system
Fibre
Channel
Fibre
Channel
Turn to these instructions:Of this model or
platform…
To cable this K2 device…
XDP/XDT direct-connect storage on page 15K2 Summit 3G
system or first
generation K2
Summit system
K2 Summit system
K2 RAID direct-connect on page 30K2 RAIDK2 RAID
12 K2 Storage Cabling Guide 02 February 2012
Start with the K2 storage system diagram

Chapter 2
Cable K2 devices
This section contains the following topics:
•Cable K2 Summit system
•Cable Ethernet switch
•Cable K2 Media Server
•Cable NH10GE K2 Media Server
•Cable K2 RAID
02 February 2012 K2 Storage Cabling Guide 13

Cable K2 Summit system
As directed by the system diagram for your K2 storage, cable the K2 Summit system using the
instructions in this section.
Related Links
K2-XDP basic on page 14
K2-XDP redundant on page 14
XDP/XDT direct-connect storage on page 15
K2-XDP basic
These cabling instructions apply to the following:
•K2 Summit 3G system or first generation K2 Summit system on a basic (non-redundant) online
or production K2 SAN
Refer to "K2 Summit Production Client Quick Start Guide" for additional cabling details.
!
OK
~AC
C1 C2 C3 C4
USB/1394 100BT/1000BT
GPI
VGA REF. LOOP THROUGH
!
OK
~AC
To control port
on GigE switch
To media (iSCSI) port
on GigE switch
K2-XDP redundant
These cabling instructions apply to the following:
•K2 Summit 3G system or first generation K2 Summit system on a redundant online or production
K2 SAN
Refer to "K2 Summit Production Client Quick Start Guide" for additional cabling details.
!
OK
~AC
C1 C2 C3 C4
USB/1394 100BT/1000BT
GPI
VGA REF. LOOP THROUGH
!
OK
~AC
To control port
on GigE switch A
To control port
on GigE switch B
To media (iSCSI) port
on GigE switch A
To media (iSCSI) port
on GigE switch B
14 K2 Storage Cabling Guide 02 February 2012
Cable K2 devices

XDP/XDT direct-connect storage
These cabling instructions apply to the following:
•K2 Summit 3G system, first generation K2 Summit system, or K2 Summit Transmission Client
with direct-connect K2 RAID storage
Refer to related topics in "K2 System Guide" for additional information about direct-connect storage.
Refer to "K2 Summit Production Client Quick Start Guide" for additional cabling details.
!
OK
~AC
C1 C2 C3 C4
USB/1394 100BT/1000BT
GPI
VGA REF. LOOP THROUGH
!
OK
~AC
K2 Summit system
To K2 RAID
Controller
To K2 RAID
Controller
02 February 2012 K2 Storage Cabling Guide 15
Cable K2 devices

Cable Ethernet switch
As directed by the system diagram for your storage system, cable the switch or switches for your
system using the instructions in this section.
These instructions are for the HP ProCurve switch 2900 and 2910 series. You must use this switch
for iSCSI traffic.
For control and FTP/streaming traffic, it is allowed to use a different brand of switch, such as a
Cisco Catalyst switch, if required by your site. If you are using a non-HP switch, apply the information
in the following procedures accordingly. Refer to the documentation you received with the switch
as necessary.
Install the switch in its permanent location. When installing in a video equipment rack, use 10-32
screws. Do not use HP’s 12-24 screws, as they can cause thread damage.
Provide power to the switch.
Related Links
K2-SWE basic online/production on page 16
K2-SWE redundant online/production on page 18
K2-SWE basic nearline on page 19
K2-SWE redundant nearline on page 20
Ethernet cable requirements
For making Ethernet connections, cabling must meet the following requirements:
•Use CAT5e or CAT6 cables. The maximum cable length is 50 meters for CAT5e and 100 meters
for CAT6.
K2-SWE basic online/production
These cabling instructions apply to the following:
•HP 29xx series Gigabit Ethernet switch on a basic (non-redundant) online or production K2
SAN.
Front view
Rear view
16 K2 Storage Cabling Guide 02 February 2012
Cable K2 devices

02 February 2012 K2 Storage Cabling Guide 17
Cable K2 devices

K2-SWE redundant online/production
These cabling instructions apply to the following:
•HP 29xx series Gigabit Ethernet switch on a redundant online or production K2 SAN.
Front view
Rear view
If you have other iSCSI clients, such as Aurora Edits, that have just one iSCSI connection and one
control connection, approximately half of the clients should be connected to switch A and half of
the clients should be connected to switch B. In a failover event, only the clients connected to one
of the switches will remain operational, so make connections accordingly. Connect the client’s
iSCSI connection to one of the media ports on a switch and the client’s control connection to one
of the control ports on the same switch.
If you have more than one optional NH10GE K2 Media Servers, balance servers between switch A
and switch B.
18 K2 Storage Cabling Guide 02 February 2012
Cable K2 devices

K2-SWE basic nearline
These cabling instructions apply to the following:
•HP 29xx series Gigabit Ethernet switch on a nearline K2 SAN with one NH K2 Media Server.
Front view
Rear view
To server
10 Gig
Use SFP+ cable
with integrated
GBIC
02 February 2012 K2 Storage Cabling Guide 19
Cable K2 devices

K2-SWE redundant nearline
These cabling instructions apply to the following:
•HP 29xx series Gigabit Ethernet switch on a nearline K2 SAN.
Front view
Rear view
20 K2 Storage Cabling Guide 02 February 2012
Cable K2 devices
