Great Land Rescue Laser Light User manual

G
Willow, Alaska 99688
Toll-Free: 866.889.3425
Federal Law allows an EXCEPTION
for laser emergency signaling devices
Product Specifications:
• Visibility: 20 m (32 km) nighttime, optimum conditions
• Daytime signaling up to 1-3 miles (1.6 - 4.8 km)
• Waterproof: to 80 feet (24 m)
• Laser Diode: Red - 10,000 hours meantime life
• Laser Class: 3R < 5mW cw max
• Beam Divergence: Operating temperature: -10˚ C ~ +50˚ C
• Operational Life: 40 hours continuous use before
changing battery
• Battery: CR123 lithium battery
• Non-flammable, environmentally friendly
• Hole in end cap for attachment to a lanyard or key ring
• Rugged anodized aluminum, corrosion resistant
• Limited Lifetime Warranty - see website for details
854071013014
Rescue Laser™Light
SKU: RLL013-01
greatlandlaser.com
reatlan d laser
G
Expanding line of light makes it easy to signal and produces a safe, and brilliant flash of light
And beyond
8 Miles
3000’
16 Miles
6000’
Our compact, hand-held signal device can be seen up to 20 miles
Find us on social media
Brave Any Adventure
actual sizeactual size
User Guide
Rescue Laser™Light
Rescue Laser™Light
Emergency Distress Signal
Our hand-held models, the size of a small,
single-cell flashlight, project a laser light through a
special lens that can be seen up to 20 miles.
Patented technology converts a point of laser light
into an expanding line of light with much higher
visibility than traditional signaling devices.
safety and rescue products
Greatland Laser
™

G
(a)
(b)
Greatland Laser LLC
PO Box 792
Willow, Alaska 99688 USA
Toll-Free: 866.889.3425
Greatland Laser LLC
PO Box 792
Willow, Alaska 99688 USA
Toll-Free: 866.889.3425
© 2023 Greatland Laser LLC • Manufactured in the USA
G
Assembly and Operation
1. To assemble, unscrew end cap. Insert one CR123, 3V lithium battery
and then screw on end cap.
2. Point the light output end (laser aperture) down for safety and
continue tightening end cap until laser flare is switched on (visible
through protective front cap). Remove protective plastic cap on
front end of unit. Turn sight ring until it is aligned with vertical laser
line. Your Rescue Laser™ is ready for use.
3. Ensure Rescue Laser™ emergency signaling device is secured so it
cannot be lost. Use the hole in the end cap to secure with a tether or
lanyard.
4. To turn Rescue Laser™ off, point the light output end ( laser aperture )
down for safety and twist then unscrew back end cap until the laser is
off, plus one more turn. Replace protective cap
to keep lens clean.
Signaling (a)*
Aim Rescue Laser™ emergency signaling device in
the direction of the target ( aircraft, boat, vehicle,
rescue party ) you wish to signal. With the laser line
vertical ( up and down ), point laser aperture
toward the target. Make a “V” with your
outstretched hand over the intended target. With
the signaling device held near your eye in line of
sight, very slowly scan the vertical laser back and
forth between your fingers toward the target
making each finger red as you scan and line up
target through the sight ring.
Important: Always point the laser output end away from your eyes.
Keep signaling until you have positive contact with your rescuers or target
and they are able to see you without the use of the signaling device.
*Signals up to 20 miles away. Testing conducted
with the naked eye, on a clear moonless night with
no background or environmental lighting. The
effectiveness of any signaling device may be
compromised by actual environmetal conditions.
Detecting (b)
When looking for reflective materials, point the
laser aperture toward the object you are scanning
and hold the laser near your line of sight to see the
return flash from the object.
Safety Summary
Caution: use of controls or adjustments, or performance of procedures
other than those specified herein may result in hazardous radiation
exposure.
This laser process machine is certified as a Class IIIa laser product to the
requirements of the US Federal product performance standard for laser
products contained in the regulations in 21 CFR sub-chapter J.
This device should only be used to signal persons at a distance greater
than 13 feet (4 meters).
During the performance of routine maintenance procedures such as
cleaning the exterior or changing batteries the power should be turned to
the off position.
Under no circumstance shall attempts be made to disassemble or service
this product. All service is to be performed by the manufacturer or their
authorized agent.
AVOID DIRECT EYE EXPOSURE TO THE BEAM
Battery Replacement and Maintenance
Battery replacement and exterior cleaning are the only maintenance
required. There are no user serviceable components inside the device.
Attempting to gain access to the laser components will void the warranty.
Turn laser off before changing battery or cleaning. The Rescue Laser™
Light operates on one CR123, 3V lithium battery. To replace the battery,
turn laser off, unscrew end cap and remove battery. Insert one fresh
battery as shown in the diagram above with the positive (+) end facing
toward the end cap, then screw on end cap. Tighten end cap until laser
light is switched on (visible through protective front plastic cap), then
unscrew until light is off, plus one more turn. For optimum performance,
the battery in your Rescue Laser™should be replaced at least once every
year.
Lens may be cleaned with a soft dry cloth or camera lens brush. Do not
use cleaning fluids. Exterior may be wiped with a damp cloth to remove
surface dirt, then dried.
Troubleshooting
1. Rescue Laser™ emergency signaling device does not turn on or stay
on, verify battery has been inserted with the positive end facing outward
as shown in diagram above. Check contact between the battery and the
end cap. Any corrosion formed by a foreign substance should be
carefully removed.
2. Laser light failure — verify one CR123, 3V lithium battery has been
properly inserted with the positive end facing outward as shown in the
diagram above, if necessary, replace battery.
3. If the above steps have been followed and the Rescue Laser™
emergency signaling device still does not perform properly, follow the
steps in the how and when to make a warranty claim, or contact
our warranty and repair facility: 1. 907.245.4475. Limited Lifetime
Warranty and online registration available at www.greatlandlaser.com
Rescue Laser™Light
Emergency Distress Signal
Certification and Warning label
End cap with
lanyard hole
Twist to Turn
On/Off
Laser Aperture
3-Volt lithium battery ± polarity
It is illegal to point this device at an
aircraft except in an emergency! LASER APERTURE
Greatland Laser
Ranch Cucamonga, CA, USA
Model: Rescue Laser Light
Manufactured: 2022 2023 2024
1 2 3 4 5 6
7 8 9 10 11 12
Serial Number: RLL013-01 H09319
AIM
