Gree Gpc08al-a3nna2b User manual

MODEL: GPC08AL-A3NNA2B

www.gree.ca

Saint-Mathieu-de-Beloeil (Quebec) Canada

042021

Made in China

TABLE OF CONTENTS

SAFETY WARNIN ......................................................................................1

PART'S NAME ..............................................................................................2

CLEAN AND MAINTENANCE ......................................................................3

MALFUNCTION ANALYSIS..........................................................................5

INSTALLATION PRECAUTION ....................................................................8

PREPARATION BEFORE INSTALLATION ..................................................9

INSTALLIN WIRE THE HOOK ..................................................................10

REMOVIN COLLECTED WATER ..............................................................11

INSTALLATION IN A DOUBLE-HUN SASH WINDOW ............................14

INSTALLATION IN A SLIDIN SASH WINDOW ..........................................18

INSTALLATION AND DISASSEMBLY OF HEAT DISCHAR E PIPE ..........22

OPERATION INTRODUCTION FOR CONTROL PANEL ............................25

BUTTONS ON REMOTE CONTROL ..........................................................27

REPLACIN THE BATTERIES ..................................................................31

WARRANTY..................................................................................................32

model no 043-6138-6 / 043-5443-4 contact us: 1.866.523.5218

00738_ 10-11-2015Owner's Manual Air conditioner Portable (Shiny) Final_Climatiseur Mobile8.5x11 An+FR 15-12-18 16:22 Page2

� DANGER

� WARNING

� CAUTION

NOTICE



 



 



 





  

 

 





°°° °





  









 

 









 

 







S







 

SAFETY WARNING

• This appliance can be used by children aged from 8 years and

above and people with reduced physical ,sensory or mental

capabilities or lack of experience and knowledge if they have

been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved.

Children shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without supervision.

• Before operation, please confirm whether power specification

complies with that on nameplate.

• Before cleaning or maintaining the air conditioner, please turn off

air conditioner and pull out the power plug.

• Make sure the power cord hasn't been pressed by hard objects.

• Do not pull or drag the power cord to pull out the power plug or

move the air conditioner.

• Do not insert or pull out the power plug with wet hands.

• Please use the grounded power. Make sure the gounding is reliable.

• If the supply cord is damaged, it must be replaced by the

manufacturer or its service agent or a similarly qualified person

in order to avoid a hazard.

• If the power cord is damaged, it must be replaced by

manufacturer or professional person.

• If abnormal condition occurs (e.g. burned smell), please

disconnect power at once and then contact local dealer.

• When nobody is taking care of the unit, please turn it off and

remove the power plug or disconnect power.

• Do not splash or pour water on air conditioner. Otherwise, it may

cause short circuit or damage to air conditioner.

• If drainage hose is used, ambient temperature can't be lower than

0°C .Otherwise, it will cause water leakage to air conditioner.

• Prohibit operating heating equipment around the air conditioner.

• Keep far away from fire source, inflammable and explosive objects.

• Children and disabled people are not allowed to use the

portable room air conditioner without supervision.

• Keep children from playing or climbing on the air conditioner.

• Do not put or hang dripping objects above the air conditioner.

• Do not repair or disassemble the air conditioner by yourself.

• Prohibit inserting any objects into the air conditioner.

• Do not use an extension cord

00738_ 10-11-2015Owner's Manual Air conditioner Portable (Shiny) Final_Climatiseur Mobile8.5x11 An+FR 15-12-18 16:22 Page4







  

WARNING

 

   

   





  

Clean outer case and grille





    



 

Clean filter

 

Clean filter

 





Clean filter

 



   

  °

°



   

  

 

   



CLEANING AND MAINTENANCE

Clean heat discharge pipe

Remove the heat discharge pipe from air conditioner, clean and dry it , and then

reinstall it. (For the method of installation and removal , please refer to the

instruction for "Installation and disassembly of heat discharge pipe").

Checking before use-season

1. Check whether air inlets and air outlets are blocked.

2. Check whether plug and socket are in good condition.

3. Check whether filter is clean.

4. Check whether batteries are installed in remote controller.

5. Check whether joint, window bracket and heat discharge pipe are installed

tightly.

6. Check whether heat discharge pipe is damaged.

Checking after use-season

1. Disconnect power supply.

2. Clean filter and outer case.

3. Remove dust and sundries on the air conditioner.

4. Eliminate accumulated water in chassis (refer to the section of "Drainage

wayn for details).

5. Check whether window bracket is damaged or not. If yes, please contact

dealer.

Long-time storage

If you don't use the air conditioner for a long time, please maintain it by follo-

wingsteps for good performance:

• Make sure there's no accumulated water in chassis and the heat discharge

pipe is disassembled.

• Pull out the plug and wrap the power cord.

• Clean the air conditioner and pack it well to prevent dust.

Notice for recovery

• Many packing materials are recyclable materials. Please deal with them

through local recycle bin.

• If you want to throw away the air conditioner, please contact local division or

consultant service center for the correct disposal method.

00738_ 10-11-2015Owner's Manual Air conditioner Portable (Shiny) Final_Climatiseur Mobile8.5x11 An+FR 15-12-18 16:23 Page7

MALF NCTION ANALYSIS

Please check below items before asking for maintenance. If the malfunction still

can't be eliminated, please contact local dealer or qualified professionals.

Air conditioner

canʼt operate

Poor cooling

(heating)

Air conditioner

canʼt receive

signal from

remote control or

remote control is

not sensible

• Power failure? • Wait after power recovery.

• Reinsert the plug.

• Ask professional person

to replace air switch or fuse.

• Ask professional person to

replace circuit.

• Wait for 3min, and then turn

on the unit again.

• Is plug loose?

• Whether the air switch is

tripped off or fuse is burnt?

• Is there's malfunction for

the circuit?

• Whether the unit is restarted

up after stopping

immediately?

• Is the power too low?

• Whether the air filter is too

dirty?

• Whether the set temperature

is proper?

• Whether door and window

are closed?

•Whether the unit is interfered

seriously (such as static

pressure, unstable voltage)?

• Whether remote controller is

within the receiving range?

• Whether it's blocked by

obstacles?

• Is sensitivity of remote

controller low?

• Whether there's fluorescence

lamp in the room? • Move the remote controller

close to air conditioner.

• Turn off the fluorescence

lamp and try it again.

• Check the batteries of remo-

te controller. If the power is

low, please replace the

batteries.

• Remove the obstacles.

• The receiving range of remo-

te controller is 8m. Do not

exceed this range.

• Please pull out the plug.

Insert the plug after about

3min, and then turn on the

unit.

Close door and window.

• Adjust the temperature.

• Clean the air filter.

• Wait after voltage is resumed.

Troubleshooting Solution

henomenon

00738_ 10-11-2015Owner's Manual Air conditioner Portable (Shiny) Final_Climatiseur Mobile8.5x11 An+FR 15-12-18 16:23 Page8

MALF NCTION ANALYSIS

No fan blowed

out from air

conditioner

Set temperature

canʼt be adjusted

Thereʼs off

flavour

Thereʼs anormal

sound during

operation

You can heard

water-flowing

sound

You can heard

the sound of

PAPA

• Whether air outlet or air

inlet is blocked?

• Under heating mode,

whether indoor temperatu-

re ireaches set

temperature?

• Whether evaporator is

defrosted?

(observe it by pulling out

the filter)

• Whether the unit operates

under auto mode?

• Whether the required

temperature exceeds the

temperature setting

range?

• Temperature setting

range: 61 °F(16°C)-

86°F(30°C).

• Temperature can't be

adjusted under auto mode.

• It's the normal phenome

non. Air conditioner is

defrosting. After defrosting

is finished, it will resume

operation.

• Mobile unit will stop blo

wing fan after reaching

set temperature.

• Eliminate the obstacles.

• There's off-flavour source in

the room, such as furniture,

cigarette etc.

• Whether the unit is interfered

by thunder, radio, etc?

• Whether the unit is turned on

or turned off just now?

• Whether the unit is turned on

or turned off just now? • Heat expansion or shrinkage

for the panel due to change

of temperature, which cause

friction sound.

• There's flowing sound of

refrigerant inside the air

conditioner, which is the

normal phenomenon.

•Disconnect power, put

through the power again,

and then turn on the unit

again.

• Eliminate the off-flavour

source.

• Clean the filter.

Troubleshooting Solution

henomenon

00738_ 10-11-2015Owner's Manual Air conditioner Portable (Shiny) Final_Climatiseur Mobile8.5x11 An+FR 15-12-18 16:23 Page9

MALF NCTION ANALYSIS

Malfunction code

Chassis is full of water.

Malfunction of ambient

temperature sensor.

Malfunction of evaporator

temperature sensor.

1.Refrigerant is leaking

2.System is blocked

Overload protection for

compressor

Overload malfunction

Outdoor tube temperature

sensor is open/short-

circuited.

Please contact after-sale

service person

to deal with it.

1.Check if the unit is under high-

temperature and high-humidity

environment; if ambient tempera-

ture is too high, power off the unit

and then energize it for operation

after the ambient temperature

drops below 35°C.

2.Check If the evaporator and

condenser are blocked by some

objects; if yes, take away the

objects, power off the unit and

then energize it for operation.

3.If the malfunction still occur,

please contact our after-sales

service center.

1.Re-energize the unit after

turning off and pulling out the

plug for 30min;

2.If there's still malfunction,

please contact after-sales

service.

Please contact professional

person to deal with it.

Please contact professional

person to deal with it.

1. Pour out the water inside chassis.

2. If "H8" still exits, please contact

professional person to maintain the

unit.

E 8

WARNING

• If there're following phenomenon, please turn off the air conditioner and

disconnect the power immediately, and then contact dealer immediately.

Power cord is overheating or damaged.

Abnormal sound during operation.

Off-flavor.

Water leakage

• Do not repair or refit the air conditioner by yourself.

• If operate the air conditioner under abnormal condition, it may cause

malfunction, electric shock or fire hazard.

00738_ 10-11-2015Owner's Manual Air conditioner Portable (Shiny) Final_Climatiseur Mobile8.5x11 An+FR 15-12-18 16:23 Page10

Table of contents

Other Gree Air Conditioner manuals

Gree

Gree G1407M User manual

Gree

Gree TTW Series User manual

Gree

Gree GMVVQ224WM/C-X User manual

Gree

Gree GWH09AB-A3DNA1B User manual

Gree

Gree SUPER FREE MATCH Series User manual

Gree

Gree ALTEA User manual

Gree

Gree FGR20Pd/DNa-X User manual

Gree

Gree GMV-120WL/C-X User manual

Gree

Gree GWC18KG-K3DNA5A User manual

Gree

Gree GWHD(36)NK3JO User manual

Gree

Gree U-match Series User manual

Gree

Gree GJC12AF-E3DRNG2A User manual

Gree

Gree GWC07NA-K3NNB1A User manual

Gree

Gree GJC9AG-E6RNB3A User manual

Gree

Gree MULTI56HP230V1AO User manual

Gree

Gree Terra GWH09TB-D3DNA1A User manual

Gree

Gree GJC12BL-A3RNC5A User manual

Gree

Gree G17-14ESCWAC1 User manual

Gree

Gree GFH(09)EA-K6DNA1B/I User manual

Gree

Gree MULTI24HP230V1EO Operating instructions

Gree

Gree GMV-ND28TD/A-T User manual

Gree

Gree ULTRA heating GMVND07PLS/A-T User manual

Gree

Gree GWH09MB-D3DNA3D User manual

Gree

Gree GJC10BL-A6NRNC5D User manual

Popular Air Conditioner manuals by other brands

Fujitsu

Fujitsu ASYG 09 LLCA installation manual

York

York HVHC 07-12DS Installation & owner's manual

Carrier

Carrier Fan Coil 42B Installation, operation and maintenance manual

intensity

intensity IDUFCI60KC-3 installation manual

Frigidaire

Frigidaire FAC064K7A2 Factory parts catalog

Sanyo

Sanyo KS2432 instruction manual

LG MultiV Series installation manual

CLIMAVENETA

CLIMAVENETA a-CHD U-2T 606+2209 OPERATING AND INSTALLATION Manual

Midea

Midea EWK06CW5 user manual

Pioneer

Pioneer FAB Series installation manual

SPT

SPT WA-1511S user manual

Mitsubishi Electric

Mitsubishi Electric Mr.Slim MSZ-A24NA operating instructions

Mitsubishi Electric

Mitsubishi Electric PUHZ-RP50VHA4 Service manual

Panasonic

Panasonic CS-S18HKQ Service manual

Panasonic

Panasonic CS-E15NKE3 operating instructions

Friedrich

Friedrich ZoneAire Compact P08SA owner's manual

Daikin

Daikin R32 Split Series installation manual

Daikin

Daikin FFQ09Q2VJU Operation manual

Gree GPC08AL-A3NNA2B User manual

Popular Air Conditioner manuals by other brands
