Gree GMV5 Series User manual

`
Photovoltaic Direct-driven Inverter Multi VRF
（
GMV5 Solar
）
For North America
(GC202005-I)
Capacity: 72000Btu/h~360000Btu/h
Rated Frequency: 60Hz
Operation Range: Cooling: 23~125.6℉
Heating: -4~75.2℉

Contents
CHAPTER 1 INTRODUCTION TO BASIC FEATURES OF UNITS································6
1 MODELS LIST·································································································6
2 BASIC OPERATING PRINCIPLE ········································································6
3 INTERNAL PIPING DESIGN OF THE UNITS ····························································7
3.1 Piping Diagram of GMV-Y72WM/C-F(U) 、GMV-Y96WM/C-F(U) and GMV-Y120WM/C-F(U)
····························································································································7
3.2 Names and Main Functions of Components·······························································8
4 BASIC PARAMETERS ······················································································9
4.1 Basic Parameter of Outdoor Unit·············································································9
4.2 Basic Parameter of Photovoltaic Parts and Components············································· 13
5 ELECTRICAL PARAMETERS··········································································· 14
6 Circuit Diagram······························································································ 15
6.1 Circuit diagram of GMV-Y72WM/C-F(U)·································································· 15
6.2 Circuit diagram of GMV-Y96WM/C-F(U) and GMV-Y120WM/C-F(U) ····························· 16
7 UNIT OPERATING TEMPERATURE·································································· 16
CHAPTER 2 INSTALLATION ·············································································· 17
1 ENGINEERING INSTALLATION PREPARATION ················································· 17
1.1 Installation Safety ······························································································17
1.2 Importance of Installation Engineering ····································································17
1.3 Cooperation between Different Professions ·····························································18
1.4 Onsite Review of Design Drawing ·········································································21
1.5 Construction Organization Process········································································ 22
2 MATERIAL SELECTION·················································································· 23
2.1 Requirement for Selecting Construction Materials ·····················································23
2.2 Requirement for Selecting Major Materials ······························································23
3 INSTALLATION SPACE REQUIREMENT ··························································· 26
3.1 Place Selection for Installing ODU ········································································· 26
3.2 ODU Dimensions and Installation Hole Size····························································· 26
3.3 Installation Space Requirement for ODU ································································· 28
4 REQUIREMENTS ON FOUNDATION INSTALLATION ·········································· 35
4.1 ODU Foundation ······························································································· 35
4.2 ODU Fixing ······································································································36
4.3 Vibration Reduction for ODU ················································································36
5 PIPING CONNECTION ··················································································· 37
5.1 Schematic Diagram of Piping Connection································································ 37
5.2 Schematic Diagram of Piping Sequence ································································· 38

5.3 Allowable Pipe Length and Drop Height among Indoor and Outdoor Units ······················ 40
5.4 Connection Pipe among Outdoor Modules······························································· 42
5.5 Fitting pipe between Outdoor Unit and the First Manifold ············································ 43
6 PIPE INSTALLATION AND INSULATION ···························································· 48
6.1 Pipe Installation for the Cooling System ·································································· 48
6.2 Pipe Installation for the Condensate Water System ·························································59
6.3. Requirements on Independent Drainage for Each IDU ····················································62
6.4. Requirements on Centralized Drainage for IDUs ···························································62
7 ELECTRIC AND CONTROLLER INSTALLATION ················································· 64
7.1 Precautions ······································································································64
7.2 Installation of the Power Cable ············································································· 65
8 Installation of Photovoltaic System····································································· 74
8.1 Notice for Installation ··························································································74
8.2 Installation Project of Photovoltaic System·······························································76
9 VACUUMIZATION AND DESICCATION FOR THE REFRIGERANT SYSTEM············ 84
9.1 Air-Tightness Test ······························································································ 84
9.2 Vacuumization and Desiccation for the System························································· 85
10 REFRIGERANT PERFUSION ········································································· 86
10.1 Calculation Method for Perfusing Refrigerant·························································· 86
10.2 Method for Perfusing Refrigerant ········································································· 89
CHAPTER 3 COMMISSIONING OPERATION························································ 92
1 SECURITY REQUIREMENTS ·········································································· 92
1.1 precautions for Construction················································································· 92
1.2 Precautions for the Use of Refrigerants ·································································· 92
1.3 Function Settings of ODUs ·················································································· 92
2 COMMISSIONING PROCESS·········································································115
2.1 Necessity of VRF Engineering Commissioning ······················································· 115
2.2 Required Files and Tools for Engineering Commissioning ········································· 116
2.3 Engineering Commissioning Procedures······························································· 116
2.4 References for Proper Unit Operation Parameters ·················································· 139
CHAPTER 4 MAINTENANCE ··········································································· 141
1 SYSTEM FAILURE CODE TABLE ··································································· 141
2 EXCEPTION AND TROUBLESHOOTING························································· 146
2.1 How to Locate a Faulty IDU Promptly··································································· 146
2.2 Form Analyzing ······························································································· 147
2.3 System Faults································································································· 155
3 MAINTENANCE OF KEY PARTS ···································································· 259
3.1 Cautions on ODU AP1 Replacement···································································· 259

3.2 Method and Notice for Replacement of Compressor ················································ 260
3.3 Disassembly and Assembly Procedure of Outdoor Unit Main Parts ····························· 284
3.4 Maintenance of Photovoltaic Parts······································································· 296
4 APPENDIXES ····························································································· 301
4.1 Minutes about a Debug Solution Confirmation Meeting ············································ 301
4.2 Visual Inspection Checklist of the Debug System ···················································· 301
4.3 Debug Parameter Record List ············································································ 302
4.4 Common Parameter Lists ·················································································· 303
4.5 Exploded Views and Spare Part List····································································· 313

GREE Photovoltaic Direct-driven Inverter Multi VRF Units
1
PREFACE
This manual specifies safe operation requirements for Photovoltaic Direct-driven Inverter Multi
VRF units from perspectives of engineering and installation, commissioning and maintenance, as well as
basic principles and implementation methods. Professional operators must abide by relevant national
(local) safety requirements and technical specifications set forth in this manual during operations;
otherwise, the air conditioning system may fail or be damaged, and personnel safety accident may also
occur.

GREE Photovoltaic Direct-driven Inverter Multi VRF Units
2
SAFTY PRECAUTIONS
To prevent injury to the user or other people and property damage, the following instructions must
be followed.
Incorrect operation due to ignoring instruction will cause harm or damage. The seriousness is
classified by the following indications.
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all
safety messages that follow this symbol to avoid possible injury or death.
WARNING This mark indicates procedures which, if improperly performed, might lead to the death or serious
injury of the user.
CAUTION This mark indicates procedures which, if improperly performed, might possibly result in personal
harm to the user, or damage to property.
NOTICE is used to address practices not related to personal injury.
■Installation
Have all electric work done by a licensed electrician according to "Electric Facility
Engineering
Standard" and "Interior Wire Regulations" and the instructions given in this manual and
always use a special circuit.
• If the power source capacity is inadequate or electric work is performed improperly, electric shock
or fire may result.
Ask the dealer or an authorized technician to install the air conditioner.
• Improper installation by the user may result in water leakage, electric shock, or fire.
Always ground the product.
• There is risk of fire or electric shock.
Always install a dedicated circuit and breaker.
• Improper wiring or installation may cause fire or electric shock.
For re-installation of the installed product, always contact a dealer or an Authorized Service
Center.
• There is risk of fire, electric shock, explosion, or injury.
Do not install, remove, or re-install the unit by yourself (customer).
• There is risk of fire, electric shock, explosion, or injury.
Do not store or use flammable gas or combustibles near the air conditioner.
• There is risk of fire or failure of product.
Use the correctly rated breaker or fuse.
• There is risk of fire or electric shock.
Prepare for strong wind or earthquake and install the unit at the specified place.
• Improper installation may cause the unit to topple and result in injury.
Do not install the product on a defective installation stand.

GREE Photovoltaic Direct-driven Inverter Multi VRF Units
3
• It may cause injury, accident, or damage to the product.
When installing and moving the air conditioner to another site, do not charge it with a
different refrigerant from the refrigerant specified on the unit.
• If a different refrigerant or air is mixed with the original refrigerant, the refrigerant cycle may
malfunction and the unit may be damaged.
Do not reconstruct to change the settings of the protection devices.
• If the pressure switch, thermal switch, or other protection device is shorted and operated forcibly,
or parts other than those specified by GREE are used, fire or explosion may result.
Ventilate before operating air conditioner when gas leaked out.
• It may cause explosion, fire, and burn.
Securely install the cover of control box and the panel.
• If the cover and panel are not installed securely, dust or water may enter the outdoor unit and fire
or electric shock may result.
If the air conditioner is installed in a small room, measures must be taken to prevent the
refrigerant concentration from exceeding the safety limit when the refrigerant leaks.
• Consult the dealer regarding the appropriate measures to prevent the safety limit from being
exceeded. Should the refrigerant leak and cause the safety limit to be exceeded, hazards due to lack of
oxygen in the room could result.
■Operation
Do not damage or use an unspecified power cord.
• There is risk of fire, electric shock, explosion, or injury.
Use a dedicated outlet for this appliance.
• There is risk of fire or electrical shock.
Be cautious that water could not enter the product.
• There is risk of fire, electric shock, or product damage.
Do not touch the power switch with wet hands.
• There is risk of fire, electric shock, explosion, or injury.
When the product is soaked (flooded or submerged), contact an Authorized Service Center.
• There is risk of fire or electric shock.
Be cautious not to touch the sharp edges when installing.
• It may cause injury.
Take care to ensure that nobody could step on or fall onto the outdoor unit.
• This could result in personal injury and product damage.
Do not open the inlet grille of the product uring operation. (Do not touch the electrostatic
filter, if the unit is so equipped.)
• There is risk of physical injury, electric shock, or product failure.

GREE Photovoltaic Direct-driven Inverter Multi VRF Units
4
■Installation
Always check for gas (refrigerant) leakage after installation or repair of product.
• Low refrigerant levels may cause failure of product.
Do not install the product where the noise or hot air from the outdoor unit could damage the
neighborhoods.
• It may cause a problem for your neighbors.
Keep level even when installing the product.
• To avoid vibration or water leakage.
Do not install the unit where combustible gas may leak.
• If the gas leaks and accumulates around the unit, an explosion may result.
Use power cables of sufficient current carrying capacity and rating.
• Cables that are too small may leak, generate heat, and cause a fire.
Do not use the product for special purposes, such as preserving foods, works of art, etc. It is
a consumer air conditioner, not a precision refrigeration system.
• There is risk of damage or loss of property.
Keep the unit away from children. The heat exchanger is very sharp.
• It can cause the injury, such as cutting the finger. Also the damaged fin may result in degradation
of capacity.
When installing the unit in a hospital, communication station, or similar place, provide
sufficient protection against noise.
• The inverter equipment, private power generator, high-frequency medical equipment, or radio
communication equipment may cause the air conditioner to operate erroneously, or fail to operate. On
the other hand, the air conditioner may affect such equipment by creating noise that disturbs medical
treatment or image broadcasting.
Do not install the product where it is exposed to sea wind (salt spray) directly.
• It may cause corrosion on the product. Corrosion, particularly on the condenser and evaporator
fins, could cause product malfunction or inefficient operation.
■Operation
Do not use the air conditioner in special environments.
• Oil, steam, sulfuric smoke, etc. can significantly reduce the performance of the air conditioner or
damage its parts.
Do not block the inlet or outlet.
• It may cause failure of appliance or accident.
Make the connections securely so that the outside force of the cable may not be applied to
the terminals.
• Inadequate connection and fastening may generate heat and cause a fire.
Be sure the installation area does not deteriorate with age.
• If the base collapses, the air conditioner could fall with it, causing property damage, product failure,

GREE Photovoltaic Direct-driven Inverter Multi VRF Units
5
or personal injury.
Install and insulate the drain hose to ensure that water is drained away properly based on the
installation manual.
• A bad connection may cause water leakage.
Safely dispose of the packing materials.
• Packing materials, such as nails and other metal or wooden parts, may cause stabs or other
injuries.
• Tear apart and throw away plastic packaging bags so that children may not play with them. If
children play with a plastic bag which was not torn apart, they face the risk of suffocation.
Turn on the power at least 6 hours before starting operation.
• Starting operation immediately after turning on the main power switch can result in severe damage
to internal parts. Keep the power switch turned on during the operational season.
Be very careful about product transportation.
• Only one person should not carry the product if it weighs more than 44lbs (20kg).
• Some products use PP bands for packaging. Do not use any PP bands for a means of
transportation. It is dangerous.
• Do not touch the heat exchanger fins. Doing so may cut your fingers.
• When transporting the outdoor unit, suspending it at the specified positions on the unit base. Also
support the outdoor unit at four points so that it cannot slip sideways.
Do not touch any of the refrigerant piping during and after operation.
• It can cause a burn or frostbite.
Do not operate the air conditioner with the panels or guards removed.
• Rotating, hot, or high-voltage parts can cause injuries.
Do not directly turn off the main power switch after stopping operation.
• Wait at least 5 minutes before turning off the main power switch. Otherwise it may result in water
leakage or other problems.
Auto-addressing should be done in condition of connecting the power of all indoor and
outdoor units. Auto-addressing should also be done in case of changing the indoor unit PCB.
Use a firm stool or ladder when cleaning or maintaining the air conditioner.
• Be careful and avoid personal injury.
Do not insert hands or other objects through the air inlet or outlet while the air conditioner is
plugged in.
• There are sharp and moving parts that could cause personal injury.

GREE Photovoltaic Direct-driven Inverter Multi VRF Units
6
CHAPTER 1 INTRODUCTION TO BASIC FEATURES OF UNITS
1 MODELS LIST
Model Product Code
Capacity
Ref. Power
Supply Appearance
Cooling
(Btu/h)
Heating
(Btu/h)
GMV-Y72WM/C-F(U) CN870W0240 72000 81000 R410A 208/240V
3~60Hz
GMV-Y96WM/C-F(U) CN870W0220 96000 108000 R410A 208/240V
3~60Hz
GMV-Y120WM/C-F(U) CN870W0230 120000 135000 R410A 208/240V
3~60Hz
2 BASIC OPERATING PRINCIPLE
Outdoor units of Photovoltaic Direct-driven Inverter Multi VRF air conditioner can be implemented
by combining multiple modules in parallel. Similarly, indoor units (IDUs) consist of multiple units
connecting in parallel. The operating principle is as follows: When an IDU is operating in cooling mode,
the outdoor unit (ODU) can correspondingly enable the outdoor module based on the operating load
requirement of the IDU. The outdoor heat exchanger serves as a system condenser, and the heat
exchangers of cooling IDUs are connected in parallel to serve as a system evaporator. The circulation of
air supply and air return of the IDU is performed to adjust the indoor temperature and humidity. When an
IDU is operating in heating mode, all four-way valves in the ODU module are switched into energized
status. The outdoor heat exchange serves as the system evaporator, and the heat exchanger of the IDU
serves as the system condenser. The circulation of air supply and air return of the IDU is performed to
adjust the indoor temperature and humidity.

GREE Photovoltaic Direct-driven Inverter Multi VRF Units
7
3 INTERNAL PIPING DESIGN OF THE UNITS
3.1 Piping Diagram of GMV-Y72WM/C-F(U) 、GMV-Y96WM/C-F(U)
and GMV-Y120WM/C-F(U)

GREE Photovoltaic Direct-driven Inverter Multi VRF Units
8
3.2 Names and Main Functions of Components
No Name Main Function
1 Compressor Adjusts its own rotational speed based on the actual requirement of the
system to implement capacity control.
2 Compressor heat tape
Maintains a proper oil temperature in the compressor when the
compressor is in standby status, ensuring the reliability during compressor
startup.
3 Compressor casing-top temperature
sensor
Detects a compressor's exhaust gas temperature for compressor control
and protection.
4 Exhaust pipe temperature sensor of
compressor
Detects a compressor's exhaust gas temperature for compressor control
and protection.
5 High-pressure circuit breaker
Protects a compressor by sending feedback signal to stop the system
when the compressor's discharge temperature exceeds the operating
value of high-pressure circuit breaker.
6 Oil extractor Separates the gas and oil in the system to ensure compressor reliability.
7 Oil balance device
Equalizes the oil for all modules in the case of excess oil in the current
module when multiple modules are arranged in parallel, thus ensuring the
system reliability.
8 Heat tape of oil balance device
Maintains a proper oil temperature in the compressor when the
compressor is in standby status, ensuring the reliability of compressor
startup.
9 One-way valve Prevents high-pressure gas from entering the compressor and fast
balances the suction pressure and discharge pressure in a compressor.
10 High-pressure sensor Detects the high pressure value in the system in real time mode for
compressor protection and other control functions.
11 Four-way valve Used for the switching between the cooling and heating functions of
system IDU.
12
Heat exchanger
Used for outdoor heat exchange.
13
Fan
Strengthens heat exchanging.
14
Defrosting temperature sensor
Used for defrosting detection.
15
Electronic expansion valve for heating
Controls refrigerant adjustment in heating mode.
16
One-way valve
Controls refrigerant flow direction.
17 Subcooler electronic expansion valve Controls the degree of subcooling of tube refrigerant when the system is
running in cooling mode, and reduces the capacity loss on pipes.
18 Subcooler Controls the degree of subcooling of tube.
19 Liquid outlet temperature sensor of
subcooler
Detects tube temperature.
20 Inlet temperature sensor of gas-liquid
separator
Detects the inlet temperature of gas-liquid separator to prevent the system
from running when the refrigerant flows back to the compressor.
21 Gas outlet temperature sensor of
subcooler
Detects gas temperature of subcooler.
22 Low-pressure sensor Detects system low pressure to avoid extra-low operating pressure.
23 Gas-liquid separator Separate gas and liquid to prevent the system from running when the
refrigerant flows back to the compressor.
24 Outlet temperature sensor of gas-liquid
separator
Detects internal status of gas-liquid separator to further control the
compressor suction performance.
25
Oil balance valve 1
Used for oil balance control among modules.
26
One-way valve
Used for oil balance control among modules and avoid reverse flow of oil.
27 Unloading valve Avoids over-high pressure caused by pipeline blind spot.
28 Oil balance valve 2 Used for oil balance control among modules.
29 Filter Prevents impurities from entering components and parts.
30 Capillary tube Supports flow regulating and pressure reduction.

GREE Photovoltaic Direct-driven Inverter Multi VRF Units
9
No Name Main Function
31 Liquid valve Stop valve, closed when the unit is delivered from the factory and will be
opened after installation.
32 Gas valve Stop valve, closed when the unit is delivered from the factory and will be
opened after installation.
33 Low-pressure measurement valve Detects the low pressure value or charges refrigerant during system
running.
34 Oil balance valve Stop valve, closed when the unit is delivered from the factory and will be
opened after installation.
35 Oil check valve Checks the quality of refrigerating machine oil of compressor during
maintenance.
36
Unloading valve
Avoid over-high pressure caused by pipeline blind spot.
37
Air by-pass valve
Avoids extra-high or low operating pressure.
38
Pressure-balanced valve
Ensures success startup of compressor.
4 BASIC PARAMETERS
4.1 Basic Parameter of Outdoor Unit
Outdoor Units_Heat Pump
－
6Ton
8Ton
10Ton
Model －GMV-Y72WM/C
-F(U)
GMV-Y96WM/C
-F(U)
GMV-Y120WM/C
-F(U)
Module (combinated)
－－－－
Cooling capacity
Btu/h
72000
96000
120000
Heating capacity
Btu/h
81000
108000
135000
Air volume
CFM
6710
8240
8240
Max. external static
pressure
Pa 82 82 82
Noise(sound level)
dB(A)
60
61
63
Power － 208/240V 3~ 60Hz 208/240V 3~ 60Hz 208/240V 3~ 60Hz
Input power for cooling
kW
5.45 7.30 10.00
Input power for heating
kW
5.80 7.85 10.50
Input current for cooling
A
16.42 20.37 26.27
Input current for heating
A
17.29 23.50 27.87
MOP
A
45(208V)/40(240V) 45(208V)/40(240V) 45(208V)/40(240V)
MCA
A
35.3(208V)/30.3(240V)
43.6(208V)/37.3(240V) 44.8(208V)/39.8(240V)
Compressor type
－
Inverter Scroll
Inverter Scroll
Inverter Scroll
Compressor quantity N 1 1 1
Refrigeration oil no. of
compressor
－FVC68D or FV68H FVC68D or FV68H FVC68D or FV68H
Oil
Charge
Compressor
L
1.1
1.1
1.1
Oil separate tank
L
3.5
4
4
Total L 4.6 5.1 5.1
Ambient temperature
range for cooling
℉23~125.6 23~125.6 23~125.6
Ambient temperature
range of heating
℉-4~75.2 -4~75.2 -4~75.2
Refrigerant type
－
R410A
R410A
R410A
Charging volume of
refrigerant
oz 229.3 398.6 416.2
Max. quantity of
connected indoor unit
unit 13 16 19
Size of gas pipe
in.
Φ3/4
Φ7/8
Φ1-1/8

GREE Photovoltaic Direct-driven Inverter Multi VRF Units
10
Outdoor Units_Heat Pump
－
6Ton
8Ton
10Ton
Model －GMV-Y72WM/C
-F(U)
GMV-Y96WM/C
-F(U)
GMV-Y120WM/C
-F(U)
Size of liquid pipe in. Φ3/8 Φ3/8 Φ1/2
Size of oil-balanced pipe
in.
Φ3/8
Φ3/8
Φ3/8
Outline
dimension(WxDxH)
in. 36-5/8x30
-1/8x63-1/4
52-3/4x30
-1/8x63-1/4
52-3/4x30
-1/8x63-1/4
Packing size(WxDxH) in. 39-3/4x33
-1/8x69-7/8
55-7/8x33
-1/8x69-7/8
55-7/8x33
-1/8x69-7/8
Net weight
(Not include converter)
LBS 487 650 650
Gross weight
(Not include converter)
LBS 514 683 683
Outdoor Units_Heat Pump
－
12Ton
14Ton
16Ton
Model
－
GMV-Y144WM/C-F(U)
GMV-Y168WM/C-F(U)
GMV-Y192WM/C-F(U)
Module (combinated) －GMV-Y72WM/C-F(
U)+
GMV-Y72WM/C-F(U)
GMV-Y72WM/C-F(U)+GM
V-Y96WM/C-F(U)
GMV-Y96WM/C-
F(U)+
GMV-Y96WM/C-F(U)
Cooling capacity
Btu/h
144000
168000
192000
Heating capacity
Btu/h
162000
189000
216000
Air volume
CFM
6710+6710
6710+8240
8240+8240
Max. external static
pressure
Pa 82 82 82
Power
－
208/240V 3~ 60Hz
208/240V 3~ 60Hz
208/240V 3~ 60Hz
Input power for cooling
kW
5.45+5.45 5.45+7.30 7.30+7.30
Input power for heating
kW
5.80+5.80 5.80+7.85 7.85+7.85
Input current for cooling
A
16.42+16.42
16.42+20.37
20.37+20.37
Input current for heating
A
17.29+17.29 17.29+23.50 23.50+23.50
MOP A
208V:45+45
240V:40+40
208V:45+45
240V:40+40
208V:45+45
240V:40+40
MCA A
208V:35.3+35.3
240V:30.3+30.3
208V:35.3+43.6
240V:30.3+37.3
208V:43.6+43.6
240V:37.3+37.3
Refrigeration oil no. of
compressor
－FVC68D or FV68H FVC68D or FV68H FVC68D or FV68H
Ambient temperature range
for cooling
℉23~125.6 23~125.6 23~125.6
Ambient temperature range
of heating
℉-4~75.2 -4~75.2 -4~75.2
Refrigerant type
－
R410A
R410A
R410A
Charging volume of
refrigerant
oz 229.3+229.3 229.3+398.6 398.6+398.6
Max. quantity of connected
indoor unit
unit 23 29 33
Size of gas pipe
in.
Φ1-1/8
Φ1-1/8
Φ1-1/8
Size of liquid pipe
in.
Φ1/2
Φ5/8
Φ5/8
Size of oil-balanced pipe
in.
Φ3/8
Φ3/8
Φ3/8
Outline dimension(WxDxH) in. (36-5/8x30-1/8x63-1/4)
x2
(36-5/8x30-1/8x63-1/4)
+(52-3/4x30-1/8x63-1/4)
(52-3/4x30-1/8x63-1/4)
x2
Packing size(WxDxH)
in.
/
/
/
Net weight
(Not include converter)
LBS 487+487 487+650 650+650
Gross weight
(Not include converter)
LBS 514+514 514+683 683+683

GREE Photovoltaic Direct-driven Inverter Multi VRF Units
11
Outdoor Units_Heat Pump －18Ton 20Ton 22Ton
Model －GMV-Y216WM/C-F(U) GMV-Y240WM/C-F(U) GMV-Y264WM/C-F(U)
Module (combinated) －GMV-Y96WM/C-
F(U)+
GMV-Y120WM/C-F(U)
GMV-Y120WM/C-
F(U)+
GMV-Y120WM/C-F(U)
GMV-Y72WM/C-
F(U)+
GMV-Y96WM/C-
F(U)+
GMV-Y96WM/C-F(U)
Cooling capacity Btu/h 216000 240000 264000
Heating capacity Btu/h 243000 270000 297000
Air volume CFM 8240+8240 8240+8240 6710+8240+8240
Max. external static pressure Pa 82 82 82
Power － 208/240V 3~ 60Hz 208/240V 3~ 60Hz 208/240V 3~ 60Hz
Input power for cooling kW 7.30+10.00 10.00+10.00 5.45+7.30+7.30
Input power for heating kW 7.85+10.50 10.50+10.50 5.80+7.85+7.85
Input current for cooling A 20.37+26.27 26.27+26.27 16.42+20.37+20.37
Input current for heating A 23.50+27.87 27.87+27.87 17.29+23.50+23.50
MOP A
208V:45+45
240V:40+40
208V:45+45
240V:40+40
208V:45+45+45
240V;40+40+40
MCA A
208V:43.6+44.8
240V:37.3+39.8
208V:44.8+44.8
240V:39.8+39.8
208V:35.3+43.6+43.6
240V:30.3+37.3+37.3
Refrigeration oil no. of
compressor
－FVC68D or FV68H FVC68D or FV68H FVC68D or FV68H
Ambient temperature range
for cooling
℉23~125.6 23~125.6 23~125.6
Ambient temperature range of
heating
℉-4~75.2 -4~75.2 -4~75.2
Refrigerant type －R410A R410A R410A
Charging volume of
refrigerant
oz 398.6+416.2 416.2+416.2 229.3+398.6+398.6
Max. quantity of connected
indoor unit
unit 36 39 46
Size of gas pipe in. Φ1-1/8 Φ1-3/8 Φ1-3/8
Size of liquid pipe in. Φ5/8 Φ5/8 Φ3/4
Size of oil-balanced pipe in. Φ3/8 Φ3/8 Φ3/8
Outline dimension(WxDxH) in. (52-3/4x30-1/8x63-1/4)
x2
(52-3/4x30-1/8x63-1/4)
x2
(36-5/8x30-1/8x63-1/4)
+(52-3/4x30-1/8x63-1/4)x2
Net weight
(Not include converter)
LBS 650+650 650+650 487+650+650
Gross weight
(Not include converter)
LBS 683+683 683+683 514+683+683

GREE Photovoltaic Direct-driven Inverter Multi VRF Units
12
Outdoor Units_Heat
Pump
－24Ton 26Ton 28Ton 30Ton
Model －
GMV
-Y288WM/C-F(U) GMV-Y312WM/C-
F(U)
GMV-Y336WM/C-
F(U)
GMV-Y360WM/C-F(U)
Module (combinated) －
GMV-Y96WM/C-F(U)
+ GMV-Y96WM/C-F(U)
+GMV-Y96WM/C-F(U)
GMV-Y96WM/C-F(U)
+GMV-Y96WM/C-F(U)
+GMV-Y120WM/C-F(U)
GMV-Y96WM/C-F(U)
+GMV-Y120WM/C-F(U)
+GMV-Y120WM/C-F(U)
GMV-Y120WM/C-F(U)
+GMV-Y120WM/C-F(U)
+GMV-Y120WM/C-F(U)
Cooling capacity Btu/h 288000 312000 336000 360000
Heating capacity Btu/h 324000 351000 378000 405000
Air volume CFM 8240+8240+8240 8240+8240+8240 8240+8240+8240 8240+8240+8240
Max. external static
pressure
Pa 82 82 82 82
Power － 208/240V 3~ 60Hz 208/240V 3~ 60Hz 208/240V 3~ 60Hz 208/240V 3~ 60Hz
Input power for cooling kW 7.30+7.30+7.30 7.30+7.30+10.00 7.30+10.00+10.00 10.00+10.00+10.00
Input power for heating kW 7.85+7.85+7.85 7.85+7.85+10.50 7.85+10.50+10.50 10.50+10.50+10.50
Input current for
cooling
A 20.37+20.37+20.37 20.37+20.37+26.27 20.37+26.27+26.27 26.27+26.27+26.27
Input current for heating
A 23.50+23.50+23.50 23.50+23.50+27.87 23.50+27.87+27.87 27.87+27.87+27.87
MOP A 208V:45+45+45
240V:40+40+40
208V:45+45+45
240V:40+40+40
208V:45+45+45
240V:40+40+40
208V:45+45+45
240V:40+40+40
MCA A 208V:43.6+43.6+43.6
240V:37.3+37.3+37.3
208V:43.6+43.6+44.8
240V:37.3+37.3+39.8
208V:43.6+44.8+44.8
240V:37.3+39.8+39.8
208V:44.8+44.8+44.8
240V:39.8+39.8+39.8
Refrigeration oil no. of
compressor
－FVC68D or FV68H FVC68D or FV68H FVC68D or FV68H FVC68D or FV68H
Ambient temperature
range for cooling
℉23~125.6 23~125.6 23~125.6 23~125.6
Ambient temperature
range of heating
℉-4~75.2 -4~75.2 -4~75.2 -4~75.2
Refrigerant type －R410A R410A R410A R410A
Charging volume of
refrigerant
oz 398.6+398.6+398.6 398.6+398.6+416.2 398.6+416.2+416.2 416.2+416.2+416.2
Max. quantity of
connected indoor unit
unit 50 53 56 59
Size of gas pipe in. Φ1-3/8 Φ1-3/8 Φ1-3/8 Φ1-5/8
Size of liquid pipe in. Φ3/4 Φ3/4 Φ3/4 Φ3/4
Size of oil
-
balanced pipe
in. Φ3/8 Φ3/8 Φ3/8 Φ3/8
Outline
dimension(WxDxH)
in. (52-3/4x30-1/8x63-1/4)
x3
(52-3/4x30-1/8x63-1/4)
x3
(52-3/4x30-1/8x63-1/4)
x3
(52-3/4x30-1/8x63-1/4)
x3
Packing size(WxDxH) in. / / / /
Net weight LBS 650+650+650 650+650+650 650+650+650 650+650+650
Gross weight LBS 683+683+683 683+683+683 683+683+683 683+683+683
No matter how many outdoor units there are, the total rated capacity of indoor units must not
exceed 135% of the total rated capacity of outdoor units. Stable and safe operation can only be
guaranteed in a range of 50%~135%.

GREE Photovoltaic Direct-driven Inverter Multi VRF Units
13
4.2 Basic Parameter of Photovoltaic Parts and Components
4.2.1 Photovoltaic modules
Type of battery Monocristalline PV
module
Monocristalline PV module
Monocristalline PV
module
Quantity of battery
60
60
60
Peak power (Wp)
285
290
295
Peak voltage (V)
31.47
31.66
31.86
Peak current (A)
9.06
9.16
9.26
Open-circuit voltage (V)
38.23
38.45
38.67
Short-circuit current (A)
9.50 9.61 9.72
Efficiency of component (%)
17.33 17.64 17.94
Temperature coefficient of peak power
(%/℃) -0.410
Temperature coefficient of open-circuit
voltage (%/℃) -0.330
Temperature coefficient of short-circuit
current (%/
℃
)
0.059
Temperature coefficient of peak power and
voltage (%/℃)-0.323
Dimension (mm)
1658×992×22
Weight (kg)
23.3
4.2.2 Current converting unit
G-IEMS
Intelligent Converter
GIE-ADC12K5E
Max. PV Input Voltage(OC)
1000VDC
Isc PV
39A
Max. continuous input current
2*14A
Max. PV Input Power
14kW
MPPT Range
400V—780V
Max. DC continuous output current
25A
Rated DC output Current
25A
DC output Voltage
400V—780V
Rated AC Voltage
208 / 240Vac 3~ + PE
Rated Frequency
60Hz
Rated AC Power
12.5kW
Rated AC Current
35A*3 / 30A*3
Power factor
-0.8~0.8
Ambient Temperature -20℃—50℃
Ingress Protection
TYPE 3
Certifications
UL 1741
IEEE 1547
Note: The product can work in different modes by configuring Grid voltage.
Manufacturer: GREE Energetic & Environmental Technologies Co., Ltd. of
Zhuhai
Made in China

GREE Photovoltaic Direct-driven Inverter Multi VRF Units
14
5 ELECTRICAL PARAMETERS
Outdoor Unit (208V)
Outdoor units Power Supply Fuse Capacity
Minimum Circuit
Ampacity
Maximum Overcurrent
Protection
V/ Ph /Hz A A A
GMV-Y72WM/C-F(U) 208V 3~ 60Hz 45 35.3 45
GMV-Y96WM/C-F(U) 208V 3~ 60Hz 45 43.6 45
GMV-Y120WM/C-F(U)
208V 3~ 60Hz 45 44.8 45
GMV-Y144WM/C-F(U)
208V 3~ 60Hz 45+45 35.3+35.3 45+45
GMV-Y168WM/C-F(U)
208V 3~ 60Hz 45+45 35.3+43.6 45+45
GMV-Y192WM/C-F(U) 208V 3~ 60Hz 45+45 43.6+43.6 45+45
GMV-Y216WM/C-F(U) 208V 3~ 60Hz 45+45 43.6+44.8 45+45
GMV-Y240WM/C-F(U)
208V 3~ 60Hz 45+45 44.8+44.8 45+45
GMV-Y264WM/C-F(U)
208V 3~ 60Hz 45+45+45 35.3+43.6+43.6 45+45+45
GMV-Y288WM/C-F(U)
208V 3~ 60Hz 45+45+45 43.6+43.6+43.6 45+45+45
GMV-Y312WM/C-F(U)
208V 3~ 60Hz 45+45+45 43.6+43.6+44.8 45+45+45
GMV-Y336WM/C-F(U) 208V 3~ 60Hz 45+45+45 43.6+44.8+44.8 45+45+45
GMV-Y360WM/C-F(U) 208V 3~ 60Hz 45+45+45 44.8+44.8+44.8 45+45+45
Outdoor Unit (240V)
Outdoor units Power Supply Fuse Capacity
Minimum Circuit
Ampacity
Maximum Overcurrent
Protection
V/ Ph /Hz A A A
GMV-Y72WM/C-F(U) 240V 3~ 60Hz 40 30.3 40
GMV-Y96WM/C-F(U) 240V 3~ 60Hz 40 37.3 40
GMV-Y120WM/C-F(U)
240V 3~ 60Hz 40 39.8 40
GMV-Y144WM/C-F(U) 240V 3~ 60Hz 40+40 30.3+30.3 40+40
GMV-Y168WM/C-F(U)
240V 3~ 60Hz 40+40 30.3+37.3 40+40
GMV-Y192WM/C-F(U) 240V 3~ 60Hz 40+40 37.3+37.3 40+40
GMV-Y216WM/C-F(U)
240V 3~ 60Hz 40+40 37.3+39.8 40+40
GMV-Y240WM/C-F(U) 240V 3~ 60Hz 40+40 39.8+39.8 40+40
GMV-Y264WM/C-F(U)
240V 3~ 60Hz 40+40+40 30.3+37.3+37.3 40+40+40
GMV-Y288WM/C-F(U) 240V 3~ 60Hz 40+40+40 37.3+37.3+37.3 40+40+40
GMV-Y312WM/C-F(U)
240V 3~ 60Hz 40+40+40 37.3+37.3+39.8 40+40+40
GMV-Y336WM/C-F(U) 240V 3~ 60Hz 40+40+40 37.3+39.8+39.8 40+40+40
GMV-Y360WM/C-F(U) 240V 3~ 60Hz 40+40+40 39.8+39.8+39.8 40+40+40
Power cable wire gauge and circuit breaker must be selected based on the above parameters
and in compliance with local safety requirements. If there is conflict between above parameters and
national requirements, please contact the manufacture promptly.
If power cable wire gauge and circuit breaker is out of the above design range, fire hazard may
occur.

GREE Photovoltaic Direct-driven Inverter Multi VRF Units
15
6 Circuit Diagram
6.1 Circuit diagram of GMV-Y72WM/C-F(U)

GREE Photovoltaic Direct-driven Inverter Multi VRF Units
16
6.2 Circuit diagram of GMV-Y96WM/C-F(U) and GMV-Y120WM/C-F(U)
NOTICE! This drawing is just for reference; please always refer to the electric wiring stuck to the
unit for actual wiring.
When conducting maintenance based on above circuit diagrams, units must be power-
off. Please
strictly following the circuit diagrams when reconnecting the wires, otherwise, electric shock may occur.
7 UNIT OPERATING TEMPERATURE
Cooling Ambient temperature: -5ºC(23ºF)~52ºC(125.6ºF)
Heating Ambient temperature: -20ºC (-4ºF)~24ºC (75.2ºF)
In the case of a full fresh air conditioning IDU, the unit operating temperature is as follows:
Cooling Ambient temperature: 16ºC(60.8ºF)~45ºC(113ºF)
Heating Ambient temperature: -7ºC (19.4ºF)~16ºC (60.8ºF)

If unit operates out of the above range, it may not work stably and components may even be
damaged.
