GREEN INSTRUMENTS Maritime G6200 User manual

G6200
Water Monitoring
System
User Manual
Document ID number.: 103864
Maritime

Water Monitoring System
User Manual
Page 2of 82 Ver. 1.1 – Revision March 2022
GreenInstrumentsA/S
Erhvervsparken 29
DK-9700 Brønderslev
Denmark
Phone: [phone]
Fax: [phone]
Email: [e-mail]
Web: www.greeninstruments.com
Copyright © 2022 Green Instruments A/S.
All rights reserved. No part of this documentation may be duplicated in
whole or in part or reproduced in any form without the express written
permission of Green Instruments A/S.
This user manual must be read carefully and must be kept for future use
with the system.
For safe and proper use, read and follow all instructions in this manual.
For spare parts, refer to the separate respective spare parts catalogue.
Green Instruments A/S reserves the right to make adjustments and
improvements to its products and systems. This means that documentation
is subject to change without notice.
Green Instruments A/S has taken all measures to ensure the information in
this user manual is accurate and comprehensive. Green Instruments A/S
reserves the right to make corrections and cannot be held liable for any
errors or omissions in this manual.
All claims and inquiries for spares shall be addressed to
GreenInstrumentsA/S or our distributors. In all correspondence or when
ordering spare parts, carefully state the equipment type and serial number,
which can be found on the label on the equipment.
GreenInstrumentsA/S appreciates all feedback and suggestions for
improvement. If you have any questions relating to the user manual or there
are discrepancies in this user manual, contact Green Instruments A/S.
Language: English

Page 3of 82
Content
1. Terms & abbreviations ........................................................................................................... 7
2. Introduction ................................................................................................................................. 8
2.1 About the system ............................................................................................................ 8
2.1.1 PAH......................................................................................................................... 8
2.1.2 Turbidity................................................................................................................ 9
2.1.3 pH & Temperature............................................................................................ 9
2.2 Technical specications............................................................................................... 10
2.3 Storage and handling.................................................................................................... 13
2.3.1 Storage ................................................................................................................. 13
2.3.2 Calibration kit...................................................................................................... 13
2.4 Control of delivery........................................................................................................... 13
3. Safety .............................................................................................................................................. 14
4. Menu structure ......................................................................................................................... 17
4.1 Security and login ........................................................................................................... 20
4.2 Settings ............................................................................................................................... 21
4.3 System settings................................................................................................................ 22
4.4 Alarm action...................................................................................................................... 24
5. Installation.................................................................................................................................... 25
5.1 Mechanical........................................................................................................................ 25
5.1.1 System installation .......................................................................................... 25
5.1.2 Sampling point................................................................................................... 26
5.1.3 Legislation and piping ................................................................................... 26
5.2 Electrical ............................................................................................................................. 27
5.2.1 Electrical documentation.............................................................................. 27
5.2.2 Power .................................................................................................................... 27
5.2.3 Communication................................................................................................. 27
5.3 Commissioning................................................................................................................ 28
5.3.1 Check ethernet settings ................................................................................ 28
5.3.2 Modbus map ...................................................................................................... 28
5.3.3 Web viewer (VNC) ............................................................................................ 30
5.3.4 Remote connection ......................................................................................... 31
5.3.5 Commissioning checklist.............................................................................. 32
Content

Water Monitoring System
User Manual
Page 4of 82 Ver. 1.1 – Revision March 2022
6. Operation....................................................................................................................................... 34
6.1 Sampling............................................................................................................................. 34
6.1.1 Remote operating mode................................................................................ 34
6.1.2 Local operating mode .................................................................................... 34
6.2 Adjustment of reduction and safety valve.............................................................35
6.2.1 Reduction valve ................................................................................................. 35
6.2.2 Safety valve.......................................................................................................... 35
6.3 Adjustment of needle valve ........................................................................................ 36
6.4 Adjustment of ow.......................................................................................................... 36
6.5 pH/temperature electrode .......................................................................................... 36
6.6 Moving average ............................................................................................................... 37
6.7 Alarms & warnings......................................................................................................... 37
6.8 Log & data export ........................................................................................................... 38
6.9 Software update .............................................................................................................. 39
7. Validation & Calibration......................................................................................................... 42
7.1 Introduction ....................................................................................................................... 42
7.2 pH Validation & calibration.......................................................................................... 44
7.3 Turbidity validation & calibration .............................................................................. 48
7.4 PAH validation/calibration .......................................................................................... 52
7.4.1 PAH validation methods................................................................................. 53
7.4.2 PAH sensor ranges.......................................................................................... 53
7.4.3 Before Validation/Calibration....................................................................... 54
7.4.4 PAH validation procedure ............................................................................ 55
7.4.5 PAH calibration procedure .......................................................................... 57
8. Maintenance................................................................................................................................ 59
8.1 Planned maintenance................................................................................................... 59
8.2 General inspection & cleaning routines................................................................ 61
8.2.1 PAH......................................................................................................................... 61
8.2.2 Turbidity................................................................................................................ 61
8.2.3 pH............................................................................................................................ 62
8.3 Lifetime of components ............................................................................................... 62
8.3.1 PAH......................................................................................................................... 62
8.3.2 Turbidity................................................................................................................ 62
8.3.3 pH............................................................................................................................ 63
9. Services.......................................................................................................................................... 64
9.1 Remote connectivity ...................................................................................................... 64
9.2 PAH services ..................................................................................................................... 64
9.3 Turbidity .............................................................................................................................. 65
9.4 pH .......................................................................................................................................... 65
9.5 Return of equipment...................................................................................................... 65

Page 5of 82
10. Troubleshooting ........................................................................................................................ 66
10.1 General troubleshooting .............................................................................................. 66
10.2 PH/Temperature ............................................................................................................. 69
11. System hibernation.................................................................................................................. 72
12. Maintenance instructions .................................................................................................. 73
MI6200-0001..................................................................................................................... 73
MI6200-0002..................................................................................................................... 74
MI6200-0003..................................................................................................................... 75
MI6200-0004..................................................................................................................... 76
MI6200-0005..................................................................................................................... 77
MI6200-0007..................................................................................................................... 78
MI6200-0008..................................................................................................................... 79
MI6200-0009..................................................................................................................... 80
MI6200-0010..................................................................................................................... 81
MI6200-0013..................................................................................................................... 82

Water Monitoring System
User Manual
Page 6of 82 Ver. 1.1 – Revision March 2022
List of Figures
Figure 4.1: HMI home screen layout, menu structure and settings options.......18
Figure 4.2: Trend screen ...........................................................................................................19
Figure 4.3: Alarm screen...........................................................................................................19
Figure 4.4: User access levels................................................................................................20
Figure 4.5: Admin login..............................................................................................................20
Figure 4.6: Settings screen ......................................................................................................21
Figure 4.7: Sensor pop-up........................................................................................................21
Figure 4.8: System settings......................................................................................................22
Figure 4.9: Alarm action............................................................................................................24
Figure 5.1: MODBUS Map........................................................................................................29
Figure 5.2: HMI .............................................................................................................................30
Figure 5.3: Remote connection..............................................................................................31
Figure 6.1: Inlet valve arrangement......................................................................................35
Figure 6.2: pH electrode installation....................................................................................37
Figure 6.3: Alarm screen...........................................................................................................38
Figure 6.4: Software update ....................................................................................................39
Figure 7.1: Main page ................................................................................................................43
Figure 7.2: : Login screen .........................................................................................................43
Figure 7.3: pH Validation/calibration procedure.............................................................44
Figure 7.4: Valves .........................................................................................................................45
Figure 7.5: G6130 pH pop-up menu ....................................................................................46
Figure 7.6: G6130 pH validation menu ..............................................................................46
Figure 7.7: G6130 pH calibration ..........................................................................................47
Figure 7.8: G6120 Turbidity pop-up menu.........................................................................49
Figure 7.9: Turbidity validation................................................................................................49
Figure 7.10: PAH Validation/calibration procedure .......................................................52
Table 7.1: Validation/calibration liquid selection ............................................................54
Table 7.2: Validation tolerance table ....................................................................................55
Figure 7.11: G6111 PAH sensor & PAH calibration chamber ...................................55
Figure 7.12: G6111 PAH pop-up menu...............................................................................56
Figure 7.13: PAH validation......................................................................................................56
Figure 7.14: G6111 PAH sensor & PAH calibration chamber ...................................57
Figure 8.1: Planned maintenance program for the WMS ...........................................60
Figure 10.1: pH negative oset - reading too low...........................................................70
Figure 10.2: pH positive oset – reading too high..........................................................70

Terms & abbreviations
Page 7of 82
1. Terms & abbreviations
The following table lists terms and abbreviations that are used in this user
manual.
When a term is rst used, it will be written out in full and include its
abbreviation for the sake of clarity.
Description Abbreviation
Exhaust Gas Cleaning System EGCS
Marine Environment Protection Committee MEPC
Polycyclic Aromatic Hydrocarbons PAH
Water Monitoring System WMS
Firmware FW
Software SW

Water Monitoring System
User Manual
Page 8of 82 Ver. 1.1 – Revision March 2022
2. Introduction
2.1 About the system
The G6200 water monitoring system is a modular system that continuously
monitors scrubber water. With its robust and durable design, the system
can be used in both open, closed, and hybrid systems and includes a de-
bubbler, which avoids interference due to sample degassing.
Compared to our G6100 version, the G6200 WMS is simpler, with no need
for a pump cabinet unit or a pressure reduction unit. The G6200 WMS only
requires water from scrubber pumps or a free-standing supply pump.
The G6200 WMS has a wide water pressure and ow range, making it
suitable for both the inlet and outlet of the scrubber. The ranges are highly
exible, meaning dierent pumps such as impeller pumps or hose pumps
can be connected to the system. Having a WMS on board is an extremely
eective way of ensuring compliance with international regulations. The
G6200 WMS is fully compliant with MEPC.259(68) & MEPC.340(77).
The system design and choice of materials used are based on more than
one thousand systems installed on various vessel types. The system is easy
to service, includes on-board verication and does not include a costly
sensor servicing program.
2.1.1 PAH
The polycyclic aromatic hydrocarbons module measures the content of
PAH in water as specied by MEPC.259(68) & MEPC. 340(77). The module
uses a UV technique and detects PAH concentration in μg/l (ppb) in water.
A special measuring arrangement ensures a reliable and repeatable
measurement while keeping the need for cleaning at an absolute minimum.
A unique feature is local validation which ensures a reliable measurement of
PAH.
The PAH measurement is compensated for the eects of turbidity by means
of a turbidity compensation formula and input from the turbidity sensor
module G6120.

Introduction
Page 9of 82
2.1. 2 Turbidity
The Turbidity measures the turbidity of water in accordance with
MEPC.259(68) & MEPC.340(77). The module used a 90° IR technique in
accordance with ISO 7027. The Turbidity module can detect soot, particles,
and suspended soil in the water. Special precaution is taken to avoid
interference from dissolved gasses and bubbles and an integrated wiper
keeps optical fouling at a minimum. Certied calibration solutions are used
to perform local calibration.
2.1.3 pH & Temperature
The pH/Temperature measures the pH value and temperature of the water.
Temperature compensation ensures accurate and reliable measurements.
Calibration is simple and fast.
Download product certicates at https://greeninstruments.com/.

Water Monitoring System
User Manual
Page 10 of 82 Ver. 1.1 – Revision March 2022
2.2 Technical specications
G6200 Water Monitoring System
Function Monitoring EGCS discharge water in accordance with IMO
resolution MEPC.259(68) & MEPC.340(77)
Power supply 400-440VAC 50-60 Hz 3 phased
Display 7" TFT LCD color display
External communication ■Standard: Modbus TCP/IP
■Optional: Modbus RTU (RS-485) via converter
To be specied upon order
Sample connections Flange Standard DIN20/JIS3/4" 10K PN10
Sample pressure
Inlet:
With pressure
reduction valve Max 10 bar (g)
Without pressure
reduction valve Max 2.5 bar (g)
Outlet: Max 1.8 bar (g)
Sample temperature 0–50°C
Sample purity Particle size of max. 2 mm
Sample condition The system is designed for maritime SO2 scrubber wash
water containing seawater, polluted seawater, freshwater
with NaOH, residue particles from HFO combustion, and
salts (Na2SO4 etc.).
Chemical capability and material lifetime depend on a
combination of local factors such as temperature, acidity,
oxygen, and oil among others. Therefore, always consult a
chemical compatibility database with reference to each of
the materials.
Wetted materials
(In weighted order)
PVC – PP / PPGF – PC – PET – POM – PVDF – PPS – PE
– PTFE – NBR – EPDM – FKM – PA6T/6I – 316L – AI2O3
– ETFE – Quartz glass – Glass – Epoxy preform (cured) –
polyamide 6.
Max ambient temperature Class A 45°C (Tested to 55°C)
Humidity Class B
Vibration Class A
Emc Class A
Enclosure & material Class B (IP65) AISI 1008 Painted
Dimensions 600 x 1200 x 300 mm
Weight 85 kg

Introduction
Page 11 of 82
Sensor Modules
PAH Module – Type G6111
Compliance Complies with MEPC.259(68) & MEPC.340(77)
Certicates Download at https://greeninstruments.com/
Measurement technology UV induced uorescence
Excitation wavelength: 254 +/-10 nm
Detection wavelength: 360 +/- 50 nm
The PAH measurement is compensated for the eects of
turbidity by means of a turbidity compensation formula and
input from the turbidity sensor module G6120.
Measurement range Low range: 0-100 µg/l phenanthrene equivalence, or
High range: 0-800 µg/l phenanthrene equivalence or
Dual range: 0-100/800 µg/l phenanthrene equivalence
Must be specied in the order.
Power supply Refer to Electrical Drawings
Wetted materials PVC, fused silica glass, AISI 316, PVDF and NBR
Signal RS-232 and Analog 0/4-20 mA (Active)
Accuracy Max. ±5% of sensor range or
Max. ±5% of the nominal standard test concentration,
which value is no less than 80% of the sensor range.
Turbidity Module – Type G6120
Compliance Complies with MEPC.259(68) & MEPC.340(77)
Certicates Download at https://greeninstruments.com/
Measurement technology According to ISO 7027
Measurement range 0-400 NTU
Power supply Refer to Electrical Drawings
Wetted materials Acetal, polycarbonate, PVC, AISI 316, NBR, EPDM,
fused silica glass, polyamide 6, Epoxy preform (cured).
Signal Analog 4-20 mA (Active)
Accuracy Max ± 2 NTU
pH/Temperature Module – Type G6130
Compliance Complies with MEPC.259(68) & MEPC.340(77)
Certicates Download at https://greeninstruments.com/
Measurement technology According to BS EN ISO 60746-1 & BS EN ISO 60746-2:2003
Measurement range 0-14 pH units; 0-50°C

Water Monitoring System
User Manual
Page 12 of 82 Ver. 1.1 – Revision March 2022
Power supply Refer to Electrical Drawings
Wetted materials AISI 316 or PPS, glass, PVDF & PVC
Signals 2 Analog 4-20 mA (Passive)
Accuracy Max. ±0.2 pH unit
Specications are subject to changes without notice.

Introduction
Page 13 of 82
2.3 Storage and handling
2.3.1 Storage
The ambient temperature must be 0-45°C, and the relative humidity must be
20-90% RH.
The pH/Temperature sensor uses an electrode which is stored inside the
system in a separate container to maximize electrode lifetime. The electrode
is packed in a sealed bag and delivered with a safety cap on to ensure the
electrode is kept moist. The electrode will be damaged if it dries out. Refer
to section 6.5 for additional information.
2.3.2 Calibration kit
Calibration solutions come with expiry dates. The calibration kit has an
expiry date of approximately 12 months from the date of delivery. Store
calibration kits at 5-25°C.
Calibration solutions can become damaged at temperatures below 0°C
and temperatures above 25°C may reduce their accuracy and lifetimes.
However, storage temperatures of up to 35°C for calibration liquids are
permitted during transport but only for a period of seven days.
When using the calibration liquids, ensure their temperature is about 20°C
for the highest accuracy.
2.4 Control of delivery
Please check the equipment upon arrival, ensuring that the equipment has
been transported properly.
Check for any damage. If any damage is found immediately make a note on
the delivery document. Remove the packing and check for intrusive water or
signs of humidity.
Check for missing parts against the packing list. Any discrepancy or damage
should be reported to Green Instruments A/S immediately.

Water Monitoring System
User Manual
Page 14 of 82 Ver. 1.1 – Revision March 2022
3. Safety
Before operating the system,
read and understand the entire user manual.
WARNING
Failure to follow the instructions can lead to serious injury or death.
Follow the instructions:
■Ensure all power and signal cables connections are correct before
operating the water monitoring system.
■The PAH sensor module and turbidity sensor modules use UV and IR light
that can damage eyes. Do not look directly into the lenses.
■Avoid air in the sampling system to prevent the risk of air locks occurring,
which can trigger a ow alarm.
■Always ensure there is positive suction pressure and keep discharge
pressure as low as possible in order to maximize pump lifetime.
■Do not block a safety valve’s drain or outlet connection, as this will
damage components.
■Check the safety valve to ensure it functions correctly. Follow the planned
maintenance program.
■The system may only be installed in a safe, non-hazardous area. It must
not be used with ammable sample liquids. Non-wetted components such
as enclosures must be kept dry and clean.
WARNING
Use of unqualied, unskilled, and untrained personnel can lead to serious
injury or death.
The installation and operation of this system and associated equipment
must be carried out by skilled, and trained personnel. Green Instruments
A/S bears no responsibility for the operation of the system and associated
equipment. The correct and safe operation of this equipment depends on
proper handling, installation, operation, and maintenance.

Safety
Page 15 of 82
The equipment must only be used as described in this user manual. If the
system is used in any other way not specied by Green Instruments A/S,
equipment safety may become impaired. Green Instruments A/S cannot be
held liable for any resulting damage or injury.
Hazardous voltage
Disconnect power before installing or servicing the equipment. Failure
to disconnect power can result in severe personal injury or damage to
materials. Read the installation instructions carefully to ensure all power and
signal leads have been correctly connected
Ensure that the correct supply voltage is connected to the system.
Circuit breaker
The installation must include a means of isolating electrical power by a
clearly marked external switch or circuit breaker. The external switch or
circuit breaker must be in close proximity to the system and within easy
reach of the operator.
Overload protection
In accordance with the safety requirements in IEC 61010-1 (2010), the
installation must include a means of overcurrent protection to provide
protection against excessive energy being drawn from the system power
supply if the equipment has a fault.
Protective earth
The system must be connected to protective earth.
Installation and fault nding
Risk of electrocution
Electrical installation and system fault nding may only be carried out by a
suitably trained and qualied engineer.
EMC
In accordance with the EMC product standard IEC 60533 (1999),
connection cables for the main power supply and communication signals
must be shielded or have equivalent protection.

Water Monitoring System
User Manual
Page 16 of 82 Ver. 1.1 – Revision March 2022
ATTENTION
Sensors can become damaged. The sensor modules must be connected to
the WMS before powering up otherwise they can become avoid damaged.
When the system is powered on, the connection to the sensor modules
must not be disconnected. If a sensor is to be connected or disconnected,
switch o the power rst. The equipment must not be exposed to strong
mechanical shocks.
ATTENTION
Pressurized system. Never shut-o the pipeline to or from the system when
the system is operating, as this may damage components.
De-pressurize the system before removing any wetted components.
WARNING
Harmful components: poisoning and chemical burns hazard.
The water can contain poisonous components that are potential
harmful to humans and animals. Some calibration solutions contain high
concentrations of harmful components. There is a risk of chemical burns.
Wear personal protective equipment whenever there is a risk of coming into
contact with the water or calibration liquids.
Recycling
Do not dispose of the equipment with normal waste. Disposal must be
carried out in accordance with the requirements of the applicable statutory
regulations.
Symbol identication!
General warning sign Protective earth
Electric shock hazard
The CE mark indicates the
product meets EU safety,
health and environmental
protection requirements
Chemical hazard Hot surface hazard

Menu structure
Page 17 of 82
4.Menu structure
The WMS HMI home screen layout, menu structure and dierent user
options are shown in Figure 4.1. Figure 4.2 shows the trend screen and
Figure 4.3 shows the alarm screen.
The illustrations use yellow lines and yellow boxes to show the relationships
between screens and dierent user options, and to explain button functions.
HMI settings and system settings page are explained in detail in section 4.2
and 4.3.

Water Monitoring System
User Manual
Page 18 of 82 Ver. 1.1 – Revision March 2022
Figure 4.1: HMI home screen layout, menu structure and settings options

Menu structure
Page 19 of 82
Figure 4.2: Trend screen
Figure 4.3: Alarm screen

Water Monitoring System
User Manual
Page 20 of 82 Ver. 1.1 – Revision March 2022
4.1 Security and login
The WMS is equipped with three user access levels.
Level Access Username Password
1Standard access on power up guest -
2Service access service 1234
3Admin access admin Generated one-
time password
Figure 4.4: User access levels
Level 1 – Guest
The user can view trends, active alarms, alarm history, activate start/stop
and local/remote functions.
Level 2 – Service
Only for trained personnel.
The user can access system settings, calibration, validation and moving
average functions.
Level 3 – Admin
ATTENTION
The following may only carried out in collaboration with Green Instruments.
The user can change calibration set-points, sensor communication, sensor
setup and sensor signal scaling.
To access this level, the user must contact Green Instruments with the
information shown on the login screen. Green instruments can then
generate a one-time password that will be active for 30 minutes after login.
Figure 4.5: Admin login
