GreenWorks Pro ULTRAPOWER 60V LB602 User manual

LB602/LB6025/LB603/
LB604/LB605/LB606
EN OPERATOR MANUAL
FR MANUEL D’OPÉRATEUR
BATTERY
BATTERIE
ES MANUAL DEL OPERADORBATERÍA
www.greenworkstools.com

1 Important Safety Instructions..........2
2 Safety notes and precautions............2
3 Symbols on the product.................... 2
4 Risk levels...........................................2
5 Proposition 65.................................... 3
6 Environmentally safe battery
disposal............................................... 3
7 Operation........................................... 3
7.1 Check battery capacity.......................................3
8 Technical data.................................... 4
9 Limited warranty.............................. 5
1
English EN

1 IMPORTANT SAFETY
INSTRUCTIONS
For the proper use, maintenance and storage of this battery, it
is crucially important that you read and understand the
instructions given in this manual.
To avoid serious injury, risk of fire, explosion and danger of
electric shock or electrocution:
• If the battery pack case is cracked or damaged, DO NOT
insert into the charger. Replace with a new battery pack.
• Charge the battery pack only with the recommended
charger.
• DO NOT try to short circuit any terminals of battery
pack.
WARNING
If the battery fluid gets in your eyes, flush immediately with
clean water for at least 15 minutes. Get immediate medical
attention. Do not charge the battery pack in rain or in wet
conditions. Do not immerse the tool, battery pack, or
charger in water or other liquid.
• Do not allow the battery pack or charger to overheat. If
they are warm, allow them to cool down. Recharge only
at room temperature.
• Do not place the battery pack in the sun or in a warm
environment. Keep at normal room temperature.
• Keep in shady, cool and dry condition, if the battery is not
charged for a long time; charge the battery for 2 hours
every 2 months.
• The battery pack cells may develop a small leak under
extreme usage or temperature conditions. If the outer seal
is broken and the leakage gets on your skin:
- Use soap and water to wash immediately.
- Neutralize with lemon juice, vinegar, or other mild
acid.
• If leakage gets in your eyes, follow instructions above
and seek medical attention.
• Please check prior use, if output voltage and current of
the battery charger is suitable for the charging battery
pack.
• During transporting, the battery pack needs protective
packaging.
• Handle with care.
• Keep away from humidity and fire.
2 SAFETY NOTES AND
PRECAUTIONS
• Do not disassemble the battery.
• Keep away from the children.
• Do not expose the battery to water or salt water, battery
should be stored in a cool and dry location and should
place the battery in cool and dry environment.
• Do not place the battery in high-temperature locations,
such as near a fire, heater, etc.
• Do not reverse the positive terminal and the negative
terminal of the battery.
• Do not connect the positive terminal and the negative
terminal of the battery to each other with any metal
objects.
• Do not knock, strike or step on the battery.
• Do not solder directly onto the battery and pierce the
battery with nails or other edge tools.
• In the event that the battery leaks and the fluid gets into
one’s eye, do not rub the eye. Rinse well with water.
• Immediately discontinue use of the battery, if, while using
the battery emits an unusual smell, feels hot, changes
color, changes shape, or appears abnormal in any other
way.
3 SYMBOLS ON THE PRODUCT
Some of the following symbols may be used on this tool.
Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the
tool better and safer.
Symbol Explanation
V Voltage
W Power
Direct current
Read all safety warnings and all instruc-
tions.
Precautions that involve your safety.
4 RISK LEVELS
The following signal words and meanings are intended to
explain the levels of risk associated with this product.
SYM-
BOL
SIGNAL MEANING
DANGER Indicates an imminently haz-
ardous situation,which, if not
avoided, will result in death
or serious injury.
WARNING Indicates a potentially hazard-
ous situation,which, if not
avoided, could result in death
or serious injury.
CAUTION Indicates a potentially hazard-
ous situation, which, if not
avoided, may result in minor
or moderate injury.
2
English
EN

SYM-
BOL
SIGNAL MEANING
CAUTION (Without Safety Alert Sym-
bol) Indicates a situation that
may result in property dam-
age.
5 PROPOSITION 65
WARNING
This product contains a chemical known to the state of
California to cause cancer, birth defects or other
reproductive harm. Some dust created by power sanding,
sawing, grinding, drilling, and other construction activities
contains chemicals known to cause cancer, birth defects or
other reproductive harm. Some examples of these chemicals
are:
• Lead from lead-based paints;
• Crystalline silica from bricks and cement and other
masonry products;
• Arsenic and chromium from chemically treated lumber.
Your risk of exposure to these chemicals varies depending
on how often you do this type of work. To reduce your
exposure to these chemicals, work in a well-ventilated area,
and work with approved safety equipment, such as dust
masks that are specially designed to filter out microscopic
particles.
6 ENVIRONMENTALLY SAFE
BATTERY DISPOSAL
WARNING
If the battery pack cracks or breaks, with or without leaks,
do not recharge it and do not use. Dispose of the battery and
replace with a new battery pack. DO NOT ATTEMPT TO
REPAIR IT! To avoid injury and risk of fire, explosion, or
electric shock, and to avoid damage to the environment:
• Cover the battery’s terminals with heavy-duty adhesive
tape.
• DO NOT attempt to remove or destroy any of the
battery pack components.
• DO NOT attempt to open the battery pack.
• If a leak develops, the released electrolytes are
corrosive and toxic. DO NOT get the solution in the
eyes or on skin, and do not swallow it.
• DO NOT place these batteries in your regular
household trash.
• DO NOT incinerate.
• DO NOT place them where they will become part of
any waste landfill or municipal solid waste stream.
• Take them to a certified recycling or disposal centre.
7 OPERATION
7.1 CHECK BATTERY CAPACITY
Press the battery capacity indicator (BCI) button. The lights
will illuminate according to the batteries capacity level. See
chart below:
2
1
Lights Capacity
4 Green Lights The battery is above 80% capacity
3 Green Lights The battery is between 80% and 60%
capacity.
2 Green Lights The battery is between 60% and 40%
capacity.
1 Green Light The battery is between 40% and 20%
capacity.
1 Blinking Green
Light
The battery is between 20% and 10%
capacity.
Lights go out The battery is less than 10% capacity
and requires charging immediately.
* 1. BATTERY CAPACITY INDICATOR (BCI) BUTTON
2. LIGHT METRE
3
English EN

This lithium-ion battery packs are designed with features that
protect the lithium-ion cells and maximize battery life.
If the tool stops during use, release the trigger to reset and
resume operation. If the tool still does not work, the battery
needs to be recharged.
COLD WEATHER OPERATION
The lithium-ion battery pack can be used in temperatures
down to -14°C (6.8°F). Put the battery pack on a tool and use
the tool in a light duty application. After about a minute, the
pack will warm up and begin operating normally.
8 TECHNICAL DATA
Model LB602
Battery 54 V 2Ah, 108Wh, 60V Max
Voltage per
cell
3.6 V
Cell number 15
Charge time 30min. (1 Battery) (use
60DPC10A
Charger)
30min. (2 Batteries)
30min. (1 Battery) (use
CH60DP01
Charger)
40min. (2 Batteries)
20min. (use CH60R00 Charger)
40min. (use CAC801 Charger)
Model LB6025
Battery 54 V 2.5Ah, 135Wh, 60V Max
Voltage per
cell
3.6 V
Cell number 15
Charge time 37.5min. (1 Battery) (use
60DPC10A
Charger)
37.5min. (2 Batteries)
37.5min. (1 Battery) (use
CH60DP01
Charger)
50min. (2 Batteries)
25min. (use CH60R00 Charger)
50min. (use CAC801 Charger)
Model LB603
Battery 54 V 3Ah, 162Wh, 60V Max
Voltage per
cell
3.6 V
Cell number 15
Charge time 45min. (1 Battery) (use
60DPC10A
Charger)
45min. (2 Batteries)
45min. (1 Battery) (use
CH60DP01
Charger)
60min. (2 Batteries)
30min. (use CH60R00 Charger)
60min. (use CAC801 Charger)
Model LB604
Battery 54 V 4Ah, 216Wh, 60V Max
Voltage per
cell
3.6 V
Cell number 30
Charge time 40min. (1 Battery) (use
60DPC10A
Charger)
48min. (2 Batteries)
40min. (1 Battery) (use
CH60DP01
Charger)
80min. (2 Batteries)
40min. (use CH60R00 Charger)
24min. (use CAC801 Charger)
Model LB605
Battery 54 V 5Ah, 270Wh, 60V Max
Voltage per
cell
3.6 V
Cell number 30
Charge time 50min. (1 Battery) (use
60DPC10A
Charger)
60min. (2 Batteries)
50min. (1 Battery) (use
CH60DP01
Charger)
100min. (2 Batteries)
50min. (use CH60R00 Charger)
100min. (use CAC801 Charger)
Model LB606
Battery 54 V 6Ah, 324Wh, 60V Max
Voltage per
cell
3.6 V
Cell number 30
4
English
EN
BATTERY PROTECTION FEATURES

Charge time 60min. (1 Battery) (use
60DPC10A
Charger)
72min. (2 Batteries)
60min. (1 Battery) (use
CH60DP01
Charger)
120min. (2 Batteries)
60min. (use CH60R00 Charger)
120min. (use CAC801 Charger)
9 LIMITED WARRANTY
M
E
I
L
L
E
U
R
D
A
N
S
S
A
C
A
T
É
G
O
R
I
E
•
M
E
J
O
R
E
N
C
L
A
S
E
B
E
S
T
I
N
C
L
A
S
S
GARANTIE OUTIL &
BATTERIE • GARANTÍA PARA
HERRAMIENTAS Y BATERÍAS
Greenworks hereby warranties this product, to the original
purchaser with proof of purchase, for a period of four (4)
years against defects in materials, parts or workmanship.
Greenworks, at its own discretion will repair or replace any
and all parts found to be defective, through normal use, free
of charge to the customer. This warranty is valid only for
units which have been used for personal use that have not
been hired or rented for industrial/commercial use, and that
have been maintained in accordance with the instructions in
the owners’ manual supplied with the product from new.
ITEMS NOT COVERED BY WARRANTY:
1. Any part that has become inoperative due to misuse,
commercial use, abuse, neglect, accident, improper
maintenance, or alteration; or
2. The unit, if it has not been operated and/or maintained in
accordance with the owner's manual; or
3. Normal wear, except as noted below;
4. Routine maintenance items such as lubricants, blade
sharpening;
5. Normal deterioration of the exterior finish due to use or
exposure.
HELPLINE:
Warranty service is available by calling our toll-free helpline,
at 1-855-345-3934.
TRANSPORTATION CHARGES:
Transportation charges for the movement of any power
equipment unit or attachment are the responsibility of the
purchaser. It is the purchaser’s responsibility to pay
transportation charges for any part submitted for replacement
under this warranty unless such return is requested in writing
by Greenworks.
USA address: Canadian address:
Greenworks Tools Greenworks Tools Canada Inc.
P.O. Box 1238 P.O. Box 93095, Newmarket,
Ontario
Mooresville, NC 28115 L3Y 8K3
5
English EN
