GreenWorks 1600002 User manual

7.2V Cordless Grass Shear/Shrub
Read all safety rules and instructions carefully before operating this tool.
Owner’s Manual
TOLL-FREE HELPLINE: 1-888-90WORKS (888.909.6757)
www.GreenWorksTools.com
1600002

2
CONTENTS
Contents .............................................................................................................................. 2
Product Specications ........................................................................................................ 2
Important Safety Instructions............................................................................................... 3
Symbols............................................................................................................................... 7
Know Your Grass Shear/Shrub ............................................................................................ 9
Assembly ........................................................................................................................... 10
Operation........................................................................................................................... 12
Maintenance........................................................................................................................... 13
Troubleshooting..................................................................................................................17
Warranty..................................................................................................................................18
Exploded View and Part List.................................................................................................19
PRODUCT SPECIFICATIONS
7.2V CORDLESS GRASS SHEAR/SHRUB
Motor ............................................................................................................................. 7.2 V
No load speed .................................................................................................1100rpm±10%
Max. Weight .........................................................................................................1.5 lbs (0.7 kg)
Grass shear blade length ....................................................................................3.0 in. (7.6 cm)
Grass shear blade cutting capacity ....................................................................1.0 in. (2.4 cm)
Shrub shear blade length .....................................................................................4.0 in. (10 cm)
Shrub shear blade cutting capacity ..................................................................0.3 in. (0.8cm)
Charger .................................................................................................YLS0121A-T095050
Charge-time .................................................................................................................< 4.5 hrs
4
YEAR/AÑO
TOOL WARRANTY
GARANTÍA DE
INSTRUMENTO

3
IMPORTANT SAFETY INSTRUCTIONS
WARNING
Read and understand all instructions before using this product. Failure to follow all
instructions listed below may result in electric shock, fire, and/or serious personal injury.
Save all warnings and instructions for future reference. The term “power tool” in the warnings
refers to your mainsoperated (corded) power tool or battery-operated (cordless) power tool.
WORK AREA SAFETY
•Keep work area clean and well lit. Cluttered or dark areas invite accidents.
•Do not operate power tools in explosive atmospheres, such as in the presence of
ammableliquids,gasesordust. Power tools create sparks which may ignite the dust or
fumes.
•Keep children and bystanders away while operating a power tool. Distractions greatly
increase the risk of injury.
ELECTRICAL SAFETY
•Power tool plugs must match the outlet. Ensure that the Power Tool plug matches
theoutletbeforeuse.Donotusethisproductwithanyadaptersormodiedplugs.
Unmodied plugs and matching outlets will reduce risk of electric shock.
•Avoid body contact with grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is grounded.
•Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
•Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the
risk of electric shock.
•When operating a power tool outdoors, use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
PERSONAL SAFETY
•Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the influence of drugs,
alcohol or medication. A moment of inattention while operating power tools may result in
serious personal injury.
•Usepersonalprotectiveequipment.Alwaysweareyeprotection. Protective equipment
such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
•Prevent unintentional starting. Ensure the switch is in the off-position before
connecting the tool to a power source and/or battery pack before picking up or
carrying the tool. Carrying power tools with your nger on the switch or energising power
tools that have the switch on invites accidents.

4
IMPORTANT SAFETY INSTRUCTIONS
•Remove any adjusting key or wrench before turning the power tool on. A wrench or a
key left attached to a rotating part of the power tool may result in personal injury.
•Keep proper footing and balance at all times. This enables better control of the power tool
in unexpected situations.
•Dress appropriately, do not wear loose clothing or jewellery. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in
moving parts.
POWER TOOL USE AND CARE
•Use the correct power tool for your application. The correct power tool will do the job
better and safer at the rate for which it was designed.
•Do not use the power tool if the on and off switch is malfunctioning. Any power tool that
cannot be controlled with the on and off switch is dangerous and must be repaired.
•Disconnect the power tool from the power source before storing the product or making
any adjustments. Such preventive safety measures reduce the risk of starting the power tool
accidentally.
•Store idle power tools out of the reach of children. Do not allow anyone to operate the
power tool unless they have read the instruction manual. Power tools are dangerous in
the hands of untrained users.
•Check and maintain your power tool before and after every use. Look for binding of
moving parts, misalignment, damage, or any other conditions that may affect the
power tool’s operation. If damaged, have the power tool repaired before use. Many
accidents are caused by poorly maintained power tools.
•Clean and sharpen all cutting tools before and after use. Properly maintained cutting
tools with sharp cutting edges are less likely to bind and are easier to control.
•Do not use power tools or accessories for any purpose outside it’s intended use. Use
of the power tool for operations different from those intended could result in a hazardous
situation.
BATTERY TOOL USE AND CARE
•Rechargeonlywiththechargerspeciedbythemanufacturer.Use of a charger that is
not designed for the battery pack may create a risk of re.
•Keep the charging inlet away from other metal objects such as paper clips, coins,
keys, nails, screws or other small metal objects. These objects may cause the battery
terminal to short which could result in burns or res.
HEDGE TRIMMER SAFETY WARNINGS:
• Keep all body parts away from the cutting blade while the power tool is plugged into the power
source. Make sure the power tool is unplugged from the power source when clearing jammed
material from the blade. A moment of inattention while operating the hedge trimmer may result
in serious personal injury.

5
• Always carry the hedge trimmer by the handle with lock button engaged until the product is
in use. Always install the blade cover when transporting or storing the hedge trimmer. Proper
handling of the hedge trimmer will reduce possible personal injury from the cutter blades.
• Always hold the power tool by the insulated grip handle. This will help protect the user should
the tool come in contact with any live wires. Contact with live wires may make exposed metal
parts of the tool live which could injure the operator.
• Keep any cords or extension cords away from the cutting blade. Contact cords or cables may
damage the tool and increase the risk of injury for the operator.
• Check the hedge for foreign objects before use.
WARNING
The blades continue to move for a few seconds after the garden product is switched off.
W A R N I N G (PROPOSITION 65)
Some dust created by power sanding, sawing, grinding, drilling, and other construction activities
contains chemicals known to cause cancer, birth defects or other reproductive harm. Some
examples of these chemicals are:
• Lead from lead-based paints
• Crystalline silica from bricks and cement and other masonry products, and
• Arsenic and chromium from chemically treated lumber.
Your risk of exposure to these chemicals varies depending on how often you do this type of
work. To reduce your exposure to these chemicals, work in a well-ventilated area, and work with
approved safety equipment, such as dust masks that are specially designed to lter out microscopic
particles.
IMPORTANT SAFETY INSTRUCTIONS

6
IMPORTANT SAFETY INSTRUCTIONS
BATTERY CHARGERS
WARNING
Keep the battery charger away from rain or moisture. Penetration of water in the battery charger
increases the risk if an electric shock.
• Keep Children and bystanders at a safe distance from the work area while the tool is being
used.
• The charger is designed for use from a standard household electrical supply. Do not attempt
to connect the charger to a supply with a different voltage.
• Do not charge other batteries. The battery charger is suitable only for the cordless shrub/
grass shear. Use of the charger with other products may result in re and explosion.
• Do not charge non-rechargeable batteries. There is danger of explosion.
• To reduce the risk of an electric shock, unplug the charger from the power supply before
attempting to clean it. Removing the output terminal alone does not reduce the risk.
• Pull on the charger to disconnect it from the power source. Do not pull on the lead.
• Keep the battery charger clean. Contamination can lead to danger of an electric shock.
• Before each use, check the battery charger. If damage is detected, do not use the battery
charger. Never open the battery charger yourself. Have repairs performed only by a qualied
technician and only using original spare parts. Damaged battery chargers, cables and plugs
increase the risk of an electric shock.
• Do not operate the battery charger on or near ammable products such as paper, textiles, etc.
• The heating of the battery charger during the charging process can pose a re hazard.

7
Some of the following symbols may be used on this product. Please study them and learn their
meaning. Proper interpretation of these symbols will allow you to operate the product effectively and
safely.
SYMBOL DESIGNATION/EXPLANATION
WARNING: To reduce the risk of injury, user must read instruction
manual
Wear eye and ear protection at all times while operation the machine.
Wear safety gloves at all times while operating the machine.
Do not expose to moisture or rain.
Blade continues to run after the motor is switched off.
Warning: Keep bystanders away.
Only use the battery charger indoors.
SYMBOLS

The following signal words and meanings are intended to explain the levels of risk associated
with this product.
DANGER Indicates an imminently hazardous situation, which, if not
avoided, will result in death or serious injury.
WARNING Indicates a potentially hazardous situation, which, if not avoided,
could result in death or serious injury.
CAUTION Indicates a potentially hazardous situation, which, if not avoided,
may result in minor or moderate injury.
CAUTION (Without Safety Alert Symbol) Indicates a situation that may
result in property damage.
SYMBOLS
SAVE THESE INSTRUCTIONS
8
SYMBOL SIGNAL MEANING

9
KNOW YOUR CORDLESS GRASS SHEAR/SHRUB
KNOW YOUR CORDLESS GRASS SHEAR/SHRUB (See Figure 1.)
The safe use of this product requires an understanding of the information on the product and in
this operator’s manual as well as a knowledge of the project you are attempting. Before use of this
product, familiarize yourself with all operating features and safety rules.
Fig. 1
BATTERY CHARGER
HANDLE
BATTERY CHARGE-
LED INDICATOR
GRASS SHEAR BLADE
COVER
ON/OFF SWITCH
LOCK-OUT BUTTON
PLUG CONNECTOR
FOR CHARGER
SOCKET FOR
CHARGE PLUG

10
ASSEMBLY
WARNING
When parts are missing or damaged, please contact your dealer.
PACKING LIST
Carefully remove the garden product from its packaging and check if the following parts are
complete:
1. Main machine
2. Battery charger
3. Grass shear blade and cover
4. Shrub shear blade and cover
INTENDED USE
The garden product is intended for light trimming of shrubs and lawn edges in domestics use.
This product has many features for making its use more pleasant and enjoyable.
Safety, performance, and dependability have been given top priority in the design of this
product making it easy to maintain and operate.
UNPACKING
This product has been shipped completely assembled.
• Carefully remove the product and any accessories from the box. Make sure that all items
listed in the packing list are included.
• Inspect the tool carefully to make sure no breakage or damage occurred during shipping.
• Do not discard the packing material until you have carefully inspected and satisfactorily
operated the tool.
• If any parts are damaged or missing, please call 1-888- 909-6757 for assistance.
21
3
4
Fig. 2

ASSEMBLY
11
BATTERY CHARGING
• Do not use any other battery chargers other than the one provided to charge this tool.
Charging the tool with a non manufacturer specied charger may result in re or explosion.
• Ensure that the plug matches the outlet before use.
• The voltage range of the charger is 100-240V. Do not use this product with any outlets that do
not meet the minimum voltage requirements or exceed them.
Note: the battery is supplied partially charged. To ensure full capacity of the battery, completely
charge the battery in the battery charger before using your power tool for the rst time.
CHARGING PROCEDURE (LED INDICATOR)
LED STATUS DESCRIPTION
Solid Red Battery is charging.
Solid Green Fully charged
Green light goes out once then the red light
blinks twice. Low voltage
Green light goes out once then the red light
blinks three times.
Over current
Solid Green Normal
WARNING
Do not continue to press the on/off switch after the garden product has been automatically switched
off. The battery can be damaged.
• Plug the battery charger into a socket outlet and the charger plug into the socket on the rear
side of the handle.
• The charging procedure starts as soon as the charger plug of the battery charger is inserted
into the socket.
• The battery LED indicator indicates the charging progress. The indicator light will ash green
throughout the charging process. The indicator light will stop ashing and become a solid green
when the battery is fully charged.
• During the charging procedure, the handle of the garden product warms up. This is normal.
• Disconnect the power tool from the charger when not using it for longer periods.

12
OPERATION
WARNING
Do not allow familiarity with this product to make you careless. Remember that a careless fraction
of a second is sufcient to inict serious injury.
SWITCHING ON
• Press the lock-off button and squeeze the on/off switch. Once unit turns on release the lock-
off button while continuously holding the on/off switch for operation.
SWITCH OFF
• Release the On/Off switch.
CUTTING GRASS
• Place the tool horizontally over the area you wish to cut. Results are best when the lawn is
dry. Unlock the safety switch, and then depress the ON/OFF switch to cut the grass.
NOTE: To avoid serious personal injury, always turn off the machine before cleaning or when
removing jammed material. Use a soft brush to remove debris from intakes and cutting blade.
Then restart the machine.
TRIMMING HEDGES
• The device may be used to trim small hedges and shrubs. Hold the device in a slight angle
to the hedge you would like to trim. First, trim the lateral areas from the lower to the upper
edges, and then trim the top edge.

13
WARNING
Switch off before adjusting or cleaning. The blade continues to move for a few seconds after the
garden product is switched off.
CAUTION
Do not touch the moving blades.
Note: To ensure long and reliable service, carry out the following maintenance regularly.
Regularly check for obvious defects such as loose xings, and worn or damaged components.
• Ensure that the guard and protective devices are undamaged and properly mounted. Before
using, carry out any necessary maintenance or repairs.
• If the garden product should happen to fail, repairs should always be carried out by an
authorized customer service agent for garden products.
BLADE MAINTENANCE
• Always clean and lubricate the blades with Maintenance Spray after use.
• During longer cutting jobs, we recommend periodically lubricating the cutting blade with
Maintenance Spray.
• Visually check the condition of the blades cutting edges.
• Ensure that the cutting blade is stored with the blade guard supplied when not in use.
CHANGING THE BLADE (see gure 3-6)
WARNING
Always wear protective gloves when using, adjusting or cleaning the garden product.
WARNING
Do not change the blade without blade covers.
MAINTENANCE

14
MAINTENANCE
BLADE REMOVAL (see gure 3-4)
• Lift up the cover release button.
• Slide the cover towards the on/off switch.
• Lift away from the housing.
• Lift the blade out.
BLADE
BLADE FITTING (see gure 5)
• Locate the end of blade under the retaining rib in the rear corner of the housing, press down
the whole blade until aligning the holes in the blade onto the pins.
• When retting the cover ensure all location legs are inside the housing prior to sliding cover
into place.
• Slide the cover back towards the blade to secure.
1
2
ON/OFF
SWITCH
RELEASE BUTTON
COVER
Fig. 3 Fig. 4
Fig. 5

15
STORING SHRUB/GRASS SHEARS
WARNING
Switch off before adjusting or cleaning. The blades continue to move for a few seconds after the
garden product is switched off.
WARNING
Always wear protective gloves when using, adjusting or cleaning the garden product.
• Clean the exterior of the garden product thoroughly using a soft brush and cloth. Do not use
water, solvents or polishes. Remove all debris.
• Store the garden product in a secure, dry place out of the reach of children. Do not place
other objects on top of the garden product.
MAINTENANCE

16
TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
Motor fails to start when switch
trigger is depressed.
Battery is not charged. Charge the battery pack
according to the instructions
included with your model.
Motor runs, but cutting blades
do not move.
Hedger damaged.
Do not use hedge trimmer.
Call for technical service.
Motor hums, blades do not
move.
Debris or other may be
jamming the blades.
Switch off, clear debris
blockage from blades.

17
LIMITED FOUR-YEAR WARRANTY
GREENWORKS™ hereby warranties this product, to the original purchaser with proof of
purchase, for a period of four (4) years against defects in materials, parts or workmanship.
GREENWORKS™, at its own discretion will replace any and all parts found to be defective,
through normal use, free of charge to the customer. This warranty is valid only for units which
have been used for personal use that have not been hired or rented for industrial/commercial
use, and that have been maintained in accordance with the instructions in the owners’ manual
supplied with the product from new.
ITEMS NOT COVERED BY WARRANTY:
1. Any part that has become inoperative due to misuse, commercial use, abuse, neglect,
accident, improper maintenance, or alteration; or
2. The unit, if it has not been operated and/or maintained in accordance with the owner's
manual; or
3. Normal wear, except as noted below;
4. Routine maintenance items such as lubricants, blade sharpening;
5. Normal deterioration of the exterior nish due to use or exposure.
GREENWORKS HELPLINE (1 888 90WORKS):
Warranty service is available by calling our toll-free helpline at 1-888-909-6757
(1-888-90WORKS).
TRANSPORTATION CHARGES:
Transportation charges for the movement of any power equipment unit or attachment are the
responsibility of the purchaser. It is the purchaser’s responsibility to pay transportation charges
for any part submitted for replacement under this warranty unless such return is requested in
writing by GREENWORKS.
4
YEAR/AÑO
TOOL WARRANTY
GARANTÍA DE
INSTRUMENTO

18
EXPLODED VIEW
7

19
PARTS LIST
Item No. Part No. Description QTY
1311081649 Motor assembly 1
231107839 Blade assembly 1
331106839 Blade assembly 1
434128839-1 Gear box cover 1
533306839 Blade cover 1
633307839 Blade cover 1
7365011649 Battery charger 1

TOLL-FREE HELPLINE: 1-888-90WORKS (888.909.6757)
Rev: 00 (11-08-14) Printed in China on 100% Recycled Paper
