10
ASSEMBLY INSTRUCTIONS
PART NAME FIGURE PART NO.
Pressure Washer 1
Upper Handle
1
Spray tip panel assy(spray tip
included) 1
Soap tank 1
Trigger Assembly 1
Spray Wand 1
Gun Holder 1
Turbo Nozzle 1
Spray Tip Cleaning Tool 1
Screw 2
Screw 4
Wheels 2
Washer 2
Axle sleeve 2
Pin 2
Axle 2
Operator’s Manual
1800 PSI 1.1 GPM
ELECTRICPRESSUREWASHER
GPW 1800
Readallsafetyrulesandinstructionscarefullybeforeoperatingthistool.
www.greenworkstools.com
OPERATOR’SMANUAL
TOLL-FREEHELPLINE:1-888-90WORKS
(888.909.6757)
1
Quick Start Guide
Missingparts,accessoriesorneed a service center?
DoNotReturn to Store
Call:1-888-909-6757
www.GreenWorksTools.com
Rev:02
USINGDETERGENT
Putpressurewasherdetergent in detergent tank.
Installblueorblack soap nozzle.
Squeezetriggerandwait approx.1 minute for soap.
SPRAYTIP SPRAYTIPAPPLICATION
0
O
Red-Streamtip (0° )
Thered0degree tip provides a straight line of spray. It provides the highest
amountofpressure.It is best used for removing hard, stuck-on grime or dirt.
25
O
Green-Narrowfan tip (25° )
Thegreenpressurewasher tip provides high versatility with its 25 degree angle tip.
Referredtoasthe washing tip, because it provides adequate pressure to remove
dirtfromsurfaces,but is designed to not damage many surfaces. This pressure
washertipisdesigned for “sweeping” foliage or debris given its wide angle. This tip
isversatiledueto its wide area of cleaning and strong pressure application.
40
O
White-Widefan tip (40° )
Thewhite40degree tip, referredto as the “fan” tip creates the widest area of
cleaningwithrelativelylow pressure. This pressure washer tip is best used for light
ordelicatecleaningapplications. It is recommended for light cleaning on wood
decksandothersoft or delicate surfaces.
SOAP
Black-Soapspray tip
Theblacksoapspray tip, is used for soap application. Soap is applied under low
pressurehighvolumefor optimum performance. Soap cannot be applied under
highpressurewiththis machine.
TurboNozzleTip
Thenozzlerotatesin a zero to 15 degree spray pattern in a circular motion to
breakdowntoughdirt and grime. The spray pattern can cover area of 4 to 8 inches
wide,dependingona distance between the tip and the surface being cleaned.
Connectgardenhoseto pressure
washerwaterintake.
Assemblepressurewashergun to spray wand.
Inserthighpressurehose into trigger
handle.
Turnonwaterat outlet.
Runwaterhosefor 30 seconds with the
motorinOFFposition. This helps drain air
fromthetankand lines.
Connectpowercordto wall outlet
Extensioncordnotrecommended.
TurnonPressureWasher
IMPORTANT:Ensurewateroutletis On
beforeturningpowerOn to avoid damage
tothepump.
NOTE:
AUTOON/OFFSWITCH: This Pressure washer is equipped
withanAuto Start/Stop feature.
Tooperate:Turnthe power switch to the On (I) position.
Pumpwillpressurize and shut down immediately.
Oncethetrigger of the gun is depressed the unit will turn on.
Unitwillshut off and be in standby mode when trigger is
released.
1800PSI / 1.1 GPM
ELECTRICPRESSURE WASHER
GPW1800
ThisQuickStartGuide is not a substitute for reading the operator's manual. Toreduce the risk
ofinjuryordeath, user must read and understand operator's manual before using this product.
WARNING:
Set-up
25
Installingtheupperhandle
Pushandholdthe push-pin buttons on the sides of the upper
handleassembly(1)as you slide the handle onto the frame (2).
Installingthewheels
Inserttheaxlethrough the wheel.
Slidethewasherover the axle pass the pin hole.
Inserttheaxleand wheel through the frame. Slide the washer
overtheaxleand insert the pin through the hole to firmly fasten
thewheelassembly.
Installingthegunholder
Lineupthe screw sleeves with the holes in the upper handle
andpushthrough.
Insertthescrewand turn clockwise with a Phillips head
screwdriver(notincluded)until the screw is tight.
6
9
Connectdesiredpressuretip.
Connectthehighpressure hose to the
wateroutletconnector.
1
3
25
(1)
(2)
S
7
2
4
5
8
Push-pin
30
Axle
Wheel
WasherPin
1
