Grixx GROCHW10WB01 User manual

Grixx User Guide
1
User Guide
GROCHW10WB01

Grixx User Guide
2
Congratulations on your purchase!
Dear Grixx product owner,
Thank you for your trust in Grixx and the purchase of the wireless
charger.
This convenient charger, enables you to charge your smartphone
without connecting with a cable to your device.
As an owner of a Grixx product you are entitled to our warranty,
which is available to you for 2 years after your purchase. For any
questions or problems please contact warran[email protected]. We are
happy to help you and solve any issues.
Happy Times!

Grixx User Guide
3
Content
Welcome 2
About these instructions 4
Intended use 4
Specifications 4
In the box 4
Qi devices 5
How to use 5
Phone cases 5
Cleaning 5
FAQ’s 6
Safety instructions 6
Operating conditions 6
Exclusion of liability 6
Environmental information 7
Disposal 7
Compliance 8
Social Compliance 8
About Grixx 9

Grixx User Guide
4
About these instructions
Read these instructions carefully and please observe and read all references made in these
instructions to guarantee a long life and reliable use of the device. Please keep these instructions
ready to hand and pass them on to other users of the device.
Intended use
This wireless charger is intended exclusively for the power supply of smartphones with an operating
voltage of 5V direct current and are suited for wireless charging. Another use, or one going beyond
this, is deemed as not intended and can lead to damages and injuries.
This product is not intended for commercial use or for medical and special applications, where the
failure of the product can cause injuries, mortalities or considerable material damages.
Claims of any kind due to damages from improper use or non-observance of safety instructions are
excluded.
Specifications
Qi enabled yes
Input power 5V / 2A
Output power 5V / 1A
Maximum power 5W (10W with fast charger; not included)
Frequency 110 –250kHz
Charging efficiency ≤75%
Charging distance ≤10mm
Overcharge protection yes
High temperature protection yes
Over circuit protection yes
Short circuit protection yes
In the box
•Wireless charger
•Micro USB cable

Grixx User Guide
5
Qi devices
This wireless charger can charge all Qi-enabled devices.
How to use the wireless charger?
• Connect the wireless charger to a power source using the included Micro-USB cable.
• When the power is on, the indicator light will be lit blue once.
• To charge a device, place it in the centre of the wireless charger, the indicator light will stay
lit blue while charging.
o Make sure you place the smartphone correctly on the charging plate.
• The charger will detect the smartphone and will automatically start charging.
o When an abnormality or interference occurs it will automatically turn off.
• When your device is completely charged, the indicator light will turn off.
• Remove the device from the charging pad.
Phone cases
lt can charge your smartphone with phone case unless thickness is less than 5mm.
Cleaning
• lf the charg ing pad needs cleaning, wipe it using a soft, dry cloth.
• Never use any abrasive cleaning agents.
• Periodically wipe off any accumulated dust.

Grixx User Guide
6
Frequently asked questions & solutions
LED indication light is not on!
•Make sure that wall charger is charging and check if the charging cabIe is plugged in
correctly.
Smartphone does not charge!
•Make sure that there is no metal or magnetic materials on the back of smartphone. and the
phone case thickness is less than 5mm.
Important safety instructions
Failure to follow the safety instruct ion s can lead to fire, electrica l shock, personal in jury or
property damage or damage to the wireless charger.
Make sure to read the entire manual.
• Do not use this unit for anything other than its intended use.
• Keep the unit away from heat sources and direct sunlight.
• Do not expose the unit to extreme high or low temperatures; below 0° C and above 35° C
• Do not let the unit come in contact with water or any other liquid. lf the unit gets wet,
immediately unplug it from the power source.
• Do not handIe the unit, USB cable or wall charger with wet hands .
• Do not use the product if it has been dropped or damaged in any way.
• Do not disassemble to device into its component parts and do not try to repair it yourself. It
does not contain any parts requiring maintenance. Repairs to electrical equipment should
only be performed by a qualified electrician. Improper repairs may place the user at serious
risk and the guarantee expires in this case.
• lf you have an electrical healthcare device, such as a pacemaker, consult a physician before
using this product.
• Do not place metals and/or magnetic cards, such as credit cards or key rings on or near this
product.
• Use the specified power source and voltage.
• Do not use a voltage converter/travel adapter.
• Make sure the wall charger is inserted correct in the electrical outlet; when not in use,
unplug the wall charger.
• Place the unit on a sturdy and flat surface during charging.
• Keep the unit out of reach of children.
• The device develops warmth when in use, this is normal. Do not cover the device when this
is in use.
Operating conditions
Operate the device at 0 to 35 degrees Celsius at max. 90% relative humidity (for a short time). If you
do not use the charger for a longer period of time, store it at between -10 and 45 degrees Celsius at
max. 90% relative humidity (for a short time).
Exclusion of liability
The firmware and/or hardware may be changed at any time without prior notice. For this reason it is
possible that parts of these instructions, technical data and images in this documentation differ
slightly from the product in your possession. All points described in these instructions only serve the
purpose of clarification and must not inevitably correspond to a certain situation. Legal claims cannot
be made on the basis of these instructions.

Grixx User Guide
7
Environmental information
All unnecessary packaging has been omitted. We have tried to make the packaging easy to separate
into two materials: cardboard and plastic. The whole product packaging consists of materials which
can be recycled and reused if disassembled by a specialized company. Please observe the local
regulations regarding the disposal of packaging materials and old equipment.
This symbol on packaging signifies that the producer has made a financial contribution towards the
recovery and recycling of packaging.
Disposal of your old product
Your product is designed and manufactured with high quality materials and components, which can
be recycled and reused.
This symbol on a product means that the product is covered by European Directive 2012/19/EU and
cannot be disposed of with normal household waste. We strongly advise you to take your product to
an official collection point. Inform yourself about the local separate collection system for electrical
and electronic products. Follow local rules and never dispose of the product with normal household
waste. Correct disposal of old products helps prevent negative consequences for the environment
and human health.

Grixx User Guide
8
Compliance
Compliant with CE
This symbol means that the product is compliant with health, safety, and environmental protection
standards for products sold within the European Economic Area. The product is manufactured in
accordance with provisions imposed by EMC (Electromagnetic Compatibility) and RoHS (Restriction
of Hazardous Substances) Directives. To minimize the environmental impact and take more
responsibility to the earth we live on, the product complies with the restriction of SVHC (Substances
of Very High Concern) and REACH (Registration, Evaluation, Authorization, and Restriction of
Chemicals) regulated by the European Union.
Social Compliance
Grixx endorses the importance of equal and good working conditions for everyone within the
production chain. That is why the manufacturer of this product is BSCI and /or SA8000 certified. This
means that this product is designed and produced in a community that adheres to ethical
sustainability and endeavors to protect the health, safety, and rights of the employees and
environment in which they operate.
The producer follows the rules based, among others, on the United Nations' International Labor
Organization (ILO) 'code of conduct' and the Human Rights Declaration. The main principles affiliated
with the social compliance include:
•No discrimination
•No child labor
•Legal minimum wages
•Protection on the number of hours people have to work
•No forced labor
•Safe working environment
•Measures against corruption
Having the Grixx product manufactured in compliance with social sustainability values, where high
standards are required of the supplier, helps contribute to the people involved in production of the
product being treated fair, with dignity and respect.
For more information go to https://www.amfori.org/

Grixx User Guide
9
About Grixx
Grixx offers a complete range of mobile accessories that enable users to optimize the use of their
mobile device. Each product offers great value for money and is developed and produced with
respect for the environment, people and working conditions.
The range contains –amongst others –headphones, powerbanks, (wireless) chargers, sync & charge
cables and many more!
For more information and more products please go to www.grixx.eu.
Grixx and the Grixx logo are registered trademarks of Leli Group Holding B.V.; Leli Group Holding B.V.
is the warrantor in relation to this product.
