Grizzly 350 000 Assembly instructions

1
©Alcor 2011 All rights reserved
GRIZZLY
OPERATOR’S INSTRUCTION MANUAL
MODEL: ____________________ ENGINE MODEL: _______________
SERIAL: _____________________ ENGINE SERIAL: _______________
DATE OF PURCHASE: ____________
PURCHASED FROM: __________________________
WARNING: THIS PRODUCT IS DESIGNED AND MANUFACTURED TO
PROVIDE SAFE AND DEPENDABLE SERVICE IF OPERATED
ACCORDING TO INSTRUCTIONS. THE MANUFACTURER
PROVIDES THE FOLLOWING INSTRUCTIONS FOR USE AND
CARE OF THIS EQUIPMENT AND RELIES UPON THE
PURCHASER TO SEE TO IT THAT THESE INSTRUCTIONS ARE
MADE CLEAR TO THE PERSONS WHO WILL ACTUALLY BE
USING THE EQUIPMENT. FAILURE TO DO SO COULD RESULT
IN SERIOUS INJURY OR EQUIPMENT DAMAGE.
GRIZZLY EQUIPMENT
9475 PASCAL GAGNON STREET, ST-LÉONARD, QUEBEC, CANADA
TEL: [phone] FAX: [phone]
E-MAIL: [email protected] Web site: www.grizzlyequip.com
350 000

2
©Alcor 2011 All rights reserved
INDEX
INTRODUCTION.............................................................................................................................................................................3
PREPARATION ...............................................................................................................................................................................4
OPERATOR; ...............................................................................................................................................................................4
WEAR PROPER ATTIRE ..................................................................................................................................................................4
ROOF PREPARATION.....................................................................................................................................................................4
INSPECT ROOF DECK .................................................................................................................................................................4
WARNING LINE SYSTEM............................................................................................................................................................4
HOISTING TO ROOF.......................................................................................................................................................................5
INSPECT THE HOIST...................................................................................................................................................................5
CONNECTING TO LIFT RINGS ....................................................................................................................................................5
SAFETY PRECAUTIONS ..................................................................................................................................................................6
OPERATION...................................................................................................................................................................................7
Before Operation ......................................................................................................................................................................7
Engine Start-Up Operation .......................................................................................................................................................7
The Controls..............................................................................................................................................................................8
MAINTENANCE..........................................................................................................................................................................9
Carbide Block Removal and Installation ...................................................................................................................................9
Engine Service.............................................................................................................................................................................10
Lubrication ..............................................................................................................................................................................10
Belt Adjustment......................................................................................................................................................................10
SAFETY HAZARDS ........................................................................................................................................................................11
Falls .........................................................................................................................................................................................11
Burns.......................................................................................................................................................................................11
Heavy Lifting ...........................................................................................................................................................................11
Fire/Explosion .........................................................................................................................................................................11
Electrocution...........................................................................................................................................................................12
Falling Objects.........................................................................................................................................................................12
Flying Objects..........................................................................................................................................................................12
Unguarded Machinery............................................................................................................................................................12

3
©Alcor 2011 All rights reserved
INTRODUCTION
350 000 ROOF PLANER
Thank you for purchasing this quality GRIZZLY product. With proper use and care the Roof Planer will provide many
years of reliable service. For the safety of all job-site personnel it is mandatory that the instructions provided for the use and
handling of the equipment be read and thoroughly understood by the operators.
CAUTION
INTENDED USE; THIS MACHINE IS INTENDED TO BE USED ON FLAT, LEVEL ROOFS ONLY FOR THE SOLE
PURPOSE OF LOSSENING EMBEDDED GRAVEL. ANY OTHER USE OF THIS EQUIPMENT VOIDS THE
MANUFACTURER’S WARRANTY AND IS THE SOLE RESPONSIBILITY OF THE OWNER/USER, SHOULD ANY
DAMAGE OR INJURY OCCUR.

4
©Alcor 2011 All rights reserved
PREPARATION
OPERATOR;
START BY READING AND FULLY UNDERSTANDING OPERATING INSTRUCTIONS. IF SOMETHING IS NOT
UNDERSTOOD, HAVE SOMEONE ELSE READ AND EXPLAIN THE INSTRUCTIONS TO THE OPERATOR OR
CALL THE MANUFACTURER FOR INFORMATION. AN UNINFORMED OPERATOR CAN SUBJECT HIMSELF
AND OTHERS TO DEATH OR SERIOUS INJURY.
WEAR PROPER ATTIRE
Safety glasses are recommended and must be worn if any roof cutting or scraping is being done in the vicinity. Safety glasses
and or face shield are also necessary when working with hot stuff.
Wear properly fitting clothes. Tight clothing can restrict movement and slow down reaction time in a dangerous situation.
Loose fitting clothing can be dangerous and cause serious injury if it gets caught in moving mechanical parts. Wear a long-
sleeved shirt, buttoned at the cuffs, safety shoes, and pants without cuffs, and knit wrist type gloves.
A hard hat must be worn by operator when working on a job site.
ROOF PREPARATION
INSPECT ROOF DECK
Before allowing equipment and personnel access to roof, make certain roof is strong enough to support the weight. Check
load limits of deck with owner, builder or architect. Clear the work area of all potentially dangerous obstacles that could
cause personal injury to the operator or others. Keep unauthorized people away from construction area. Check to see that all
roof openings are guarded to protect against falls.
WARNING LINE SYSTEM
When operating parallel to roof edge warning line system must be at least six feet from edge. When operating perpendicular
to edge warning line must be ten feet from roof edge.

5
©Alcor 2011 All rights reserved
HOISTING TO ROOF
WARNING; ALWAYS CHECK DECK LOAD LIMITS WITH BUILDER, OWNER, OR ARCHITECT
BEFORE DECIDING TO USE ON THE ROOF.
INSPECT THE HOIST
Make certain hoist is in safe operating condition, to be operated by trained personnel. The hoist should be clear of ground
objects and overhead obstacles, such as power lines; it should be secure and properly counterbalanced. Hoist should be
inspected for frayed cables, bent frame members of faulty mechanical parts. Make sure everyone on the ground is completely
clear of the hoisting area. Do not exceed the weight and size capacity of your hoist. Do not use if you are in doubt.
CONNECTING TO LIFT RINGS
There is one centered lift ring on the machine (see Fig. 2) Always lift machine by this ring using the proper hook and cable.
Do not attempt to lift the machine by any other part. Always inspect ring for wear or damage and make sure the hoist, cable,
hook etc. are in good running order or damage or injury may result.
WEIGHT: 230 LBS
Fig. 2

6
©Alcor 2011 All rights reserved
SAFETY PRECAUTIONS
Do not allow other people to be near the machine during operation (except operator)
Other workers on the job site must wear eye protection when in the vicinity of the Planer.
Be certain all guards, shields and covers are secure and tight before starting.
Never operate a planer that is damaged in any way. Repairs or replacement of damaged components must be made
by a qualified mechanic
Do not modify the equipment. Do not operate a modified piece of equipment.
Never reach into the planer disc area when the engine is operating. Keep hands and feet away from planer disc.
Wear safety footwear, eye protection and snug fit clothing.
Operate the Planer only from the “Walk Behind” position.
Operate on flat, level roofs only.
Use only GRIZZLY planer blocks.
Keep away from electrical lines.
Use caution when handling fuel. Gasoline is very flammable. Shut off engine, and allow cooling before refuelling.
Clean up gasoline before restarting.
Guard all openings on the roof.
Do not allow anyone to walk in front of the Planer.
Do not operate within 10 feet of roof edge (or within 6 feet, if operating parallel to the edge).
Never lilt the machine during planning.
Do not operate this machine if you are under the influence of alcohol, marijuana, or drugs that could impair judgment
and ability.
Keep the equipment in good condition.
Do not walk backward while operating.
Remove loose debris before planning.
The owner or operator must see that all warning decals are in place and legible. Write to GRIZZLY Equipment for
replacement decals and instructions.
Make certain the operator and others in the vicinity wear a respirator and other protective gear as conditions warrant.
Inspect disc and block tightness before starting engine. Do not operate with damaged or worn out blocks.
Keep away from planning disc and chain guard when starting the engine and when the engine is running.
Keep guard chains in good working order to prevent material from flying out from underneath.

7
©Alcor 2011 All rights reserved
OPERATION
Before Operation
Check to see that engine is serviced properly. Read Honda operation and safety instructions. Handle gasoline with extreme
caution. Make certain belt guards and blade guards are in place and secure and that there are no signs of damage or wear of
these parts. Never operate machine with damaged or missing guards. Serious injury may otherwise result.
Engine Start-Up Operation
After checking the planer disc and blocks (refer to the planer block installation section), put the depth control in the idle
position and make certain the control is set so that the blocks do not come in contact with the roof deck (see Fig. 3). Pushing
Down on the handles will allow the depth control to slide to the idle position.
At this point, after you have read through all of the instructions, the Planer should be ready for operation.
Position planer where work is to be done, start the engine and allow to warm up. (Please refer to the engine manufacturer’s
owner’s manual). Depth adjustment must be set so that blocks do not come in contact with deck when set in idle position
(Fig. 3).
The throttle is located on the right hand side (Fig. 6). To actuate choke, lever must be in fully contracted position (all the way
down). Push the throttle control slightly to find full throttle position, and pull farther up for lower speed settings. To stop the
engine, pull all the way up on control lever.
Fig. 3 Planer in idle position

8
©Alcor 2011 All rights reserved
The Controls
The depth control (ser Fig. 4 and Fig. 5) is located on the centre of the machine, just over the engine. Fig. 4 shows the control
in the idle position and Fig. 5 shows the planning position. Turning the crank clockwise adjusts the planning depth lower;
counter-clockwise rotation of crank raises the planning disc. Operator must be familiar with operation of this control before
using planer on the job.
The throttle is located on the right hand side (see Fig. 6). To actuate choke, lever must be in fully contracted position (all the
way down). Push the throttle control slightly to find full throttle position, and pull farther up for lower speed settings. To
stop the engine, pull all the way up on control lever. Lowering control lever increases the engine speed. Raising the control
lever decreases the engine speed.
Fig. 4 Depth control in idle position
Fig. 5 Depth control in operation position
Fig. 6 Throttle control

9
©Alcor 2011 All rights reserved
Follow this procedure: while engine is running at low speed and with the planer in it’s idle position, move depth control lever
from it’s idle position to the working position slowly. If you engage the surface, immediately put the machine back in the
idle position and turn the depth control lever counter-clockwise to raise the disc. Try this procedure again until the machine
is in it’s working position without engaging the surface. Now set throttle to 2/3 to 3/4 of full speed and turn depth control
lever clockwise to slowly engage roof to desired depth setting. Adjust it just low enough to do a clean job, no lower.
Periodic adjustments may be necessary as the blocks wear. Operator must observe quality of planning job and make
adjustments accordingly.
When planning, don’t push the machine faster than it is capable of working. Walk forward only, pushing the machine at a
pace at which it does a clean job. At the end of the row, turn the machine without tilting it.
WARNING; NEVER TILT MACHINE TO EXPOSE DISC WHILE OPERATING. SEVERE PERSONAL
INJURY COULD OTHERWISE RESULT TO OPERATOR OR OTHERS ON THE JOB
SITE. SHUT MACHINE OFF WHEN NOT ATTENDED BY OPERATOR.
MAINTENANCE
Carbide Block Removal and Installation
CAUTION; Disconnect spark plug wire before working on machine.
There are four carbide blocks installed on the planning disc. The blocks are each held in place by an allen screw. Eventually
the blocks will become worn and replacement will be necessary. When the carbide has worn from the blocks, it is time to
replace with new blocks. Make certain you disconnect spark plug wire before working on machine.
To remove the blocks, use a long arm allen wrench. The blocks do not drop off the disc after screws have been turned out,
you may need to tap them out with a block of wood. It is best to replace screws at the same time you replace the blocks.
When installing new blocks, countersink side of block faces out. Use care to align screw properly and turn evenly; damage to
threads could otherwise result. Make certain the blocks are tightened securely. See Fig. 7, illustration of blocks installed on
the planning disc.
Fig. 7 Carbide blocks on disc planer

10
©Alcor 2011 All rights reserved
Engine Service
CAUTION; Disconnect spark plug wire before working on machine.
For the engine, read “Honda Owner’s Manual”. Engine oil should be changed in conformity with “Honda Owner’s Manual”.
Keep the cylinder head clean so that it can cool the engine properly. Frequent oil changes will significantly prolong life of
engine. SAW 10W30 is recommended by Honda (see Honda Engines Owner’s manual). Unleaded gasoline is also
recommended to increase valve life.
If service or repair of engine is needed, contact an authorized Honda Centre,
GRIZZLY equipment warranty does not cover the engine, which is covered by a separate warranty from Honda.
Lubrication
Lubrication recommendations are as follows: Roller bearings on wheels are pre-lubricated and require no greasing. Flange
bearings (item 17 on part list) that support planer disc are pre-lubricated and require greasing only about every 100 hours
operation. In extremely severe conditions greasing may be required more frequently. A high-quality lithium based multi-
purpose grease is proper lubricant. Use extreme care when pumping grease into bearing not to push too hard. Destruction of
bearing seal will otherwise result. Removal of belt guard is necessary for access t upper flange bearing. Treaded rod on
depth control requires a spray lubricant (such as WD40) to keep it turning freely.
Belt Adjustment
Belt adjustment may be necessary at times. To inspect belt remove dust plate on back of motor mount (see Fig. 8). Push
down on the belt with your thumb midway between pulley with about 20 lbs. pressure. When properly adjusted you should
get a deflection of nearly 3/4". To adjust belt, loosen 4 bolts on engine mount (item 101 on parts list). Then loosen locknut
on belt adjustment bolt, shown in Fig. 9. Turn bolt clockwise to tighten belt, counter clockwise to loosen. When desired
tension is set, re-tighten the locknut and also the four engine mount bolts. If belt replacement is necessary, remove belt cover
(item 4 on parts list) by removing two bolts. Replace belt cover after changing belt. Tighten bolts securely.
Fig. 9 Belt adjustment: A- adjustment bolt
Fig. 8 Dust plate
A
