Grizzly G0453 User manual

MODEL G0453/G0454
15" & 20" MOBILE PLANERS
OWNER'S MANUAL
8DENG><=IB6N!'%%*7N<G>OOAN>C9JHIG>6A!>C8#!G:K>H:9B6N!'%&&IH
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
;DGBD9:AHB6CJ;68IJG:9H>C8:($%-IG,')+EG>CI:9>C8=>C6

This manual provides critical safety instructions on the proper setup,
operation, maintenance, and service of this machine/tool. Save this
document, refer to it often, and use it to instruct other operators.
Failure to read, understand and follow the instructions in this manual
may result in fire or serious personal injury—including amputation,
electrocution, or death.
The owner of this machine/tool is solely responsible for its safe use.
This responsibility includes but is not limited to proper installation in
a safe environment, personnel training and usage authorization,
proper inspection and maintenance, manual availability and compre-
hension, application of safety devices, cutting/sanding/grinding tool
integrity, and the usage of personal protective equipment.
The manufacturer will not be held liable for injury or property damage
from negligence, improper training, machine modifications or misuse.
3OMEDUSTCREATEDBYPOWERSANDINGSAWINGGRINDINGDRILLINGAND
OTHERCONSTRUCTIONACTIVITIESCONTAINSCHEMICALSKNOWNTOTHE3TATE
OF#ALIFORNIATOCAUSECANCERBIRTHDEFECTSOROTHERREPRODUCTIVE
HARM3OMEEXAMPLESOFTHESECHEMICALSARE
s ,EADFROMLEADBASEDPAINTS
s #RYSTALLINESILICAFROMBRICKSCEMENTANDOTHERMASONRYPRODUCTS
s !RSENICANDCHROMIUMFROMCHEMICALLYTREATEDLUMBER
9OURRISKFROMTHESEEXPOSURESVARIESDEPENDINGONHOWOFTENYOU
DOTHISTYPEOFWORK4OREDUCEYOUREXPOSURETOTHESECHEMICALS
7ORKINAWELLVENTILATEDAREAANDWORKWITHAPPROVEDSAFETYEQUIP
MENTSUCHASTHOSEDUSTMASKSTHATARESPECIALLYDESIGNEDTOFILTER
OUTMICROSCOPICPARTICLES

Table of Contents
SECTION 5: ACCESSORIES......................... 28
SECTION 6: MAINTENANCE......................... 30
HX]ZYjaZ###################################################### (%
8aZVc^c\EgdiZXi^c\################################## (%
AjWg^XVi^dc################################################### (&
SECTION 7: SERVICE ................................... 33
IgdjWaZh]ddi^c\########################################### ((
HZii^c\$GZeaVX^c\@c^kZh############################# (+
K"7ZaiIZch^dc^c\$GZeaVXZbZci################## (,
IVWaZ=Z^\]i8]V^cIZch^dc######################## (.
;ZZY GdaaZgh! 8]^e 7gZV`Zg  EgZhhjgZ 7Vg
=Z^\]ih######################################################### )%
GdaaZgHeg^c\IZch^dc################################## )(
Edh^i^dc^c\8]^e9Z[aZXidg########################### )(
HXVaZ8Va^WgVi^dc########################################## ))
6ci^"@^X`WVX`;^c\Zgh################################## ))
EjaaZn6a^\cbZci########################################## )*
SECTION 8: WIRING...................................... 46
L^g^c\HV[Zin>chigjXi^dch############################ )+
<%)*(L^g^c\9^V\gVb################################ ),
<%)*)L^g^c\9^V\gVb################################ )-
SECTION 9: PARTS....................................... 49
<%)*(=ZVYhidX`######################################## ).
<%)*(IVWaZ################################################ *&
<%)*(8dajbch########################################### *'
<%)*(8VW^cZiHiVcY################################## *(
<%)*(<ZVgWdm########################################### **
<%)*(AVWZaEaVXZbZci############################## *+
<%)*)=ZVYhidX`######################################## *,
<%)*)IVWaZ################################################ +%
<%)*)8dajbch########################################### +&
<%)*)8VW^cZiHiVcY################################## +'
<%)*)<ZVgWdm########################################### +)
<%)*)AVWZaEaVXZbZci############################## +*
WARRANTY AND RETURNS ........................ 69
INTRODUCTION............................................... 2
BVcjVa6XXjgVXn########################################### '
8dciVXi>c[d####################################################'
BVX]^cZ9ZhXg^ei^dc###################################### '
>YZci^[^XVi^dc################################################### (
>ciZgcVa8dbedcZcih###################################### )
<%)*(BVX]^cZ9ViVH]ZZi########################## *
<%)*)BVX]^cZ9ViVH]ZZi########################## ,
SECTION 1: SAFETY....................................... 9
HV[Zin>chigjXi^dch[dgBVX]^cZgn################## .
6YY^i^dcVaHV[Zin>chigjXi^dch[dgEaVcZgh#### &&
SECTION 2: POWER SUPPLY ...................... 12
SECTION 3: SETUP ....................................... 14
CZZYZY[dgHZije######################################### &)
JceVX`^c\#################################################### &)
>ckZcidgn######################################################&*
8aZVcje######################################################## &+
H^iZ8dch^YZgVi^dch###################################### &,
A^[i^c\Bdk^c\7VhZJc^i########################## &-
6hhZbWan##################################################### &-
9jhi8daaZXi^dc############################################# '&
8]ZX`<ZVgWdmD^a###################################### '&
IZhiGjc###################################################### '&
GZ"IZch^dcK"7Zaih###################################### ''
GZXdbbZcYZY6Y_jhibZcih######################## ''
SECTION 4: OPERATIONS ........................... 23
DeZgVi^dcDkZgk^Zl##################################### '(
EaVc^c\I^eh################################################# ')
Ldg`e^ZXZ>cheZXi^dc################################### ')
LddY=VgYcZhh########################################### '*
;ZZYGViZ#################################################### '*
9Zei]d[8ji################################################# '+
7ZYGdaaZg=Z^\]i######################################### '+

"'" <%)*($<%)*)B[\#H^cXZ($%-
I]Z BdYZa <%)*($<%)*) EaVcZg ^h YZh^\cZY id
gZbdkZ bViZg^Va ^c egZX^hZ ^cXgZbZcih [gdb i]Z
hjg[VXZ d[ cVijgVa lddY [^WZg hidX` id bV`Z i]Z
ldg`e^ZXZ[aVi#
DcXZ i]Z YZei] d[ Xji ^h hZi! i]Z ldg`e^ZXZ ^h
eaVXZY dc i]Z iVWaZ VcY bdkZY ^cid i]Z ^c[ZZY
gdaaZg! l]^X]ejaahi]Zldg`e^ZXZjcYZgi]ZgdiVi"
^c\ XjiiZg]ZVY l]ZgZ i]Z bViZg^Va ^h gZbdkZY#
6[iZg i]Z ldg`e^ZXZ ^h XdbeaZiZan [gZZ [gdb i]Z
dji[ZZY gdaaZg! i]Z YZei] d[ Xji ^h ^cXgZVhZY VcY
i]Zldg`e^ZXZ^heVhhZYi]gdj\]i]ZeaVcZgV\V^c#
I]^hegdXZhhXdci^cjZhjci^ai]Zldg`e^ZXZ^h[aVi
VcYd[i]ZXdggZXii]^X`cZhh#
INTRODUCTION
Machine Description
LZ hiVcY WZ]^cY djg bVX]^cZh# >[ ndj ]VkZ
VcnfjZhi^dch dg cZZY]Zae! jhZ i]Z^c[dgbVi^dc
WZadlidXdciVXijh#7Z[dgZXdciVXi^c\!eaZVhZ\Zi
i]ZhZg^Va cjbWZg VcYbVcj[VXijgZ YViZ d[ndjg
bVX]^cZ#I]^hl^aa]Zaejh]Zaendj[VhiZg#
<g^ooanIZX]c^XVaHjeedgi
&'%(AnXdb^c\BVaa8^gXaZ
BjcXn!E6&,,*+
E]dcZ/*,%*)+".++(
:bV^a/iZX]hjeedgi5\g^ooan#Xdb
LZlVcindjg[ZZYWVX`dci]^hbVcjVa#L]ViY^Y
ndj a^`Z VWdji ^i4 L]ZgZ XdjaY ^i WZ ^begdkZY4
EaZVhZiV`ZV[Zlb^cjiZhid\^kZjh[ZZYWVX`#
<g^ooan9dXjbZciVi^dcBVcV\Zg
E#D#7dm'%+.
7Zaa^c\]Vb!L6.-'',"'%+.
:bV^a/bVcjVah5\g^ooan#Xdb
Contact Info
LZVgZegdjYidd[[Zgi]^hbVcjVal^i]ndjgcZl
bVX]^cZ LZkZ bVYZ ZkZgn Z[[dgi id WZ ZmVXi
l^i] i]Z ^chigjXi^dch! heZX^[^XVi^dch! YgVl^c\h!
VcY e]did\gVe]h d[ i]Z bVX]^cZ lZ jhZY l]Zc
lg^i^c\i]^hbVcjVa#=dlZkZg!hdbZi^bZhlZhi^aa
bV`ZVcdXXVh^dcVab^hiV`Z#
6ahd!dl^c\iddjgeda^Xn d[Xdci^cjdjh^begdkZ"
bZci!your machine may not exactly match the
manual#>[ndj[^cYi]^hidWZi]ZXVhZ!VcYi]ZY^["
[ZgZcXZWZilZZci]ZbVcjVaVcYbVX]^cZaZVkZh
ndj ^c YdjWi! X]ZX` djg lZWh^iZ [dg i]Z aViZhi
bVcjVajeYViZdgXVaaiZX]c^XVahjeedgi[dg]Zae#
7Z[dgZXVaa^c\![^cYi]ZbVcj[VXijgZYViZd[ndjg
bVX]^cZWnadd`^c\Vii]ZYViZhiVbeZY^cidi]Z
bVX]^cZ >9 aVWZa hZZ WZadl# I]^h l^aa ]Zae jh
YZiZgb^cZ ^[ i]Z bVcjVa kZgh^dc ndj gZXZ^kZY
bViX]Zhi]ZbVcj[VXijgZYViZd[ndjgbVX]^cZ#
;dgndjgXdckZc^ZcXZ!lZedhiVaaVkV^aVWaZbVc"
jVahVcYbVcjVajeYViZh[dg[gZZdcdjglZWh^iZ
Viwww.grizzly.com#6cnjeYViZhidndjgbdYZa
d[ bVX]^cZ l^aa WZ gZ[aZXiZY ^c i]ZhZ YdXjbZcih
VhhddcVhi]Z
n
VgZXdb
e
aZiZ#
BVcj[VXijgZ9ViZ
d[NdjgBVX]^cZ
Manual Accuracy

"("
<%)*($<%)*)B[\#H^cXZ($%-
Identification
Figure 1.<ZcZgVa^YZci^[^XVi^dc#
BV\cZi^X
DC$D;;
Hl^iX]
GZijgc
GdaaZgh
IVWaZ
=Z^\]i
=VcYl]ZZa <ZVgWdm
A^[i^c\
7Vg
&d[)
AdX`^c\
;ddi
EZYVa
K"7Zai
8dkZg
;ZZYGViZ
8dcigda@cdW
7ZYGdaaZgh
8VW^cZi
6XXZhh
EVcZa
;gdci
:miZch^dc
L^c\
GZVg
:miZch^dc
L^c\
IVWaZ
AdX`h

")" <%)*($<%)*)B[\#H^cXZ($%-
Internal Components
Ldg`e^ZXZ
Figure 2.Ldg`e^ZXZeVi]VcYbV_dgeaVc^c\XdbedcZcihh^YZXjiVlVnk^Zl#
A.Anti-Kickback Fingers: Egdk^YZ VYY^i^dcVa
hV[Zin[dgi]ZdeZgVidg#
B.Serrated Infeed Roller: Ejaahi]Zldg`e^ZXZ
idlVgYi]ZXjiiZg]ZVY#
C. Chip Breaker: 7gZV`h d[[ X]^eh XgZViZY Wn
i]ZXjiiZg]ZVYidegZkZciiZVgdjiVcYY^kZgih
i]ZX]^ehidi]ZYjhiedgi#
D. Chip Deflector: 9^gZXih X]^eh ^cid i]Z Yjhi
]ddY#
E. Cutterhead: =daYh i]Z `c^kZh i]Vi gZbdkZ
bViZg^Va[gdbi]Zldg`e^ZXZ#
6
8
7
:
=
=
>
;
F. Pressure Bar: HiVW^a^oZhi]Zldg`e^ZXZVh^i
aZVkZhi]ZXjiiZg]ZVYVcYVhh^hih^cYZ[aZXi"
^c\ lddY eVgi^XaZh idlVgY i]Z Yjhi ]ddY
<%)*)dcan#
G. Outfeed Rollers: Ejaahi]Zldg`e^ZXZi]gdj\]
i]ZeaVcZg#
H. Table Rollers: Egdk^YZjelVgY egZhhjgZdc
i]Zldg`e^ZXZZcVWa^c\i]Z[ZZYgdaaZghidejaa
i]Zldg`e^ZXZVadc\#
I. Planer Table: Egdk^YZh V hbddi] VcY aZkZa
eVi] [dg i]Z ldg`e^ZXZ Vh ^i bdkZh i]gdj\]
i]ZeaVcZg#
<
9
Like all machinery there is potential danger when operating this machine. Accidents are fre-
quently caused by lack of familiarity or failure to pay attention. Use this machine with respect
and caution to decrease the risk of operator injury. If normal safety precautions are overlooked
or ignored, serious personal injury may occur.

"*"
<%)*($<%)*)B[\#H^cXZ($%-
0$&+,1('$7$
6+((7
Customer Service #: [phone] · To Order Call: [phone] · Fax #: [phone]
02'(/*3/$1(5
Product Dimensions:
Weight.............................................................................................................................................................. 655 lbs.
Width (side-to-side) x Depth (front-to-back) x Height............................................................... 32-1/2 x 42 x 45-7/8 in.
Footprint (Length x Width)..................................................................................................................... 22-1/2 x 22 in.
Shipping Dimensions:
Type.......................................................................................................................................................... Wood Crate
Content........................................................................................................................................................... Machine
Weight.............................................................................................................................................................. 675 lbs.
Length x Width x Height....................................................................................................................... 31 x 30 x 47 in.
Electrical:
Power Requirement........................................................................................................... 220V, Single-Phase, 60 Hz
Minimum Circuit Size........................................................................................................................................ 20 Amp
Switch........................................................................................................ Magnetic with Thermal Overload Protector
Switch Voltage..................................................................................................................................................... 220V
Cord Length............................................................................................................................................................ 5 ft.
Cord Gauge................................................................................................................................................... 12 gauge
Plug Included........................................................................................................................................................... No
Recommended Plug/Outlet Type............................................................................................................... NEMA 6-20
Motors:
Main
Type.................................................................................................................. TEFC Capacitor Start Induction
Horsepower................................................................................................................................................ 3 HP
Voltage....................................................................................................................................................... 220V
Phase....................................................................................................................................................... Single
Amps............................................................................................................................................................ 15A
Speed................................................................................................................................................ 3450 RPM
Cycle......................................................................................................................................................... 60 Hz
Number of Speeds............................................................................................................................................ 1
Power Transfer ..................................................................................................................... Triple V-Belt Drive
Bearings......................................................................................................................... Sealed and Lubricated
Main Specifications:
Operation Info
Max. Cut Width.......................................................................................................................................... 15 in.
Min. Stock Length....................................................................................................................................... 8 in.
Min. Stock Thickness.............................................................................................................................. 3/16 in.
Max. Stock Thickness.................................................................................................................................. 8 in.
No. of Cuts Per Inch.............................................................................................. 63 at 16 FPM, 42 at 30 FPM
No. of Cuts Per Minute............................................................................................................................ 15,000
Cutterhead Speed............................................................................................................................. 5000 RPM
Planing Feed Rate........................................................................................................................... 16, 30 FPM
Max. Cut Depth Planing Full Width......................................................................................................... 3/32 in.
Max. Cut Depth Planing 6 Inch Wide Board............................................................................................. 1/8 in.
G0453 Machine Data Sheet
YViVh]ZZi

"+" <%)*($<%)*)B[\#H^cXZ($%-
Cutterhead Info
Cutterhead Type...................................................................................................................................... 3 Knife
Cutterhead Dia............................................................................................................................................. 3 in.
No. of Knives.................................................................................................................................................... 3
Knife Type................................................................................................................................................... HSS
Knife Size Length....................................................................................................................................... 15 in.
Knife Size Width.......................................................................................................................................... 1 in.
Knife Size Thickness................................................................................................................................ 1/8 in.
Knife Adjustment............................................................................................................................ Jack Screws
Table Info
Table Movement.......................................................................................................................................... 8 in.
Table Bed Size Length.............................................................................................................................. 20 in.
Table Bed Size Width................................................................................................................................ 15 in.
Table Bed Size Thickness..................................................................................................................... 1-3/4 in.
No. of Bed Rollers............................................................................................................................................ 2
Floor To Table Height...................................................................................................................... 27 — 35 in.
Roller Ext Table Size Length..................................................................................................................... 42 in.
Roller Ext Table Size Width....................................................................................................................... 15 in.
Roller Ext Table Size Thickness............................................................................................................ 1-3/4 in.
Construction
Table....................................................................................................................... Precision Ground Cast Iron
Body..................................................................................................................................................... Cast Iron
Stand............................................................................................................................................. Formed Steel
Cutterhead Assembly................................................................................................................................. Steel
Infeed Roller....................................................................................................................... Solid Serrated Steel
Outfeed Roller.................................................................................................................... Solid Serrated Steel
Paint........................................................................................................................................... Powder Coated
Other
Table Locks.................................................................................................................................... Two Positive
Measurement Scale................................................................................................................... Inch and Metric
No. of Dust Ports.............................................................................................................................................. 1
Dust Port Size.............................................................................................................................................. 4 in.
Other Specifications:
Country Of Origin ............................................................................................................................................... China
Warranty ........................................................................................................................................................... 1 Year
Serial Number Location ....................................................................................................... ID Label on Upper Cover
Assembly Time ........................................................................................................................................... 30 minutes
Features:
Inch and Metric Measurement Scale
Two Adjustable Bed Rollers
Chip Breaker and Pressure Bar
Knife Setting Jig Included
Board Return Rollers
Built-in Mobile Base
Cast Iron Extension Wings
Four Column Support with Table Locks
Two Speed Automatic Board Feed

","
<%)*($<%)*)B[\#H^cXZ($%-
0$&+,1('$7$
6+((7
Customer Service #: [phone] · To Order Call: [phone] · Fax #: [phone]
02'(/*3/$1(5
Product Dimensions:
Weight.............................................................................................................................................................. 890 lbs.
Width (side-to-side) x Depth (front-to-back) x Height........................................................ 39-1/2 x 55-1/2 x 45-7/8 in.
Footprint (Length x Width)............................................................................................................... 29-1/2 x 23-1/2 in.
Shipping Dimensions:
Type.......................................................................................................................................................... Wood Crate
Content........................................................................................................................................................... Machine
Weight.............................................................................................................................................................. 920 lbs.
Length x Width x Height....................................................................................................................... 39 x 30 x 49 in.
Electrical:
Minimum Circuit Size........................................................................................................................................ 30 amp
Switch........................................................................................................ Magnetic with Thermal Overload Protector
Switch Voltage..................................................................................................................................................... 220V
Cord Length...................................................................................................................................................... 6-1/2 ft.
Cord Gauge................................................................................................................................................... 12 gauge
Plug Included........................................................................................................................................................... No
Recommended Plug/Outlet Type........................................................................................................................ L6-30
Motors:
Main
Type.................................................................................................................. TEFC Capacitor Start Induction
Horsepower................................................................................................................................................ 5 HP
Voltage....................................................................................................................................................... 220V
Phase....................................................................................................................................................... Single
Amps............................................................................................................................................................ 25A
Speed................................................................................................................................................ 3450 RPM
Cycle......................................................................................................................................................... 60 Hz
Number of Speeds............................................................................................................................................ 1
Power Transfer ..................................................................................................................... Triple V-Belt Drive
Bearings......................................................................................................................... Sealed and Lubricated
Main Specifications:
Operation Info
Max. Cut Width.......................................................................................................................................... 20 in.
Min. Stock Length................................................................................................................................. 7-1/2 in.
Min. Stock Thickness.............................................................................................................................. 3/16 in.
Max. Stock Thickness.................................................................................................................................. 8 in.
No. of Cuts Per Inch............................................................................................................................... 104, 83
No. of Cuts Per Minute............................................................................................................................ 20,000
Cutterhead Speed............................................................................................................................. 5000 RPM
Planing Feed Rate........................................................................................................................... 16, 20 FPM
Max. Cut Depth Planing Full Width........................................................................................................... 1/8 in.
Max. Cut Depth Planing 6 Inch Wide Board............................................................................................. 1/8 in.
G0454 Machine Data Sheet

"-" <%)*($<%)*)B[\#H^cXZ($%-
Cutterhead Info
Cutterhead Type...................................................................................................................................... 4 Knife
Cutterhead Dia...................................................................................................................................... 3-1/8 in.
No. of Knives.................................................................................................................................................... 4
Knife Type................................................................................................................................................... HSS
Knife Size Length....................................................................................................................................... 20 in.
Knife Size Width.......................................................................................................................................... 1 in.
Knife Size Thickness................................................................................................................................ 1/8 in.
Knife Adjustment........................................................................................................ Jack Screws and Springs
Table Info
Table Movement.......................................................................................................................................... 8 in.
Table Bed Size Length........................................................................................................................ 25-3/4 in.
Table Bed Size Width................................................................................................................................ 20 in.
Table Bed Size Thickness..................................................................................................................... 1-3/4 in.
No. of Bed Rollers............................................................................................................................................ 2
Floor To Table Height............................................................................................................ 26-1/2 - 34-1/2 in.
Roller Ext Table Size Length............................................................................................................... 55-1/2 in.
Roller Ext Table Size Width....................................................................................................................... 20 in.
Roller Ext Table Size Thickness............................................................................................................ 1-3/4 in.
Construction
Table....................................................................................................................... Precision Ground Cast Iron
Body..................................................................................................................................................... Cast Iron
Stand............................................................................................................................................. Formed Steel
Cutterhead Assembly................................................................................................................................. Steel
Infeed Roller....................................................................................................................... Solid Serrated Steel
Outfeed Roller.................................................................................................................... Solid Serrated Steel
Paint........................................................................................................................................... Powder Coated
Other
Table Locks.................................................................................................................................... Two Positive
Measurement Scale................................................................................................................... Inch and Metric
No. of Dust Ports.............................................................................................................................................. 1
Dust Port Size.............................................................................................................................................. 5 in.
Other Specifications:
Country Of Origin ............................................................................................................................................... China
Warranty ........................................................................................................................................................... 1 Year
Serial Number Location ....................................................................................................... ID Label on Upper Cover
Assembly Time ........................................................................................................................................... 30 minutes
Sound Rating ..................................................................................................................................................... 80 dB
Features:
Inch and Metric Measurement Scale
Two Adjustable Bed Rollers
Chip Breaker and Pressure Bar
Knife Setting Jig Included
Board Return Rollers
Built-in Mobile Base
Cast Iron Extension Wings
Four Column Support with Table Locks
Two Speed Automatic Board Feed
