G0608X Extreme Series Tilting Spindle Shaper -45-
Table & Cabinet Parts Breakdown



























 























 






 
 
 
 









   
 











-46- G0608X Extreme Series Tilting Spindle Shaper
Table & Cabinet Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0608X001 KNOB 10-1.5 X 25 40 P0608X040 ELECTRICAL BOX
3 P0608X003 SAFEGUARD 40-1 P0608X040-1 STOP SWITCH
4 P0608X004 FEMALE KNOB 1/2-13 40-2 P0608X040-2 POWER SWITCH
5 P0608X005 HANDLE ROD 40-3 P0608X040-3 REVERSIBLE SWITCH
6 P0608X006 FIX POLE 40-4 P0608X040-4 CONTACTOR 220V
8 P0608X008 POLE 40-5 P0608X040-5 THERMAL OVERLOAD RELAY 220V
9 P0608X009 HEX BOLT 10-1.5 X 40 40-6 P0608X040-6 FUSE HOUSING W/DIODE
10 P0608X010 SUPPORT 40-7 P0608X040-7 2A FUSE
11 P0608X011 HOLD DOWN FINGER 40-8 P0608X040-8 ELECTRICAL MOUNTING PANEL
12 PB14M HEX BOLT M10-1.5 X 35 40-9 P0608X040-9 JUNCTION BLOCK
13 P0608X013 LEVER 10-1.5 X 30 40-10 P0608X040-10 ELECTRIC BOX WIRING HARNESS
14 PSS16M SET SCREW M8-1.25 X 10 41 P0608X041 PVC ELECTRIC FACING
15 P0608X015 FENCE BASE 42 P0608X042 BASE CABINET
16 P0608X016 DUST HOOD 43 P0608X043 LATCH HANDLE
17 PS05M PHLP HD SCR M5-.8 X 8 44 P0608X044 DOOR HANDLE
18 P0608X018 HOLD DOWN SUPPORT 45 P0608X045 MOTOR ACCESS DOOR
19 P0608X019 KNOB 46 P0608X046 T-HANDLE
20 P0608X020 SPECIAL RING 47 P0608X047 LOCKING SHAFT
21 PEC12M E-CLIP 12MM 48 PS108M PHLP HD SCR M6-1 X 55
22 P0608X022 HEX BOLT 10-1.5 X 35 49 P0608X049 PVC HANDWHEEL FACING
23 PW04M FLAT WASHER 10MM 50 P0608X050 TABLE INSERT SET ASSEMBLY
24 P0608X024 FENCE SUPPORT RIGHT 50-1 P0608X050-1 TABLE INSERT 9-7/8 ID X 13-3/4 OD
24-1 P0608X024-1 FENCE SUPPORT LEFT 50-2 P0608X050-2 TABLE INSERT 5-7/8 ID X 10-5/8 OD
25 P0608X025 PLATE 50-3 P0608X050-3 TABLE INSERT 2-3/4 ID X 6-3/4 OD
26 PW04M FLAT WASHER 10MM 50-4 PSS08M SET SCREW M4-.7 X 5
27 P0608X027 FENCE BOARD RIGHT 131 P0608X131 440V CONVERSION KIT
27-1 P0608X027-1 FENCE BOARD LEFT 131-1 P0608X131-1 CONTACTOR 440V
28 PSB72M CAP SCREW M10-1.5 X 30 131-2 P0608X131-2 THERMAL OVERLOAD RELAY 440V
29 P0608X029 CUTTER GUARD 132 PAW01.5M HEX WRENCH 1.5MM
30 PB34M HEX BOLT M10-1.5 X 60 133 PAW02M HEX WRENCH 2MM
31 PW04M FLAT WASHER 10MM 134 PAW02.5M HEX WRENCH 2.5MM
32 P0608X032 HOLD DOWN FINGER 135 PAW03M HEX WRENCH 3MM
33 P0608X033 TABLE 136 PAW04M HEX WRENCH 4MM
34 P0608X034 MITER GAUGE ASSEMBLY 137 PAW05M HEX WRENCH 5MM
34-1 P0608X034-1 MITER BODY 138 PAW10M HEX WRENCH 5.5MM
34-2 P0608X034-2 HANDLE 139 PAW06M HEX WRENCH 6MM
34-3 P0608X034-3 SLIDING PLATE 140 PAW08M HEX WRENCH 8MM
34-4 P0608X034-4 PIN 141 PAW10M HEX WRENCH 10MM
34-5 P0608X034-5 INDICATOR 142 PWR1113 WRENCH 11 X 13
35 P0608X035 REAR CABINET COVER 143 PWR1719 WRENCH 17 X 19
36 PN07 HEX NUT 10-24 144 P0608X144 SPINDLE NUT WRENCH 36MM
37 PW03 FLAT WASHER #10 157 P0608X157 SHAFT NUT WRENCH
38 P0608X038 ALL THREAD #10-24 X 3 160 P0608X160 STRAIN RELIEF
39 P0608X039 POWER J-BOX W/J-BLOCK 161 P0608X161 STRAIN RELIEF BUSHING

G0608X Extreme Series Tilting Spindle Shaper -47-
Motor & Spindle Parts Breakdown







 

 






 




 






























 



 


































 
 





-48- G0608X Extreme Series Tilting Spindle Shaper
Motor & Spindle Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
51 P0608X051 SHAFT 99 P0608X099 PLATE
52 PEC04M E-CLIP 13MM 100 P0608X100 FLEXIBLE HOSE 10"
53 PN13M HEX NUT M16-2 101 P0608X101 FLEXIBLE HOSE 4"
54 P0608X054 BEARING 3047 102 P0608X102 DUST HOOD
55 P0608X055 WORM GEAR BRASS 103 P0608X103 TILTING BASE SUPPORT HOUSING
56 P0608X056 BEARING 3047 104 P0608X104 LEFT TILTING BASE
57 P0608X057 WORM GEAR HOUSING 105 P0608X105 SPECIAL RETAINING SCREW
58 P6002 BALL BEARING 6002ZZ 106 P0608X106 SPECIAL LOCKING NUT
59 PR29M INT RETAINING RING 32MM 107 P0608X107 SUPPORT PLATE
60 P0608X060 WORM GEAR 108 P0608X108 RETAINING BOLT
61 P0608X061 COUPLER 109 P0608X109 WORM GEAR SUPPORT
62 P0608X062 EXTENSION COUPLER 110 PB33M HEX BOLT M12-1.75 X 50
63 PSS01M SET SCREW M6-1 X 10 111 PN09M HEX NUT M12-1.75
64 PB04M HEX BOLT M6-1 X 10 112 P0608X112 MOTOR BASE
65 PSS01M SET SCREW M6-1 X 10 113 P0608X113 MOTOR PULLEY
66 PB04M HEX BOLT M6-1 X 10 114 PW06M FLAT WASHER 12MM
67 P6002 COUPLER 115 PB15M HEX BOLT M8-1.25 X 40
68 P6002 BALL BEARING 6002ZZ 116 PSB31M CAP SCREW M8-1.25 X 25
69 P0608X069 SUPPORT PLATE 117 PW01M FLAT WASHER 8MM
70 P0608X070 SHAFT 118 P0608X118 SPINDLE PULLEY
71 P6002 BALL BEARING 6002ZZ 119 P0608X119 LEVER 10-1.5 X 30
71-1 P0608X071-1 HEX NUT 15-1.5 120 PW04M FLAT WASHER 10MM
72 P0608X072 HANDWHEEL 121 P0608X121 BELT TENSIONING BAR
73 PSBS23M BUTTON HD CAP SCR M8-1.25 X 25 122 P0608X122 COMPRESSION SPRING
74 P0608X074 KNOB M8-1.25 X 120 123 P0608X123 PIN
75 PN08 HEX NUT 3/8-16 124 P0608X124 SUPPORT ARM
76 P0608X076 HANDLE 125 PB161M HEX BOLT M6-1 X 70
77 P0608X077 MOTOR, 7.5HP, 220/440V, 60HZ 126 PB45M HEX BOLT M8-1.25 X 100
77-1 P0608X077-1 MOTOR FAN COVER 127 P0608X127 LOCKING WIRE
77-2 P0608X077-2 MOTOR FAN 128 P0608X128 LOCKING PIN
77-3 P0608X077-3 MOTOR JUNCTION BOX 129 PVA40 V-BELT A-40 4L400
77-4 P0608X077-4 MOTOR WIRING HARNESS 130 P0608X130 CUTTER SHAFT ASSEMBLY
78 P0608X078 HANDLE 130-1 P6206 BALL BEARING 6206ZZ
79 PN08 HEX NUT 3/8-16 130-2 PR38M INT RETAINING RING 62MM
80 P0608X080 TILT DIAL 130-3 P0608X130-3 QUILL
81 P0608X081 KNOB M8-1.25 X 120 130-4 P0608X130-4 BALL BEARING 6210ZZ
82 PSBS23M BUTTON HD CAP SCR M8-1.25 X 25 130-5 P0608X130-5 INT RETAINING RING 90MM
83 P0608X083 HANDWHEEL 130-6 P0608X130-6 DUST COVER
84 P0608X084 HEX NUT M15-1.5 130-7 PSB31M CAP SCREW M8-1.25 X 25
85 P6002 BALL BEARING 6002ZZ 130-8 PW01M FLAT WASHER 8MM
86 P0608X086 SHAFT 130-9 P0608X130-9 KEY 8 X 7 X 35
87 P0608X087 SUPPORTING PLATE 130-10 P0608X130-10 SPINDLE CARTRIDGE
88 P6002 BALL BEARING 6002ZZ 130-11 P0608X130-11 SPINDLE SHAFT NUT
89 P0608X089 UNIVERSAL COUPLER 130-12 P0608X130-12 SPINDLE
90 P0608X090 KNOB 130-13 P0608X130-13 SPACER 15MM
91 P0608X091 SHAFT 130-14 P0608X130-14 SPACER 20MM
92 PSBS22M BUTTON HD CAP SCR M8-1.25 X 20 130-15 P0608X130-15 SPACER 25MM
93 P0608X093 SHAFT SUPPORT 130-16 P0608X130-16 SPACER 30MM
94 P0608X094 WORM GEAR 130-17 P0608X130-17 SPACER 35MM
95 P0608X095 FENDER WASHER 8 ID X 30MM OD 130-18 P0608X130-18 SHAFT NUT
96 P0608X096 WORM GEAR 130-19 PW06M FLAT WASHER 12MM
97 PN32M HEX NUT M14-2 130-20 PB25M HEX BOLT M12-1.75 X 25
98 P0608X098 RIGHT TILTING BASE

G0608X Extreme Series Tilting Spindle Shaper -49-
Label Placement
REF PART # DESCRIPTION REF PART # DESCRIPTION
145 P0608X145 MACHINE ID LABEL 152 PLABEL-14 ELECTRICITY LABEL
146 P0608X146 DISCONNECT POWER LABEL 153 P0608X153 OUTLET HORIZ LABEL
147 P0608X147 EXTREME SERIES LOGO 10 X 3-1/4 154 P0608X154 CUTTER HORIZ LABEL
148 G8589 GRIZZLY LOGO 10-3/4 X 5-1/4 155 P0608X155 ENTANGLEMENT HORIZ LABEL
149 P0608X149 G0608X LABEL 156 P0608X156 DISCONNECT HORIZ LABEL
150 P0608X150 READ HORIZ LABEL 158 PPAINT-1 GRIZZLY GREEN TOUCH UP PAINT
151 P0608X151 GLASS-RESP HORIZ LABEL 159 PPAINT-11 GRIZZLY PUTTY TOUCH UP PAINT
Safety labels warn about machine hazards and ways to prevent injury. The owner of this machine
MUST maintain the original location and readability of the labels on the machine. If any label is
removed or becomes unreadable, REPLACE that label before using the machine again. Contact
Grizzly at [phone] or www.grizzly.com to order new labels.
145
148
149
150
151
155
156
152
146
153
154
Rear View Top View
147
