Grizzly G0945 User manual

WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE

OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.

#KS21841 PRINTED IN TAIWAN V1. 07. 2 1

MODEL G0945/G0946/G0947

6" & 8" BENCHTOP JOINTERS

OWNER'S MANUAL

(For models manufactured since 06/21)

(G0946)

(G0945)

(G0947)

This manual provides critical safety instructions on the proper setup,

operation, maintenance, and service of this machine/tool. Save this

document, refer to it often, and use it to instruct other operators.

Failure to read, understand and follow the instructions in this manual

may result in fire or serious personal injury—including amputation,

electrocution, or death.

The owner of this machine/tool is solely responsible for its safe use.

This responsibility includes but is not limited to proper installation in

a safe environment, personnel training and usage authorization,

proper inspection and maintenance, manual availability and compre-

hension, application of safety devices, cutting/sanding/grinding tool

integrity, and the usage of personal protective equipment.

The manufacturer will not be held liable for injury or property damage

from negligence, improper training, machine modifications or misuse.

Some dust created by power sanding, sawing, grinding, drilling, and

other construction activities contains chemicals known to the State

of California to cause cancer, birth defects or other reproductive

harm. Some examples of these chemicals are:

• Lead from lead-based paints.

• Crystalline silica from bricks, cement and other masonry products.

• Arsenic and chromium from chemically-treated lumber.

Your risk from these exposures varies, depending on how often you

do this type of work. To reduce your exposure to these chemicals:

Work in a well ventilated area, and work with approved safety equip-

ment, such as those dust masks that are specially designed to filter

out microscopic particles.

Table of Contents

INTRODUCTION............................................... 2

Contact Info.................................................... 2

Manual Accuracy ........................................... 2

Identification ................................................... 3

Controls & Components ................................. 4

G0945 Machine Data Sheet .......................... 5

G0946 Machine Data Sheet .......................... 7

G0947 Machine Data Sheet .......................... 9

SECTION 1: SAFETY..................................... 11

Safety Instructions for Machinery ................ 11

Additional Safety for Jointers ....................... 13

SECTION 2: POWER SUPPLY ...................... 14

SECTION 3: SETUP ....................................... 16

Needed for Setup ......................................... 16

Unpacking .................................................... 16

Inventory ...................................................... 17

Cleanup ........................................................ 18

Site Considerations ...................................... 18

Bench Mounting ........................................... 19

Assembly ..................................................... 19

Dust Collection ............................................. 21

Test Run ...................................................... 22

SECTION 4: OPERATIONS ........................... 23

Operation Overview ..................................... 23

Stock Inspection........................................... 24

Setting Depth of Cut .................................... 25

Squaring Stock............................................. 26

Surface Planing............................................ 27

Edge Jointing ............................................... 28

Bevel Cutting................................................ 29

SECTION 5: ACCESSORIES ......................... 30

SECTION 6: MAINTENANCE......................... 32

Schedule ...................................................... 32

Cleaning & Protecting .................................. 32

Lubrication ................................................... 32

SECTION 7: SERVICE ................................... 33

Troubleshooting ........................................... 33

Rotating/Replacing Inserts (G0946/G0947) . 36

Checking/Setting Knives (G0945) ................ 37

Checking/Adjusting Table Parallelism ......... 39

Checking/Adjusting Extension Parallelism

(G0947) ........................................................ 43

Checking/Adjusting Fence Positive Stops ... 44

Replacing/Tensioning Belt ............................ 46

Replacing Motor Brushes ............................ 47

SECTION 8: WIRING...................................... 48

Wiring Safety Instructions ............................ 48

Wiring Diagram ............................................ 49

SECTION 9: PARTS....................................... 50

G0945 Main ................................................. 50

G0946 Main ................................................. 52

G0947 Main ................................................. 54

Labels & Cosmetics ..................................... 56

WARRANTY & RETURNS ............................. 57

We stand behind our machines! If you have ques-

tions or need help, contact us with the information

below. Before contacting, make sure you get the

serial number

and manufacture date from the

machine ID label. This will help us help you faster.

Grizzly Technical Support

1815 W. Battlefield

Springfield, MO 65807

Phone: (570) 546-9663

Email: [email protected]

We want your feedback on this manual. What did

you like about it? Where could it be improved?

Please take a few minutes to give us feedback.

Grizzly Documentation Manager

P.O. Box 2069

Bellingham, WA 98227-2069

Email: [email protected]

Contact Info

We are proud to provide a high-quality owner’s

manual with your new machine!

made every effort to be exact with the

instruc-

tions, specifications, drawings, and photographs

in this manual. Sometimes we make mistakes, but

our policy of continuous improvement also means

that

sometimes the machine

you receive is

slightly different than shown in the manual

If you find this to be the case, and the difference

between the manual and machine leaves you

confused or unsure about something

check our

website for an updated version. W

e post

current

manuals and

manual updates for free

on our web-

site at

www.grizzly.com.

Alternatively, you can call our Technical Support

for help. Before calling, make sure you write

down the

manufacture date and

serial number

from the machine ID label (see below). This

information is required for us to provide proper

tech support, and it helps us determine if updated

documentation is available for your machine.

Manufacture Date

Serial Number

Manual Accuracy

-2- Model G0945/G0946/G0947 (Mfd. Since 06/21)

INTRODUCTION

For Your Own Safety Read Instruction Manual Before Operating Jointer

a) Wear eye protection.

b) Always keep cutterhead and drive guards in place and in proper operating condition.

c) Never cut deeper than 1⁄8" in one pass.

d) Always use hold-down or push blocks when jointing material narrower than 3" or planing

material thinner than 3".

e) Never perform cuts on pieces shorter than 10" in length.

Model G0945/G0946/G0947 (Mfd. Since 06/21) -3-

Identification

Become familiar with the names and locations of the controls and features shown below to better understand

the instructions in this manual.

Fence

Outfeed

Table

Fence Tilt Lock Handle ON/OFF Paddle Switch

w/Removable Key

Infeed Table

Adjustment Knob

Table Height

Lock Knob

Infeed

Table

Table Leveling

Adjuster (1 of 8)

Cutterhead Guard

Fence Slide

Lock Handle

Belt

Cover

Fence Support

Bracket

Foot Pad

(1 of 4)

21⁄2" Dust

Port

Fence Slide

Bracket

Depth-of-Cut Scale

Cutterhead Rotation

Guide (G0946/G0947)

Cutterhead Lock

(G0945)

Mounting

Hole

(1 of 4)

Infeed/Outfeed

Table Extension

(G0947)

To reduce your risk of

serious injury, read this

entire manual BEFORE

using machine.

Figure 1. Main components.

Figure 2. Fence components.

-4- Model G0945/G0946/G0947 (Mfd. Since 06/21)

Controls &

Components

Main Components

Refer to the following figures and descriptions to

become familiar with the basic controls and com-

ponents of this machine. Understanding these

items and how they work will help you understand

the rest of the manual and minimize your risk of

injury when operating this machine.

A. Outfeed Table: Supports workpiece after it

passes over cutterhead.

B. Cutterhead Guard: Covers cutterhead until

pushed aside by workpiece during operation.

When workpiece leaves cutterhead, guard

springs back to its starting position. DO NOT

operate jointer if guard is not functioning

properly.

C. Infeed Table: Supports workpiece before it

reaches cutterhead. Height of infeed table

relative to cutterhead determines depth of

cut.

D. Infeed Table Adjustment Knob: Adjusts

height of infeed table to control depth of cut.

E. Table Height Lock Knob: Tighten to secure

infeed table position; loosen for making

table adjustments.

F. ON/OFF Paddle Switch w/Removable Key:

Turns motor ON when moved up; turns

motor OFF when pressed down. Removal of

yellow key disables switch, preventing motor

operation.

G. Depth-of-Cut Scale: Shows depth of cut

(per pass).

H. Infeed/Outfeed Table Extensions (G0947):

Supports large workpieces beyond the length

of the infeed/outfeed tables.

Fence & Support Components

I. Fence: Supports workpiece laterally as it

moves across cutterhead; determines angle

of cut when edge or bevel joining.

J. Fence Bracket Assembly: Changes posi-

tion of fence relative to tables and secures it

in position during operation.

K. Dust Port: Connects machine to dust col-

lection system. ALWAYS remove dust port if

operating machine without dust collection!

L. Fence Slide Lock Handle: Adjusts position

of fence over tables. ALWAYS tighten lock

before beginning operations.

M. Fence Tilt Lock Handle: Secures fence tilt

angle. Fence tilt can be adjusted between

90º–135º. ALWAYS tighten lock before begin-

ning operations.

The information contained herein is deemed accurate as of 7/25/2021 and represents our most recent product specifications.

Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 1 OF 2

Model G0945

MACHINE DATA

SHEET

Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901

MODEL G0945 6" BENCHTOP JOINTER

Product Dimensions:

Weight................................................................................................................................................................ 43 lbs.

Width (side-to-side) x Depth (front-to-back) x Height..................................................................... 30 x 17-1/2 x 13 in.

Footprint (Length x Width)....................................................................................................................... 19 x 9-1/2 in.

Shipping Dimensions:

Type..................................................................................................................................................... Cardboard Box

Content........................................................................................................................................................... Machine

Weight................................................................................................................................................................ 44 lbs.

Length x Width x Height....................................................................................................................... 33 x 13 x 12 in.

Electrical:

Power Requirement........................................................................................................... 120V, Single-Phase, 60 Hz

Full-Load Current Rating........................................................................................................................................ 10A

Minimum Circuit Size.............................................................................................................................................. 15A

Connection Type....................................................................................................................................... Cord & Plug

Power Cord Included.............................................................................................................................................. Yes

Power Cord Length.............................................................................................................................................. 72 in.

Power Cord Gauge......................................................................................................................................... 18 AWG

Plug Included.......................................................................................................................................................... Yes

Included Plug Type................................................................................................................................................ 5-15

Switch Type.................................................................................................. Paddle Safety Switch w/Removable Key

Motors:

Main

Horsepower.......................................................................................................................................... 1-1/2 HP

Phase............................................................................................................................................ Single-Phase

Amps............................................................................................................................................................ 10A

Speed............................................................................................................................................. 19,000 RPM

Type..................................................................................................................................................... Universal

Power Transfer ............................................................................................................................................ Belt

Bearings..................................................................................................... Shielded & Permanently Lubricated

Main Specifications:

Main Specifications

Jointer Size.................................................................................................................................................. 6 in.

Bevel Jointing.................................................................................................................................... 0 - 45 deg.

Maximum Width of Cut................................................................................................................................ 6 in.

Maximum Depth of Cut............................................................................................................................. 1/8 in.

Minimum Workpiece Length...................................................................................................................... 10 in.

Minimum Workpiece Thickness................................................................................................................ 1/2 in.

Number of Cuts Per Minute..................................................................................................................... 24,000

Fence Information

Fence Length....................................................................................................................................... 19-3/4 in.

Fence Width.............................................................................................................................................. 7/8 in.

Fence Height....................................................................................................................................... 4-5/16 in.

Model G0945/G0946/G0947 (Mfd. Since 06/21) -5-

The information contained herein is deemed accurate as of 7/25/2021 and represents our most recent product specifications.

Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 2 OF 2

Model G0945

Cutterhead Information

Cutterhead Type........................................................................................................................... Straight Knife

Cutterhead Diameter............................................................................................................................. 1-7/8 in.

Cutterhead Speed.......................................................................................................................... 12,000 RPM

Knife Information

Number of Knives............................................................................................................................................. 2

Knife Type.................................................................................................................... SK5 Steel, Single-Sided

Knife Length.......................................................................................................................................... 6-1/4 in.

Knife Width............................................................................................................................................... 7/8 in.

Knife Thickness...................................................................................................................................... 1/16 in.

Knife Adjustment............................................................................................................................. Cap Screws

Table Information

Table Length.............................................................................................................................................. 30 in.

Table Width........................................................................................................................................... 6-1/4 in.

Table Thickness........................................................................................................................................... 1 in.

Floor to Table Height........................................................................................................................... 8-5/16 in.

Table Adjustment Type.............................................................................................................................. Knob

Table Movement Type.............................................................................................................................. Swing

Construction

Body Assembly...................................................................................................................... Pre-Formed Steel

Fence Assembly.................................................................................................................. Extruded Aluminum

Guard.......................................................................................................................................... Stamped Steel

Table.......................................................................................................................................... Cast Aluminum

Paint Type/Finish.................................................................................................................................... Enamel

Other Information

Number of Dust Ports....................................................................................................................................... 1

Dust Port Size........................................................................................................................................ 2-1/2 in.

Other Specifications:

Country of Origin .............................................................................................................................................. Taiwan

Warranty ........................................................................................................................................................... 1 Year

Approximate Assembly & Setup Time ........................................................................................................ 20 Minutes

Serial Number Location ................................................................................................................... Machine ID Label

Sound Rating .............................................................................................................................................. 90 - 92 dB

ISO 9001 Factory .................................................................................................................................................. Yes

Certified by a Nationally Recognized Testing Laboratory (NRTL) ......................................................................... Yes

Features:

Straight-Knife Cutterhead with Two SK5 Steel Knives

2-1/2" Dust Port

Cast Aluminum Infeed and Outfeed Tables

Infeed Table Height Adjustment Lock

Accessories Included:

Two Safety Push Blocks

Torx T-25 T-Handle Driver

Hex Wrenches 2.5, 4mm

-6- Model G0945/G0946/G0947 (Mfd. Since 06/21)

The information contained herein is deemed accurate as of 7/25/2021 and represents our most recent product specifications.

Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 1 OF 2

Model G0946

MACHINE DATA

SHEET

Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901

MODEL G0946 6" BENCHTOP JOINTER WITH SPIRAL

CUTTERHEAD

Product Dimensions:

Weight................................................................................................................................................................ 43 lbs.

Width (side-to-side) x Depth (front-to-back) x Height............................................................... 30 x 17-1/2 x 13-1/2 in.
