-34- G0610 Dovetail Machine














 

  





















Table Parts Breakdown

G0610 Dovetail Machine -35-
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0610001 HUB 22 PSB40M CAP SCREW M8-1.25 X 35
2 PK42M KEY 6 X 6 X 30 23 P0610023 CLAMPING SEAT
3 P0610003 ECCENTRIC WHEEL 24 P0610024 GUIDE ROD
4 P0610004 SLIDING ROD 25 PSB14M CAP SCREW M8-1.25 X 20
5 P0610005 CLAMP SCALE R-L 26 P0610026 ADJUSTMENT PLATE
6 P0610006 EYE BOLT M10-1.5 X 15 27 P0610027 SPRING KEY
7 P0610007 WORK TABLE 28 P0610028 LOCKING HANDLE M8-1.25 X 35
8 PSB02M CAP SCREW M6-1 X 20 29 PSS06M SET SCREW M8-1.25 X 16
9 PW03M FLAT WASHER 6MM 30 P0610030 SCALE
10 P0610010 BUFFER PAD 31 PSB31M CAP SCREW M8-1.25 X 25
11 PLW04M LOCK WASHER 8MM 32 PW01M FLAT WASHER 8MM
12 PSB13M CAP SCREW M8-1.25 X 30 33 PB09M HEX BOLT M8-1.25 X 20
13 P0610013 ADJUSTMENT SCREW 34 P0610034 BUFFER PAD
14 P0610014 ADJUSTMENT NUT 35 P0610035 FENCE BASE
15 P0610015 BUFFER PAD 36 P0610036 LOCKING HANDLE M8-1.25 X 25
16 P0610016 FENCE BASE 37 P0610037 LOCKING HANDLE M8-1.25 X 45
17 P0610017 MICRO-ADJUSTMENT SEAT 38 P0610038 WING SCREW M6-1 X 35
18 P0610018 SLIDING ROD 39 P0610039 COPYING TEMPLATE
19 PSS04M SET SCREW M6-1 X 12 40 PN09M HEX NUT M12-1.75
20 P0610020 CLAMP SCALE L-R 41 P0610041 LEVER
21 P0610021 ECCENTRIC WHEEL 42 P0610042 HANDLE KNOB M12-1.75 X 82
Table Parts List

-36- G0610 Dovetail Machine

















































 























Headstock Parts Breakdown

G0610 Dovetail Machine -37-
REF PART # DESCRIPTION REF PART # DESCRIPTION
101 P0610101 MOTOR 1HP, 110V/220V, 1-PH 129 P0610129 GUIDE ROD 16 X 459MML
101-1 P0610101-1 MOTOR FAN COVER 130 P0610130 LINEAR BUSHING 25UU
101-2 P0610101-2 MOTOR FAN 131 P0610131 SEAL 25 X 40 X 7 X 2
101-4 P0610101-4 CAPACITOR 300MFD 250VAC 132 PR23M INT RETAINING RING 40MM
101-6 P0610101-6 CAPACITOR 30MFD 250VAC 133 P0610133 CUTTER
101-7 P0610101-7 MOTOR JUNCTION BOX 134 P0610134 GUIDE ROD 25 X 599MML
102 P0610102 CABLE TIE CLAMP 135 P0610135 FLEXIBLE HOSE 2.5" X 53"
103 PSB40M CAP SCREW M8-1.25 X 35 136 P0610136 HOSE CLAMP 2-3/4"
104 PW01M FLAT WASHER 8MM 137 P0610137 CARRIAGE
105 P0610105 CAP SCREW M8-1.25 X 100 138 PZERK2 GREASE FITTING M6-1 x 5
106 P0610106 SPINDLE SLIDE SEAT 139 P0610139 GUARD
107 PN06M HEX NUT M5-.8 139-1 P0610139-1 BOTTOM GUARD BRUSH
108 PSB79M CAP SCREW M5-.8 X 35 139-2 P0610139-2 SIDE GUARD BRUSH
109 PSB15M CAP SCREW M5-.8 X 20 140 P0610140 HEX BOLT M10-1.5 X 185
110 P0610110 SPRING 141 PN02M HEX NUT M10-1.5
111 P0610111 MOTOR BRACKET 142 PW04M FLAT WASHER 10MM
112 P0610112 MOTOR PULLEY 143 P0610143 PANEL
113 PSS53M SET SCREW M5-.8 X 12 144 P0610144 PLUG 22MM
114 P0610114 FLAT BELT 670 X 25 145 P0610145 WINDOW
115 PW03M FLAT WASHER 6MM 146 PS17M PHLP HD SCR M4-.7 X 6
116 PSB02M CAP SCREW M6-1 X 20 147 PSB66M CAP SCREW M8-1.25 X 65
117 P0610117 FIXING NUT 148 P0610148 BUSHING
118 P0610118 BEARING 60005TB.P63 149 P0610149 CLAMPING PIECE
119 P0610119 SPRING AK6005 150 P0610150 GEAR SHAFT
120 P0610120 SPACER 151 PB03M HEX BOLT M8-1.25 X 16
121 PSS07M SET SCREW M5-.8 X 5 152 P0610152 SPONGE COATING
122 P0610122 SPINDLE BEARING HOUSING 153 P0610153 HANDLE
122A P0610122A SPINDLE ASSEMBLY 154 P0610154 ADJUSTMENT SCREW
123 P0610123 FIXING NUT 155 P0610155 TRACER PIN
124 P0610124 ECCENTRIC SPINDLE 156 P0610156 WING SCREW M6-1 X 20
125 PSS16M SET SCREW M8-1.25 X 10 157 P0610157 PLUG 30MM
126 P0610126 LINEAR BUSHING 16UU 158 P0610158 MOTOR CORD
127 P0610127 SEAL 16 X 28 X 7 X 3 159 PW02M FLAT WASHER 5MM
128 PR20M INT RETAINING RING 28MM 160 P0610160 WING SCREW M5-.8 X 15
Headstock Parts List

-38- G0610 Dovetail Machine
















Stand Parts Breakdown

G0610 Dovetail Machine -39-
REF PART # DESCRIPTION
201 P0610201 ON/OFF PUSH BUTTON SWITCH
202 PS52M PHLP HD SCR M4-.7 X 20
203 PSB01M CAP SCREW M6-1 X 16
204 PW03M FLAT WASHER 6MM
205 P0610205 CABLE TIE CLAMP
206 P0610206 POWER CORD W/PLUG
207 P0610207 SWITCH BOX
208 PSB58M CAP SCREW M8-1.25 X 12
209 PSB40M CAP SCREW M8-1.25 X 35
210 PLW04M LOCK WASHER 8MM
211 PSS05M SET SCREW M5-.8 X 10
212 P0610212 DUST PORT 4"
213 P0610213 CABINET
214 P0610214 DOOR LINER BOARD
215 P0610215 DOOR
216 P0610216 DOOR LOCK
217 PHTEK26M TAP SCREW M5 X 10
Stand Parts List

-40- G0610 Dovetail Machine


 










Labels Parts Breakdown
Safety labels warn about machine hazards and ways to prevent injury. The owner of this machine
MUST maintain the original location and readability of the labels on the machine. If any label is
removed or becomes unreadable, REPLACE that label before using the machine again. Contact
Grizzly at [phone] or www.grizzly.com to order new labels.
REF PART # DESCRIPTION REF PART # DESCRIPTION
301 P0610143 CONTROL PANEL LABEL 308 P0610308 MACHINE ID LABEL
302 P0610302 TAIL SHORTER LABEL 309 P0610309 DISCONNECT POWER LABEL
303 P0610303 TAIL LONGER LABEL 310 PPAINT-1 "GRIZZLY GREEN" TOUCH-UP PAINT
304 P0610304 MOTOR LABEL 311 G8588 GRIZZLY LOGO PLATE
305 PLABEL-14 ELECTRICITY LABEL 312 P0610312 G0610 MODEL NUMBER LABEL
306 P0610306 EYEBOLT NOTICE LABEL 313 PLABEL-12A READ MANUAL LABEL
307 PPAINT-14 "PUTTY" TOUCH-UP PAINT 314 P0610314 GREASE SPINDLE LABEL


 










