Groen BPM-15EC/EA User manual

PART NUMBER 177366, REV. B (10/20)
This manual provides information for:
ERGONOMIC TILTING BRAISING PAN
MODELS BPM-15/30/40E(C,A)
(CE) INTERNATIONAL
EQUIPMENT DESCRIPTION
The BPM is a stainless steel, electrically heated Braising Pan which is equipped
with integrated heating elements, a hand operated tilting mechanism,
electronic controls and a hinged cover. The Braising Pan serves as a braising
unit, griddle, fry pan, oven, kettle, bain-marie, or food warmer and server. It
can also be adapted for use as a non-pressure steamer.
The pan body is constructed of heavy-duty stainless steel, welded into a solid
piece. It has a polished interior and exterior finish. A pouring lip is welded
to the top of the front wall. The cooking surface is a stainless steel clad
plate fitted with clamped-on electrical heating elements. The elements are
positioned to ensure uniform heat transfer over the entire surface.
Pans are mounted on an open-leg frame which is fabricated from tubular
stainless steel.
An easily operated worm and gear mechanism tilts the pan body and provides
precise control for pouring or dumping its contents. This tilting mechanism
is located in a stainless steel console to right of the pan body. To facilitate
cleaning, the pan body can be tilted past the vertical position.
Heating elements and other electrical components are enclosed for safety. The
temperature controller, heating indicator light and tilting switch are contained
in a compact control console which is mounted to the right of the pan body.
The temperature controller provides automatic control of cooking temperature.
Turning the temperature dial starts and stops heating and sets the pan
temperature. Only one electrical connection is required to install the unit.
A heavy gauge, one-piece, stainless steel cover with a rear condensate drip shield on
the underside is standard on the braising pan. A fully enclosed torsion bar-type counter-
balance provides easy operation to open the cover to maintain it open at any position.
The cover opens to the back. It is hinged to the frame, so it moves independently from
the pan body.
The following sizes and options are available:
Model
PAN DIMENSIONS
Tilt
Left to Right Front to Rear Depth
BPM-15EC/EA 18-1/8” (460mm) 28-1/4” (718mm) 8” (203mm) Manual
BPM-30EC/EA 26-1/4” (667mm) 28-1/4” (718mm) 10” (254mm) Manual
BPM-40EC/EA 35-3/4” (908mm) 28-1/4” (718mm) 10” (254mm) Manual
Options/accessories available with these models are:
1. Fill faucet with swing spout, left or right mounted - specify single or double pantry
2. Fill faucet with 48” (1219 mm) or 60” (1524 mm) spray hose assembly, left or right
mounted - specify single or double pantry
3. Caster mounting kit
4. Flanged Feet
5. 2” (51 mm) Tangent draw-off (Factory-installed must be indicated on initial order)
6. Steamer Insert set
REFERENCES
NFPA/70 - The National Electrical Code
NSF/ANSI - Standard 4
UL/ANSI - Standard 197
NATIONAL FIRE PROTECTION ASSOCIATION
60 Battery March Park
Quincy, Massachusetts 02269
NSF INTERNATIONAL
789 N. Dixboro Road
P.O. Box 130140
Ann Arbor, Michigan 48113-0140
UNDERWRITERS LABORATORIES, INC.
333 Pfingsten Road
Northbrook, Illinois 60062
OPERATOR MANUAL
IMPORTANT INFORMATION, KEEP FOR OPERATOR
2016 Gees Mill Road, Suite 200, Conyers, GA 30013
888-994-7636, fax [phone]
unifiedbrands.net
THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ,
UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS
CONTAINED IN THIS MANUAL.
FOR YOUR SAFETY Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
WARNING Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death. Read the
installation, operating and maintenance instructions thoroughly before
installing or servicing this equipment.
NOTIFY CARRIER OF DAMAGE AT ONCE It is the responsibility of the
consignee to inspect the container upon receipt of same and to determine
the possibility of any damage, including concealed damage. Unified
Brands suggests that if you are suspicious of damage to make a notation
on the delivery receipt. It will be the responsibility of the consignee to file
a claim with the carrier. We recommend that you do so at once.
Manufacture Service/Questions 888-994-7636.
Information contained in this document is known to be current and accurate at the time of printing/creation. Unified Brands recommends
referencing our product line websites, unifiedbrands.net, for the most updated product information and specifications. © 2019 Unified Brands.
All Rights Reserved. Unified Brands is a wholly-owned subsidiary of Dover Corporation.

2 OM-BPM-15/30/40E(C,A) (CE) INTERNATIONAL
IMPORTANT - READ FIRST - IMPORTANT
WARNING: TO PREVENT SHOCKS, ALL APPLIANCES WHETHER GAS OR ELECTRIC,
MUST BE EARTHED.
ON COMPLETION OF THE INSTALLATION, THESE INSTRUCTIONS SHOULD
BE LEFT WITH THE ENGINEER-IN-CHARGE FOR REFERENCE DURING
SERVICING. FURTHER TO THIS, THE USERS INSTRUCTIONS SHOULD
BE HANDED TO THE USERS AND THE INSTALLER SHOULD INSTRUCT
THE RESPONSIBLE PERSON(S) IN THE CORRECT OPERATION AND
MAINTENANCE OF THE APPLIANCE. EMPHASIS SHOULD BE MADE WITH
REGARD TO SAFE OPERATION OF DRAIN VALVE.
IT IS MOST IMPORTANT THAT THESE INSTRUCTIONS BE CONSULTED
BEFORE INSTALLING AND COMMISSIONING THE APPLIANCE. FAILURE TO
COMPLY WITH THE SPECIFIED PROCEDURES MAY RESULT IN DAMAGE OR
THE NEED FOR A SERVICE CALL.
CAUTION: SHIPPING STRAPS ARE UNDER TENSION AND CAN SNAP BACK WHEN CUT.
WARNING: DISCONNECT POWER BEFORE SERVICING. FAILURE TO DISCONNECT
COULD RESULT IN ELECTROCUTION AND DEATH.
CAUTION: UNIT WEIGHS 420 TO 560 LB. (191 TO 255 KG). FOR SAFE HANDLING,
INSTALLER SHOULD OBTAIN HELP AS NEEDED, OR EMPLOY APPROPRIATE
MATERIALS HANDLING EQUIPMENT (SUCH AS A FORKLIFT, DOLLY, OR
PALLET JACK) TO REMOVE THE UNIT FROM THE SKID AND MOVE IT TO THE
PLACE OF INSTALLATION.
WARNING: INSTALLATION OF THE BRAISING PAN MUST BE DONE BY PERSONNEL
QUALIFIED TO WORK WITH ELECTRICITY. IMPROPER INSTALLATION CAN
RESULT IN INJURY TO PERSONNEL AND/OR DAMAGE TO EQUIPMENT.
DANGER: ELECTRICALLY GROUND THE UNIT AT THE TERMINAL PROVIDED. FAILURE
TO GROUND UNIT COULD RESULT IN ELECTROCUTION AND DEATH.
CAUTION: BE SURE ALL OPERATORS READ, UNDERSTAND AND FOLLOW THE
OPERATING INSTRUCTIONS, CAUTIONS AND SAFETY INSTRUCTIONS
CONTAINED IN THIS MANUAL.
CAUTION: THE BRAISING PAN IS NOT INTENDED FOR USE AS A DEEP-FAT FRYER.
SHALLOW-FRYING IS PERMISSIBLE AS LONG AS THE OIL LEVEL DOES
NOT EXCEED THE HEIGHT MARK ON THE LOWER REAR WALL (2”, 50MM
MAXIMUM). SEE THE USER INSTRUCTIONS SECTION FOR SPECIFIC DETAILS.
CAUTION: KEEP FLOORS IN BRAISING PAN WORK AREA CLEAN AND DRY. IF SPILLS
OCCUR, CLEAN IMMEDIATELY TO AVOID THE DANGER OF SLIPS OR FALLS.
WARNING: WHEN TILTING BRAISING PAN FOR PRODUCT TRANSFER: 1) USE CONTAINER
DEEP ENOUGH TO CONTAIN AND MINIMIZE PRODUCT SPLASHING. 2) PLACE
CONTAINER ON STABLE, FLAT SURFACE, AS CLOSE TO PAN AS POSSIBLE.
3) STAND TO SIDE OF PAN WHILE POURING — NOT DIRECTLY IN POUR
PATH OF HOT CONTENTS. 4) RETURN PAN BODY TO LEVEL POSITION AFTER
CONTAINER IS FILLED OR TRANSFER IS COMPLETE. 5) DO NOT OVERFILL
CONTAINER, AVOIDING DIRECT SKIN CONTACT WITH HOT CONTAINER AND
ITS CONTENTS.
INSPECTION & UNPACKING
CAUTION: SHIPPING STRAPS ARE UNDER TENSION AND CAN SNAP BACK WHEN CUT.
CAUTION: UNIT WEIGHS 420 TO 560 LB (190 TO 255KG). FOR SAFE HANDLING,
INSTALLER SHOULD OBTAIN HELP AS NEEDED, OR EMPLOY APPROPRIATE
MATERIALS HANDLING EQUIPMENT (SUCH AS A FORKLIFT, DOLLY, OR
PALLET JACK) TO REMOVE THE UNIT FROM THE SKID AND MOVE IT TO THE
PLACE OF INSTALLATION.
The unit will arrive completely assembled, wrapped in protective plastic on a heavy
skid, in a heavy wooden crate. Immediately upon receipt, inspect the crate for
damage. Report any apparent shipping damage or an incorrect shipment to the
delivery agent.
When installation is to begin, get someone to assist in removing the crate. Lift it
straight up and away from the unit. Write down the model number, serial number,
and installation date of your unit, and keep this information for future reference.
Space for these entries is provided at the top of the Service Log in this manual.
WARNING: DO NOT HEAT EMPTY PAN FOR MORE THAN 5 MINUTES AT A SETTING HIGHER
THAN 300ºF (149ºC).
WARNING: IF THE PAN CONTAINS ITEMS IN HOT LIQUIDS SUCH AS SAUCE OR MELTED FAT,
THEY CAN SLIDE FORWARD SUDDENLY DURING TILTING AND CAUSE THE HOT
LIQUID TO SPLASH OUT.
WARNING: AVOID ALL DIRECT CONTACT WITH HOT FOOD PRODUCT OR WATER IN THE
PAN. DIRECT CONTACT COULD RESULT IN SEVERE BURNS.
WARNING: IT IS RECOMMENDED THAT WATER AND SOLUTIONS BE KEPT OUT OF
CONTROLS. DO NOT USE WATER JET SPRAY, HIGH PRESSURE HOSE OR STEAM
DIRECTLY ON THE CONTROL CONSOLE AND ELECTRICAL CONNECTIONS.
CAUTION: MOST CLEANERS ARE HARMFUL TO THE SKIN, EYES, MUCOUS MEMBRANES
AND CLOTHING. PRECAUTIONS SHOULD BE TAKEN TO WEAR RUBBER GLOVES,
GOGGLES OR FACE SHIELD AND PROTECTIVE CLOTHING.CAREFULLY READ THE
WARNINGS AND FOLLOW THE DIRECTIONS ON THE LABEL OF THE CLEANER
TO BE USED. FAILURE TO DISCONNECT COULD RESULT IN ELECTROCUTION
AND DEATH.
WARNING: BEFORE REPLACING ANY PARTS, DISCONNECT THE UNIT FROM THE ELECTRIC
POWER SUPPLY.
CAUTION: USE OF ANY REPLACEMENT PARTS OTHER THAN THOSE SUPPLIED BY
AUTHORIZED DISTRIBUTORS CAN CAUSE INJURY TO THE OPERATOR AND
DAMAGE TO THE EQUIPMENT AND WILL VOID ALL WARRANTIES.
IMPORTANT : SERVICE PERFORMED BY OTHER THAN GROEN AUTHORIZED SERVICE AGENT
WILL VOID ALL WARRANTIES.
IMPORTANT: THIS APPLIANCE IS MARKED “CE” ON THE BASIS OF COMPLIANCE WITH EMC AND
LOW VOLTAGE DIRECTIVE.
WARNING: THIS UNIT IS INTENDED FOR USE IN THE COMMERCIAL HEATING, COOKING AND
HOLDING OF WATER AND FOOD PRODUCTS, PER THE INSTRUCTIONS CONTAINED
IN THIS MANUAL. THIS EQUIPMENT IS NOT FOR CONTINUOUS MASS PRODUCTION
OF FOOD PRODUCTS OR ANY OTHER USE COULD RESULT IN SERIOUS PERSONAL
INJURY OR DAMAGE TO THE EQUIPMENT AND WILL VOID WARRANTY.
WARNING: WHEN OPENING TANGENT DRAW-OFF (TDO) VALVE FOR PRODUCT TRANSFER:
1) USE CONTAINER DEEP ENOUGH TO CONTAIN AND MINIMIZE PRODUCT SPLASHING.
2) PLACE CONTAINER ON STABLE, FLAT SURFACE, AS CLOSE TO UNIT AS POSSIBLE.
3) DO NOT OVER FILL CONTAINER. AVOID DIRECT SKIN CONTACT WITH HOT
CONTAINER AND ITS CONTENTS.
CAUTION: THIS APPLIANCE IS NOT TO BE USED BY PERSONS (INCLUDING CHILDREN)
WITH REDUCED PHYSICAL, SENSORY or MENTAL CAPABILITIES, OR LACK OF
EXPERIENCE AND KNOWLEDGE, UNLESS THEY ARE SUPERVISED OR GIVEN
PROPER INSTRUCTIONS.
CAUTION: CHILDREN SUPERVISED ARE NOT TO PLAY WITH THIS APPLIANCE.
CAUTION: CLEANING AND USER MAINTENANCE SHALL NOT BE MADE BY CHILDREN
WITHOUT SUPERVISION.
7. Steamer pan carrier
8. Pouring lip strainer
9. Strainer for 2” (51 mm) TDO valve
Cut the straps holding the unit on the skid, and lift the unit straight up off the skid.
The unit ships strapped to a skid and crated. (Shown is a 40-gallon (151 lites) model
with optional 2” (51 mm) tangent draw-off).
Adjustable Bullet Feet
One Piece Cover
IPX6 Water Wash-
Down Rated Control
Console
Power
Switch
Indicator
Light
Manual Tilt
Handwheel
Standard Faucet
Bracket
2” Tangent Draw-Off

3 OM-BPM-15/30/40E(C,A) (CE) INTERNATIONAL
INSTALLATION
WARNING: THE UNIT MUST BE INSTALLED BY PERSONNEL WHO ARE QUALIFIED TO
WORK WITH ELECTRICITY AND PLUMBING. IMPROPER INSTALLATION CAN
CAUSE INJURY TO PERSONNEL AND/OR DAMAGE TO THE EQUIPMENT. THE
UNIT MUST BE INSTALLED IN ACCORDANCE WITH APPLICABLE CODES.
WARNING: ELECTRICALLY GROUND THE UNIT AT THE TERMINAL PROVIDED. FAILURE
TO GROUND UNIT COULD RESULT IN ELECTROCUTION AND DEATH. BEFORE
ANY ELECTRICAL CONVERSION,VERIFY THAT THE BRANCH CIRCUIT WIRING
IS ADEQUATE TO HANDLE ANY INCREASE IN AMPERAGE REQUIREMENTS.
REFER TO THE ELECTRICAL SPECIFICATIONS LISTED BELOW.
Figure 2Figure 1
Internal wiring for the Braising Pan is supplied complete. When you receive the
unit, it is ready for connection. A wiring diagram is located inside the control box
on the right side of the pan, as well as in this manual.
Your pan was performance-tested at the factory to confirm that all controls and
heating elements were functioning correctly.
Installation is as follows:
1. Set the unit in place and level it by turning the adjustable feet. Crank the pan
body to a completely horizontal position. Check levelness by placing a spirit
level on the bottom of the pan. The unit must be level to avoid uneven cooking
across the pan.
2. Make a waterproof connection with the incoming power line at the electrical
service entrance at the bottom of the connection box at rear of control console.
A BX connection is NOT recommended. ELECTRICALLY GROUND THE UNIT at
the proper terminal.
3. Provide the proper electrical supply as specified on the electrical information
plate. Comply with local codes and the National Electrical Code ANSI/NFPA
7- latest edition.
4. Use only copper wire, rated at least 75ºC and of proper gage. See chart below.
5. Standard equipment is shipped ready for 230V, 1-Phase or 480V, 3-phase
operation. Refer to the wiring diagram located on the inside cover of the control
box and the instructions below for conversion to single-phase operation.
6. Electrically protective earth ground the unit at the terminal provided (figure 1).
7. This unit is fitted with an equipotential terminal in accordance with national
regulations and CE directives. Locate this marking for equipotential terminal
connection (figure 2).
ELECTRICAL REQUIREMENTS
Use only copper wire rated for 75°C or higher; Gauge recommendations (AWG) are
for 25’ runs from the breaker box (if longer runs are required, increase wire size
accordingly).
Model
SINGLE PHASE 3-PHASE
KW
230
KW
240V
(NO NEUTRAL) KW
480V
(NEUTRAL)
Amps Wire
(AWG) Amps Wire (AWG) Amps Wire (AWG)
BPM-15EC/EA 7.0 30.6 8 7.6 18 10 7.0 9 12
BPM-30EC/EA 10.6 46 6 11.5 28 8 10.6 15.4 12
BPM-40EC/EA 14.1 61.1 4 15.3 37 8 14.1 19 10
INITIAL START-UP
WARNING: WATER IS EXTREMELY HOT AND CAN CAUSE SEVERE BURNS. AVOID
CONTACT WITH HOT WATER WHEN EMPTYING UNIT.
CAUTION: ALWAYS RAISE PAN COVER BEFORE TILTING TO AVOID DAMAGING THE
HINGE AND COUNTERBALANCE.
Now that your braising pan has been installed, you should test it to ensure that the
unit is operating correctly.
1. Remove literature and packing materials from the interior and exterior of the
unit.
2. Put enough water into the pan to cover the bottom to a depth of 1/4 to 1/2 inch
(6 to 13 mm). With the pan body in the horizontal position, note how the water
lies in the pan, to confirm that the pan was leveled properly during installation.
3. Turn on the electrical power to the unit.
4. Set the temperature controller to 235°F (113°C) using instruction in this
manual. The heating indicator light should come on to show that the pan is
heating. Heating should continue until the water boils.
5. To shut the unit down, turn off the electrical power to the unit.
6. When the water has cooled to a safe temperature, turn the tilting handwheel
clockwise to pour out the water and to confirm that the pan body can be tilted
smoothly from horizontal to vertical. For power tilt models, push the UP/DOWN
switch to confirm operation of tilting system.
If the unit functions as described above, it is ready for use. If it does not, contact
your local Authorized Engineer (CE).
OPERATION
CAUTION: DO NOT HEAT AN EMPTY PAN FOR MORE THAN FIVE MINUTES AT A SETTING
HIGHER THAN 300°F (149°C). DAMAGE TO THE PAN COULD RESULT.
WARNING: KEEP THE AREA AROUND BRAISING PAN FREE AND CLEAR OF COMBUSTIBLE
MATERIALS.
CAUTION: KEEP FLOORS IN BRAISING PAN WORK AREA CLEAN AND DRY. IF SPILLS
OCCUR, CLEAN IMMEDIATELY TO AVOID THE DANGER OF SLIPS OR FALLS.
CAUTION: REPLACE THE HOLE PLUG BEFORE CLEANING OTHERWISE WATER COULD
ENTER THE ELECTRICAL CONTROL BOX AND DAMAGE THE PARTS.
Classic Control Advanced Control
OPERATOR CONTROLS
1. Classic Control (-EC) Models
a. Lighted Power ON switch located on the control console. It controls main
power to the unit.
b. The temperature knob, located on the control console, is used to set the
pan temperatures between 175° (79°C) and 400°F (204°C).
c. Heating indicator light located on the control console, lights when the
controller energizes the heating elements and will cycle on and off once
the unit reaches set temperature. If the unit is tilted, the heating elements
will be disabled and the light will turn off until the unit is returned to the
cooking position.

4 OM-BPM-15/30/40E(C,A) (CE) INTERNATIONAL
d. A handwheel controls the worm and gear mechanism that smoothly tilts
the pan body and holds it in the desired position.
e. For power tilt units a switch is located on the control panel to raise and
lower the pan body.
2. Advanced Control (-EA) models
a. Lighted Power ON switch located on the control console. It controls main
power to the unit.
b. Heating indicator light located on the control console, lights when the
controller energizes the heating elements and will cycle on and off once
the unit reaches set temperature. If the unit is tilted, the heating elements
will be disabled and the light will turn off until the unit is returned to the
cooking position.
c. SET TnnP Mode - Allows power to the controller without the pan heating;
the pan will heat once the LOW TEMP, MANUAL or HIGH TEMP button is
selected.
d. LOW TEMP Button – Used to set operating temperature on of the pan at
a preset low temperature (default = 175°F/79°C). Can be pressed at any
point during operation of the unit to change the set temperature to the
preset value except when there is an active TIMER enabled.
e. MANUAL Mode button – Enables the user modify the desired cooking
temperature of the pan (between 175 ° F/79 °C and 400 ° F/204 °C ) using
the temperature knob and display (default = 212 ° F/100 °C ). The operator
will press the MANUAL button and set the desired temperature using the
temperature knob and display. Once the desired temperature is shown in
the display, the user may either press the MANUAL button again or wait 5
seconds and the set temperature will be accepted by the controller and
locked in. After the set temperature is accepted, it may be changed at any
time by pressing the MANUAL button and resetting the temperature using
the same process above.
f. HIGH TEMP button – Used to set operating temperature of the pan at a
preset high temperature (default = 400ºF/204 °C ). Can be pressed at any
time during operation of the unit to change the set temperature to the
preset value except when there is an active TIMER enabled.
g. TIMER button - once the appropriate set temperature is selected using the
HIGH TEMP, MANUAL or LOW TEMP buttons; a countdown timer can be set
to remind the user when the cooking process is completed.
1. Range – 1 minute to 10 hours
2. When the timer expires:
A. The set temperature will automatically change to the LOW TEMP
setting and will continue at this setting until the user changes the
temperature via MANUAL or HIGH TEMP buttons.
B. An audible alarm will notify the user that attention is required,
the alarm will continue to sound until the user presses the TIMER
button.
3. An active TIMER can be cancelled by pressing and holding the TIMER
button for 5 secs.
4. Set temp can be changed during an active timer by pressing the
MANUAL button and adjusting the set temp using the Temperature
knob and display.
5. HIGH TEMP and LOW TEMP presets cannot be used to change the
setpoint once a TIMER has started.
h. READY alarm – The control will sound 3 beeps when the unit has reached
within 20°F (7°C) of set point during pre-heat or when a higher set
temperature is selected.
i. A handwheel controls the worm and gear mechanism that smoothly tilts
the pan body and holds it in the desired position.
OPERATING PROCEDURE
WARNING: WHEN TILTING BRAISING PAN FOR PRODUCT TRANSFER:
1) USE CONTAINERS DEEP ENOUGH TO CONTAIN AND MINIMIZE PRODUCT
SPLASHING.
2) PLACE CONTAINER ON A STABLE, FLAT SURFACE, AS CLOSE TO THE
BRAISING PAN AS POSSIBLE.
3) STAND TO THE SIDE OF THE PAN WHILE POURING — NOT DIRECTLY IN
THE POUR PATH OF HOT CONTENTS.
4) RETURN PAN BODY TO UPRIGHT POSITION AFTER CONTAINER IS FILLED
OR TRANSFER IS COMPLETE.
5) DO NOT OVERFILL CONTAINER. AVOID DIRECT SKIN CONTACT WITH HOT
CONTAINER AND CONTENTS.
CAUTION: DO NOT HEAT AN EMPTY PAN FOR MORE THAN FIVE MINUTES AT A SETTING
HIGHER THAN 300°F (149°C). DAMAGE TO THE PAN COULD RESULT.
WARNING: STEAM CAN CAUSE BURNS. AVOID ESCAPING STEAM WHEN RAISING
COVER.
WARNING: ITEMS IN SAUCE OR MELTED FAT CAN SLIDE FORWARD SUDDENLY DURING
TILTING AND SPLASH THE HOT LIQUID.
WARNING: KEEP THE AREA AROUND BRAISING PAN FREE AND CLEAR OF COMBUSTIBLE
MATERIALS.
CAUTION: KEEP FLOORS IN BRAISING PAN WORK AREA CLEAN AND DRY. IF SPILLS
OCCUR, CLEAN IMMEDIATELY TO AVOID THE DANGER OF SLIPS OR FALLS.
CAUTION: REPLACE THE HOLE PLUG BEFORE CLEANING OTHERWISE WATER COULD
ENTER THE ELECTRICAL CONTROL BOX AND DAMAGE THE PARTS.
CAUTION: DO NOT OVERFILL THE BRAISING PAN WHEN COOKING, HOLDING OR
CLEANING. KEEP LIQUIDS AT LEAST 2-3” (5-8 CM) BELOW THE PAN BODY
RIM TO ALLOW CLEARANCE FOR STIRRING, BOILING PRODUCT AND SAFE
TRANSFER.
1. To Tilt Pan Body
Turn the tilting handwheel clockwise to tilt the pan body, or counterclockwise
to return the pan body to horizontal. 23 complete turns of the handwheel will
tilt the body 90 degrees to vertical.
2. Cooking
a. To simmer or slowly heat an item, set the temperature at 210°F (99°C)
or lower. Put the cover down to minimize moisture loss, or leave it up to
help dry or reduce the product. Set the control higher to cook or drive off
moisture faster. You may adjust the control to any setting to cook the item
exactly as required.
b. Standing to one side of the pan (to avoid the steam that will be released)
grasp the nearer corner of the cover handle and raise the cover. The cover
will stay in the open position until you push it down.
c. To pour product, remove grease, or assist in cleaning, first raise the cover,
then tilt the pan forward by turning the tilting handwheel. When you stop
turning the wheel, the pan body will hold its position.
d. To return the pan to the horizontal position, turn the wheel counter-
clockwise.
e. To turn the pan off, turn the power switch to the “OFF” position.
NOTICE: It is recommended that an instant-read thermometer be used to check
the internal temperature throughout the cooking process and after the cooking
process has been completed to ensure the food has been cooked sufficiently.

5 OM-BPM-15/30/40E(C,A) (CE) INTERNATIONAL
3. Routine Clean-Up
After each use, turn the control and power switch to “OFF” and clean all food
contact surfaces to ensure proper sanitation. At the end of the day, or at least
once every 24 hours, turn off the heat and shut off electric power to the unit
and clean both the interior and exterior of the pan. See CLEANING section for
more detailed cleaning instructions.
SEQUENCE OF OPERATION
The following “action-reaction” outline is provided to help you understand how the
braising pan actually functions.
When you turn the main power switch to “ON” and set the temperature, the
contactors close and power flow to the heating elements and indicator light.
When the pan temperature reaches the value set on the dial, the relay switch
opens and causes the contactors to open. This stops the flow of power to the
heating elements and the indicator light. As soon as the controller senses that the
pan is cooling below the set temperature, the relay closes, the contactors close,
and the heaters and indicator light come on again.
This on and off cycle continues, maintaining the pan at the set temperature. This
is why the indicator light on and off cycling is seen during normal operation. If the
pan temperature exceeds 400°F (204°C) for any reason, a high-limit thermostat
shuts off the power until the pan cools. At that point, the thermostat automatically
resets to permit normal operation to start again.
Turning the main power “OFF” shuts down all control and heating circuits.
The heating is controlled by alternating between feeding full power and completely
cutting power off.The pan heats as fast as it can until it reaches the set temperature,
no matter what that temperature is. Turning the dial to a higher setting will cause
heating to continue longer, until the pan reaches a higher temperature, but it
cannot make the pan heat any faster.
Manual tilt models, turning the hand wheel rotates a shaft, which turns a gear
wheel on one of the trunnions supporting the pan body. Turning the gear produces
the tilting action.
Power tilt models, pushing the up/down switch operates a gear motor which turns
shaft and gear wheel as described above.
For all braising pans, the power to the heaters is cut off when the pan is tilted past
a slight inclination of 10°. It is acceptable to cook with the pan tilted forward at a
small angle (about 5 - 7°) to let liquids collect to front of pan or allow them to drain
out of the draw off valve.
CLEANING
WARNING: KEEP WATER AND SOLUTIONS OUT OF CONTROLS AND ELECTRICAL
EQUIPMENT. DO NOT USE A WATER JET SPRAY, HIGH PRESSURE HOSE,
OR STEAM TO CLEAN THE CONTROL CONSOLE, ELECTRICAL CONNECTIONS,
ETC.
CAUTION: MOST CLEANERS ARE HARMFUL TO THE SKIN, EYES, MUCOUS
MEMBRANES AND CLOTHING. PRECAUTIONS SHOULD BE TAKEN TO WEAR
RUBBER GLOVES, GOGGLES OR FACE SHIELD AND PROTECTIVE CLOTHING.
CAREFULLY READ THE WARNINGS AND FOLLOW THE DIRECTIONS ON THE
LABEL OF THE CLEANER TO BE USED.
WARNING: BEFORE ANY CLEANING OPERATION, TURN THERMOSTAT DIAL TO “OFF”
TO CUT ANY POWER TO THE HEATING ELEMENTS. BEFORE CLEANING ANY
PART OTHER THAN THE INSIDE OF THE PAN, DISCONNECT ELECTRICAL
SUPPLY AT CIRCUIT BREAKER OR FUSE BOX.
CAUTION: NEVER LEAVE A CHLORINE SANITIZER IN CONTACT WITH STAINLESS STEEL
SURFACES FOR LONGER THAN 30 MINUTES. LONGER CONTACT CAN CAUSE
CORROSION.
CAUTION: KEEP CAUSTIC COMPOUNDS SUCH AS FRYER BOILOUT CLEANERS
AWAY FROM ALUMINUM PARTS OF THE LID HINGE SYSTEM AND THE
COUNTERBALANCE ASSEMBLY. HIGHLY CAUSTIC COMPOUNDS COULD
DAMAGE THIS MATERIAL.
Use a brush, sponge, cloth, plastic or
rubber scraper, or plastic wool to clean.
Don’t use metal
implements or steel wool.
BRAISING PAN
1. Suggested Tools
a. A good stainless steel cleaner
b. Brushes in good condition
c. Cloth for cleaning controls
d. Chlorine sanitizer
e. Heavy Duty Cleaner (if required)
2. Procedure
1. Clean all food-contact surfaces soon after use. It is best to clean the pan
before it has completely cooled. If the unit is in continuous use, completely
clean and sanitize both the inside and outside at least once every 12 hours.
2. To remove any large amount of food left in the pan, tilt the pan all the way
up and flush it with lukewarm water. Do not damage the surface of the pan
by scraping it with a metal tool. Scratches make the surface more difficult to
clean, and provide ideal breeding places for bacteria.
3. Following the supplier’s directions, make up a warm solution of the cleaner.
Carefully wash the inside and outside of the pan body with the cleaning
solution.
4. Use a cloth moistened with cleaning solution to clean controls, the control
console, and electric conduit.
5. Rinse the pan very well with lukewarm water, and drain it completely.
6. As part of the daily cleaning program, clean all inside and outside surfaces that
may have been soiled. Remember to check such parts as the undersides of the
cover, the electrical console and other more remote spots. Clean between the
pan body and the consoles using a brush.
7. Controls and the control console may be cleaned with a damp cloth or sprayed
with a garden hose spray connected to city water supply. Do not use a pressure
sprayer directly on the unit or electrical parts.
8. To remove materials stuck to the equipment, use a brush, sponge, cloth, plastic
or rubber scraper, or plastic wool with the cleaning solution. To make washing
easier, let the cleaning solution sit in the unit and soak into the residue, or
heat the solution briefly. Do not use any gritty cleaner or metal tool that might
scratch the surface. Scratches make the surface harder to clean, and also
provide places for bacteria to grow. Do not use steel wool. Small bit of steel
wool left in the surface of the unit can cause rusting and pitting.
9. The outside of the unit may be polished with a recognized stainless steel
cleaner such as Zepper from the Zep Manufacturing Company.
10. When the equipment needs to be sanitized, use a sanitizing solution equivalent
to one that supplies 100 parts per million available chlorine. Get advice about
the best sanitizing agent from you supplier of sanitizing products.
11. Following supplier instructions, apply the sanitizing agent after the unit has
been cleaned and drained. Thoroughly drain off the sanitizer.
12. After the unit has been cleaned, sanitized and drained, let all surfaces air dry
unless the unit must be used again right away.
13. It is recommended that the unit be sanitized just before use. Follow the
directions of the sanitizer supplier.
14. About once a week (more often if the water is very hard), use a heavy duty

6 OM-BPM-15/30/40E(C,A) (CE) INTERNATIONAL
cleaner to remove any mineral deposits or film left by hard water or foods.
Follow the supplier’s directions very carefully, and rinse the unit off thoroughly,
as soon as cleaning is finished.
15. If especially difficult cleaning problems persist, contact your cleaning product
supplier for help. The supplier has a trained technical staff with laboratory
facilities to serve you.
MAINTENANCE
WARNING: ELECTRIC POWER ALWAYS SHOULD BE SHUT OFF BEFORE WORK IS DONE
ON INTERNAL COMPONENTS.
WARNING: DISCONNECT ELECTRICAL POWER FROM THE UNIT BEFORE ATTEMPTING
TO GREASE THE TRUNNION BEARINGS.
Your braising pan is designed to require minimum maintenance, but certain parts
may need replacement after prolonged use. After installation, no user adjustment
should be necessary. If a service need arises, only authorized personnel should
perform the work.
Service personnel should check the unit at least once a year. This periodic
maintenance should include inspecting electrical wires and connections, cleaning
the inside of the control console, and possible adjustment of the pilot light. (Units
with standing pilot ignition only) At least twice a year, grease the two trunnion
bearings and worm gear.
We recommend the use of number two grade LGI lithium grease. Add grease
through the zerk fittings on the gear hosing until grease flows out of the bearings
around trunnion shaft. Also, add grease in the gear to cover arc that is in contact
with the worm gear. Clean up excess grease.
A Service Log is provided with the warranty information at the back of this manual.
Each time service is performed on your equipment, enter the date on which
the work was done, what was done, and who did it. Keep the manual with the
equipment for quick and easy reference.
REPLACEMENT PARTS
To order parts, contact your Authorized Service Agent. Supply the model
designation, serial number, part description, part number, quantity, and when
applicable, voltage and phase.
CONTACT US
If you have questions pertaining to the content in this manual, contact Unified
Brands at 888-994-7636.
TROUBLESHOOTING
This unit is designed to operate smoothly and efficiently if properly maintained.
However, the following is a list of checks to make in the event of a problem.
Wiring diagrams are found at the end of this manual. When in doubt, turn unit
off and call for service at 888-994-7636. If an item on the check list is marked
with (X), it means that the work should be done by a Authorized Service Agent.
WARNING: ELECTRICAL POWER MUST BE SHUT OFF BEFORE WORK IS DONE ON INTERNAL
COMPONENTS. USE OF ANY REPLACEMENT PARTS OTHER THAN THOSE
SUPPLIED BY THE MANUFACTURER OR THEIR AUTHORIZED DISTRIBUTOR
CAN CAUSE INJURY TO THE OPERATOR AND DAMAGE TO THE EQUIPMENT
AND WILL VOID ALL WARRANTIES. SERVICE PERFORMED BY OTHER THAN
FACTORY-AUTHORIZED PERSONNEL WILL VOID ALL WARRANTIES.
SYMPTOM WHO WHAT TO CHECK (X indicates work that should only be
performed by a qualified service representative)
Display not lit
(Advanced only)
User a. That power supply is on.
Authorized
Service Rep
Only
b. Fuses, accessible by removing caps on the side of the
control box.
c. For loose or broken wires or damaged RTD probe. X
d. Temperature controller functioning, by listening for a click
when the switch opens or closes and verifying LEDs on
back of board. X
e. Contactor functioning. X
PROB in display
(Advanced only)
Authorized
Service Rep
Only
a. For loose or broken wires or damaged/failed RTD probe. X
b. PCB board malfunction/failure
HI in display
(Advanced only)
Authorized
Service Rep
Only
a. For loose or broken wires or damaged/failed RTD probe. X
b. PCB board malfunction/failure
Pan will not heat,
but
indicator light
comes on
Authorized
Service Rep
Only
a. Heating elements for short circuit. X
Pan will not heat,
and
indicator light
will not
light (STD and
Classic)
User a. That power supply is on.
Authorized
Service Rep
Only
b. Fuses, accessible by removing caps on the side of the
control box.
c. For loose or broken wires or damaged RTD probe. X
d. Temperature controller functioning, by listening for a click
when the switch opens or closes and verifying LEDs on
back of Classic board. X
e. Contactor functioning. X
Pan continues
to heat
after it reaches
desired
temperature
User a. Temperature controller dial setting. Turn down if too high.
Authorized
Service Rep
Only
b. Temperature controller functioning. X
c. Temperature Controller calibration and offsets. X
d. Contactor, to determine if it is de-energized. X
Pan does not
reach
desired
temperature
User a. Temperature Controller dial setting. Turn up if too low.
Authorized
Service Rep
Only
b. Heating elements for ground short or open (burned out)
element. X
c. Temperature controller functioning, by listening for a click
when the switch opens or closes. X
d. Temperature Controller calibration and offsets. X
e. Contactor functioning. X
Rapid clicking
noise
(chattering)
User a. For low voltage.
Authorized
Service Rep
Only
b. Contactor for dirt or corrosion on the contacts. X
Uneven cooking
due
to “hot spots”
User a. That the pan body is level.
Uneven cooking
due
to “cold spots”
Authorized
Service Rep
Only
a. For open (burned out) heating element. X
Pan is hard to tilt
(Manual Tilt
Models)
Authorized
Service Rep
Only
a. Gears for foreign materials, lubrication and alignment. X

7 OM-BPM-15/30/40E(C,A) (CE) INTERNATIONAL
Parts List
STAND & FOOT ASSEMBLY
CALL FACTORY FOR REPLACEMENT PARTS:
888-994-7636
Key Description Part #
1 CASTER KIT (SET OF 2 WITH BRAKE
AND 2 W/O BRAKE)
146354
1 CASTER WITH BRAKE (W/O FOOT
ADAPTER)
146513
1 CASTER WITHOUT BRAKE (W/O
FOOT ADAPTER)
NOT SHOWN
146515
2FOOT ADAPTER 146516
3 FLANGED FOOT
(W/O FOOT ADAPTER)
146521
4 BULLET FOOT
(W/O FOOT ADAPTER)
146628
5 FRICTION RING 146520
Parts List
COVER & COUNTERBALANCE
ASSEMBLIES
CALL FACTORY FOR REPLACEMENT PARTS:
888-994-7636
Key Qty Description Part #
1 1 COVER &
COUNTERBALANCE
ASSEMBLY,
15 GALLON
162232
162235
1 1 COVER &
COUNTERBALANCE
ASSEMBLY,
30 GALLON
144812
145480
1 1 COVER &
COUNTERBALANCE
ASSEMBLY,
40 GALLON
144453
144790
3 4 STUD WELD,
1/4”-20 X 1-1/4”
012589
4 4 WASHER, LOCK 3/8” 005618
5 4 SCREW, HEX HEAD CAP 3/8”-
16 X 1”
005612
6 4 NUT, HEX 3/8”-16 005619
7 4 DOME NUTS, 1/4-20 090567
8 2 SCREW, TRUSS HEAD,
#10-32 X 3/8”
004173

8 OM-BPM-15/30/40E(C,A) (CE) INTERNATIONAL
Parts List
CALL FACTORY FOR REPLACEMENT PARTS:
888-994-7636

9 OM-BPM-15/30/40E(C,A) (CE) INTERNATIONAL
To order parts, contact your Authorized Service Agent. Supply the model designation, serial number, part description, part number,
quantity, and when applicable, voltage and phase.
Parts List
KEY DESCRIPTION PART NO.
1 STAND ASSEMBLY - 15 GAL 155725
1 STAND ASSEMBLY - 30 GAL 144848
1 STAND ASSEMBLY - 40 GAL 144332
2 PAN WELDMENT - 15 GAL 162573
2 PAN WELDMENT - 30 GAL 145654
2 PAN WELDMENT - 40 GAL 144789
4a TEMP CONTROL - EC 174842
4b TEMP CONTROL - EA 174836
5LIGHT, AMBER 116384
6 TILT SWITCH 143319
7 CONTACTOR 148102
8GROUND TERMINAL 129417
9 TERMINAL BLOCK 003888
10 FUSE HOLDER 077854
11 FUSE, 3 AMP 077853
12 TRANSFORMER - 208/240V 148899
13 POWER SWITCH 177910
14 HIGH LIMIT THERMOSTAT 142755
15 ELEMENT - 240V 146185
16 COVER ELEMENT HOUSING - 15 GAL 162575
16 COVER ELEMENT HOUSING - 30 GAL 146186
16 COVER ELEMENT HOUSING - 40 GAL 144343
17 RIGHT SIDE COVER (HIDDEN) 175146
18 LEFT TRUNNION COVER ASSEMBLY 144776
19 TILT SWITCH BRACKET ASSEMBLY 145689
20 CONTROL BOX ASSEMBLY 175153
22 TERMINAL BLOCK BOX 175042
23 TERMINAL BLOCK BOX COVER 175043
24a KNOB ALUMINUM - EC 175095
24b KNOB ALUMINUM -EA 174829
KEY DESCRIPTION PART NO.
26 FUSE, 3AMP 3AG 2077853
x FERRITE BEAD 175836
x TRUNION SEAL 175017
x RETAINING RING 175164
x O-RING 138359
x EXTERNAL RET. RING 138356
x COLLAR, SHAFT SEAL 138354
x SHAFT SEAL 1.00” 136088
x OVERLAY, MANUAL TILT, CLASSIC 175044
x OVERLAY, POWER TILT, CLASSIC 175045
xOVERLAY, MANUAL TILT, ADVANCED 175048
xOVERLAY, POWER TILT, ADVANCED 175205
x- Item not depicted/called out in drawing or photograph
CALL FACTORY FOR REPLACEMENT PARTS:
888-994-7636

10 OM-BPM-15/30/40E(C,A) (CE) INTERNATIONAL
Parts List
MANUAL TILT ASSEMBLY
CALL FACTORY FOR REPLACEMENT PARTS:
888-994-7636
Key Qty Description Part #
1 1 GEAR CARRIER 002624
2 1 SHAFT, HANDWHEEL 144834
3 1 GEAR, WORM 128001
4 1 GEAR SECTOR 009829
5 1 KEY GIB 012031
6 1 HANDWHEEL 139152
7 2 PIN ROLL 012614
8 2 SCREW SET SOCKET 012060
9 2 BEARING ROLLER 002790
10 2 BEARING SLEEVE 137239
11 1 PLUG PIPE 010286
14 1 FITTING GREASE 90 (NOT
SHOWN)
012195
15 1 BUSHING SNAP
(NOT SHOWN)
000453
16 2 WASHER LOCK 005618
17 2 SCREW HEX HEAD CAP 005612

11 OM-BPM-15/30/40E(C,A) (CE) INTERNATIONAL
Wiring Diagram
CALL FACTORY FOR REPLACEMENT PARTS:
888-994-7636

12 OM-BPM-15/30/40E(C,A) (CE) INTERNATIONAL
Service Log
Model No: Purchased From:
Serial No: Location:
Date Purchased: Date Installed:
Purchase Order No: For Service Call:
Date Maintenance Performed Performed By
