Gronomics DMGP-3-1T User manual

East Bethel, MN USA 763-753-7374
Continued
1
Parts Identification Box 1, Box 2 And Box 3
NOTE: Box 1, 2 and 3 will each contain the parts shown on
the right. The total quantity of parts from Box 1, 2 and 3 are
shown in the parts list below.
Stack matching pieces in piles. Using the parts list, locate and
count the individual pieces and verify that you have received
the correct number of pieces.
Check all the pieces for damage. If any pieces are damaged
or missing, contact Gronomics at www.gronomics.com.
NOTE: It is recommended to place a protective layer between
the ground and the pieces during assembly. This will help
prevent damage to the pieces.
2
1
Parts List Box 1, 2 and 3
ITEM QTY. PART # DESCRIPTION
1 12 R1300 Corner Post, 4” x 4” x 13”
2 21 R4501 Side Rail, 45” x 5-1/2” x 1”
3 3 R4501L Side Rail w/Logo, 45” x 5-1/2” x 1”
3
Deluxe Modular Garden Package
Assembly Instruction
DMGP-3-1T
Packaged & Inspected by: Date:
Parts List Box 4
ITEM QTY. PART # DESCRIPTION
4 1 Trellis
5 4 RSS 8 x 1-1/2” GRK Screw (Trellis)
Check all the pieces for damage. If any pieces are damaged
or missing, contact Gronomics at www.gronomics.com.
NOTE: It is recommended to place a protective layer
between the ground and the pieces during assembly. This
will help prevent damage to the pieces.
Box 4 of 4
2
5
4

East Bethel, MN USA 763-753-7374
NOTE: Always assemble the garden beds on a level surface
and keep posts and side rails square when assembling.
Stand two 4” x 4” x 13” corner posts (Item 1) upright.
Install a 45” x 5-1/2 “ side rail (Item 2) into the slots and slide
down.
Repeat procedure for the two remaining corner posts and
45” x 5-1/2 “ side rail.
Side Rail Assembly
3
2
1 1
Final Side Rail Assembly
5
Install the remaining three 45” x 5-1/2 “ side rails (Item 2)
and one side rail w/logo (Item 3) into the slots and slide
down.
2
Logo
2
3
Continue to assemble your garden beds as desired.
The Deluxe Modular Garden Package can be assembled
in several different configurations. Shown are two different
ways you can assemble your Garden Package. Create your
own configuration as desired.
Place the trellis (Item 4) at the desired location. Align the
bottom of the trellis with the bottom of the top side rail,
center the trellis between the posts and make sure the trellis
is straight.
Install four 8 x 1-1/2” screws (Item 5) into the pre-drilled
holes.
Garden Bed And Trellis Assembly
6
Install two 45” x 5-1/2” side rails (Item 2) into the slots and
slide down.
Side Rail Assembly Continued
4
2
2
4
5
