Grundig DSR 1773 CY User manual

DIGITAL
SATELLITE
RECEIVER
DSR 1773 CY

2
CONTENTS
4-5 General information
4 Packing contents
4 Receiving digital stations
5 Special features of your digital receiver
6 Set-up and safety
7-8 Overview
7 The digital satellite receiver
7 The infrared receiver
8 The remote control
9-11 Connection and preparation
9 Connecting the antenna
9 Connecting the television
10 Connecting the infrared receiver
10 Connecting the power supply unit
10 Inserting batteries in the remote control
11 Inserting a Smart card
11 Connecting the Dolby Surround system
12-19 Basic settings
12 The menu
13 Initial setup
14 Settings stations, Option 1
15-16 Settings stations, Option 2
17-19 Editing favourites lists
20-22 Basic functions
20 Switching on and off
20 Mode selection
20 Selecting presets
20 Selecting stations from lists
21 Switching from the current station to the previous one
21 Adjusting the volume
21 Muting the sound
21 Displaying the time
21 Using options
22 Electronic TV Guide
23 Teletext mode
23 Teletext
23 Additional functions
24-31 Settings
24-25 Picture settings
26-27 Language settings
28-29 Menu settings
30-31 Miscellaneous settings

ENGLISH
3
CONTENTS____________________________________________
32 The recording timer
33-34 Additional functions
33 Security functions
34 Conditional access
35-39 Special settings
35-36 Searching for new stations
37 LNB settings
38 Resetting the digital receiver to its original state
38 Updating the digital receiver software
39 Changing remote control levels
40-42 Information
40 Displaying station reception properties
40 Displaying device information
41 Technical data
41 Environmental note
42 Troubleshooting

4
Packing contents
Digital Satellite Receiver DSR 1773 CY
Tele Pilot 766 S remote control with 2 batteries
SCART extension cable
Power supply unit
Infrared receiver
Operating manual
Receiving digital satellite channels
In order to use your new DSR 1773 CY digital receiver you need a
digital-compatible satellite antenna, which must be installed and ali-
gned to the satellites (for example Astra and EutelSat/Hotbird).
Unlike broadcasts of analog satellite channels, not every digital TV or
radio station is assigned to one transmission frequency, but several TV
and/or radio stations are broadcast by one transponder.
To help you with the choice and settings for satellite channels, a
selection of TV and radio stations have already been programmed
for this device. You can start a channel search to ensure that any
new satellite channels are available on your device.
How this works and what you need to remember can be found on
page 35 of this operating manual.
Of course, you can easily program new satellite channels. You can
find the latest transponder information on the teletext pages of
various broadcasters, in a current satellite TV magazine or on the
internet.
GENERAL INFORMATION__________________

ENGLISH
5
Special features of your digital receiver
This digital receiver DSR 1773 CY has a built-in digital receiver unit for
satellite channels. The receiver unit converts the signals from digital
satellite channels to provide outstanding audio and picture quality.
The DSR 1773 CY digital receiver can receive and process encrypted
and all unencrypted digital channels.
So that your new digital receiver always works with the latest program
data and operating software, it is first necessary to conduct an update.
Using the Astra 19.2° East satellite, you can update the device software
of the satellite receiver. How this works and what you need to remember
can be found on page 40 of this operating manual.
The TV guide tells you of any schedule changes at short notice, and also
provides an overview of all the channels’ schedules for the next few
hours.
Detailed information on individual television programmes is available at
the touch of a button.
This digital receiver has a very comprehensive, user-friendly menu
system. The menu is displayed on the television screen, and the functions
of the remote control buttons are explained.
GENERAL INFORMATION__________________

6
SET-UP AND SAFETY___________________________
To ensure that this high-quality and user-friendly digital receiver
provides you with many years of entertainment, please observe the
following instructions:
This digital receiver set is designed to receive video and audio
signals. Any other use is expressly prohibited.
When setting up the device, make sure the mains plug is easily
accessible.
If the digital receiver is subject to a sudden change in temperature,
for example when brought in from the cold to a warm room, let it
stand for at least two hours before you connect it to the mains supply.
Do not expose the digital receiver to moisture of any kind.
The digital receiver is designed for use in dry rooms. If you do use it
outdoors, make sure it is protected from moisture such as rain or
splashing water.
Thunderstorms are a danger to all electrical devices. Even if the digital
receiver is switched off, it can be damaged by a lightning strike to the
mains or the antenna.
Always disconnect the mains and antenna plugs during a storm.
Never open the digital receiver casing under any circumstances.
Warranty claims are excluded for damage resulting from improper
handling.
Notes:
Do not connect any other equipment while the device is switched
on. Switch off the other equipment as well before connecting it.
Do not plug in the power supply of your device until you have
connected the external equipment and the antenna.
Make sure the power supply is freely accessible.

ENGLISH
7
OVERVIEW____________________________________________
The digital satellite receiver
ʐʐ
IN Antenna socket for the satellite
antenna.
Smart card reader.
EURO AV SCART connector (output) for
connecting to TV.
IR remote Connection socket for infrared
receiver.
SP DIF Audio outputs (optical) for PCM/
Dolby digital/DTS signals.
For connecting to a digital multi-
channel audio/video amplifier or
AV receiver.
12 VDC Connection socket for the
18 W max. power supply unit supplied.
The infrared receiver
The infrared receiver receives the infrared signals
for the remote control and forwards the commands
by wire to the digital receiver. Position the infrared
receiver so that it can receive the remote control
commands.
When you switch on from standby, the receiver
switches to the last selected station (Last Station
Memory).
•(red) The digital receiver is in standby
mode.
•(green) The digital receiver is switched on.
A
A

8
OVERVIEW____________________________________________
The remote control
ǼSwitches the digital receiver to standby, and from
standby to the channel last selected.
PIP This has no function.
EDisplays the picture format and the audio information.
?Displays programme information.
1 … 0 Select stations.
dSwitches the sound to mute and on again.
iOpens the main menu.
ZSwitches the current menu level off.
ǸǷ Adjust the volume.
P+ P- Switch channels up and down one by one.
OK Opens the channel list.
Press
A/B to switch from the channel lists to favourite
lists.
TXT Switches from TV mode to teletext mode, mix mode
and back to TV mode.
TV-G Opens the electronic TV guide.
TV Switches to TV mode.
MHP This has no function.
A/B Switches between the two most recently selected
channels.
RADIO Switches to radio mode.
ȄDisplays the time.
ǷǷSwitches between audio channels.
FOpens the options (not available for all stations).
DR, TV Switches to operating a GRUNDIG
DVD AV receiver, GRUNDIG television or GRUNDIG
DVD player.
Keep the appropriate button (»DR«, »TV«, »DVD«)
pressed down. Then press the appropriate button.
Note:
The functions available depend on the model of the
device you are using.
Just try it out.
Tele Pilot 766 S
DR DVD
TV
z
TXT
PIP
A/B
MHP
d
TV-G
Radio
TV

ENGLISH
9
CONNECTION/PREPARATION __________
Connecting the antenna
1Connect the antenna cable of the satellite antenna to the socket
»ʐʐIN« of the digital receiver (screw connector, F connector).
Connecting the television
1Plug the digital receiver into the corresponding SCART socket
on the television.
If this is not possible for reasons of space, use the SCART
extension supplied.
7
12

10
CONNECTION/PREPARATION __________
Connecting the infrared receiver
1Insert the plug of the infrared receiver into the »IR remote«
socket of the digital receiver.
Connecting the power supply unit
1Insert the plug of the power supply unit supplied into the
»12 VDC« socket of the digital receiver.
2Insert the power supply unit into the wall socket.
Notes:
Do not insert the power supply unit of your device into the
socket until you have connected the television and the antenna.
The only way to fully disconnect the digital receiver from the
mains supply is to pull out the power supply.
Inserting batteries in the remote control
1Open the battery compartment by removing the lid.
2Put in the batteries (AA, 2 x 1.5 V). Make sure the polarity is
correct (as shown on the base of the battery compartment).
3Close the battery compartment.
Note:
If the digital receiver no longer reacts properly to remote control
commands, the batteries may be flat. Always remove used
batteries.
The manufacturer accepts no liability for damage caused by
leaking batteries.
Environmental note
Batteries, including those which contain no heavy metal, should
not be disposed of with household waste. Please dispose of
used batteries in an environmentally sound manner. Find out
about the legal regulations which apply in your area.

ENGLISH
11
Inserting a smart card
You will need a smart card from your station provider to enable you
to receive encoded (Crypto Works) digital satellite stations.
1Switch off the digital receiver by pressing »Ǽ«.
2Take the smart card out of the packet and insert it in the smart
card reader.
Note:
The smart card must be fully inserted all the way into the digital
receiver.
There might a slight resistance you will need to push past when
inserting the card.
3Switch on the digital receiver by pressing »Ǽ«.
4Select a preset with the subscribed station and wait until the
connection is made and you have a picture.
Notes:
The chip on the smart card must be facing the digital receiver
and forwards towards the SCART socket.
Leave the smart card inserted the whole time after installation.
Connecting the Dolby Surround* system
You can enjoy sound in digital quality with this connection.
1Plug a standard optical cable into the »SP DIF« socket on the
digital receiver and the corresponding socket on the Dolby Sur-
round system.
Note:
The digital audio must be switched on, see page 31.
CONNECTION/PREPARATION __________
* Manufactured under licence from Dolby Laboratories Licensing Corpo-
ration. “Dolby”, “Dolby Pro Logic”, “Dolby Digital” and the double-D
symbol “ij” are trademarks of the Dolby Laboratories Licensing Cor-
poration. Copyright 1992 Dolby Laboratories, Inc. All rights reserved.
** DTS and DTS Digital Out are trademarks of Digital Theatre Systems,
Inc. All rights reserved.

1212
The menu
This digital receiver has a very comprehensive, user-friendly menu
system. The menu is displayed on the television screen.
The digital receiver responds to many functions which you select on
the remote control with informative menus and icons on the tele-
vision screen.
It enables you to select many different settings and contains infor-
mation on using your digital receiver.
The menu contains the most important controls for your digital
receiver. Its menu system controls the dialogue between you and the
digital receiver.
Press »i« to open the main menu. You can navigate in the menu by
pressing »P-« or »P+« and select the symbol. The selected symbol
is highlighted.
When you press »OK« to confirm your selection, a sub-menu
appears. You can also navigate here by pressing »P-« or »P+«
and select the item you want. The selected item is highlighted.
Press »OK« to confirm. Another menu usually appears, where you
can use »P-« or »P+« to navigate and make the setting. Make
settings using »P-«, »P+«, »Ǹ« or »Ƿ«.
Press »Z« to quit the current menu level.
Press »i« to quit the menu entirely.
BASIC SETTINGS __________________________________

ENGLISH
13
Initial setup
There are several way to set stations on your Digital Satellite
Receiver.
In option 1
you select the menu language for your device, the country in which
your digital satellite receiver is situated and any alterations required
for your TV device.
The digital satellite receiver is already pre-programmed with stations of
the Astra 19.2° East sattelite. No further settings are necessary.
The pre-programmed stations are transferred to the channel list.
Use option 2
if you wish to receive stations from various satellites and are familar
with the configuration of the reception system (antenna, LNB fre-
quencies, multiswitch).
The settings are described on page 15.
Searching for new stations
New satellite channels are frequently added or satellite data is
changed. Therefore we recommend that you start an automatic
search from time to time on the digital receiver.
The settings are described on page 35.
If the station search does not find a particular station automatically,
it can search for it using the manual search. To do this all the para-
meters for the station must be correctly entered. You can find the
latest transponder information on the teletext pages of various broa-
dcasters, in a current satellite TV magazine or on the Internet.
These settings are described on page 36.
BASIC SETTINGS __________________________________

14
Setting stations, Option 1
1Switch on the television and select the preset channel for the
digital receiver.
2Switch on the digital receiver by pressing »Ǽ«.
– The »Erstinstallation« (First Time Installation) page appears
when the device is first switched on.
3Press »OK« to start initial setup.
4Select your language using »Ǹ« or »Ƿ« and press »OK« to
confirm.
– The »Settings« menu appears.
5Press »Ǹ« or »Ƿ« to select the country.
6Press »P-« or »P+« to select the »Screen Format« line and press
»Ǹ« or »Ƿ« to select the screen format for your television.
7Press »P-« or »P+« to select the »TV Output Format« line and
press »Ǹ« or »Ƿ« to select the video signal for your television.
8Press »P-« or »P+« to select the »OK« button and press »OK«
to confirm the entries.
– The »LNB settings« menu appears and the sattelite Astra
19.2° East is set under »Position A«.
9Confirm the settings with »OK«.
– The preprogrammed stations are transferred to the channel
list.
10 Press »OK« to conclude the setting.
Note:
From this list of channels, you can now copy your chosen stati-
ons into four favourites lists, arrange the order of the prepro-
grammed stations according your own wishes and delete any
channels you do not need (see pages 17 to 19).
BASIC SETTINGS __________________________________

ENGLISH
15
Setting stations, Option 2
1Switch on the television and select the preset channel for the
digital receiver.
2Switch on the digital receiver by pressing »Ǽ«.
– The »Erstinstallation« (First Time Installation) page appears
when the device is first switched on.
3Press »OK« to start initial setup.
4Select your language using »Ǹ« or »Ƿ« and press »OK« to
confirm.
– The »Settings« menu appears.
5Press »Ǹ« or »Ƿ« to select the country.
6Press »P-« or »P+« to select the »Screen Format« line and press
»Ǹ« or »Ƿ« to select the screen format for your television.
7Press »P-« or »P+« to select the »TV Output Format« line and
press »Ǹ« or »Ƿ« to select the video signal for your television.
8Press »P-« or »P+« to select the »OK« button and press »OK«
to confirm the entries.
– The »LNB settings« menu appears and the sattelite Astra
19.2° East is set under »Position A«.
Note:
If you wish to receive several satellites and your receiver system
is equipped for this, you can make the settings required for this.
9Select by pressing »P-« or »P+«.
– »LNB control«, select with »Ǹ« or »Ƿ«:
DiSEqC 1.0
Using a DiSEqC switch, you can receive up to four satelli-
tes at once. Under positions A-D, you choose the corre-
sponding satellite for the relevant DiSEqC positions.
You can set the number of sequences for special systems
under »DiSEqC sequence«.
No LNB power
Switching between LNB/ satellites is switched off.
No DiSEqC
No power supply to LNB.
Toneburst
Toneburst enables you to receive up to two satellites
simultaneously. In positions A-B, you choose the corre-
sponding satellite for the relevant position.
– »DiSEqC sequence«, select with »Ǹ« or »Ƿ«:
Here you can select whether the information on DiSEqC
1.0 is to be sent once, twice or three times.
BASIC SETTINGS __________________________________

16
– »Position A« to »Position D«:
You can enter various sattelites here – regardless of the
receiver.
Select the »Position A« to »Position D« line with »P-« or
»P+« and press »OK« to activate.
Press »P-« or »P+« to select the »Satellite« line and sel-
ect the required satellites using »Ǹ« or »Ƿ«.
Press »P-« or »P+« to select the line »Low-Band LOF« or
»High-Band LOF« and use »1...0« to enter the required
frequencies.
Select the »OK« button with »P-« or »P+« and press
»OK« to confirm.
To save this setting select the »Yes« button with »OK«.
10 Select the »OK« button with »P+« or »P-« and confirm the
entries with »OK«.
Notes:
The preprogrammes stations for the Astra 19.2° East sattelite
are transferred to the channel list.
The station search function must be started for stations of satteli-
tes that have been set for the first time. You can find the setting
in the section »Searching for new stations« on page 35.
11 Conclude setting with »OK«.
Note:
From this list of channels, you can now copy your chosen stati-
ons into four favourites lists, arrange the order of the prepro-
grammed stations according your own wishes and delete any
channels you do not need (see next page).
BASIC SETTINGS __________________________________

ENGLISH
17
Editing favourites lists
The stations (TV and radio stations) that were found in the search
are stored in the channel list.
You can copy your favourite stations in up to four favourites lists.
You can then change the order of presets as required and delete
stations you do not need.
Before you edit the favourites lists, you can filter the station list. This
facilitates the subsequent selection of stations in the favourites lists.
Filtering stations in the station list
You can select stations in the station list according to several criteria:
– Satellite;
the stations of a satellite, of several satellites or of all satellites
are displayed in the channel list.
– Channels;
all stations which are free to air or encrypted are displayed in
the station list.
– Sorting;
the channels can be ordered according to their numbers, from
A to Z, from Z to A or according to their service IDs.
1Press »i« to open the main menu.
2Press »P-« or »P+« to select the »Sort Channels« line and con-
firm with »OK«.
– The overview of favourites lists appears.
3Open favourites list 1 with »OK«.
– When the list of channels and favorites list 1 appears, the cur-
sor is positioned in the channels list.
4Open the »Filter channels« function by pressing »ǷǷ« (yellow).
5Select the required line by pressing »P-« or »P+«.
6Press »Ǹ« or »Ƿ« to select the selection criterion.
7Press »P-« or »P+« to select the »OK« button and press »OK«
to confirm the entries.
8Press »i« to conclude the setting.
BASIC SETTINGS __________________________________

18
BASIC SETTINGS __________________________________
Copying stations into the favourites list(s)
1Press »i« to open the main menu.
2Press »P-« or »P+« to select the »Sort Channels« line and con-
firm with »OK«.
– The overview of favourites lists appears.
3Select the desired favourites list using »P-« or »P+« and press
»OK« to open.
– The station list and the favourites list you have selected appear.
Note:
You can use » « or » « to switch between TV stations
and radio stations in the station list.
4Press »P-« or »P+« to select the desired station in the station list.
5Copy the selected station into the favourites list using »OK«.
– The favourite station is marked with a star in the station list.
Note:
Repeat the procedure for any other stations.
6Press »i« to conclude the setting.
Sorting stations in the favourite lists
1Press »i« to open the main menu.
2Press »P-« or »P+« to select the »Sort Channels« line and con-
firm with »OK«.
– The overview of favourites lists appears.
3Select the desired favourites lists »P-« or »P+« and press
»OK« to open.
Note:
You can use » « or » « to switch between TV stations
and radio stations in the station list.
4Press »A/B« to switch to the favourites list.
5Select the station to be moved with »P-« or »P+« and press
»OK« to confirm.
– The name of the station appears.
6Press »P-«, »P+«, »Ǹ« or »Ƿ« to select the preset and press
»OK« to confirm.
Note:
Repeat the procedure for any other stations.
7Press »i« to conclude the setting.
RadioTV
RadioTV

ENGLISH
19
Deleting stations from the channel list
1Press »i« to open the main menu.
2Press »P-« or »P+« to select the »Sort Channels« line and con-
firm with »OK«.
– The overview of favourites lists appears.
3Select the desired favourites lists »P-« or »P+« and press
»OK« to open.
– When the list of channels and favorites list 1 appears, the cur-
sor is positioned in the channels list.
Note:
You can use » « or » « to switch between TV stations
and radio stations in the station list.
4Press »A/B« to switch to the favourites list.
5Press »P-« or »P+« to select the station to delete.
6Press »z« to delete the station.
– The station is deleted from the favourites list.
Note:
You can delete all the stations from a favourites list at once by
pressing »ǷǷ«.
7Press »i« to conclude the setting.
Saving settings
After all the modifications to the favourites lists have been carried
out, they must be saved.
1After making the final change, confirm the security query (Yes)
by pressing »OK«;
or
if you do not wish to save the changes, select the »No« display
by pressing »Ǹ« or »Ƿ« and press »OK« to confirm.
2Press »i« to conclude the setting.
RadioTV
BASIC SETTINGS __________________________________

20
Switching on and off
1Switch on the television and select the preset channel for the
digital receiver.
2Switch on the digital receiver from standby mode with »Ǽ«.
– The mode indicator lights up green.
3Switch the digital receiver to standby mode with »Ǽ«.
– The mode indicator lights up red.
Mode selection
You can choose between TV and radio modes.
1Press » « or » « to select the mode.
Selecting presets
1Move up and down the presets by pressing »P+« or »P-« as
required.
2Enter single-digit or multi-digit preset numbers by pressing
»1 ... 0«.
– Presets with no stations assigned are ignored.
Note:
Every time you change station, a display appears informing
you of the current preset number, the name of the station, the
time, the title of the current and subsequent broadcast and the
start time.
Pressing »i« displays detailed information on the current
programme. Pressing »Ƿ« displays information on the next
programme. Pressing »Ǹ« returns you to information on the
current programme.
Selecting stations from lists
You can select stations from various lists (e.g. TV stations,
favourites).
1Open the station list with »OK«.
– The most recently activated station list appears.
2Change the station list with »A/B«.
3Press »Ǹ« or »Ƿ« to scroll through the lists.
Press »P-« or »P+« to select the station and press »OK« to call
it up.
4Switch off the station list with »Z«.
RadioTV
BASIC FUNCTIONS______________________________
