Gulfstream GS 8200 SPA User manual

SAVE THESE INSTRUCTIONS
Operation Instructions
GS 8200 SPA
MASSAGE CHAIR

Thanks for purchasing this product. Please read this manual instruction carefully in
order to know how to use this product correctly before operation. Please pay more
attention to some important safety warning and keep this manual book properly for
future use.
Note: Our Company reserves the right to revise the design and description of this
product without any further notice. Please refer to the actual color of this product.
CONTENTS
01
02
04
05
06
13
Important Safety Warning
Name and function of components
Function
Method of usage
Product specification

0302
Safety and maintenance
IMPORTANT SAFETY WARNING
1.Important safety warning.
·Don't allow children to touch moveable part of this product.
·Please use well-grounding power supply suited to this product.
·Please pull out the plug after use or before cleaning to avoid injury or Damage to
the product.
·Please operate this product according to this manual instruction.
·Don't use accessories which are not recommended.
·Don't use this product outdoors.
·Please read this manual instruction carefully before operation.
·Any other usage that is not listed in this manual instruction is forbidden.
·20 minutes of usage each time is recommended.
·Please don't use it if the leather is broken or damaged.
·Please don't use it if the cover or leather is damaged.
·Please don't use it if the radiator hole is covered or blocked.
·Please don't drop anything into this product.
·Please don't fall asleep while using this product.
·Please don't use it if drunk or feel unwell.
·Please don't use it within one hour after having meal.
·Please don't make the massage function too strong for avoiding Injury.
2. Environment for usage.
·Please don't use it under high temperature and moist environment such as
bathroom.
·Please don't use it immediately while the environmental temperature changes
sharply.
·Please don't use it under heavy-dusty or caustic environment.
·Please don't use it where there is not enough space or not good ventilation.
3. People who are not suitable to use this product.
·People who are suffering from osteoporosis are not suitable to use this product.
·People who are suffering from heart disease or carrying electronic medical
equipment such as heart pacemaker are not suitable to use this product.
·People who are suffering from fever are not suitable to use this product.
·Pregnant women or women that are in menses period are not suitable to use
thisproduct.
·People who got injured or skin disease are not suitable to use this product.
·Children under 14-year old or people mentally unbalanced without being
Supervised are not allowed to use this machine.
·People who are told by doctor to have rest or people who feel unwell are not
suitable to use this product.
·People whose bodies are wet are forbidden to use this product.
4. Safety.
·Check the voltage if it is suitable to the specification of this product.
·Don't use wet hand to pull the plug.
·Don't make water go inside this product to avoid electric shock or cause
damage to this product.
·Don't damage the wires or change the circuit of this product.
·Don't use wet cloth to clean the electric parts such as switch and plug.
·Be away from this product under power cut state to avoid injury if the power
comeback suddenly.
·Stop using this product while it works abnormal, and please consult local agent
immediately.
·Stop using this product if you feel unwell, and please consult health care doctor.
·This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
·Children should be supervised to ensure that they do not play with the
Appliance.
·If the supply cord is damaged, it must be replaced by the manufacturer, its Service
agent or similarly qualified persons in order to avoid a hazard.
5. Maintenance.
·This product should be maintained by certain appointed agents, users are
prohibited to disassemble or maintain by themselves.
·Please don't forget to cut the power after usage.
·Don't use this product if the socket looses.
·If this product will be left unused for long, please curl up the wires and reserve this
product in dry and dustless environment.
·Don't reserve this product under high temperature or near fire and avoid longtime
direct sunshine.
·If the detachable cord / supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to avoid a
Hazard.
·Please clean this product by dry cloth. Don't use thinner, benzene or alcohol.
·The mechanical components of this product are specially designed and made, it is
not necessary to be specially maintained.
·Don't use edged res to thrust this product.
·Don't roll or pull this product above uneven ground, it should be lifted before
moving.
·Please use it intermittently; don t make this product work continuously for long.
6. Solution of ordinary malfunctions.
·It is nature movement voice if the motor sounds while in usage.
·If the controller can't work normally, please check the plug and socket if they are
connected strongly and make sure the switch is turned on.
·If the rated working time is over, the product will automatically activate the
power-off button; If this product works continuously for long, the temperature
protector will make the product automatically power-off, it should be used again
after half an hour s r est.
Warning:
This product can expose you to chemicals including lead which are known to the
State of California to cause cancer or birth defects or other reproductive harms.
For more information go to www.P65Warnings.ca.gov/furniture.

0504
Name and function of components
1
5
6
3
Function
4
2
·This product is designed with a set of massage machine hand
that can walk up and down.
·Set five kinds of artificial massage techniques: finger pressing,
kneading, flapping, knocking flapping and kneading.
·Set automatic massage function: neck massage, body
massage, back waist massage
·Set the upper body manual massage function (full, partial, fixed
point three massage parts selection, acupressure, kneading,
flapping, flapping, kneading and flapping five kinds of artificial
massage techniques; each massage technique has three
speeds adjustable, Under the fixed point state, the machine
hand can adjust the upper and lower position; when flapping,
shiatsu, flapping massage, the width of the massage ball is
wide, medium and narrow.
·airbag massage function: hip pressure, upper body pressure,
arm pressure (two airbags built into the left and right armrests),
a total of eight airbags. Air pressure three mode selection, third
gear strength
·The bathtub can be adjusted freely in and out, the backrest
frame lifting adjustment and one-button lifting adjustment
function.
·With the bathtub shortcut button to adjust the bathtub forward
or backward and the backrest angle to tilt freely.
1.Head cushion
2.Shoulder airbag assembly
3.Remote controller
4.Arm airbag assembly
5.Cup holder
6.Seat cushion
7.Back cushion
8.Waist airbag
9.Remote controller pocket
7
8
9

0706
Method of usage Method of usage
Shouler
Massage
Seat
Airbag
Back
Stretch
Manual
Wide
Middle Narrow
Massage
Method
Auto
Upper
Back Full
Back Lower
Back
Back
Reset
Speed
Air
Mode Air
Intensity Time
1).Remote controller operation
Shouler Massage
Back Reset
Seat Airbag
·Turn on the power switch, start massage
1.Start the massage
Button Description
Power switch: Turns all massage functions on or off.
2).Shoulder air pressure intensity adjustment
Button Description
The shoulder air pressure is increased and adjust three level
The shoulder air pressure is decreased and adjust three level
3).One-button reset
Button Description
The backrest frame reset with one key
4).Car adjustment
Button Description
Press and hold the button to move the bathtub forward, when you
hear shortly :BiBiBi..” it means the tub reach the maximum
Press and hold the button and move the bathtub backwards. when
you hear shortly :BiBiBi..”, it means the tub reach the minimum
5).Cushion air Pressure
Button Description
Turn on/off the air pressure function
5). Angle Adjustment
Button Description
Press and hold the button to raise the backrest, when you hear
shortly :BiBiBi..” it means the tub reach the maximum
Press and hold the button on the backrest to lie down, when you
hear shortly :BiBiBi..” it means the tub reach the maximum

0908
Method of usage Method of usage
Back Stretch
Upper Back
Full Back
Lower Back
Massage
Method
Speed
Wide
Middle
Narrow
Air Mode
Air Intensity
Time
·During the massage, turn off the power switch, the backrest frame is lifted, and the
machine hand resets all massage functions to stop.
7).Automatic Massage
Button Description
Help blood circulation in the neck.
Help body fatigue and relaxes muscles.
Promote body functions.
8).Automatic Massage
Description
Button
Features
Kneading,
Flapping,
kneading
and Flapping,
Shiatsu, knock,
Stop
Kneading: Speed.
knocking: Speed, Width.
Knocking and Flapping: Speed.
Shiatsu: Speed, Width.
Knocking: Speed, Width.
Three levels of speed can be adjusted.
Three levels of width can be adjusted.
Speed
Width
Medium
and Narrow
In the manual mode knock, flapping and finger
pressing modes, the machine hand can be adjusted in
width, middle and narrow.
Back
Stretch
Fixed position massage.
Area massage.
Full massage.
Press and hold the button in manual mode with the
machine hand going up.
Press and hold the button in manual mode with the
machine hand going down.
9).Air pressure massage
Button Description
Three airbag mode switch buttons.
Three levels of strength can be adjusted.
10).Time out
Button Description
Press to pause and run all massage functions. If pausing time
exceeds the set time for 20 minutes during massage, all massage
functions will be automatically turned off.
11). Time Setting
Button Description
Massage time setting.
12). Turn off the power, Finish the massage
2.Installation instructions
1).Backrest Installation
·First install the backrest shaft into the slot of the frame.
·The backrest support and the backrest electric cylinder mounting holes are
aligned; use 8*55mm pins and 1.6*35 quick release pins and 2 isolation sleeves
for installation.

1110
Method of usage Method of usage
(1).insert the plug into the socket outlet.
(2).switch on the power button behind the armrest.
SWITCH ON POWER
MASSAGE
(1)Select relative massage according to the operation
instructions of the control.
(1).stop overall massage.
(2).switch off the power button behind the armrest.
(3).pull the plug out of the socket outlet.
SWITCH OFF POWER
3.Operation sequence
(1). The correct method of operation: before operating the controller, please make
sure that the backrest electronic cylinder is connected well with the pin that fixes
the backrest.
(2). When the backrest electric cylinder is not connected with the pin that fixes the
backrest, please hold the electronic cylinder in case it touches the ground when
operate the controller.
(3). When debugging and installation, before operating the controller, please make
sure that the backrest electric cylinder is connected well with the pin that fixes
the backrest. Otherwise, after shutting down the switch, the front part of the
electronic cylinder will hit the board under the seat frame to cause bad distortion
of the seat frame, and even make the rail go out of the railway or damage the
steel-ball railway.
(1) (2)
Caution
(3)
2).Seat Frame Installation
·The male and female buckles of the frame assembly 8 are tightened with a tool
hammer.
·Use two m5*16 Phillips flat head screws to lock the frame assembly.
3).Armrest Installation
·The left and right armrests are mounted using four M6*10mm Phillips pan head
screws.
·Use 2 8*30 hex socket head cap screws to lock the left and right armrests.
4).Cup Holder Instructions
·This is the state of the tea cup.
·After the cup holder is placed back to the back of the armrest, the cup holder can
be put down.

1312
Method of usage
Backrest adjustment
press and hold the button on the controller,the backrest will recline backward
slowly. Release the button,then the backrest will be stopped upright
press and hold the button on the controller,the backrest will move slowly.
Loose the button,then the backrest will be stopped .
WARNING: DO NOT EXERT ANY PRESSURE OTHER THAN YOUR OWN BODY
ON THE BACK WHILE IT IS RISING.
400mm (15.7in)
5.To Adjust The Back Simultaneously
The flex fuction of seat frame could fix the different height of the people to adjust the
massage place of the calf airbags,the maximum distance moving forward and
backward is 400mm.
6.To Adjust Seat Frame Separately
Product specification
Model: GS 8200
Name: SPA Massage Chair
Power supply: 110-120V~ 50Hz/60Hz
220-240V~ 60Hz
Rated power: 90W
Safety structure: Class ў
115°-130°
400mm
Method of usage
The pillow pad and back cushion (recommended) reduces the kneading intensity of
your neck and shoulder, but you can decide to put it on or not according to your
personal need.(1) Sticker connects the pillow pad and back cushion.
WARNING : IN CASE OF DANGER, DO NOT REMOVE THE CUSHION
(1)
4.Attaching or detaching the pillow pad and back cushion
