Assembly instructions
AUW oil protector

Ölprotektor.de
2
These assembly instructions must be
read carefully before commissioning
and using the AUW oil protector! These
assembly instructions are considered
part of the AUW oil protector and must
always be kept in the immediate vicinity
of the installation site, or with the pro-
tector itself.
Subject to alterations.
We assume no liability for errors and misprints.
Version: April 2020
Contents
3 Product overview
4 Safety information
5 Description
6 AUW oil protector scope of delivery
6 AUW oil protector assembly instructions
7 Warning, Maintenance and Cleaning
Introduction

3
AUW oil protector - assembly instructions
Standard sizes L x W x H mm Oil quantity Ltr.
AUW 1 320 x 900 x 35 1,19
AUW 2 400 x 950 x 35 1,52
AUW 3 500 x 1.150 x 35 2,30
AUW 4 850 x 1.140 x 35 3,87
AUW 5 930 x 1.140 x 35 4,24
AUW 6 780 x 1.500 x 35 4,68
AUW 7 1.200 x 1.500 x 35 5,40
AUW 8 850 x 1.430 x 35 4,90
AUW 9 590 x 1.200 x 35 3,00
AUW 10 850 x 1.750 x 35 5,80
Material: Aluminium AlMg3
Process: Welding according to DIN EN ISO 9606-1
Custom sizes
AUW S Depending on requirements
Optionales Zubehör
Leaf protection
grille For overall height up to 50 mm
Heating kit Heating mat and 3.0
Product overview
AUW oil protector custom sizes
AUW oil protector optional accessories
Note:
Load capacity of included feet:
AUW-1 & AUW-2: 100 kg
AUW-3 to AUW-10: 180 kg

Ölprotektor.de
4
Safety information
Read the operating instructions carefully
before using the AUW oil protector for the
󰊟rst time. It contains useful tips, informa-
tion and warnings to avoid hazards to per-
sons and property.
Failure to comply with the instructions can
lead to danger to persons, the environ-
ment and the installation, and thus the
loss of possible claims.
Note:
• Keep these instructions near the AUW oil protectors.
• The installation and assembly of the AUW oil protectors and their compo-
nents may only be carried out by quali󰊟ed personnel.
• Installation, connection and operation of the AUW oil protectors and their
components must be carried out in accordance with operating conditions
as described in the instructions, and in compliance with applicable regio-
nal regulations.
• The condensate drip tray must be earthed.
• Modi󰊟cations to the protectors or their components supplied by GUS
Gewässer-Umwelt-Schutz GmbH may cause malfunctions and are not per-
mitted. The AUW oil protectors and their components must not be ope-
rated in areas where there is an increased risk of damage. Minimum clea-
rances must be observed.
• The operational safety of the AUW oil protectors and their components
can only be guaranteed if they are used as intended and if they are fully
assembled. Safety devices must not be changed or bypassed.
• Do not operate the AUW oil protectors or their components if there are
visible defects, or if they appear to be damaged.
• The AUW oil protectors and their components must be kept at a safe dis-
tance from 󰊠ammable, explosive, combustible, aggressive and polluted
areas or environments. Assembly, repairs and maintenance must only be
carried out by authorized specialist personnel. Visual inspections and
cleaning can be carried out by the operator.
• When assembling, repairing, maintaining or cleaning the AUW oil pro-
tectors, appropriate measures must be taken to prevent risks to people.

5
AUW oil protector - assembly instructions
Recycling
Removal of packaging
All products are carefully packed for trans-
port. Make a valuable contribution to was-
te prevention and conservation of raw ma-
terials and dispose of packaging materials
only at designated collection points.
Warranty
Warranty conditions are listed in “Gene-
ral Terms and Conditions”. Please contact
your dealer 󰊟rst.
Decription
The German Water Resources Act and the
German Systems Ordinance regulate the
handling of water-polluting substances.
The stainless steel AUW Oil Protector helps
meet these legal requirements.
In the event of leaks, it prevents oil
from water hazard classes one to three
from contaminating the environment,
as per legal requirements. The patented
collection basin with integrated oil sepa-
rator removes the highest amount of pre-
cipitation measured in Germany, without
causing the tray to over󰊠ow. The new
standard sizes guarantee short-term deli-
very of the safety system for all common
split devices.

Ölprotektor.de
6
AUW oil protector scope of delivery
Note:
Check if your delivery is
complete.
AUW oil protector
as depicted
Mounting feet
2 pieces per AUW oil protector
Locking screws
2 pieces per AUW oil protector
Assembly
The separator works according to the
same principle as the CUW Oil Protector.
Thanks to the outlets on both sides, con-
tamination can be detected immediately,
and cleaning the separator also becomes
considerably easier.
After securing the mounting feet with the
wall or oor mounting system, insert the
AUW Oil Protector from the right or left
between the pre-assembled mounting
feet.
Place the outdoor unit on the mounting
feet. By tightening the screws, the protec-
tor is clamped in the holder.
The dimensions allow the installation of
condensing units and machines of many
well-known manufacturers, and allow in-
stallation on standard mounting beams,
vibration dampers and wall brackets.

7
AUW oil protector - assembly instructions
Note:
If you have any questions regarding assembly, installation, maintenance etc.,
please do not hesitate to contact us at:
Service number: [phone] - 0.
Warning
Make sure that other metals do not come
into contact with the AUW Oil Protector, or
obtain information about possible bimetal-
lic corrosion.
Maintenance
Because leaves and other particles can
impair the function of the AUW Oil Protec-
tor, make sure it is checked and cleaned
regularly. The oil separator can be 󰊠ushed
through the water drain.
Cleaning
If there are traces of water-hazardous sub-
stances in the AUW Oil Protector, switch
o󰊞 the installation immediately. Check the
installation for leaks. Traces of water-pollu-
ting substances must be disposed of pro-
perly.
Please note that various cleaning agents
dissolve oil in water. If this type of cleaning
agent is used, the AUW Oil Protector must
be rinsed in water until all traces of the
cleaning agent have been removed from
it.
