H3C S5130S-EI series User manual

H3C S5130S-EI Switch Series
Installation Guide
New H3C Technologies Co., Ltd.
http://www.h3c.com
Document version: 6W102-20180205

Copyright © 2017-2018, New H3C Technologies Co., Ltd. and its licensors
All rights reserved
No part of this manual may be reproduced or transmitted in any form or by any means without prior written
consent of New H3C Technologies Co., Ltd.
Trademarks
H3C, , H3CS, H3CIE, H3CNE,Aolynk, , H3Care, , IRF, NetPilot, Netflow, SecEngine,
SecPath, SecCenter, SecBlade, Comware, ITCMM and HUASAN are trademarks of New H3C Technologies
Co., Ltd.
All other trademarks that may be mentioned in this manual are the property of their respective owners
Notice
The information in this document is subject to change without notice. All contents in this document, including
statements, information, and recommendations, are believed to be accurate, but they are presented without
warranty of any kind, express or implied. H3C shall not be liable for technical or editorial errors or omissions
contained herein.
Environmental protection
This product has been designed to comply with the environmental protection requirements. The storage, use,
and disposal of this product must meet the applicable national laws and regulations.

Preface
H3C S5130S-EI Switch Series Installation Guide describes the appearance, installation, power-on,
maintenance, and troubleshooting of the H3C S5130S-EI Switch Series.
This preface includes the following topics about the documentation:
•Audience.
•Conventions
•Documentation feedback
Audience
This documentation is intended for:
•Network planners.
•Field technical support and servicing engineers.
•Network administrators working with the S5130S-EI switch series.
Conventions
The following information describes the conventions used in the documentation.
Command conventions
Convention Description
Boldface Bold text represents commands and keywords that you enter literally as shown.
Italic Italic text represents arguments that you replace with actual values.
[ ] Square brackets enclose syntax choices (keywords or arguments) that are optional.
{ x | y | ... }
Braces enclose a set of required syntax choices separated by vertical bars, from which
you select one.
[ x | y | ... ]
Square brackets enclose a set of optional syntax choices separated by vertical bars,
from which you select one or none.
{ x | y | ... } *
Asterisk marked braces enclose a set of required syntax choices separated by vertical
bars, from which you select a minimum of one.
[ x | y | ... ] *
Asterisk marked square brackets enclose optional syntax choices separated by vertical
bars, from which you select one choice, multiple choices, or none.
&<1-n> The argument or keyword and argument combination before the ampersand (&) sign
can be entered 1 to n times.
# A line that starts with a pound (#) sign is comments.
GUI conventions
Convention Description
Boldface Window names, button names, field names, and menu items are in Boldface. For
example, the New User window opens; click OK.
> Multi-level menus are separated by angle brackets. For example, File > Create >
Folder.

Symbols
Convention Description
WARNING! An alert that calls attention to important information that if not understood or followed
can result in personal injury.
CAUTION: An alert that calls attention to important information that if not understood or followed
can result in data loss, data corruption, or damage to hardware or software.
IMPORTANT: An alert that calls attention to essential information.
NOTE: An alert that contains additional or supplementary information.
TIP: An alert that provides helpful information.
Network topology icons
Convention Description
Represents a generic network device, such as a router, switch, or firewall.
Represents a routing-capable device, such as a router or Layer 3 switch.
Represents a generic switch, such as a Layer 2 or Layer 3 switch, or a router that
supports Layer 2 forwarding and other Layer 2 features.
Represents an access controller, a unified wired-WLAN module, or the access
controller engine on a unified wired-WLAN switch.
Represents an access point.
Wireless terminator unit.
Wireless terminator.
Represents a mesh access point.
Represents omnidirectional signals.
Represents directional signals.
Represents a security product, such as a firewall, UTM, multiservice security
gateway, or load balancing device.
Represents a security module, such as a firewall, load balancing, NetStream, SSL
VPN, IPS, or ACG module.
Examples provided in this document
Examples in this document might use devices that differ from your device in hardware model,
configuration, or software version. It is normal that the port numbers, sample output, screenshots,
and other information in the examples differ from what you have on your device.
T
T
T
T





Documentation feedback
You can e-mail your comments about product documentation to [e-mail].
We appreciate your comments.

i
Contents
Preparing for installation ····································································1
Safety recommendations ·············································································································1
Examining the installation site·······································································································2
Temperature/humidity ··········································································································2
Cleanliness ························································································································2
EMI ··································································································································3
Laser safety ·······················································································································3
Installation tools·························································································································3
Installing the switch ··········································································4
Installing the switch in a 19-inch rack ·····························································································4
Mounting brackets ···············································································································4
Attaching the mounting brackets to the switch ···········································································6
Rack-mounting the switch ·····································································································8
Mounting the switch on a workbench···························································································· 10
Mounting the switch on a wall ····································································································· 10
Grounding the switch ················································································································ 12
Grounding the switch with a grounding strip ············································································ 12
Grounding the switch with a grounding conductor buried in the earth ground·································· 13
Grounding the switch by using the PE wire of the AC power cord ················································ 14
Installing and removing power modules ························································································ 14
Installing a power module···································································································· 15
Removing a power module ·································································································· 15
Connecting the power cord ········································································································ 16
Connecting the AC power cord for a switch with fixed power modules··········································· 17
Connecting the DC power cord for a switch with fixed power modules ·········································· 17
Connecting the power cord for a PSR75-12A/PSR150-A1 power module ······································ 18
Connecting the power cord for a PSR150-D1 power module······················································· 19
Verifying the installation············································································································· 20
Accessing the switch for the first time ················································· 21
Setting up the configuration environment ······················································································ 21
Connecting the serial console cable ····························································································· 21
Connecting the micro USB console cable······················································································ 22
Setting terminal parameters ······································································································· 24
Powering on the switch ············································································································· 24
Setting up an IRF fabric ···································································26
IRF fabric setup flowchart ·········································································································· 26
Planning IRF fabric setup··········································································································· 27
Planning IRF fabric size and the installation site······································································· 27
Identifying the master switch and planning IRF member IDs ······················································· 27
Planning IRF topology and connections·················································································· 27
Identifying IRF physical ports on the member switches ······························································ 28
Planning the cabling scheme ······························································································· 29
Configuring basic IRF settings ···································································································· 31
Connecting the IRF physical ports ······························································································· 31
Verifying the IRF fabric setup······································································································ 31
Maintenance and troubleshooting ······················································32
Fixed power module failure ········································································································ 32
AC input failure ················································································································· 32
RPS DC input failure ·········································································································· 32
Concurrent RPS and AC inputs failure ··················································································· 33
Removable power module failure ································································································ 33
Symptom ························································································································· 34
Solution··························································································································· 34

ii
Fan tray failure ························································································································ 34
Symptom ························································································································· 34
Solution··························································································································· 34
Configuration terminal issues······································································································ 34
No display on the configuration terminal ················································································· 34
Garbled display on the configuration terminal ·········································································· 35
Appendix A Chassis views and technical specifications ··························36
Chassis views ························································································································· 36
S5130S-10P-EI················································································································· 36
S5130S-12TP-EI ··············································································································· 37
S5130S-20P-EI················································································································· 37
S5130S-28P-EI/S5130S-28P-EI-M························································································ 38
S5130S-28TP-EI ··············································································································· 39
S5130S-52P-EI/S5130S-52P-EI-M························································································ 39
S5130S-52TP-EI ··············································································································· 40
S5130S-28S-EI/S5130S-28S-EI-M························································································ 41
S5130S-52S-EI/S5130S-52S-EI-M························································································ 41
S5130S-10P-HPWR-EI······································································································· 42
S5130S-12TP-HPWR-EI····································································································· 43
S5130S-20P-PWR-EI········································································································· 43
S5130S-28P-PWR-EI········································································································· 44
S5130S-28P-HPWR-EI······································································································· 45
S5130S-52P-PWR-EI········································································································· 46
S5130S-28S-PWR-EI········································································································· 46
S5130S-28S-HPWR-EI······································································································· 47
S5130S-52S-PWR-EI········································································································· 48
S5130S-28F-EI ················································································································· 49
S5130S-52F-EI ················································································································· 50
Technical specifications············································································································· 50
Appendix B FRUs··········································································· 59
Appendix C Ports and LEDs ····························································· 60
Ports ····································································································································· 60
Console port····················································································································· 60
10/100/1000BASE-T autosensing Ethernet port ······································································· 60
SFP port·························································································································· 60
SFP+ port ························································································································ 64
Combo interface················································································································ 65
LEDs····································································································································· 65
System status LED ············································································································ 65
Power module status LED ··································································································· 66
RPS status LED ················································································································ 66
Mode LED (MODE)············································································································ 66
SFP/SFP+ port LED··········································································································· 67
10/100/1000BASE-T autosensing Ethernet port LED ································································ 67
Index ···························································································68

1
Preparing for installation
The H3C S5130S-EI Switch Series includes the following models:
•S5130S-10P-EI.
•S5130S-12TP-EI.
•S5130S-20P-EI.
•S5130S-28P-EI.
•S5130S-28P-EI-M.
•S5130S-28TP-EI.
•S5130S-52P-EI.
•S5130S-52P-EI-M.
•S5130S-52TP-EI.
•S5130S-28S-EI.
•S5130S-28S-EI-M.
•S5130S-52S-EI.
•S5130S-52S-EI-M.
•S5130S-10P-HPWR-EI.
•S5130S-12TP-HPWR-EI.
•S5130S-20P-PWR-EI.
•S5130S-28P-PWR-EI.
•S5130S-28P-HPWR-EI.
•S5130S-52P-PWR-EI.
•S5130S-28S-PWR-EI.
•S5130S-28S-HPWR-EI.
•S5130S-52S-PWR-EI.
•S5130S-28F-EI.
•S5130S-52F-EI.
NOTE:
The available chassis models and accessories vary by country and region. This document describes
only the preceding models. For the chassis models and accessories available in your country or
region, contact the local H3C marketing personnel.
Safety recommendations
To avoid equipment damage or bodily injury, read the following safety recommendations before
installation. Note that the recommendations do not cover every possible hazardous condition.
•Before cleaning the switch, remove all power cords from the switch. Do not clean the switch
with wet cloth or liquid.
•Do not place the switch near water or in a damp environment. Prevent water or moisture from
entering the switch chassis.
•Do not place the switch on an unstable case or desk.

2
•Ensure good ventilation at the installation site and keep the air inlet and outlet vents of the
switch free of obstruction.
•Connect the yellow-green protection grounding cable before power-on.
•Make sure the power source voltage is as required.
•To avoid electrical shocks, do not open the chassis while the switch is operating or when the
switch is just powered off.
•To avoid ESD damage, wear an ESD wrist strap to hot-swap a power module.
Examining the installation site
The S5130S-EI switches must be used indoors. You can mount your switch in a rack or on a
workbench, but make sure:
•Adequate clearance is reserved at the air inlet and exhaust vents for ventilation.
•The rack or workbench has a good ventilation system.
•The rack is sturdy enough to support the switch and its accessories.
•The rack or workbench is reliably grounded.
To ensure correct operation and long service life of your switch, install it in an environment that meets
the requirements described in the following subsections.
Temperature/humidity
Maintain temperature and humidity in the equipment room as described in "Technical specifications."
•Lasting high relative humidity can cause poor insulation, electricity leakage, mechanical
property change of materials, and metal corrosion.
•Lasting low relative humidity can cause washer contraction and ESD and cause problems
including loose mounting screws and circuit failure.
•High temperature can accelerate the aging of insulation materials and significantly lower the
reliability and lifespan of the switch.
For the temperature and humidity requirements of different switch models, see "Appendix A Chassis
views and technical specifications."
Cleanliness
Dust buildup on the chassis might result in electrostatic adsorption, which causes poor contact of
metal components and contact points, especially when indoor relative humidity is low. In the worst
case, electrostatic adsorption can cause communication failure.
Table 1 Dust concentration limit in the equipment room
Substance Concentration limit (particles/m³)
Dust ≤3 x 104 (no visible dust on the tabletop over three days)
NOTE:
Dust diameter ≥5 μm
The equipment room must also meet strict limits on salts, acids, and sulfides to eliminate corrosion
and premature aging of components, as shown in Tabl e 2.

3
Table 2 Harmful gas limits in the equipment room
Gas Maximum concentration (mg/m3)
SO20.2
H2S 0.006
NH30.05
Cl20.01
EMI
All electromagnetic interference (EMI) sources, from outside or inside of the switch and application
system, adversely affect the switch in the following ways:
•A conduction pattern of capacitance coupling.
•Inductance coupling.
•Electromagnetic wave radiation.
•Common impedance (including the grounding system) coupling.
To prevent EMI, use the following guidelines:
•If AC power is used, use a single-phase three-wire power receptacle with protective earth (PE)
to filter interference from the power grid.
•Keep the switch far away from radio transmitting stations, radar stations, and high-frequency
devices to make sure the EMI levels do not exceed the compliant range.
•Use electromagnetic shielding when necessary. For example, use shielded interface cables.
•To prevent signal ports from getting damaged by overvoltage or overcurrent caused by lightning
strikes, only route interface cables indoors.
Laser safety
WARNING!
Disconnected optical fibers or transceiver modules might emit invisible laser light. Do not stare into
beams or view directly with optical instruments when the switch is operating.
The S5130S-EI switches are Class 1 laser devices.
Installation tools
No installation tools are provided with the switch. Prepare them yourself as required.
•Flat-blade screwdriver
•Phillips screwdriver
•ESD wrist strap
•Needle-nose pliers
•Diagonal pliers
•Crimping tool
•Marker
•Heat gun

4
Installing the switch
CAUTION:
Keep the tamper-proof seal on a mounting screw on the chassis cover intact, and if you want to open
the chassis, contact H3C for permission. Otherwise, H3C shall not be liable for any consequence.
Figure 1 Hardware installation flow
Installing the switch in a 19-inch rack
Mounting brackets
Table 3 describes the mounting brackets applicable to the switch.
Ground the switch
Install the switch
Start
Connect power cords
Verify the installation
Turn on the circuit breakers
Select and install power
modules
Hot-swap power
modules?
Yes
No
Operating correctly? Turn off the circuit
breakers
Troubleshoot the switch
No
Yes
End
Install interface connectors
and cables

5
Table 3 Mounting brackets applicable to the switch
Switch model Mounting brackets Views
S5130S-28P-EI
S5130S-28P-EI-M
S5130S-28TP-EI
S5130S-52P-EI
S5130S-52P-EI-M
S5130S-52TP-EI
S5130S-28S-EI
S5130S-28S-EI-M
S5130S-52S-EI
S5130S-52S-EI-M
S5130S-28P-PWR-EI
S5130S-28P-HPWR-EI
S5130S-52P-PWR-EI
S5130S-28S-PWR-EI
S5130S-28S-HPWR-EI
S5130S-52S-PWR-EI
Mounting brackets A (provided) See A in Figure 2.
S5130S-28F-EI
S5130S-52F-EI Mounting brackets B (provided) See B in Figure 2.
S5130S-20P-EI
S5130S-10P-HPWR-EI
S5130S-12TP-HPWR-EI
S5130S-20P-PWR-EI
Mounting brackets C with product code
SOHO-SWITCH-FL-02 (optional) See C in Figure 2.
S5130S-10P-EI
S5130S-12TP-EI
Mounting brackets D with product code
SOHO-SWITCH-FL-01 (optional) See D in Figure 2.

6
Figure 2 Mounting brackets
(1) Screw hole for attaching the bracket to the switch
(2 ) Screw hole for attaching the bracket to the rack post
Attaching the mounting brackets to the switch
1. Determine the installation position for the mounting brackets.
{The S5130S-28F-EI and S5130S-52F-EI switches provide two installation positions for the
mounting brackets: port side mounting position and power module side mounting position.
{The other S5130S-EI switches provide only the port side mounting position for the mounting
brackets.
2. Align one mounting bracket with the screw holes at the mounting position. Use M4 screws to
attach the mounting bracket to the chassis. See Figure 3 for installing mounting bracket
A, Figure 4 and Figure 5 for installing mounting bracket B, Figure 6 for installing mounting
bracket C, and Figure 7 for installing mounting bracket D.
M4 screws are provided only for switches shipped with mounting brackets.
An optional mounting bracket kit contains M4 screws.
3. Repeat step 2to attach the other mounting bracket to the chassis.

7
Figure 3 Attaching mounting bracket A (S5130S-28P-HPWR-EI switch)
Figure 4 Attaching mounting bracket B to the port side mounting position (S5130S-52F-EI
switch)
Figure 5 Attaching mounting bracket B to the power module side mounting position
(S5130S-52F-EI switch)
Figure 6 Attaching mounting bracket C (S5130S-20P-PWR-EI switch)

8
Figure 7 Attaching mounting bracket D (S5130S-10P-EI switch)
Rack-mounting the switch
This task requires two people. To mount the switch in the rack:
1. Wear an ESD wrist strap and make sure it makes good skin contact and is reliably grounded.
2. Verify that the mounting brackets have been securely attached to the switch chassis.
3. Install cage nuts in the mounting holes in the rack posts.
No cage nuts are provided with the switch. Prepare them yourself.
4. One person holds the switch chassis and aligns the mounting brackets with the mounting holes
in the rack posts, and the other person attaches the mounting brackets to the rack with M6
screws.
M6 screws are provided only for switches shipped with mounting brackets. For switches not
shipped with mounting brackets, prepare M6 screws yourself.
5. Verify that the switch chassis is horizontal and secure.
Figure 8 Mounting an S5130S-52F-EI switch in the rack (port side mounting position for the
mounting brackets)

9
Figure 9 Mounting an S5130S-52F-EI switch in the rack (power module side mounting
position for the mounting brackets)
Figure 10 Mounting an S5130S-20P-PWR-EI switch in the rack
Figure 11 Mounting an S5130S-10P-EI switch in the rack

10
Mounting the switch on a workbench
IMPORTANT:
•Ensure 10 cm (3.9 in) of clearance around the chassis for heat dissipation.
•Do not place heavy objects on the switch.
If a standard 19-inch rack is not available, you can place you switch on a workbench.
To mount the switch on a workbench:
1. Verify that the workbench is sturdy and reliably grounded.
2. Place the switch with bottom up, and clean the round holes in the chassis bottom with dry cloth.
3. Attach the rubber feet to the four round holes in the chassis bottom.
4. Place the switch with upside up on the workbench.
Mounting the switch on a wall
CAUTION:
•Before drilling holes in a wall, make sure no electrical lines exist in the wall.
•Leave a minimum clearance of 10 mm (0.39 in) around the chassis for heat dissipation.
Table 4 describes the switch models that support wall mounting and installation holes distances
required for wall-mounting the switch. Screw anchors and screws as shown in Figure 12 are
provided with these switches for wall-mounting.
Table 4 Installation hole distances for switch models that support wall mounting
Switch model Hole distance
S5130S-10P-EI
S5130S-12TP-EI 170 mm (6.69 in)
S5130S-20P-EI 176 mm (6.93 in)
S5130S-10P-HPWR-EI
S5130S-12TP-HPWR-EI 102 mm (4.02 in)
S5130S-20P-PWR-EI 116 mm (4.57 in)
Figure 12 Screw anchor and screw
To mount the switch on a wall:
1. Mark two installation holes on the wall. Make sure the two holes are on the same horizontal line.
See Table 4 for the distance requirement between the two holes.

11
Figure 13 Installing the switch on a wall (1)
2. Drill two holes with a diameter of 6 mm (0.24 in) and a depth of 25 mm (0.98 in) at the marked
locations. Hammer the screw anchors into the wall and use a Phillips screwdriver to fasten the
screw into the screw anchor. Leave 1.5 mm (0.06 in) between the screw head and the wall for
hanging the switch.
Figure 14 Installing the switch on a wall (2)
3. Align the installation holes in the switch rear with the screws on the wall and hang the switch on
the screws. Make sure the port side faces down and the left and right sides are perpendicular to
the ground.
Figure 15 Installing the switch on a wall (3)

12
Grounding the switch
WARNING!
Correctly connecting the switch grounding cable is crucial to lightning protection and EMI protection.
The power input end of the switch has a noise filter, whose central ground is directly connected to the
chassis to form the chassis ground (commonly known as PGND). You must securely connect this
chassis ground to the earth to minimize the potential for system damage, maximize the safety at the
site, and minimize EMI susceptibility of the system.
You can ground the switch in one of the following ways, depending on the grounding conditions
available at the installation site:
•Grounding the switch with a grounding strip
•Grounding the switch with a grounding conductor buried in the earth ground
•Grounding the switch by using the PE wire of the AC power cord
NOTE:
The chassis views and power module and grounding terminal positions in the following figures are
for illustration only.
Grounding the switch with a grounding strip
WARNING!
Connect the grounding cable to the grounding system in the equipment room. Do not connect it to a
fire main or lightning rod.
If a grounding strip is available at the installation site, use the grounding strip to ground the switch.
To ground the switch by using a grounding strip:
1. Attach the ring terminal end of the grounding cable to the grounding hole in the switch.
a. Remove the grounding screw from the grounding hole in the rear panel of the switch.
b. Attach the grounding screw to the ring terminal of the grounding cable.
c. Use a screwdriver to fasten the grounding screw into the grounding screw hole.

13
Figure 16 Attaching the grounding cable to the grounding hole of the switch
(S5130S-28P-HPWR-EI switch)
(1) Grounding screw (2) Ring terminal
(3) Grounding sign (4) Grounding hole
(5) Grounding cable
2. Connect the other end of the grounding cable to the grounding strip.
a. Cut the grounding cable to a length according to the distance between the switch and the
grounding strip.
b. Peel 20 mm (0.79 in) of insulation sheath by using a wire stripper.
c. Use the needle-nose pliers to bend the bare wire.
d. Hook the grounding cable to the post on the grounding strip, and use the hex nut to secure
the cable to the post.
Figure 17 Connecting the grounding cable to a grounding strip
(1) Grounding post (2) Grounding strip
(3) Grounding cable (4) Hex nut
Grounding the switch with a grounding conductor buried in
the earth ground
If the installation site has no grounding strips, but earth ground is available, hammer a 0.5 m (1.64 ft)
or longer angle iron or steel tube into the earth ground to serve as a grounding conductor.
The dimensions of the angle iron must be at least 50 × 50 × 5 mm (1.97 × 1.97 × 0.20 in). The steel
tube must be zinc-coated and its wall thickness must be at least 3.5 mm (0.14 in).
1 2
34
