Habasit PM-1306 Configuration guide

HOT PRESS
Type : PM-1306
GENERAL MANUAL
USE AND MAINTENANCE
ORDER : S.N. :
Habasit Italiana S.p.A. - Via A. Meucci 8 Zona Industriale - I - 31029 Vittorio Veneto
This document is the property of HABASIT ITALIANA and, therefore, must not be passed on to persons or Bodies outside the
sphere of the Company unless previously authorized by the Technical Department for Industrial and Quality Systems.

Habasit Italiana S.p.A.
Vittorio Veneto 31029 (TV)
Tel.: ++39(0)438.9113
Fax. ++39(0)438.200545 Hot Press PM-1306
Author: S.D.T. / KM INDEX
Edition: 02/2005 Page 1
Replaces: 01/2002
FOREWORD
IMPORTANT
BEFORE INSTALLING, SETTING UP AND OPERATING THE HOT-PRESSING DEVICE, THE
CUSTOMER MUST CAREFULLY READ THIS MANUAL AND CAREFULLY FOLLOW THE
INSTRUCTIONS IT CONTAINS IN ORDER TO ENSURE THE HOT-PRESSING DEVICE IS USED
SAFELY AND CORRECTLY.
ALL OPERATORS AND/OR MAINTENANCE PERSONNEL MUST KNOW THIS MANUAL TO ENABLE
THEM TO WORK SAFELY ON THE HOT-PRESSING DEVICE.
Hot-pressing device PM-1306

Habasit Italiana S.p.A.
Vittorio Veneto 31029 (TV)
Tel.: ++39(0)438.9113
Fax. ++39(0)438.200545 Hot Press PM-1306
Author: S.D.T. / KM INDEX
Edition: 02/2005 Page 2
Replaces: 01/2002
SUMMARY
A. REGULATIONS AND GENERAL WARNING NOTES................................................................A-1
A.1 Reading assistance notes ............................................................................................................A-2
A.2 How the manual is organized.......................................................................................................A-3
A.3 Use criteria....................................................................................................................................A-4
A.4 Guarantee conditions....................................................................................................................A-5
A.4.1 Guarantee terms and validity........................................................................................................A-5
A.4.2 When the guarantee can be voided..............................................................................................A-5
A.5 Visual signs...................................................................................................................................A-6
A.5.1 Signs.............................................................................................................................................A-6
A.6 Safety warnings..........................................................................................................................A-10
A.7 Remaining risks..........................................................................................................................A-11
A.8 Qualification of personnel...........................................................................................................A-12
A.9 References and standards .........................................................................................................A-13
A.9.1 Applicable EU Directives ............................................................................................................A-13
A.9.2 EU Directives concerning safety in the workplace .....................................................................A-13
A.9.3 EU Directives concerning personal protection ...........................................................................A-13
A.9.4 EU Directives concerning environmental protection...................................................................A-13
B. TECHNICAL SPECIFICATIONS..................................................................................................B-1
B.1 Purpose of the hot-pressing device..............................................................................................B-2
B.2 Press identification data................................................................................................................B-3
B.3 Technical characteristics of the hot-pressing device....................................................................B-4
B.4 Equipment and accessories provided...........................................................................................B-6
B.4.1 Necessary accessories for stationary use....................................................................................B-6
B.4.2 Necessary accessories for mobile use.........................................................................................B-7
B.4.3 Regulating unit options.................................................................................................................B-8
B.4.4 Cooling unit options......................................................................................................................B-8
B.4.5 Optional accessories for both stationary and mobile use.............................................................B-9
B.5 Ordering of accessories and spare parts....................................................................................B-10
C. INSTALLATION ...........................................................................................................................C-1
C.1 Preparation of working area .........................................................................................................C-2
C.2 Packing and handling...................................................................................................................C-3
C.2.1 Handling – Stationary use ............................................................................................................C-3
C.2.2 Handling – Mobile use..................................................................................................................C-4
C.3 Assembling and installation..........................................................................................................C-5
C.3.1 Positioning....................................................................................................................................C-5
C.3.2 Connection of air and water supplies ...........................................................................................C-5
C.3.3 Electrical connection.....................................................................................................................C-6
C.4 Disassembling of the hot-pressing device....................................................................................C-7
C.5 Storage.........................................................................................................................................C-8
C.6 Disposal........................................................................................................................................C-9
Hot-pressing device PM-1306

Habasit Italiana S.p.A.
Vittorio Veneto 31029 (TV)
Tel.: ++39(0)438.9113
Fax. ++39(0)438.200545 Hot Press PM-1306
Author: S.D.T. / KM INDEX
Edition: 02/2005 Page 3
Replaces: 01/2002
D. OPERATION ................................................................................................................................D-1
D.1 General warnings..........................................................................................................................D-2
D.2 Guards installed............................................................................................................................D-3
D.3 Identification of press’ parts..........................................................................................................D-5
D.3.1 View of PM-1306 ..........................................................................................................................D-5
D.3.2 Main elements of the PM-1306.....................................................................................................D-6
D.3.3 Pneumatic connection ..................................................................................................................D-7
D.4 Hot-pressing device’s configuration..............................................................................................D-8
D.4.1 Stationary operation use...............................................................................................................D-8
D.4.2 Mobile operation use..................................................................................................................D-10
D.5 Press operation...........................................................................................................................D-11
D.5.1 Working stationary and mobile...................................................................................................D-11
D.5.2 Working cycles............................................................................................................................D-11
D.5.3 Stationary operation use.............................................................................................................D-11
D.5.4 Mobile operation use..................................................................................................................D-13
D.5.5 Notes on use...............................................................................................................................D-14
D.5.6 Technical assistance ..................................................................................................................D-14
D.6 Troubleshooting..........................................................................................................................D-15
E. ORDINARY MAINTENANCE.......................................................................................................E-1
E.1 General.........................................................................................................................................E-2
E.2 General warnings..........................................................................................................................E-3
E.3 Routine and scheduled maintenance...........................................................................................E-4
E.3.1 Preliminary operations..................................................................................................................E-4
F. EXTRAORDINARY MAINTENANCE........................................................................................... F-1
F.1 Extraordinary maintenance...........................................................................................................F-2
F.1.1 Adjustments, replacements and synchronization.........................................................................F-2
G. ELECTRICAL, WATER AND COMPRESSED AIR SYSTEM.....................................................G-1
G.1 Electrical, water and compressed air system...............................................................................G-2
H. GLOSSARY..................................................................................................................................H-1
H.1 Glossary of terms..........................................................................................................................H-2
I. SPARE PARTS............................................................................................................................. I-1
I.1 Internal spare parts........................................................................................................................ I-2
I.2 Spare parts of pressure cushion.................................................................................................... I-4
I.3 External spare parts....................................................................................................................... I-6
I.4 Spare parts of belt clamping system ............................................................................................. I-8
I.5 Spare parts for pneumatic connection......................................................................................... I-10
I.6 Spare parts for electrical, water and compressed air connections.............................................. I-11
J. ANNEXED COMMERCIAL DOCUMENTS.................................................................................. J-1
J.1 Water circulation pump..................................................................................................................J-2
J.2 Portable compressor......................................................................................................................J-3
Hot-pressing device PM-1306

Habasit Italiana S.p.A.
Vittorio Veneto 31029 (TV)
Tel.: ++39(0)438.9113
Fax. ++39(0)438.200545 Hot Press PM-1306
Author: S.D.T. / KM INDEX
Edition: 02/2005 Page 4
Replaces: 01/2002
SUMMARY OF FIGURES
FIGURE 1-MACHINE IDENTIFICATION PLATE ................................................................................................B-3
FIGURE 2-POSITION OF SIGNS ON THE PRESS.............................................................................................D-4
FIGURE 3-VIEW OF PM-1306....................................................................................................................D-5
FIGURE 4-MAIN ELEMENTS OF THE PM-1306.............................................................................................D-6
FIGURE 5-PNEUMATIC CONNECTION ..........................................................................................................D-7
FIGURE 6-STATIONARY OPERATION USE WITH PMR-06 AND PMC-04.........................................................D-8
FIGURE 7-STATIONARY OPERATION USE WITH PMR-06 AND PMC-06.........................................................D-9
FIGURE 8-MOBILE OPERATION USE WITH PMR-06....................................................................................D-10
FIGURE 9-PRESS WIRING LAY-OUT.............................................................................................................G-2
FIGURE 10 -INTERNAL SPARE PARTS ............................................................................................................. I-2
FIGURE 11 -PRESSER CUSHION SPARE PARTS ............................................................................................... I-4
FIGURE 12 -EXTERNAL SPARE PARTS............................................................................................................ I-6
FIGURE 13 -BELT LOCKING SYSTEM SPARE PARTS ......................................................................................... I-8
FIGURE 14 -SPARE PARTS FOR PNEUMATIC CONNECTION............................................................................. I-10
SUMMARY OF TABLES
TABLE 1-DANGER SIGNS ...........................................................................................................................A-7
TABLE 2-PRESCRIPTIVE SIGNS ..................................................................................................................A-7
TABLE 3-TERMS AND DEFINITIONS .............................................................................................................A-8
TABLE 4-QUALIFICATIONS .......................................................................................................................A-12
TABLE 5-ELECTRICAL CHARACTERISTICS OF THE HEATERS .........................................................................B-4
TABLE 6-PNEUMATIC CHARACTERISTICS ....................................................................................................B-4
TABLE 7-WATER CHARACTERISTICS...........................................................................................................B-4
TABLE 8-DIMENSIONS AND ENVIRONMENTAL CHARACTERISTICS ..................................................................B-5
TABLE 9-CHARACTERISTICS OF WORKABLE ELEMENTS................................................................................B-5
TABLE 10 -NECESSARY ACCESSORIES FOR STATIONARY USE ........................................................................B-6
TABLE 11 -ACCESSORIES NECESSARY FOR MOBILE USE................................................................................B-7
TABLE 12 -REGULATING UNIT OPTIONS (PMR-XX) (PRESS-XX COMBINATIONS).............................................B-8
TABLE 13 -CONTROL UNIT OPTIONS (PMC-XX) (PMR-XX –PMC-XX COMBINATIONS)..................................B-8
TABLE 14 -OPTIONAL ACCESSORIES (FOR BOTH STATIONARY AND MOBILE USE)..............................................B-9
TABLE 15 -STORAGE CONDITIONS................................................................................................................C-8
TABLE 16 -TROUBLESHOOTING..................................................................................................................D-15
TABLE 17 -PERIODIC MAINTENANCE WORK ...................................................................................................E-5
TABLE 18 -GLOSSARY.................................................................................................................................H-2
TABLE 19 -SPARE PARTS AND INTERNAL PARTS ............................................................................................. I-3
TABLE 20 -SPARE PARTS AND PRESSER CUSHION L=1300............................................................................ I-5
TABLE 21 -EXTERNAL SPARE PARTS.............................................................................................................. I-7
TABLE 22 -BELT LOCKING SYSTEM SPARE PARTS ........................................................................................... I-9
TABLE 23 -SPARE PARTS FOR PNEUMATIC CONNECTION............................................................................... I-10
TABLE 24 -SPARE PARTS FOR ELECTRICAL,WATER AND AIR CONNECTIONS USED IN STATIONARY OPERATION .I-11
TABLE 25 -SPARE PARTS FOR ELECTRICAL,WATER AND AIR CONNECTIONS USED IN MOBILE OPERATION......... I-12
Hot-pressing device PM-1306

Habasit Italiana S.p.A.
Vittorio Veneto 31029 (TV)
Tel.: ++39(0)438.9113
Fax. ++39(0)438.200545 Hot Press PM-1306
Author: S.D.T. /KM REGULATIONS AND GENERAL WARNING NOTES
Edition: 02/2005 Page A-1
Replaces: 01/2002
A. REGULATIONS AND GENERAL WARNING NOTES
Hot-pressing device PM-1306

Habasit Italiana S.p.A.
Vittorio Veneto 31029 (TV)
Tel.: ++39(0)438.9113
Fax. ++39(0)438.200545 Hot Press PM-1306
Author: S.D.T. /KM REGULATIONS AND GENERAL WARNING NOTES
Edition: 02/2005 Page A-2
Replaces: 01/2002
A.1 Reading assistance notes
Meanings of notes used in this manual:
ATTENTION
Note of particular interest for the safety of the people running and maintaining the hot-pressing device.
WARNING
Note of particular interest concerning the safety of the hot-pressing device.
NOTE
A request for the reader’s attention referred to the subsequent paragraph.
Hot-pressing device PM-1306

Habasit Italiana S.p.A.
Vittorio Veneto 31029 (TV)
Tel.: ++39(0)438.9113
Fax. ++39(0)438.200545 Hot Press PM-1306
Author: S.D.T. /KM REGULATIONS AND GENERAL WARNING NOTES
Edition: 02/2005 Page A-3
Replaces: 01/2002
A.2 How the manual is organized
This hot-pressing device was designed, built and tested by expert technicians. The high quality materials
used to build the hot-pressing device make it operationally highly reliable.
For further, more detailed information or in regard to problems, please contact our the following address:
Habasit Italiana S.p.A.
Via A. Meucci 8
Zona Industriale
I - 31029 Vittorio Veneto
Tel.: [phone]
Fax: [phone]
This manual observes the organizational rules and requirements of Directive 98/37/CE, duly amended,
being the Directive of the Council of the European Community of June 14, 1989, concerning the
reconciliation of the laws of member states regarding machines, also known as the «Machine Directive»,
and also all the other Directives and Regulations referred to in the said Machine Directive, inspired by
criteria which, in addition to illustrating the technical characteristics of the machine and its use,
maintenance and troubleshooting methods, also clearly indicate the following:
All the protection measures adopted on the hot-pressing device, fully integrating design safety planning
and construction safety
All protection measures to be adopted to meet those risks that cannot be completely eliminated
All indications for the training of personnel using the hot-pressing device, while indicating where it is
necessary to provide for individual safety protection devices.
The manual is divided up into sections. Each section deals with a specific subject in which every aspect
of safety is considered and clearly highlighted in the text.
Hot-pressing device PM-1306

Habasit Italiana S.p.A.
Vittorio Veneto 31029 (TV)
Tel.: ++39(0)438.9113
Fax. ++39(0)438.200545 Hot Press PM-1306
Author: S.D.T. /KM REGULATIONS AND GENERAL WARNING NOTES
Edition: 02/2005 Page A-4
Replaces: 01/2002
A.3 Use criteria
HABASIT requests the Customer to fully read this manual on delivery of the hot-pressing device it
accompanies, and always before attempting any action on the hot-pressing device. This manual is
arranged to supply all the instructions, indications and warnings the user may need in order to know the
hot-pressing device, understand its operating principles, and to be adequately informed to ensure safe
use.
In addition to the instructions in this manual, we would ask users to observe any specific current laws.
This manual must be considered as an essential part of the machine. Its content must be made known to
the entrusted maintenance persons and users.
The purpose is to provide all the information required for good, correct use of the device.
The manual must be kept throughout the life of the hot-pressing device and must be updated in the event
of modifications aimed at improving the device’s performance.
The manual must be available to qualified personnel.
Consultation of this manual is facilitated by the general index on the first page, which makes it possible to
immediately find the subject of interest.
If the subject dealt with is particularly important it is highlighted with references to the type of technical
personnel required to intervene.
All updates HABASIT considers necessary to improve the quality of the hot-pressing device will be
communicated by way of sending further specific documentation or a new manual to replace the previous
one.
If the hot-pressing device is sold to another customer, the manual must accompany the hot-pressing
device and the new customer must be notified to HABASIT for any future modifications and updates.
A copy of this manual, delivered with the hot-pressing device, is meant for the maintenance operators,
who shall read and keep it near the hot-pressing device, and consult it before undertaking any action on
the hot-pressing device.
Hot-pressing device PM-1306

Habasit Italiana S.p.A.
Vittorio Veneto 31029 (TV)
Tel.: ++39(0)438.9113
Fax. ++39(0)438.200545 Hot Press PM-1306
Author: S.D.T. /KM REGULATIONS AND GENERAL WARNING NOTES
Edition: 02/2005 Page A-5
Replaces: 01/2002
A.4 Guarantee conditions
A.4.1 Guarantee terms and validity
The manufacturer guarantees the product against any faults either in materials or in workmanship, for 1
(one) year from the date of installation of the product at the Buyer’s premises. In this case, the
manufacturer shall limit itself to replacing or repairing any part or parts returned to the manufacturer,
which was/were found to be faulty.
The manufacturer may, at his own discretion, also replace or repair any part or parts of the product being
repaired that is/are felt to be defective.
The manufacturer shall have the sole right to decide if such parts should be repaired or replaced.
The manufacturer shall not be liable in any other case for collateral or incidental damage.
The guarantee does not apply to plant that has been repaired by third parties that have NOT been
authorized by the manufacturer.
Spare parts supplied by the manufacturer must be used. Any deviation from this rule will mean the
guarantee will not apply.
A.4.2 When the guarantee can be voided
The manufacturer's guarantee for the plant and associated equipment may be annulled as a result of
improper intervention or repairs.
The manufacturer's guarantee for the equipment may be annulled as a result of the use of improper
materials or materials not supplied by the manufacturer.
This manual’s instructions must be observed or the guarantee cover will be lost.
IMPORTANT
HABASIT CANNOT BE HELD RESPONSIBLE FOR ANY DAMAGE CAUSED BY IMPROPER,
INCORRECT AND UNREASONABLE USE OF THE HOT-PRESSING DEVICE.
Hot-pressing device PM-1306

Habasit Italiana S.p.A.
Vittorio Veneto 31029 (TV)
Tel.: ++39(0)438.9113
Fax. ++39(0)438.200545 Hot Press PM-1306
Author: S.D.T. /KM REGULATIONS AND GENERAL WARNING NOTES
Edition: 02/2005 Page A-6
Replaces: 01/2002
A.5 Visual signs
ATTENTION
Visual signs – indicator notices – are applied to the hot-pressing device. A knowledge of their meaning
helps ensure that safety regulations are observed to prevent accidents and assure good operation.
All people approaching the hot-pressing device must have a clear understanding of the symbol and its
meaning. Non observance may cause accidents entailing damage to personnel and to the hot-pressing
device.
A.5.1 Signs
The signs affixed to the hot-pressing device are shown below. Such signs enable staff operating or
working on the hot-pressing device to know about and so prevent the dangers and risks of not observing
the principal safety rules.
Hot-pressing device PM-1306

Habasit Italiana S.p.A.
Vittorio Veneto 31029 (TV)
Tel.: ++39(0)438.9113
Fax. ++39(0)438.200545 Hot Press PM-1306
Author: S.D.T. /KM REGULATIONS AND GENERAL WARNING NOTES
Edition: 02/2005 Page A-7
Replaces: 01/2002
TABLE 1-DANGER SIGNS
Attention: DANGER OF ELECTRIC SHOCKS
Indicates the personnel involved that, if the described operation is not
performed while observing safety regulations, there is a risk of suffering an
electric shock.
Attention: DANGER OF CRUSHING OF OR INJURIES TO HANDS
AND FINGERS
Indicates the presence of materials which can cause damage to limbs.
Attention: HIGH TEMPERATURE PARTS
Indicates the presence of very hot materials which could cause burns.
TABLE 2-PRESCRIPTIVE SIGNS
General obligation
An obligation to carry out the operation as described and in accordance with
safety rules so as to avoid risks and accidents.
This is usually accompanied by notices explaining the obligation.
Obligation to use protective gloves
Use of protective gloves by the operator, as the risk of hand injuries is
implicit.
Obligation to use protective shoes
Use of protective shoes by the operator as the risk of slipping, perforation or
crushing of feet is implicit.
Maximum usable pressure warning
Indication of maximum pressure that can be applied to the pressure cushion.
Hot-pressing device PM-1306

Habasit Italiana S.p.A.
Vittorio Veneto 31029 (TV)
Tel.: ++39(0)438.9113
Fax. ++39(0)438.200545 Hot Press PM-1306
Author: S.D.T. /KM REGULATIONS AND GENERAL WARNING NOTES
Edition: 02/2005 Page A-8
Replaces: 01/2002
TABLE 3-TERMS AND DEFINITIONS
TERM DEFINITION
PROTECTION DEVICES
Safety measures involving the use of specific technical means called
protection devices (guards, safety devices) to protect persons from
dangers that cannot be reasonably eliminated or sufficiently reduced in
the design of the machine.
GUARD
A part of the machine specifically used to provide protection by the use
of a physical barrier. Depending on how it is made, a guard may be
called a cowling, cover, screen, door or fence etc. Note 1 - A guard may
act: - alone; in which case it is effective only when closed - associated
with a locking device with or without locking the guard; in this case
protection is assured whatever the position of the guard. Note 2 -
«Closed» means, in the case of a fixed guard, «kept in position».
FIXED GUARD
Guard kept in position (i.e. closed), by means of a fastening (screws,
bolts etc.) that make its removal/opening impossible without the use of
tools.
MOBILE GUARD
Guard that is generally mechanically connected to the frame of the
machine or to nearby fixed element (by means for example of hinges or
guides), and that can be opened without the use of tools.
INTERLOCKED MOBILE
GUARD
Guard associated with an interlock device so that : The machine's
dangerous functions «protected» by the guard cannot be carried out
unless the guard has been closed − If the guard is opened during the
unfolding of the machine's dangerous functions, a stop command is
given − The closure of the guard permits execution of the machine's
dangerous functions «protected» by the guard but it does not control the
start up.
Hot-pressing device PM-1306

Habasit Italiana S.p.A.
Vittorio Veneto 31029 (TV)
Tel.: ++39(0)438.9113
Fax. ++39(0)438.200545 Hot Press PM-1306
Author: S.D.T. /KM REGULATIONS AND GENERAL WARNING NOTES
Edition: 02/2005 Page A-9
Replaces: 01/2002
SAFETY DEVICE Eliminates or reduces the risk, either alone or in association with a
guard.
INTERLOCK DEVICE
(INTERBLOCK)
An mechanical or electrical or other kind of device whose aim is to
prevent elements of the machine from functioning under specified
conditions (generally until the guard is closed).
PROTECTION
STRUCTURE
A physical obstacle such as a guard or part of the machine, that limits
the movement of the body and/or one of its parts. The safety distances
have been determined on the basis of the requisites at point 4.1.1 of the
standard UNI EN294.
SAFETY DISTANCE
The minimum distance a protective structure must be positioned with
respect to a dangerous area. The safety distances have been
determined on the basis of the requisites at point 4.1.1 of the standard
UNI EN294.
INDIVIDUAL
PROTECTION DEVICE
Safety devices such as gloves, shoes, helmet, visor, earplugs etc. aimed
at protecting parts of the body.
CONTROL CIRCUIT A circuit used to control the working of the machine and protect the power circuits.
CONTROL DEVICE
A device inserted into a control circuit and used to control the working of
the machine (e.g. position sensors, manual control switches, relays and
electromagnetic valves).
Hot-pressing device PM-1306

Habasit Italiana S.p.A.
Vittorio Veneto 31029 (TV)
Tel.: ++39(0)438.9113
Fax. ++39(0)438.200545 Hot Press PM-1306
Author: S.D.T. /KM REGULATIONS AND GENERAL WARNING NOTES
Edition: 02/2005 Page A-10
Replaces: 01/2002
A.6 Safety warnings
When using industrial machines and systems, one should be aware that moving mechanical parts (linear
or rotary movement), high voltage electrical parts, and any parts at high temperature, etc, can cause
serious damage to persons and materials.
In designing and building the hot-pressing device, the Manufacturer focused special attention on safety in
order to supply a SAFE hot-pressing device and, therefore, the Manufacturer has provided protective and
safety devices considered necessary according to the Risk Analysis carried out by expert personnel.
People in charge of system safety must make sure that the following essential safety regulations are
observed:
Do not run the hot-pressing device with the fixed and mobile protective devices
dismantled or disabled.
Do not run the hot-pressing device with the fixed and mobile protective devices
dismantled or disabled.
It is forbidden to switch off safety devices installed on the hot-pressing device or
create by-pass systems to limit switches or micro-switches.
Operations with reduced safety devices must be carried out strictly observing the
instructions in the relevant descriptions, and must be performed by specialized
technicians aware of the risk, under the direct supervision of the company person
responsible for safety. Active protective devices must be restored as soon as
possible, limiting this high risk status to the minimum.
Cleaning and maintenance operations must be performed with the electrical and
pneumatic cut-out devices switched OFF. To this end, the hot-pressing device is
provided with emergency push-buttons which shut down the system. It is good
practice to use them as safety lock-outs to avoid accidental starting during
inspections or mechanical jobs.
Clean covers and control panel with soft, dry cloths lightly dampened in detergent;
do not use solvents as they could damage the surfaces.
Do not modify the hot-pressing device or its parts. Otherwise, the Manufacturer
shall not hold itself responsible for damage to persons and materials. Request
any modifications/customizing directly from the Manufacturer.
OFF
Hot-pressing device PM-1306

Habasit Italiana S.p.A.
Vittorio Veneto 31029 (TV)
Tel.: ++39(0)438.9113
Fax. ++39(0)438.200545 Hot Press PM-1306
Author: S.D.T. /KM REGULATIONS AND GENERAL WARNING NOTES
Edition: 02/2005 Page A-11
Replaces: 01/2002
A.7 Remaining risks
The use of the hot-pressing device during its operation may give risk to additional risks such as the
following:
The possibility of crushing occurring during press closing.
The possibility of burns occurring in the pressing area if the temperature is not first checked or if suitably
protective gloves are not worn.
The possibility of scalding or burning occurring by hot liquid or steam in the cooling circuit if the cooling
cycle is incorrectly stopped without paying attention to the warnings given in this manual.
The possibility of contact between water and live equipment.
The user is responsible for taking care during transportation and movement of the equipment where the
use of extraneous equipment (such as forklift trucks etc.) present dangers from bumping into and
crushing persons in the area of these operations.
Ensure during equipping and maintenance operations that the stages in the chapters of the manual are
scrupulously adhered to and have these operations carried out only by suitably prepared and qualified
persons.
Hot-pressing device PM-1306

Habasit Italiana S.p.A.
Vittorio Veneto 31029 (TV)
Tel.: ++39(0)438.9113
Fax. ++39(0)438.200545 Hot Press PM-1306
Author: S.D.T. /KM REGULATIONS AND GENERAL WARNING NOTES
Edition: 02/2005 Page A-12
Replaces: 01/2002
A.8 Qualification of personnel
Each task must be assigned to a person trained in the work to be carried out and trained in correct usage
as well as fully aware of any remaining risks and dangers in that work. Personnel must not carry out work
outside their area of competence, knowledge and responsibility.
TABLE 4-QUALIFICATIONS
FIRST LEVEL MACHINE CONTROL OPERATOR
Indicates non qualified personnel i.e. without specific competencies and able only to
carry out simple tasks, including in practice running the machine with the use of the
controls on the push-button panel and loading and unloading materials used during
production. Furthermore, this operator can work with the machine while the
machine's protective devices are enabled, to carry out simple, ordinary jobs for
adjusting, starting or re-starting production following enforced down-time.
MECHANICAL MAINTENANCE PERSON
A qualified technician able to run the machine under normal conditions, to intervene
on mechanical parts to make all adjustments as well as the necessary mechanical
maintenance and repair jobs, also with the protective devices disabled.
ELECTRICAL MAINTENANCE PERSON
A qualified technician able to run the machine under normal conditions, and also with
the protective devices disabled; s/he is entrusted with all electrical jobs involving
adjustment, maintenance and repairs. This operator is able to work while the interior
of the cabinets and the connector blocks are electrically live.
QUALIFIED TECHNICIAN
A person who is by training, experience, education and knowledge of accident
prevention regulations and procedures able to perceive and avoid possible dangers
and who is authorized by the plant's safety officer to carry out all necessary
mechanical and electrical intervention.
SPECIALIZED SUPERVISOR
An expert, specialized technician provided by the Manufacturer to carry out complex
operations in particular situations, installation, first start-up, instruction of the
Customer's personnel, as well as overhauls of and modifications to the machine.
Hot-pressing device PM-1306

Habasit Italiana S.p.A.
Vittorio Veneto 31029 (TV)
Tel.: ++39(0)438.9113
Fax. ++39(0)438.200545 Hot Press PM-1306
Author: S.D.T. /KM REGULATIONS AND GENERAL WARNING NOTES
Edition: 02/2005 Page A-13
Replaces: 01/2002
A.9 References and standards
A.9.1 Applicable EU Directives
EU Directive N° 98/37 of 23.07.98 known as the "Machines directive”.
EU Directive N° 60/204 known as “Low tension directive”
EU Directive N° 89/336 for the convergence of Member State law on electromagnetic compatibility.
Application of the above directives is formalized through the signing of the MANUFACTURER'S
DECLARATION OF CONFORMITY drawn up once the inspection test has been carried out at the
place of installation.
This hot-pressing device has been constructed in a country that is part of the European Community and
therefore meets the safety requirements of EU directive 98/37/CE, in force from July 23, 1998.
This conformity is certified and the hot-pressing device bears the CE mark of compliance (see figure).
A.9.2 EU Directives concerning safety in the workplace
EU Directive N° 89/391 concerning the improvement of the safety and health of workers during work, in
addition to the following particular directives EU N° 89/654 and N° 89/655.
EU Directives N° 77/576 and N° 79/640 concerning safety signs in the workplace.
A.9.3 EU Directives concerning personal protection
EU Directive N° 89/656 and N° 89/686 concerning the use of personal protection devices.
A.9.4 EU Directives concerning environmental protection
EU Directives N° 75/442 on the disposal of waste.
EU Directives N° 78/319 on the disposal of toxical and harmful waste.
Hot-pressing device PM-1306

Habasit Italiana S.p.A.
Vittorio Veneto 31029 (TV)
Tel.: ++39(0)438.9113
Fax. ++39(0)438.200545 Hot Press PM-1306
Author: S.D.T. / KM TECHNICAL SPECIFICATIONS
Edition: 02/2005 Page B-1
Replaces: 01/2002
B. TECHNICAL SPECIFICATIONS
Hot-pressing device PM-1306

Habasit Italiana S.p.A.
Vittorio Veneto 31029 (TV)
Tel.: ++39(0)438.9113
Fax. ++39(0)438.200545 Hot Press PM-1306
Author: S.D.T. / KM TECHNICAL SPECIFICATIONS
Edition: 02/2005 Page B-2
Replaces: 01/2002
B.1 Purpose of the hot-pressing device
The hot press PM-1306 has been specifically developed for joining of HABASIT power trans-mission and
conveyor belts and machine tapes using the Thermofix and Flexproof process.
The Thermofix process includes all the flat belts and other Habasit conveyor belts with right-angled or
oblique-angled joints (for width and thickness details see: TECHNICAL CHARACTERISTICS OF THE
HOT-PRESSING DEVICE).
The Flexproof process includes most of the Food and Standard conveyor belts from Habasit as well as
the thermoplastic transmission belts (for width and thickness see: TECHNICAL CHARACTERISTICS OF
THE HOT-PRESSING DEVICE)
Further details about these processes can be obtained at:
For the Thermofix process (see technical manual Thermofix).
For the Flexproof process (see technical manual Flexproof).
NOTE
By connecting to the company’s IT net H/Net it is possible to access current valid process data.
The hot press PM-1306 has been developed exclusively for the applications described herein. No other or
inappropriate applications are permitted.
ATTENTION
ANY USE OF THE HOT-PRESSING DEVICE OTHER THAN FOR WHICH IT WAS DESIGNED MAY
BE IMPROPER USE AND RESULT IN NOT BEING SAFE FROM THE POINTS OF VIEW OF THE
OPERATOR, MAINTENANCE WORKER AND OF THE HOT-PRESSING DEVICE ITSELF. HABASIT
SHALL NOT BE HELD LIABLE FOR THE CONSEQUENCES OF ANY BREACHES OF THESE RULES.
IMPORTANT
All assembly, maintenance and repair work, as well as the operation of the equipment, is expected to be
carried out be qualified personnel or staff under the supervision of responsible specialists and experts.
In case of doubt or lack of detailed information, always contact the manufacturer (see HOW THE
MANUAL IS ORGANIZED).
Hot-pressing device PM-1306
