Haier HCE604P Mounting instructions

NZ AU
Installation instructions
and User guide
Solid hotplate cooktops
HCE604P models

1
Contents
Safety and warnings 2
Installation instructions 4
Introduction 12
Using your cooktop 14
Care and cleaning 17
Warranty and service 18
Important!
SAVE THESE INSTRUCTIONS
The models shown in this user guide may not be available in all markets and are
subject to change at any time. For current details about model and specification
availability in your country, please visit our local website listed on the back cover
or contact your local Haier dealer.

2
Important safety instructions
Installation
This appliance is to be installed only by an authorised person.
Ensure the benchtop is square and level and ensure no structural members interfere with space
requirements.
Ensure a suitable disconnection switch is incorporated in the permanent wiring, mounted and
positioned to comply with the Local Wiring Rules and Regulations.
Use easy-to-clean finishes for the wall surfaces surrounding the cooktop to aid removal of any
cooking fume staining resulting from the use of the cooktop.
Consult local building authorities and by-laws if in doubt regarding installation.
Ensure that the power supply cable is not accessible via cupboard doors after installation.
Ensure that there is adequate clearance between the cutout and the rear and/or side walls.
Safety and warnings
WARNING!
Cut Hazard
Beware of sharp edges when handling appliances.
Failure to use caution could result in injury or cuts.
WARNING!
Electrical Shock Hazard
Before carrying out any work on the electrical section of the appliance, it must
be disconnected from the mains electricity supply.
Connection to a good earth wiring system is absolutely essential and
mandatory.
Failure to do so could result in death or electrical shock.

3
Safety and warnings
Important safety instructions
Operation
Household appliances are not intended to be played with by children.
Children, or persons with a disability which limits their ability to use the appliance, should have a
responsible person to instruct them in its use. The instructor should be satisfied that they can use
the appliance without danger to themselves or their surroundings.
Handles of saucepans may be hot to touch. Check saucepan handles do not overhang other
elements that are on. Keep handles out of reach of children.
Do not use a steam cleaner.
Do not use harsh/abrasive cleaning agents to clean your cooktop.
WARNING!
Hot Surface Hazard
Accessible parts of this appliance will become hot during use.
Care should be taken to avoid touching the hotplates.
Keep children away.
Failure to do so could result in burns and scalds.
WARNING!
Electrical Shock Hazard
Switch the cooktop o at the wall before cleaning or maintenance.
Failure to do so may result in death or electrical shock.

4Installation instructions
Important!
Read these instructions carefully before installing or using this product.
Please make this information available to the person responsible for installing the product as it
could reduce your installation costs.
In order to avoid a hazard, this appliance must be installed according to these instructions for
installation.
This cooktop has been designed and constructed in accordance with the following codes and
specifications:
AS/NZS 60335-1 General Requirements for Domestic electrical appliances
AS/NZS 60335-2-6 Particular Requirements for Domestic electrical cooking appliances
AS/NZS CISPR 14.1: 2010 Electromagnetic Compatibility Requirements

5
Installation instructions
Product dimensions and clearances
The installation shall comply with the dimensions in Fig. 1, bearing in mind the following
requirements:
A minimum clearance of 30 mm has to be kept between the bottom of the cooktop and the top
of an underbench appliance or a thermal protection barrier (see Figs. 3-4).
Overhead clearances - In no case shall the clearance between the highest part of the cooktop
and a range hood be less than 600 mm. Any other downward-facing combustible surface less
than 600 mm above the highest part of the cooktop shall be protected for the full width and
depth of the cooking surface area in accordance with local regulations in force. However, in no
case shall this clearance to any surface be less than 450 mm.
Side clearances - Where the distance from the periphery of the nearest hotplate to any vertical
combustible surface is less than 100 mm, the surface shall be protected in accordance with
with local regulations in force to a height of not less than 150 mm above the cooktop for the
full dimension (width or depth) of the cooking surface area. Note: one side of the cooktop must
always be kept clear.
Protection of combustible surfaces - The required protection shall ensure that the surface
temperature of combustible surfaces does not exceed 50 °C above ambient.
To comply with this requirement satisfactorily, fix 5mm-thick ceramic tiles to the surface or
attach fire-resistant material to the surface and cover with sheet metal (minimum thickness 0.4
mm).
Important!
The underside surface of the cooktop can reach a temperature exceeding 95 °C during normal
use.
650 mm
60 mm min
100 mm min
500 mm
450 mm
Fig.1 Clearances

6Installation instructions
580
480
500
60
0
–2
560
0
–2
55
Fig. 2 Product and cutout dimensions

7
Installation instructions
Installing a thermal protection barrier
Important!
If the cooktop is installed over drawers or cupboards and its underside surface thus becomes accessible
after installation, a thermal protection barrier must be fitted at least 30 mm beneath the base of the
cooktop (see Fig. 3). This barrier must be made of low thermal conductivity material installed according to
the instructions for installation.
Note:
The requirement above is not applicable if the cooktop is installed directly above an oven.
For access to the cooktop for servicing or installation, ensure that the barrier can be removed from
beneath.
A gap of 20 mm may be allowed at the rear of the barrier (see Fig.4) for electrical connection and
ventilation.
20 mm gap
30 mm
Fig. 3 Minimum clearance for thermal
protection barrier
Thermal protection barrier
(min. 15 mm thick)
This must be fitted for the full length of the cook-
top below the bench, and be removable for
installation and service.
Fig. 4 Side sectional view

8Installation instructions
Fastening the installation brackets
Each cooktop is provided with two Rtype brackets (for the rear of the cooktop), two Ftype
brackets (for the front of the cooktop) and four screws for fastening the cooktop to benches from
20 to 40 mm thick.
1 Create a cutout according to the dimensions in Fig.2.
2 Stretch gasket “D” (Figs. 6 and 7) over the edge of the cutout, being careful to overlay the
junction edges.
3 Turn the cooktop upside down, place it on a soft surface and fasten the brackets Fand Rto the
appropriate socket holes, without tightening the screws Bfor the moment. Make sure that the
tabs are mounted correctly, as shown. Rotate the tabs so that the cooktop can be put into the
cutout.
4 Put the cooktop into the cutout and position it correctly.
5 Put the brackets Fand Rinto place; tooth Aof the brackets should go into the hole (Figs. 6 and
7).
6 Tighten screws Buntil the cooktop is completely secured to the bench.
7 Using a sharp cutter or trimmer knife, trim the excess sealing material around the edge of the
cooktop. Take care not to damage the workbench.
20 mm min. 40 mm max.
B
D
Rtype bracket
A
20 mm min. 40 mm max.
B
D
Ftype bracket
A
Fig. 6 Rear side Fig. 7 Front side
Fig. 5 Fastening the
installation brackets
FRONT
F
F
R
R
B

9
Installation instructions
Electrical requirements
The appliance must be connected to the mains electricity supply checking that the voltage
corresponds to the value given in the rating plate and that the power supply cable sections can
withstand the load specified on the plate.
A power supply cable is NOT supplied with the appliance. A suitable cable has to be connected
as shown in Figs. 8 - 10.
A suitable disconnection switch must be incorporated in the permanent wiring, mounted and
positioned to comply with the local wiring rules and regulations. The switch must be of an
approved type installed in the fixed wiring and provide a 3 mm air gap contact separation in all
poles in accordance with the local wiring rules.
In Australia and New Zealand, a switch of the approved type with a 3 mm air gap must be
installed in the active (phase) conductor of the fixed wiring.
Due to the rating of the appliance, it is NOT possible to use a standard plug. The cooktop must
be connected to the electrical system by using fixed wiring.
The power supply cable must not touch any hot parts and must be positioned so that it does not
exceed 50°C above ambient.
Once the appliance has been installed, the switch must always be accessible.
If the power supply cable is damaged, it must only be replaced by the manufacturer or its
Service Agent or a similarly qualified person in order to avoid a hazard.
This appliance must be earthed.
If the installation requires alterations to the domestic electrical system call a qualified electrician.
The electrician should also check that the domestic electrical system is suitable for the power
drawn by the appliance.

10 Installation instructions
230-240 V 50 Hz
B
A
Unhook
to open cover
PE
N (L 2 )
L
1
1
2
3
4
5
1
2
3
5
4
N
L2
PE
L1
Unscrew
to open
cable
clamp
C
D
E
F
A
Power supply special cable section type “H05V2V2-F” or
equivalent rated minimum V-90.
Resistance to temperatures of 90°C
230-240 V~ 6000-6500 W 50 Hz (27A)
Connecting the power supply cable
1 Turn the cooktop over and place it on a soft surface.
2 Unhook the terminal board cover by inserting a screwdriver into the two hooks C(fig. 8).
3 Unscrew the screw Dand open completely the cable clamp E(fig. 10).
4 Check the bridging links Fare inserted into terminal block Aas shown (Figs. 9 - 10).
5 Connect the phase, neutral and earth wires to terminal board Aaccording to the diagrams in
figs. 9 - 10.
6 Strain the feeder cable and block it with cable clamp E(by screwing screw D).
7 Close the terminal block cover (check the two hooks Care correctly hooked).
Important!
To connect the power supply cable DO NOT unscrew the screws fixing the cover plate B behind the
terminal block.
Fig. 8 Connecting the power supply cable Fig. 10 Bridging links
Fig. 9 Connection
diagram

11
Installation instructions
P3 Regular hotplate 1500 W - 230 V
P4 Regular hotplate 1000 W - 230 V
M Terminal block
T Earth connection
Key
F1/2/3/4 Hotplate switches
S1 Line pilot lamp
P1 Rapid hotplate 2000 W - 230 V
P2 Rapid hotplate 1500 W - 230 V
S 1 2 3 4
P3 P1 P2
P1
P4
P3
P2
1 2 4 3 1 2 4 3
51 3
2 4
M
T
F1
F2
F3
F4
S1
S 1 2 3 4
P3 P1 P2
S 1 2 3 4
P3 P1 P2
S 1 2 3 4
P3 P1 P2
1 2 4 3
1 2 4 3
P3 Regular hotplate 1500 W - 230 V
P4 Regular hotplate 1000 W - 230 V
M Terminal block
T Earth connection
Key
F1/2/3/4 Hotplate switches
S1 Line pilot lamp
P1 Rapid hotplate 2000 W - 230 V
P2 Rapid hotplate 1500 W - 230 V
Wiring diagram - CE604 models
Fig. 11 Wiring diagram
Installation checklist
Please check through the list provided to ensure correct installation.
Is the product earthed?
Check that the power supply cable is NOT touching the product.
This will ensure that the cable is not damaged by heat from the product.
Is the product clamped down securely?

12 Introduction
About your new cooktop
Thank you for buying a Haier cooktop. Once it is installed and ready to use, you will want to
know everything about it to make sure you get excellent results right from the start. This guide
introduces you to all its special features. We recommend you read the whole guide before using
your new cooktop, for both safety and cooking success.
Before using your new cooktop
Before using your new cooktop, please read this user guide, taking special note of the ‘Safety and
warnings’ section.

13
2
5
6
7
8
14
3
9
Introduction
1 1000 W regular hotplate
2 1500 W rapid hotplate
3 1500 W regular hotplate
4 2000 W rapid hotplate
5 Rear right hotplate control knob
6 Rear left hotplate control knob
7 Front left hotplate control knob
8 Front right hotplate control knob
9 Hotplate ON indicator light
Fig.12 Cooktop layout

14 Using your cooktop
First use
Before using the cooktop for the first time, you need to remove any protective coating that may
still be on the hotplates. After you’ve removed the protective coating, boil a saucepan of water
on each plate for about 10 minutes. There will be a distinctive smell and some light smoke visible
while this is happening. This is normal, but make sure your kitchen is well ventilated during this
process. The smell and smoke will disappear when the process is complete.
Using your cooktop
1 Make sure that all the temperature control knobs are turned to O ( off).
2 Switch on the electricity.
3 Select the hotplate you require. The rapid hotplates (with a red dot in the middle) heat up 30%
faster than the regular hotplates. The red dots do not change colour with heat.
4 Turn the temperature control knob to the setting you require. Note that the knobs have six
distinct heat settings (see Figs. 13). Do not try to leave the knobs in intermediate positions.
Fig. 13 Temperature control knob
1 position
(Low setting)
6 position
(High setting)
OFF position
2 position
3 position
4 position
5 position
Intermediate
adjustments
are NOT POSSIBLE
Fig. 14 Control knob settings

15
Using your cooktop
Fig. 15 Suitable and unsuitable uses of the pans and hotplate
Cookware and cooking tips
Use pans with thick flat bases, as they are the most effective. It is worth buying good quality
pans to get the best results from your cooktop.
Use a pan with a base that matches the diameter of the hotplate.
Ensure that the bottom of the pan you are using is dry.
Use pans with tight fitting lids to reduce cooking time and save energy.
To reduce the cooking time, set the hotplate to the maximum at the beginning and then reduce
it later.
The electric plate retains heat, so you can turn off the heat a short time before you finish
cooking.
Important!
Never turn on a hotplate without any saucepans on it. This is a hot surface hazard, and could
heat up the control panel and the adjacent benchtop.
Never cook food directly on the hotplates. Always use a pan or suitable container.
Do not place any wet or steamed-up lids on an unused hotplate, as this will lead to rust.
Do not use decorative covers over the hotplates as these hold condensation which causes rust.
The covers could also become dangerously hot if a hotplate was accidentally turned on.
Never leave handles overhanging the benchtop or other hotplates.

16 Using your cooktop
The following tables contain guidelines to show recommended heat settings for cooking
different types of food with your cooktop.
Exact settings will depend on the type of pan and quantity of food being cooked.
1
2
3
4
5
6
Temperature control knob
= Warming
= Cooking
= Frying
Temperature control knob
= Warming
= Cooking
= Frying
Electric hotplate usage table
Fig. 16 Suggested heat settings
for cooking different types of
food
Knob
setting Type of cooking
O Switched OFF
1
2For melting butter or chocolate.
2To keep foods warm or heat small
quantities of water.
3
To heat greater quantities of
water, and to reheat and simmer
soups and stews.
4
For all kinds of fried foods, steaks,
cutlets and boiling without a lid,
eg pasta.
4
5
For browning meat, cooked pota-
toes, fried sh.
6Boiling large quantities of water,
rapid frying, grilled steaks, etc.

17
Care and cleaning
General advice
Before you begin cleaning, you must ensure that the cooktop is switched off.
Allow the cooktop to cool down before cleaning.
Avoid leaving acidic substances (lemon juice, vinegar etc.) on the surfaces.
Enamelled parts
Wash all of the enamelled parts only with a sponge or soft cloth, and soapy water or non-
abrasive cleaners.
Dry with a soft cloth.
If acidic substances such as lemon juice, tomato sauce, vinegar etc. are left in contact with the
enamel for a long time they will damage the surface.
Stainless steel
Stainless steel parts should be rinsed with water and dried with a soft and clean cloth.
For burnt-on or difficult spills, use specific stainless steel non-abrasive products available
commercially or a little hot vinegar.
Control knobs
The control knobs may be removed for cleaning.
Electric hotplates
Electric hotplates are made of cast iron and though durable, will rust if moisture is left on them
regularly.
Do not place wet lids from other pans onto an unused hotplate.
Always clean when the hotplate is tepid.
Use a soft cloth, dampened, or a specific commercial cleaner. To finish off, use a soft cloth with a
little oil.
Do not use water, to avoid the formation of rust.
Important!
Do not use steam cleaners because the moisture could get inside the appliance and make it dangerous.

18 Warranty and service
Before you call for service or assistance ...
Check the things you can do yourself. Refer to the installation instructions and your user guide
and check that:
1 your product is correctly installed.
2 you are familiar with its normal operation.
If after checking these points you still need assistance or parts, please refer to the Service &
Warranty book for warranty details and your nearest Authorized Service Centre, Customer Care
or contact us through our local website listed on the back cover.
Product details
Model Serial no.
Date of purchase Purchaser
Dealer Suburb
Town Country
